ATE 13.0460-7171.2 (13046071712) Brake Pad Set, disc brake

ATE part 13.0460-7171.2 (13046071712) Brake Pad Set, disc brake

ATE 13.0460-7171.2 (13046071712) Brake Pad Set, disc brake

by ATE

Manufacturer Part Number: 13.0460-7171.2 (13046071712)
Alternative ATE part number(s): 23334, 23335, 607171

Сharacteristics:
  • Width 1 [mm]: 140,1
  • Height 1 [mm]: 57,5
  • Width 2 [mm]: 141,3
  • Height 2 [mm]: 59,4
  • Thickness [mm]: 16,7
  • Wear Warning Contact: prepared for wear indicator
  • Wear Warning Contact: excl. wear warning contact
  • Brake System: ATE
  • Inspection Tag: E1 90R-01326/614
  • MAPP code available:
  • Warning notice ---------------------- Work on the SBC brake system may only be carried out by trained specialists! ¿ Risk of injury! ¿ System is pressurized! ¿ Observe manufacturer¿s guidelines! ¿ Before starting maintenance and repair work the system must be deactivated. ¿ After finishing maintenance and repair work the system must be reactivated. ¿ Only use appropriate service and diagnosis equipment! ¿ Recommendation: ContiSys Check Item no. 03.9301-6000.4 ContiSys Scan Item no. 03.9301-5000.4 Bleeding unit ATE FB 30s Item no. 03.9302-3010.4 Continental is not liable for damages which occur due to incorrect installation of the product.

Product Details

BrandATE
ATE article (MPN)13.0460-7171.2 (13046071712) Alternative ATE part number(s): 23334, 23335, 607171
Vehicle subsystemBrake System

Original (OEM) part numbers

Suitable for MERCEDES-BENZ vehicles

OE manufacturerOEM reference numbers
MERCEDES-BENZ0004230230, 0044204420, 34205120, 0034205120

Aftermarket cross reference / interchange guide

The aftermarket competitive interchanges for ATE 13.0460-7171.2 (13046071712) Brake Pad Set, disc brake offered by A.B.S., ALANKO, ATE, AYWIPARTS, BARUM, BENDIX, BORG & BECK, BOSCH, Brake ENGINEERING, BRECK, BREMBO, BREMSI, BSF, CIFAM, DELPHI, DENCKERMANN, Dr!ve+, DURON, E.T.F., EUROBRAKE, FEBI BILSTEIN, FERODO, FOMAR, fri.tech., FTE, GALFER, GIRLING, G.U.D, HANS PRIES, HELLA, HELLA PAGID, ICER, JURID, KAGER, KAMOKA, KAWE, KRAFT, LPR, LYNX, MAGNETI MARELLI, MAPCO, MAXGEAR, METELLI, METZGER, MEYLE, MINTEX, NATIONAL, NECTO, NIBK, NK, OPEN PARTS, OPTIMAL, PAGID, PEX, PROCODIS FRANCE, PROTECHNIC, QUINTON HAZELL, RAICAM, R BRAKE, REMSA, ROADHOUSE, ROULUNDS BRAKING, sbs, SCT Germany, STOP, SWAG, TEXTAR, TRISCAN, TRUCKTEC AUTOMOTIVE, TRUSTING, TRW, VAICO, VALEO, WAGNER LOCKHEED, WEEN, WOKING, ZIMMERMANN manufacturers

ManufacturerReference numbers
A.B.S.37319
ALANKO300013, 301455
ATE13.0470-7171.2
AYWIPARTSAW1810174, AW1810320
BARUMBA2218
BENDIX571989B
BORG & BECKBBP1798
BOSCH0986495248, 0986424699
Brake ENGINEERINGPA1635
BRECK233340070220
BREMBOP50052
BREMSIBP3088
BSF10793
CIFAM8225680
DELPHILP1868
DENCKERMANNB110883
Dr!ve+DP1010100777
DURONDBP221526
E.T.F.121088
EUROBRAKE5502223353
FEBI BILSTEIN16451
FERODOFSL1526, FDB1526
FOMARFO914481
fri.tech.5840
FTEBL1831A2
GALFERB1G10206522
GIRLING6115462
G.U.DGBP099100
HANS PRIES401431
HELLA8DB355018-751
HELLA PAGID8DB355018-751
ICER181576
JURID571989J-AS, 571989JC, 571989J
KAGER351041
KAMOKAJQ1013052
KAWE099100, 810082
KRAFT6011155
LPR05P1232
LYNXBD5325
MAGNETI MARELLI363700205155, 363916060316, 363702161281
MAPCO6795
MAXGEAR190593
METELLI2205680
METZGER099100, 1170049
MEYLE0252333416PD, 0252333416
MINTEXMDB2587
NATIONALNP2614
NECTOFD7019A, FD7019N
NIBKPN0344W
NK223353
OPEN PARTSBPA099100
OPTIMAL12162
PAGIDT5155
PEX7.589
PROCODIS FRANCEPF1430
PROTECHNICPRP06363M, PRP0636
QUINTON HAZELLMBP1432, BP1432
RAICAMRA08220
R BRAKERB1576
REMSA099100
ROADHOUSE299100
ROULUNDS BRAKING603781
sbs1501223353
SCT GermanySP404PR
STOP571989S
SWAG10916451
TEXTAR2333416805, 2333481, 2333403
TRISCAN8105231594, 811023054
TRUCKTEC AUTOMOTIVE02.35.115
TRUSTING5840
TRWGDB1546
VAICOV308149, V3081491
VALEO598637
WAGNER LOCKHEEDWBP23334A
WEEN1511234
WOKINGP891300
ZIMMERMANN23334.165.1

