ATE 240128-01331 (24012801331) Brake Disc

ATE part 240128-01331 (24012801331) Brake Disc

ATE 240128-01331 (24012801331) Brake Disc

by ATE

Manufacturer Part Number: 240128-01331 (24012801331)
Alternative ATE part number(s): 428133

Сharacteristics:
  • Diameter [mm]: 324
  • Brake Disc Thickness [mm]: 28
  • Minimum thickness [mm]: 25,4
  • Brake Disc Type: Vented
  • Machining: High-carbon
  • Surface: Coated
  • Number of Holes: 5
  • Height [mm]: 47
  • Centering Diameter [mm]: 61
  • Inner diameter [mm]: 150
  • Bolt Hole Circle Ø [mm]: 108
  • Bore Ø [mm]: 15,5
  • MAPP code available:

Product Details

BrandATE
ATE article (MPN)240128-01331 (24012801331) Alternative ATE part number(s): 428133
Vehicle subsystemBrake System

Original (OEM) part numbers

Suitable for RENAULT vehicles

OE manufacturerOEM reference numbers
RENAULT8200177024, 8200570191, 8200242318, 7701207357, 8671019275

Aftermarket cross reference / interchange guide

The aftermarket competitive interchanges for ATE 240128-01331 (24012801331) Brake Disc offered by A.B.S., ALANKO, AP, BENDIX, BORG & BECK, BOSCH, Brake ENGINEERING, BRECO, BREMBO, BREMSI, CAR, CIFAM, DELPHI, DENCKERMANN, Dr!ve+, E.T.F., EUROBRAKE, FARCOM, FEBI BILSTEIN, FENOX, FERODO, FOMAR, fri.tech., FTE, GIRLING, GRAF, G.U.D, HANS PRIES, HELLA, HELLA PAGID, ICER, JP GROUP, JURID, KAMOKA, KAWE, LPR, MAGNETI MARELLI, MAPCO, MAXGEAR, METELLI, METZGER, MEYLE, MGA, MINTEX, NECTO, NK, OPEN PARTS, OPTIMAL, PAGID, PATRON, PILENGA, PROTECHNIC, QUINTON HAZELL, R BRAKE, REMSA, ROADHOUSE, ROTINGER, ROULUNDS BRAKING, SASIC, sbs, STARLINE, SWAG, TEMPLIN, TEXTAR, TRISCAN, TRUSTING, TRW, VAICO, VALEO, VILLAR, WOKING, ZIMMERMANN manufacturers

ManufacturerReference numbers
A.B.S.17449
ALANKO304257
AP25041V, 25041
BENDIX562187BC, 562187B
BORG & BECKBBD5764S
BOSCH0986478972
Brake ENGINEERINGDI956517S
BRECOBS8637, BV8637
BREMBO09.9818.10, 09.9818.11
BREMSIDBB405V
CAR142.692
CIFAM800-674
DELPHIBG9687
DENCKERMANNB130376
Dr!ve+DP1010110344
E.T.F.197357
EUROBRAKE5815203933
FARCOM230971, 231227, 230453
FEBI BILSTEIN24311
FENOXTB219195, TB219198
FERODODDF1405C, DDF1405C1, DDF1405, DDF1405-1
FOMARFO2604
fri.tech.BD1302
FTEBS5430B, BS5430
GIRLING6042315
GRAFDF29674
G.U.DGDB128133
HANS PRIES701096
HELLA8DD355109-351, 8DD355109-361
HELLA PAGID8DD355109-351, 8DD355109-361
ICER78BD73572
JP GROUP4363100909
JURID562187JC, 562187J
KAMOKA1031020
KAWE6123410, 669510
LPRR1008VR
MAGNETI MARELLI360406058900
MAPCO15136
MAXGEAR191300
METELLI23-0674
METZGER25041V, 6110349
MEYLE16-155210012
MGAD1547
MINTEXMDC1536
NECTOWN1363
NK203933, 313933
OPEN PARTSBDR245220, BDA245220
OPTIMALBS-8272
PAGID54194, 54194PRO
PATRONPBD4231
PILENGAV785, V781
PROTECHNICPRD2275
QUINTON HAZELLBSF5430, 6695.10, BDC5430
R BRAKE78RBD27357
REMSA6123410, 6695.10
ROADHOUSE6123410, 6695.10
ROTINGERRT20058, RT20058T5
ROULUNDS BRAKINGD2604
SASIC6104005
sbs1815203933, 1815313933
STARLINEPB20058C, PB20058
SWAG60924311
TEMPLIN0311025370, 0311025375
TEXTAR92119403, 98200119401, 92119400
TRISCAN812025135
TRUSTINGDF1302
TRWDF4280S, DF4231S
VAICOV4680013
VALEO186804
VILLAR6282052
WOKINGD669510, D6123410
ZIMMERMANN470.2418.00, 470.2418.50, 470241852, 470241820

Vehicle fitment / ATE 240128-01331 (24012801331) Brake Disc compatibility

This product fits the following models: RENAULT ESPACE IV, RENAULT ESPACEIV, RENAULT VEL SATIS, etc. See all vehicles this product (ATE 240128-01331 (24012801331)) fits below to verify fitment for your vehicle.
MakeModelVariantPeriodEngineDriveBody Style
RENAULTESPACE IV
JK0/1
1.9 dCi
2.0
2.0 dCi
2.0 Turbo
2.2 dCi
3.0 dCi
3.5 V6

