BREMBO 09.7806.75 (09780675) Brake Disc
BREMBO 09.7806.75 (09780675) Brake Disc
by BREMBOManufacturer Part Number: 09.7806.75 (09780675)
- for article number: 09.7806.75
- Brake Disc Type: Internally Vented
- Diameter [mm]: 258
- Brake Disc Thickness [mm]: 22
- Minimum thickness [mm]: 20
- Height [mm]: 43,5
- Centering Diameter [mm]: 63,6
- Number of Holes: 4
- Tightening Torque [Nm]: 85
- Surface: Coated
- For maximum performance in wet conditions, Brembo Max is the affordable grooved and painted disc for the enthusiast.
- Für Deutschland und Österreich: Kontrollieren Sie bitte auf www.bremboparts.com, ob die für Ihr Fahrzeug erforderliche ABE vorhanden ist.
Product Details
| Brand | BREMBO |
| BREMBO article (MPN) | 09.7806.75 (09780675) |
| Vehicle subsystem | Brake System |
Original (OEM) part numbers
Suitable for FORD, MAZDA vehicles
| OE manufacturer | OEM reference numbers |
|---|---|
| FORD | 1148202, 1320585, 1323620, 1522230, 3555344, 3573537, 4077455, 1499045, 1808479 |
| MAZDA | DD633325X, DD633325XA, DD32-33-25X, DD59-33-25X |
Aftermarket cross reference / interchange guide
The aftermarket competitive interchanges for BREMBO 09.7806.75 (09780675) Brake Disc offered by A.B.S., AP, ASHUKI, ATE, AUTOMEGA, BARUM, BENDIX, BLUE PRINT, BORG & BECK, BOSCH, Brake ENGINEERING, BRECO, BREMBO, BSG, DELPHI, DITAS, Dr!ve+, FEBI BILSTEIN, FENOX, FERODO, FOMAR, fri.tech., GALFER, GIRLING, G.U.D, HANS PRIES, HELLA, HELLA PAGID, HERTH+BUSS JAKOPARTS, JP GROUP, JURATEK, JURID, KAGER, KAVO PARTS, KAWE, KEY PARTS, KLAXCAR FRANCE, KRAFT, LUCAS ELECTRICAL, MAGNETI MARELLI, MALÒ, MAPCO, MENSAN, METELLI, MINTEX, OPEN PARTS, OPTIMAL, PAGID, PATRON, PILENGA, REMSA, ROADHOUSE, ROTINGER, sbs, STARLINE, STELLOX, SWAG, TEMPLIN, TEXTAR, TRUSTING, TRW, VAICO, VALEO, VILLAR, WOKING, ZIMMERMANN manufacturers
| Manufacturer | Reference numbers |
|---|---|
| A.B.S. | 17007 |
| AP | X24760, 24760E |
| ASHUKI | M60630 |
| ATE | 24.0122-0172.1, 24.0322-0172.1 |
| AUTOMEGA | 30105220230 |
| BARUM | BAR22172 |
| BENDIX | 562078B, 562078BC |
| BLUE PRINT | ADM54391, ADM54281 |
| BORG & BECK | BBD4120 |
| BOSCH | 0986479R64, 0986478892, 0986479922 |
| Brake ENGINEERING | DI955851 |
| BRECO | BS8344 |
| BREMBO | 0978061X, 09780611, 09.7806.14 |
| BSG | BSG30210015 |
| DELPHI | BG3359C, BG3359 |
| DITAS | DFD1024 |
| Dr!ve+ | DP1010110698 |
| FEBI BILSTEIN | 12578 |
