BREMBO 09.5058.75 (09505875) Brake Disc
BREMBO 09.5058.75 (09505875) Brake Disc
by BREMBOManufacturer Part Number: 09.5058.75 (09505875)
- for article number: 09.5058.75
- Brake Disc Type: Internally Vented
- Diameter [mm]: 284
- Brake Disc Thickness [mm]: 22
- Minimum thickness [mm]: 20,2
- Height [mm]: 39,4
- Centering Diameter [mm]: 59
- Number of Holes: 4
- Tightening Torque [Nm]: 86
- Surface: Coated
- Supplementary Article/Info 2: with screws
- For maximum performance in wet conditions, Brembo Max is the affordable grooved and painted disc for the enthusiast.
- Pillar venting technology. The innovative Brembo patented pillar venting technology boosts overall disc cooling and increases up to more than 40% resistance to thermal cracking
- Für Deutschland und Österreich: Kontrollieren Sie bitte auf www.bremboparts.com, ob die für Ihr Fahrzeug erforderliche ABE vorhanden ist.
Product Details
| Brand | BREMBO |
| BREMBO article (MPN) | 09.5058.75 (09505875) |
| Vehicle subsystem | Brake System |
Original (OEM) part numbers
Suitable for FIAT / LANCIA / ALFA vehicles
| OE manufacturer | OEM reference numbers |
|---|---|
| FIAT / LANCIA / ALFA | 60811890, 60812067, 46403958, 46427947, 46427949, 60812137, 82462136 |
Aftermarket cross reference / interchange guide
The aftermarket competitive interchanges for BREMBO 09.5058.75 (09505875) Brake Disc offered by A.B.S., AP, ATE, BENDIX, BORG & BECK, BOSCH, Brake ENGINEERING, BRECO, BREMBO, DELPHI, DENCKERMANN, Dr!ve+, FEBI BILSTEIN, FERODO, FOMAR, fri.tech., GIRLING, HELLA, HELLA PAGID, JP GROUP, JURID, KAGER, KAWE, KRAFT, LUCAS ELECTRICAL, MAGNETI MARELLI, MALÒ, MAPCO, METELLI, MINTEX, OPEN PARTS, OPTIMAL, PAGID, PATRON, PILENGA, QUINTON HAZELL, REMSA, ROADHOUSE, ROTINGER, sbs, STARLINE, SWAG, TEMPLIN, TEXTAR, TRUSTING, TRW, VAICO, VALEO, VILLAR, WOKING, ZIMMERMANN manufacturers
| Manufacturer | Reference numbers |
|---|---|
| A.B.S. | 16153 |
| AP | X24273, 24273E |
| ATE | 24.0122-0107.1 |
| BENDIX | 561508BC, 561508B |
| BORG & BECK | BBD4981 |
| BOSCH | 0986478639, 0986478786 |
| Brake ENGINEERING | DI955186 |
| BRECO | bs7997 |
| BREMBO | 09.5058.14, 08.5058.75 |
| DELPHI | BG2617 |
| DENCKERMANN | B130297 |
| Dr!ve+ | DP1010110776 |
| FEBI BILSTEIN | 22927, 12133 |
| FERODO | DRF252, DDF252 |
| FOMAR | FO2226 |
| fri.tech. | BD0546 |
| GIRLING | 6017571 |
| HELLA | 8DD355102531, 8DD355102521 |
| HELLA PAGID | 8DD355102521, 8DD355102531 |
| JP GROUP | 3363100609 |
| JURID | 561508J |
| KAGER | 370426 |
| KAWE | 631510 |
| KRAFT | 6043220 |
| LUCAS ELECTRICAL | DF1757 |
| MAGNETI MARELLI | 431602040160, 360406028800, 360406028803, 353612206240 |
| MALÒ | 1110182 |
| MAPCO | 15040 |
| METELLI | 230407, 23-0298 |
| MINTEX | MDC808 |
| OPEN PARTS | BDR123120, BDA123120, BDRS123125 |
| OPTIMAL | BS-3150 |
| PAGID | 50914 |
| PATRON | PBD1757 |
| PILENGA | V036 |
| QUINTON HAZELL | BSF3854 |
| REMSA | 631510 |
| ROADHOUSE | 631510 |
| ROTINGER | RT2761T5, RT2761 |
| sbs | 1815202327, 1815209922, 1815201019, 1815209923, 16153, 1815209921, 1815209924 |
| STARLINE | PB2761C |
| SWAG | 70912133, 70922927 |
| TEMPLIN | 0311015620, 0311015625 |
| TEXTAR | 92055200, 98200055201, 92055203 |
| TRUSTING | DF546 |
| TRW | DF1757 |
| VAICO | V2480006, V2480004 |
| VALEO | 186297 |
| VILLAR | 6281257 |
| WOKING | D631510 |
| ZIMMERMANN | 230236300, 230236320, 230.2363.52 |
Vehicle fitment / BREMBO 09.5058.75 (09505875) Brake Disc compatibility
This product fits the following models: FIAT MULTIPLA, FIAT PUNTO, etc. See all vehicles this product (BREMBO 09.5058.75 (09505875)) fits below to verify fitment for your vehicle.| Make | Model | Variant | Period | Engine | Drive | Body Style |
|---|---|---|---|---|---|---|
| FIAT | MULTIPLA 186 | 1.6 1.6 100 16V 1.6 16V 1.6 16V Bipower 1.6 16V Blupower 1.9 JTD 1.9 JTD 105 1.9 JTD 110 1.9 JTD 115 186AGB1A 186AMA1A 186AMB1A 186AXA1A 186AXB1A 186AXC1A 186AXE1A | 1999/04 - 2010/06 | 182A4.000 103 hp 76 kW 1.6 L Petrol 182B4.000 105 hp 77 kW 1.9 L Diesel 182B6.000 101 hp 74 kW 1.6 L Petrol 182B6.000 103 hp 76 kW 1.6 L Petrol 182B6.000 92 hp 68 kW 1.6 L Petrol 182B6.000 103 hp 76 kW 1.6 L Petrol 182B6.000 95 hp 70 kW 1.6 L Petrol 186A3.000 95 hp 70 kW 1.6 L Petrol 186A4.000 103 hp 76 kW 1.6 L Petrol 186A6.000 110 hp 81 kW 1.9 L Diesel 186A8.000 115 hp 85 kW 1.9 L Diesel 186A9.000 120 hp 88 kW 1.9 L Diesel | Front wheel | MPV / Van / Minivan |
| FIAT | PUNTO 188 | 1.8 130 HGT 1.9 JTD 188.738 .718 | 1999/09 - | 183A1.000 130 hp 96 kW 1.8 L Petrol 188A6.000 130 hp 96 kW 1.8 L Petrol 188B2.000 101 hp 74 kW 1.9 L Diesel | Front wheel | Hatchback / Sportback / Sport hatch |