JK00
JK0F
JK0P
JK0S
JK0W
JK01
JK02
JK1J
JK1K
JK03
JK04
JK07
JK09
JK0A
JK0B
JK0N
JK0E
JK0Y
JK0H
JK0J
JK0V
JK0K
JK0U
JK0G
2002/11 - F4R790 133 hp 98 kW 2 L Petrol
F4R792 136 hp 100 kW 2 L Petrol
F4R794 163 hp 120 kW 2 L Petrol
F4R795 163 hp 120 kW 2 L Petrol
F4R796 163 hp 120 kW 2 L Petrol
F4R797 163 hp 120 kW 2 L Petrol
F9Q680 120 hp 88 kW 1.9 L Diesel
F9Q820 120 hp 88 kW 1.9 L Diesel
F9Q826 120 hp 88 kW 1.9 L Diesel
G9T645 139 hp 102 kW 2.2 L Diesel
G9T742 150 hp 110 kW 2.2 L Diesel
G9T743 150 hp 110 kW 2.2 L Diesel
M9R740 150 hp 110 kW 2 L Diesel
M9R750 150 hp 110 kW 2 L Diesel
M9R815 150 hp 110 kW 2 L Diesel
M9R760 173 hp 127 kW 2 L Diesel
M9R761 173 hp 127 kW 2 L Diesel
M9R762 173 hp 127 kW 2 L Diesel
M9R763 173 hp 127 kW 2 L Diesel
M9R815 173 hp 127 kW 2 L Diesel
P9X701 163 hp 120 kW 3 L Diesel
P9X715 163 hp 120 kW 3 L Diesel
P9X701 177 hp 130 kW 3 L Diesel
P9X715 181 hp 133 kW 3 L Diesel
V4Y711 241 hp 177 kW 3.5 L Petrol
V4Y715 241 hp 177 kW 3.5 L Petrol
Front wheel
MPV / Van / Minivan
RENAULTESPACEIV
JK0/1
1.9 dCi
2.0
2.0 dCi
2.0 Turbo
2.2 dCi
3.0 dCi
3.5 V6

JK00
JK0F
JK0P
JK0S
JK0W
JK01
JK02
JK1J
JK1K
JK03
JK04
JK07
JK09
JK0A
JK0B
JK0N
JK0E
JK0Y
JK0H
JK0J
JK0V
JK0K
JK0U
JK0G
2002/11 - F4R790 133 hp 98 kW 2 L Petrol
F4R792 136 hp 100 kW 2 L Petrol
F4R794 163 hp 120 kW 2 L Petrol
F4R795 163 hp 120 kW 2 L Petrol
F4R796 163 hp 120 kW 2 L Petrol
F4R797 163 hp 120 kW 2 L Petrol
F9Q680 120 hp 88 kW 1.9 L Diesel
F9Q820 120 hp 88 kW 1.9 L Diesel
F9Q826 120 hp 88 kW 1.9 L Diesel
G9T645 139 hp 102 kW 2.2 L Diesel
G9T742 150 hp 110 kW 2.2 L Diesel
G9T743 150 hp 110 kW 2.2 L Diesel
M9R740 150 hp 110 kW 2 L Diesel
M9R750 150 hp 110 kW 2 L Diesel
M9R815 150 hp 110 kW 2 L Diesel
M9R760 173 hp 127 kW 2 L Diesel
M9R761 173 hp 127 kW 2 L Diesel
M9R762 173 hp 127 kW 2 L Diesel
M9R763 173 hp 127 kW 2 L Diesel
M9R815 173 hp 127 kW 2 L Diesel
P9X701 163 hp 120 kW 3 L Diesel
P9X715 163 hp 120 kW 3 L Diesel
P9X701 177 hp 130 kW 3 L Diesel
P9X715 181 hp 133 kW 3 L Diesel
V4Y711 241 hp 177 kW 3.5 L Petrol
V4Y715 241 hp 177 kW 3.5 L Petrol
Front wheel
MPV / Van / Minivan
RENAULTVEL SATIS
BJ0
2.0 16 V Turbo
2.0 16V Turbo
2.0 dCi
2.0 Turbo
2.2 dCi
3.0 dCi
3.5
3.5 V6

BJ01
BJ03
BJ03
BJ0B
BJ0E
BJ0F
BJ0E
BJ0F
BJ0G
BJ0H
BJ0H
BJ0J
BJ0N
BJ0K
BJ0R
BJ0V
BJ0U
BJ0S
2002/06 - F4R762 163 hp 120 kW 2 L Petrol
F4R763 163 hp 120 kW 2 L Petrol
F4R766 170 hp 125 kW 2 L Petrol
F4R767 170 hp 125 kW 2 L Petrol
F4R867 147 hp 108 kW 2 L Petrol
G9T600 113 hp 83 kW 2.2 L Diesel
G9T600 116 hp 85 kW 2.2 L Diesel
G9T600 140 hp 102 kW 2.2 L Diesel
G9T606 140 hp 102 kW 2.2 L Diesel
G9T607 140 hp 102 kW 2.2 L Diesel
G9T700 140 hp 102 kW 2.2 L Diesel
G9T702 140 hp 102 kW 2.2 L Diesel
G9T702 150 hp 110 kW 2.2 L Diesel
G9T703 150 hp 110 kW 2.2 L Diesel
M9R760 150 hp 110 kW 2 L Diesel
M9R760 173 hp 127 kW 2 L Diesel
M9R762 173 hp 127 kW 2 L Diesel
M9R763 173 hp 127 kW 2 L Diesel
P9X701 177 hp 130 kW 3 L Diesel
P9X715 181 hp 133 kW 3 L Diesel
V4Y701 241 hp 177 kW 3.5 L Petrol
V4Y711 241 hp 177 kW 3.5 L Petrol
V4Y715 231 hp 170 kW 3.5 L Petrol
Front wheel
MPV / Van / Minivan