| FENOX | TB217274 |
| FERODO | DDF1072, DRF1072 |
| FOMAR | FO2259, FO2926 |
| fri.tech. | BD0460 |
| GALFER | B1G22201721 |
| GIRLING | 6040361 |
| G.U.D | GDB122172 |
| HANS PRIES | 301415 |
| HELLA | 8DD355106431, 8DD355106421 |
| HELLA PAGID | 8DD355106431, 8DD355106421 |
| HERTH+BUSS JAKOPARTS | J3303085 |
| JP GROUP | 1563101400, 1563101409 |
| JURATEK | FOR116 |
| JURID | 562078J |
| KAGER | 370392 |
| KAVO PARTS | BR4747, BR4747C |
| KAWE | 657510 |
| KEY PARTS | KBD4120 |
| KLAXCAR FRANCE | 25060Z |
| KRAFT | 6042200 |
| LUCAS ELECTRICAL | DF4036 |
| MAGNETI MARELLI | 361302040206, 600000088190, 353611752240, 360406026000, 360406026003, 431602040980 |
| MALÒ | 1110160 |
| MAPCO | 15826, 158262 |
| MENSAN | 020204 |
| METELLI | 23-0476 |
| MINTEX | MDK0172, MDK0148, MDK0085, MDC1030 |
| OPEN PARTS | BDR173920, BDA173920 |
| OPTIMAL | BS-5750 |
| PAGID | 51040 |
| PATRON | PBD4036 |
| PILENGA | 4274, V274 |
| REMSA | 6575.10 |
| ROADHOUSE | 657510 |
| ROTINGER | RT2456T5, RT2456 |
| sbs | 1815202545, 1815202528, 1815204849, 17007, 1815204010, 1815202549, 1815204830 |
| STARLINE | PB2456C |
| STELLOX | 6020-2549V-SX |
| SWAG | 50912578 |
| TEMPLIN | 0311015120, 0311015125 |
| TEXTAR | 92096200, 92096203, 98200096201, 89007700, 89005500 |
| TRUSTING | DF460 |
| TRW | DF4036 |
| VAICO | V2580001 |
| VALEO | 186560 |
| VILLAR | 6280323 |
| WOKING | D657510 |
| ZIMMERMANN | 250.1343.00, 250134352, 250134320 |
Vehicle fitment / BREMBO 09.7806.75 (09780675) Brake Disc compatibility
This product fits the following models: FORD COURIER, FORD FIESTA, FORD FIESTA IV, FORD FIESTAIV, FORD FIESTA V, FORD FOCUS, FORD FOCUS CLIPPER, FORD FUSION, FORD IKON V, FORD KA, FORD PUMA, FORD STREET KA, MAZDA 121 III, MAZDA 121III, MAZDA 2, MAZDA DEMIO, MAZDA SOHO III, etc. See all vehicles this product (BREMBO 09.7806.75 (09780675)) fits below to verify fitment for your vehicle.| Make | Model | Variant | Period | Engine | Drive | Body Style |
|---|---|---|---|---|---|---|
| FORD | COURIER J5 J3 JV | 1.3 1.8 D 1.8 DI D D 1.8 TD 1.8 | 1996/02 - | J4C 60 hp 44 kW 1.3 L Petrol RTJ 60 hp 44 kW 1.8 L Diesel RTK 60 hp 44 kW 1.8 L Diesel RTK 60 hp 44 kW 1.8 L Diesel RTN 75 hp 55 kW 1.8 L Diesel RTP 75 hp 55 kW 1.8 L Diesel RTN 75 hp 55 kW 1.8 L Diesel RTP 75 hp 55 kW 1.8 L Diesel RTQ 75 hp 55 kW 1.8 L Diesel | Front wheel | LCV / Van / Cargo |
