BREMBO 09.8545.10 (09854510) Brake Disc

BREMBO part 09.8545.10 (09854510) Brake Disc
BREMBO part 09.8545.10 (09854510) Brake Disc

BREMBO 09.8545.10 (09854510) Brake Disc

by BREMBO

Manufacturer Part Number: 09.8545.10 (09854510)

Сharacteristics:
  • for article number: 09.8545.10
  • Brake Disc Type: Internally Vented
  • Diameter [mm]: 255
  • Brake Disc Thickness [mm]: 20
  • Minimum thickness [mm]: 18
  • Height [mm]: 43,2
  • Centering Diameter [mm]: 55
  • Number of Holes: 4
  • Tightening Torque [Nm]: 103

Product Details

BrandBREMBO
BREMBO article (MPN)09.8545.10 (09854510)
Vehicle subsystemBrake System

Original (OEM) part numbers

Suitable for TOYOTA vehicles

OE manufacturerOEM reference numbers
TOYOTA43512-0D030, 43512-0D050, 43512-17130, 43512-52040, 43512-52090, 43512-33100, 4351217131, 4351217120

Aftermarket cross reference / interchange guide

The aftermarket competitive interchanges for BREMBO 09.8545.10 (09854510) Brake Disc offered by A.B.S., AP, ASHIKA, ASHUKI, ATE, BENDIX, BLUE PRINT, BORG & BECK, BOSCH, Brake ENGINEERING, BRECO, BREMSI, BSF, CIFAM, DELPHI, DENCKERMANN, Dr!ve+, E.T.F., EUROBRAKE, FARCOM, FEBI BILSTEIN, FENOX, FERODO, FOMAR, fri.tech., FTE, GALFER, GIRLING, HELLA, HELLA PAGID, HERTH+BUSS JAKOPARTS, ICER, JAPANPARTS, JAPKO, JP GROUP, JURID, KAGER, KAISHIN, KAMOKA, KAVO PARTS, KAWE, LPR, LUCAS ELECTRICAL, MAGNETI MARELLI, MAPCO, MAXGEAR, MDR, METELLI, METZGER, MEYLE, MINTEX, MOTAQUIP, NATIONAL, NECTO, NIPPARTS, NK, OPEN PARTS, OPTIMAL, PAGID, PATRON, PILENGA, PROTECHNIC, QUINTON HAZELL, R BRAKE, REMSA, ROADHOUSE, ROTINGER, SAKURA, SASIC, sbs, STELLOX, SWAG, TEMPLIN, TEXTAR, TRISCAN, TRUSTING, TRW, VAICO, VALEO, VEMA, WOKING, ZIMMERMANN manufacturers

ManufacturerReference numbers
A.B.S.17028
AP24785
ASHIKA6002278, 6002230, 6002221
ASHUKIC60807, 09908212
ATE24032001751, 24.0120-0175.1
BENDIX562409BC, 562409B
BLUE PRINTADT343137
BORG & BECKBBD4339, BBD4175
BOSCH0986479S13, 0986479927, 0986AB9821, 0986AB9511, 0986479012, 0986478969, 0986479B60
Brake ENGINEERINGDI955885
BRECOBS8412
BREMSIDBB149V
BSF11462V
CIFAM800717C
DELPHIBG3520, BG4114
DENCKERMANNB130418
Dr!ve+DP1010110511
E.T.F.192040
EUROBRAKE5815204588
FARCOM231203
FEBI BILSTEIN27942
FENOXTB217661
FERODODDF1149C1, DDF1149, DRF1149, DDF11491, DDF1149C
FOMARFO2510
fri.tech.BD0721
FTEBS5194B, BS5194
GALFERB1G22001751
GIRLING6041631
HELLA8DD355108871, 8DD355108881
HELLA PAGID8DD355108881, 8DD355108-871
HERTH+BUSS JAKOPARTSJ3302128
ICER78BD20402
JAPANPARTSDI-221, DI230, DI-278
JAPKO60230, 60278, 60221
JP GROUP4863100809
JURID562409J, 562409JC
KAGER370713
KAISHINCBR206
KAMOKA103214
KAVO PARTSBR9403C, BR9403
KAWE663510
LPRT2880V
LUCAS ELECTRICALDF4163
MAGNETI MARELLI361302040192, 360406046603, 360704008600, 360406046600, 353615202524
MAPCO25551
MAXGEAR190970
MDRMFD2278, MFD2230, MFD2221
METELLI230717C, 23-0717
METZGER663510, 6110154
MEYLE30155210003PD, 30-155210003
MINTEXMDC1510, MDC1394
MOTAQUIPLVBD1071
NATIONALNBD995, NBD1137
NECTOWN1168
NIPPARTSJ3302128
NK314588, 204588
OPEN PARTSBDRS187725, BDR187720, BDA187720
OPTIMALBS-7420
PAGID54156
PATRONPBD4163
PILENGAV661
PROTECHNICPRD2631
QUINTON HAZELLBDC5194
R BRAKE78RBD22040
REMSA663510
ROADHOUSE6635.10
ROTINGERRT2570, RT2570T5
SAKURA604203865
SASIC9004897J
sbs1815314588, 18152045100, 1815204565, 17028, 1815204588, 1815204555
STELLOX6020-4588V-SX
SWAG81927942
TEMPLIN0311027985, 0311027980
TEXTAR98200115601, 92115600, 92115603
TRISCAN812013167
TRUSTINGDF721
TRWDF4163
VAICOV7080002
VALEO186766
VEMA98567
WOKINGD663510
ZIMMERMANN590258020, 590258000, 590.2580.52