Vehicle fitment / ATE 13.0460-7171.2 (13046071712) Brake Pad Set, disc brake compatibility

This product fits the following models: MERCEDES-BENZ CLS, MERCEDES-BENZ E-CLASS, MERCEDES-BENZ S-CLASS, MERCEDES-BENZ SL, etc. See all vehicles this product (ATE 13.0460-7171.2 (13046071712)) fits below to verify fitment for your vehicle.
MakeModelVariantPeriodEngineDriveBody Style
MERCEDES-BENZCLS
C219
CLS 280
CLS 300
CLS 320 CDI
CLS 350
CLS 350 CDI
CLS 350 CGI
CLS 500
CLS 550

219.322
219.354
219.356
219.357
219.372
219.375
2004/10 - M113.967 306 hp 225 kW 5 L Petrol
M272.943 231 hp 170 kW 3 L Petrol
M272.964 272 hp 200 kW 3.5 L Petrol
M272.985 292 hp 215 kW 3.5 L Petrol
M273.960 388 hp 285 kW 5.5 L Petrol
OM642.920 211 hp 155 kW 3 L Diesel
OM642.920 224 hp 165 kW 3 L Diesel
OM642.920 272 hp 200 kW 3 L Diesel
Rear wheel
Coupe / Sports car / Grand tourer / Speedster / Roadster
MERCEDES-BENZE-CLASS
S211
W211
E 200 CDI
E 200 Kompressor
E 200 NGT
E 200 T Kompressor
E 220 CDI
E 220 T CDI
E 240
E 240 4-matic
E 240 T
E 240 T 4-matic
E 270 CDI
E 270 T CDI
E 280
E 280 4-matic
E 280 CDI
E 280 CDI 4-matic
E 280 T
E 280 T 4-matic
E 280 T CDI
E 280 T CDI 4-matic
E 300
E 320
E 320 4-matic
E 320 CDI
E 320 CDI 4-matic
E 320 T
E 320 T 4-matic
E 320 T CDI
E 320 T CDI 4-matic
E 350
E 350 4-matic
E 350 T
E 350 T 4-matic
E 400 CDI
E 420 CDI
E 500
E 500 4-matic
E 500 T
E 500 T 4-matic
E 550