| FORD | FIESTA J5 J3 JV | 1.25 1.3 1.8 D 1.8 DI D D 1.8 TD 1.8 | 1996/02 - | J4C 60 hp 44 kW 1.3 L Petrol RTJ 60 hp 44 kW 1.8 L Diesel RTK 60 hp 44 kW 1.8 L Diesel RTK 60 hp 44 kW 1.8 L Diesel RTN 75 hp 55 kW 1.8 L Diesel RTP 75 hp 55 kW 1.8 L Diesel RTN 75 hp 55 kW 1.8 L Diesel RTP 75 hp 55 kW 1.8 L Diesel RTQ 75 hp 55 kW 1.8 L Diesel STJB 60 hp 44 kW 1.25 L Petrol | Front wheel | LCV / Van / Cargo Sedan / Saloon |
| FORD | FIESTA IV JA JB | 1.25 i 16V 1.3 i 1.4 i 16V 1.6 1.6 16V Sport 1.8 D 1.8 DI | 1995/08 - 2002/01 | 88 hp 65 kW 1.6 L Petrol DHA 75 hp 55 kW 1.25 L Petrol DHB 75 hp 55 kW 1.25 L Petrol DHC 75 hp 55 kW 1.25 L Petrol DHD 75 hp 55 kW 1.25 L Petrol DHE 75 hp 55 kW 1.25 L Petrol DHF 75 hp 55 kW 1.25 L Petrol DHG 75 hp 55 kW 1.25 L Petrol FHA 90 hp 66 kW 1.4 L Petrol FHE 90 hp 66 kW 1.4 L Petrol J4C 60 hp 44 kW 1.3 L Petrol J4J 60 hp 44 kW 1.3 L Petrol J4L 60 hp 44 kW 1.3 L Petrol J4Q 60 hp 44 kW 1.3 L Petrol J4R 60 hp 44 kW 1.3 L Petrol J4T 60 hp 44 kW 1.3 L Petrol JBC 60 hp 44 kW 1.3 L Petrol JJA 50 hp 37 kW 1.3 L Petrol JJC 50 hp 37 kW 1.3 L Petrol JJE 50 hp 37 kW 1.3 L Petrol JJJ 50 hp 37 kW 1.3 L Petrol JJK 50 hp 37 kW 1.3 L Petrol JJM 50 hp 37 kW 1.3 L Petrol L1T 103 hp 76 kW 1.6 L Petrol L1V 103 hp 76 kW 1.6 L Petrol RTJ 60 hp 44 kW 1.8 L Diesel RTK 60 hp 44 kW 1.8 L Diesel RTN 75 hp 55 kW 1.8 L Diesel RTP 75 hp 55 kW 1.8 L Diesel RTQ 75 hp 55 kW 1.8 L Diesel | Front wheel | Hatchback / Sportback / Sport hatch |
| FORD | FIESTAIV JA JB | 1.25 i 16V 1.3 i 1.4 i 16V 1.6 1.6 16V Sport 1.8 D 1.8 DI | 1995/08 - 2002/01 | 88 hp 65 kW 1.6 L Petrol DHA 75 hp 55 kW 1.25 L Petrol DHB 75 hp 55 kW 1.25 L Petrol DHC 75 hp 55 kW 1.25 L Petrol DHD 75 hp 55 kW 1.25 L Petrol DHE 75 hp 55 kW 1.25 L Petrol DHF 75 hp 55 kW 1.25 L Petrol DHG 75 hp 55 kW 1.25 L Petrol FHA 90 hp 66 kW 1.4 L Petrol FHE 90 hp 66 kW 1.4 L Petrol J4C 60 hp 44 kW 1.3 L Petrol J4J 60 hp 44 kW 1.3 L Petrol J4L 60 hp 44 kW 1.3 L Petrol J4Q 60 hp 44 kW 1.3 L Petrol J4R 60 hp 44 kW 1.3 L Petrol J4T 60 hp 44 kW 1.3 L Petrol JBC 60 hp 44 kW 1.3 L Petrol JJA 50 hp 37 kW 1.3 L Petrol JJC 50 hp 37 kW 1.3 L Petrol JJE 50 hp 37 kW 1.3 L Petrol JJJ 50 hp 37 kW 1.3 L Petrol JJK 50 hp 37 kW 1.3 L Petrol JJM 50 hp 37 kW 1.3 L Petrol L1T 103 hp 76 kW 1.6 L Petrol L1V 103 hp 76 kW 1.6 L Petrol RTJ 60 hp 44 kW 1.8 L Diesel RTK 60 hp 44 kW 1.8 L Diesel RTN 75 hp 55 kW 1.8 L Diesel RTP 75 hp 55 kW 1.8 L Diesel RTQ 75 hp 55 kW 1.8 L Diesel | Front wheel | Hatchback / Sportback / Sport hatch |
| FORD | FIESTA V JH JD | 1.0 1.25 16V 1.3 1.4 16V 1.4 TDCi 1.6 16V 1.6 TDCi | 2001/11 - 2010/12 | 67 hp 49 kW 1 L Petrol A9JA 69 hp 51 kW 1.3 L Petrol A9JB 69 hp 51 kW 1.3 L Petrol A9JA 69 hp 51 kW 1.3 L Petrol A9JB 69 hp 51 kW 1.3 L Petrol BAJA 60 hp 44 kW 1.3 L Petrol F6JA 68 hp 50 kW 1.4 L Diesel F6JB 68 hp 50 kW 1.4 L Diesel FUJA 75 hp 55 kW 1.25 L Petrol FUJB 75 hp 55 kW 1.25 L Petrol M7JA 70 hp 51 kW 1.25 L Petrol M7JB 70 hp 51 kW 1.25 L Petrol FXJA 80 hp 59 kW 1.4 L Petrol FXJB 80 hp 59 kW 1.4 L Petrol FYJA 100 hp 74 kW 1.6 L Petrol FYJB 100 hp 74 kW 1.6 L Petrol HHJA 90 hp 66 kW 1.6 L Diesel HHJB 90 hp 66 kW 1.6 L Diesel | Front wheel | Hatchback / Sportback / Sport hatch LCV / Van / Cargo |
| FORD | FOCUS DAW DBW DFW DNW | 1.4 16V 1.6 16V 1.6 16V Flexifuel 1.8 16V 1.8 BiFuel 1.8 DI / TDDi 1.8 TDCi 1.8 Turbo DI / TDDi 2.0 16V | 1998/10 - 2005/03 | 111 hp 82 kW 1.8 L Petrol BHDA 75 hp 55 kW 1.8 L Diesel BHDB 75 hp 55 kW 1.8 L Diesel BHDA 75 hp 55 kW 1.8 L Diesel BHDB 75 hp 55 kW 1.8 L Diesel C9DA 90 hp 66 kW 1.8 L Diesel C9DB 90 hp 66 kW 1.8 L Diesel C9DC 90 hp 66 kW 1.8 L Diesel C9DA 90 hp 66 kW 1.8 L Diesel C9DB 90 hp 66 kW 1.8 L Diesel C9DC 90 hp 66 kW 1.8 L Diesel EDDB 131 hp 96 kW 2 L Petrol EDDC 131 hp 96 kW 2 L Petrol EDDD 131 hp 96 kW 2 L Petrol EDDF 131 hp 96 kW 2 L Petrol EYDB 115 hp 85 kW 1.8 L Petrol EYDC 115 hp 85 kW 1.8 L Petrol EYDD 115 hp 85 kW 1.8 L Petrol EYDE 115 hp 85 kW 1.8 L Petrol EYDF 115 hp 85 kW 1.8 L Petrol EYDG 115 hp 85 kW 1.8 L Petrol EYDI 115 hp 85 kW 1.8 L Petrol EYDJ 115 hp 85 kW 1.8 L Petrol EYDL 115 hp 85 kW 1.8 L Petrol F9DA 115 hp 85 kW 1.8 L Diesel F9DB 115 hp 85 kW 1.8 L Diesel FFDA 100 hp 74 kW 1.8 L Diesel FXDA 75 hp 55 kW 1.4 L Petrol FXDB 75 hp 55 kW 1.4 L Petrol FXDC 75 hp 55 kW 1.4 L Petrol FXDD 75 hp 55 kW 1.4 L Petrol FYDA 100 hp 74 kW 1.6 L Petrol FYDB 100 hp 74 kW 1.6 L Petrol FYDC 100 hp 74 kW 1.6 L Petrol FYDD 100 hp 74 kW 1.6 L Petrol FYDH 100 hp 74 kW 1.6 L Petrol FYDH 102 hp 75 kW 1.6 L Petrol | Front wheel | Estate / Turnier / Vario / Wagon Hatchback / Sportback / Sport hatch Sedan / Saloon |