211.004
211.006
211.007
211.008
211.016
211.020
211.022
211.023
211.026
211.028
211.029
211.041
211.042
211.054
211.056
211.061
211.065
211.070
211.072
211.080
211.082
211.083
211.087
211.090
211.092
211.206
211.208
211.216
211.220
211.222
211.223
211.226
211.241
211.242
211.254
211.256
211.261
211.265
211.270
211.272
211.280
211.282
211.283
211.284
211.287
211.289
211.290
211.292
2002/03 - 2009/07M112.913 177 hp 130 kW 2.6 L Petrol
M112.913 177 hp 130 kW 2.6 L Petrol
M112.917 177 hp 130 kW 2.6 L Petrol
M112.917 177 hp 130 kW 2.6 L Petrol
M112.949 224 hp 165 kW 3.2 L Petrol
M112.954 224 hp 165 kW 3.2 L Petrol
M113.967 306 hp 225 kW 5 L Petrol
M113.969 306 hp 225 kW 5 L Petrol
M271.941 163 hp 120 kW 1.8 L Petrol
M271.956 184 hp 135 kW 1.8 L Petrol
M272.943 231 hp 170 kW 3 L Petrol
M272.964 272 hp 200 kW 3.5 L Petrol
M272.972 272 hp 200 kW 3.5 L Petrol
M273.960 388 hp 285 kW 5.5 L Petrol
M273.962 388 hp 285 kW 5.5 L Petrol
OM628.961 260 hp 191 kW 4 L Diesel
OM629.910 314 hp 231 kW 4 L Diesel
OM642.910 224 hp 165 kW 3 L Diesel
OM642.920 190 hp 140 kW 3 L Diesel
OM642.920 224 hp 165 kW 3 L Diesel
OM642.921 190 hp 140 kW 3 L Diesel
OM646.820 136 hp 100 kW 2.1 L Diesel
OM646.821 163 hp 120 kW 2.1 L Diesel
OM646.821 170 hp 125 kW 2.1 L Diesel
OM646.951 102 hp 75 kW 2.2 L Diesel
OM646.951 122 hp 90 kW 2.2 L Diesel
OM646.961 150 hp 110 kW 2.1 L Diesel
OM647.961 163 hp 120 kW 2.7 L Diesel
OM647.961 177 hp 130 kW 2.7 L Diesel
OM648.961 177 hp 130 kW 3.2 L Diesel
OM648.961 204 hp 150 kW 3.2 L Diesel
AWD / 4WD
Rear wheel
Estate / Turnier / Vario / Wagon
Sedan / Saloon
MERCEDES-BENZS-CLASS
C216
W220
W221
CL 500
CL 500 4-matic
CL 550
S 280
S 300
S 320 CDI
S 320 CDI 4-matic
S 350
S 350 4-matic
S 350 BlueTec
S 350 BlueTEC 4-matic
S 350 CDI
S 350 CGI
S 350 CGI 4-matic
S 400 CDI
S 400 Hybrid
S 400 L Hybrid
S 420 CDI / S 450 CDI
S 430
S 430 4-matic
S 450
S 450 4-matic
S 500
S 500 4-matic
S 550
S 600

216.371
216.386
220.025
220.125
220.028
220.128
220.067
220.167
220.070
220.170
220.075
220.175
220.875
220.083
220.183
220.084
220.184
220.087
220.187
220.176
220.878
220.178
221.022
221.122
221.026
221.126
221.028
221.128
221.054
221.056
221.156
221.057
221.157
221.070
221.170
221.071
221.171
221.080
221.180
221.082
221.182
221.083
221.183
221.084
221.184
221.086
221.186
221.095
221.195
1998/10 - 2013/12M112.972 245 hp 180 kW 3.7 L Petrol
M112.975 245 hp 180 kW 3.7 L Petrol
M113.941 279 hp 205 kW 4.3 L Petrol
M113.948 279 hp 205 kW 4.3 L Petrol
M113.960 306 hp 225 kW 5 L Petrol
M113.966 306 hp 225 kW 5 L Petrol
M113.966 306 hp 225 kW 5 L Petrol
M137.970 367 hp 270 kW 5.8 L Petrol
M272.946 231 hp 170 kW 3 L Petrol
M272.965 272 hp 200 kW 3.5 L Petrol
M272.974 279 hp 205 kW 3.5 L Hybrid
M273.922 340 hp 250 kW 4.7 L Petrol
M273.924 340 hp 250 kW 4.7 L Petrol
M273.961 388 hp 285 kW 5.5 L Petrol
M273.961 388 hp 285 kW 5.5 L Petrol
M273.968 388 hp 285 kW 5.5 L Petrol
M273.968 388 hp 285 kW 5.5 L Petrol
M275.950 500 hp 368 kW 5.5 L Petrol
M276.950 306 hp 225 kW 3.5 L Petrol
OM628.960 250 hp 184 kW 4 L Diesel
OM628.960 260 hp 191 kW 4 L Diesel
OM629.911 320 hp 235 kW 4 L Diesel
OM642.862 258 hp 190 kW 3 L Diesel
OM642.868 258 hp 190 kW 3 L Diesel
OM642.930 211 hp 155 kW 3 L Diesel
OM642.930 235 hp 173 kW 3 L Diesel
OM642.932 211 hp 155 kW 3 L Diesel
OM642.932 235 hp 173 kW 3 L Diesel
OM648.960 204 hp 150 kW 3.2 L Diesel
AWD / 4WD
Rear wheel
Coupe / Sports car / Grand tourer / Speedster / Roadster
Sedan / Saloon
MERCEDES-BENZSL
R230
300
350
500
550

230.467
230.475
2001/10 - 2012/01M112.973 245 hp 180 kW 3.7 L Petrol
M113.963 306 hp 225 kW 5 L Petrol
M272.949 231 hp 170 kW 3 L Petrol
M272.966 272 hp 200 kW 3.5 L Petrol
M273.965 388 hp 285 kW 5.5 L Petrol
Rear wheel
Convertible / cabrio