| FORD | FOCUS CLIPPER DNW | 1.4 16V 1.6 16V 1.6 16V Flexifuel 1.8 16V 1.8 BiFuel 1.8 DI / TDDi 1.8 TDCi 1.8 Turbo DI / TDDi 2.0 16V | 1999/02 - 2005/01 | 111 hp 82 kW 1.8 L Petrol BHDA 75 hp 55 kW 1.8 L Diesel BHDB 75 hp 55 kW 1.8 L Diesel C9DA 90 hp 66 kW 1.8 L Diesel C9DB 90 hp 66 kW 1.8 L Diesel C9DC 90 hp 66 kW 1.8 L Diesel EDDB 131 hp 96 kW 2 L Petrol EDDC 131 hp 96 kW 2 L Petrol EDDD 131 hp 96 kW 2 L Petrol EDDF 131 hp 96 kW 2 L Petrol EYDB 115 hp 85 kW 1.8 L Petrol EYDC 115 hp 85 kW 1.8 L Petrol EYDD 115 hp 85 kW 1.8 L Petrol EYDE 115 hp 85 kW 1.8 L Petrol EYDF 115 hp 85 kW 1.8 L Petrol EYDG 115 hp 85 kW 1.8 L Petrol EYDI 115 hp 85 kW 1.8 L Petrol EYDJ 115 hp 85 kW 1.8 L Petrol EYDL 115 hp 85 kW 1.8 L Petrol F9DA 115 hp 85 kW 1.8 L Diesel F9DB 115 hp 85 kW 1.8 L Diesel FFDA 100 hp 74 kW 1.8 L Diesel FXDA 75 hp 55 kW 1.4 L Petrol FXDB 75 hp 55 kW 1.4 L Petrol FXDC 75 hp 55 kW 1.4 L Petrol FXDD 75 hp 55 kW 1.4 L Petrol FYDA 100 hp 74 kW 1.6 L Petrol FYDB 100 hp 74 kW 1.6 L Petrol FYDC 100 hp 74 kW 1.6 L Petrol FYDD 100 hp 74 kW 1.6 L Petrol FYDH 100 hp 74 kW 1.6 L Petrol FYDH 102 hp 75 kW 1.6 L Petrol | Front wheel | Estate / Turnier / Vario / Wagon |
| FORD | FUSION JU | 1.25 1.4 1.4 LPG 1.4 TDCi 1.6 1.6 TDCi | 2002/08 - 2012/12 | F6JA 68 hp 50 kW 1.4 L Diesel F6JB 68 hp 50 kW 1.4 L Diesel FUJA 75 hp 55 kW 1.25 L Petrol FUJB 75 hp 55 kW 1.25 L Petrol FXJA 80 hp 59 kW 1.4 L Petrol FXJB 80 hp 59 kW 1.4 L Petrol FXJC 80 hp 59 kW 1.4 L Petrol FYJA 100 hp 74 kW 1.6 L Petrol FYJB 100 hp 74 kW 1.6 L Petrol FYJC 100 hp 74 kW 1.6 L Petrol HHJA 90 hp 66 kW 1.6 L Diesel HHJB 90 hp 66 kW 1.6 L Diesel UTJA 80 hp 59 kW 1.4 L Petrol | Front wheel | Estate / Turnier / Vario / Wagon |
| FORD | IKON V JH JD | 1.0 1.25 16V 1.3 1.4 16V 1.4 TDCi 1.6 16V 1.6 TDCi | 2001/11 - 2008/06 | 67 hp 49 kW 1 L Petrol A9JA 69 hp 51 kW 1.3 L Petrol A9JB 69 hp 51 kW 1.3 L Petrol BAJA 60 hp 44 kW 1.3 L Petrol F6JA 68 hp 50 kW 1.4 L Diesel F6JB 68 hp 50 kW 1.4 L Diesel FUJA 75 hp 55 kW 1.25 L Petrol FUJB 75 hp 55 kW 1.25 L Petrol M7JA 70 hp 51 kW 1.25 L Petrol M7JB 70 hp 51 kW 1.25 L Petrol FXJA 80 hp 59 kW 1.4 L Petrol FXJB 80 hp 59 kW 1.4 L Petrol FYJA 100 hp 74 kW 1.6 L Petrol FYJB 100 hp 74 kW 1.6 L Petrol HHJA 90 hp 66 kW 1.6 L Diesel HHJB 90 hp 66 kW 1.6 L Diesel | Front wheel | Hatchback / Sportback / Sport hatch |
| FORD | KA RB | 1.6 1.6 i | 2000/09 - 2008/11 | 92 hp 68 kW 1.6 L Petrol CDB 95 hp 70 kW 1.6 L Petrol CDC 95 hp 70 kW 1.6 L Petrol 96 hp 71 kW 1.6 L Petrol CDB 95 hp 70 kW 1.6 L Petrol CDC 95 hp 70 kW 1.6 L Petrol | Front wheel | Hatchback / Sportback / Sport hatch |
| FORD | PUMA EC | 1.4 16V 1.6 16V 1.7 16V ST 160 | 1997/03 - 2002/06 | 160 hp 118 kW 1.7 L Petrol FHD 90 hp 66 kW 1.4 L Petrol FHF 90 hp 66 kW 1.4 L Petrol L1W 103 hp 76 kW 1.6 L Petrol MHA 125 hp 92 kW 1.7 L Petrol MHB 125 hp 92 kW 1.7 L Petrol | Front wheel | Coupe / Sports car / Grand tourer / Speedster / Roadster |
| FORD | STREET KA RL2 | 1.6 | 2003/05 - 2005/07 | CDRA 95 hp 70 kW 1.6 L Petrol CDRB 95 hp 70 kW 1.6 L Petrol | Front wheel | Convertible / cabrio |
| MAZDA | 121 III JASM JBSM | 1.25 1.3 1.8 D | 1996/03 - 2003/04 | DHF 75 hp 55 kW 1.25 L Petrol DHG 75 hp 55 kW 1.25 L Petrol J4R 60 hp 44 kW 1.3 L Petrol J4T 60 hp 44 kW 1.3 L Petrol JJK 50 hp 37 kW 1.3 L Petrol JJM 50 hp 37 kW 1.3 L Petrol RTJ 60 hp 44 kW 1.8 L Diesel RTK 60 hp 44 kW 1.8 L Diesel | Front wheel | Hatchback / Sportback / Sport hatch |
| MAZDA | 121III JASM JBSM | 1.25 1.3 1.8 D | 1996/03 - 2003/04 | DHF 75 hp 55 kW 1.25 L Petrol DHG 75 hp 55 kW 1.25 L Petrol J4R 60 hp 44 kW 1.3 L Petrol J4T 60 hp 44 kW 1.3 L Petrol JJK 50 hp 37 kW 1.3 L Petrol JJM 50 hp 37 kW 1.3 L Petrol RTJ 60 hp 44 kW 1.8 L Diesel RTK 60 hp 44 kW 1.8 L Diesel | Front wheel | Hatchback / Sportback / Sport hatch |
| MAZDA | 2 DY | 1.2 1.25 1.3 L 1.4 1.4 CD 1.5 1.6 | 2003/02 - | F6JA 68 hp 50 kW 1.4 L Diesel F6JB 68 hp 50 kW 1.4 L Diesel FUJA 75 hp 55 kW 1.25 L Petrol FUJA 75 hp 55 kW 1.2 L Petrol FXJA 80 hp 59 kW 1.4 L Petrol FYJA 100 hp 74 kW 1.6 L Petrol FYJA 101 hp 74 kW 1.6 L Petrol ZJ04 91 hp 67 kW 1.3 L Petrol ZY-VE 111 hp 82 kW 1.5 L Petrol | Front wheel | Hatchback / Sportback / Sport hatch |
| MAZDA | DEMIO DY | 1.2 1.25 1.3 L 1.4 1.4 CD 1.5 1.6 | 2003/02 - | F6JA 68 hp 50 kW 1.4 L Diesel F6JB 68 hp 50 kW 1.4 L Diesel FUJA 75 hp 55 kW 1.25 L Petrol FUJA 75 hp 55 kW 1.2 L Petrol FXJA 80 hp 59 kW 1.4 L Petrol FYJA 100 hp 74 kW 1.6 L Petrol FYJA 101 hp 74 kW 1.6 L Petrol ZJ04 91 hp 67 kW 1.3 L Petrol ZY-VE 111 hp 82 kW 1.5 L Petrol | Front wheel | Hatchback / Sportback / Sport hatch |
| MAZDA | SOHO III JASM JBSM | 1.25 1.3 1.8 D | 1996/03 - 2003/04 | DHF 75 hp 55 kW 1.25 L Petrol DHG 75 hp 55 kW 1.25 L Petrol J4R 60 hp 44 kW 1.3 L Petrol J4T 60 hp 44 kW 1.3 L Petrol JJK 50 hp 37 kW 1.3 L Petrol JJM 50 hp 37 kW 1.3 L Petrol RTJ 60 hp 44 kW 1.8 L Diesel RTK 60 hp 44 kW 1.8 L Diesel | Front wheel | Hatchback / Sportback / Sport hatch |