Vehicle fitment / BREMBO 09.8545.10 (09854510) Brake Disc compatibility

This product fits the following models: TOYOTA ECHO, TOYOTA ECHO VERSO, TOYOTA FUN CARGO, TOYOTA MR 2 III, TOYOTA MR III, TOYOTA VITZ, TOYOTA YARIS, TOYOTA YARIS VERSO, TOYOTA YARISVITZ, etc. See all vehicles this product (BREMBO 09.8545.10 (09854510)) fits below to verify fitment for your vehicle.
MakeModelVariantPeriodEngineDriveBody Style
TOYOTAECHO
SCP1
NLP1
NCP1
1.0 16V
1.3
1.3 16V
1.4 D-4D
1.5 TS
1.5 VVT-i TS
1999/04 - 2005/091ND-TV 75 hp 55 kW 1.4 L Diesel
1ND-TV 90 hp 66 kW 1.4 L Diesel
1NZ-FE 105 hp 77 kW 1.5 L Petrol
1NZ-FE 106 hp 78 kW 1.5 L Petrol
1NZ-FE 150 hp 110 kW 1.5 L Petrol
1SZ-FE 65 hp 48 kW 1 L Petrol
1SZ-FE 68 hp 50 kW 1 L Petrol
2NZ-FE 86 hp 63 kW 1.3 L Petrol
2SZ-FE 86 hp 63 kW 1.3 L Petrol
2SZ-FE 87 hp 64 kW 1.3 L Petrol
Front wheel
Hatchback / Sportback / Sport hatch
TOYOTAECHO VERSO
NLP2
NCP2
1.3
1.4 D-4D
1.5
1.5 4WD

NCP21
NCP22
NLP22
1999/08 - 2005/091ND-TV 75 hp 55 kW 1.4 L Diesel
1NZ-FE 105 hp 77 kW 1.5 L Petrol
1NZ-FE 106 hp 78 kW 1.5 L Petrol
1NZ-FE 106 hp 78 kW 1.5 L Petrol
2NZ-FE 84 hp 62 kW 1.3 L Petrol
2NZ-FE 86 hp 63 kW 1.3 L Petrol
AWD / 4WD
Front wheel
MPV / Van / Minivan
TOYOTAFUN CARGO
NLP2
NCP2
1.3
1.4 D-4D
1.5
1.5 4WD

NCP21
NCP22
NLP22
1999/08 - 2005/091ND-TV 75 hp 55 kW 1.4 L Diesel
1NZ-FE 105 hp 77 kW 1.5 L Petrol
1NZ-FE 106 hp 78 kW 1.5 L Petrol
1NZ-FE 106 hp 78 kW 1.5 L Petrol
2NZ-FE 84 hp 62 kW 1.3 L Petrol
2NZ-FE 86 hp 63 kW 1.3 L Petrol
AWD / 4WD
Front wheel
MPV / Van / Minivan
TOYOTAMR 2 III
ZZW3
1.8 16V VT-i
ZZW30
1999/10 - 2007/061ZZ-FE 140 hp 103 kW 1.8 L Petrol
Rear wheel
Convertible / cabrio
TOYOTAMR III
ZZW3
1.8 16V VT-i
ZZW30
1999/10 - 2007/061ZZ-FE 140 hp 103 kW 1.8 L Petrol
Rear wheel
Convertible / cabrio
TOYOTAVITZ
SCP1
NLP1
NCP1
1.0 16V
1.3
1.3 16V
1.4 D-4D
1.5 TS
1.5 VVT-i TS
1999/04 - 2005/091ND-TV 75 hp 55 kW 1.4 L Diesel
1ND-TV 90 hp 66 kW 1.4 L Diesel
1NZ-FE 105 hp 77 kW 1.5 L Petrol
1NZ-FE 106 hp 78 kW 1.5 L Petrol
1NZ-FE 150 hp 110 kW 1.5 L Petrol
1SZ-FE 65 hp 48 kW 1 L Petrol
1SZ-FE 68 hp 50 kW 1 L Petrol
2NZ-FE 86 hp 63 kW 1.3 L Petrol
2SZ-FE 86 hp 63 kW 1.3 L Petrol
2SZ-FE 87 hp 64 kW 1.3 L Petrol
Front wheel
Hatchback / Sportback / Sport hatch
TOYOTAYARIS
SCP1
NLP1
NCP1
1.0 16V
1.3
1.3 16V
1.4 D-4D
1.5 TS
1.5 VVT-i TS
1999/04 - 2005/091ND-TV 75 hp 55 kW 1.4 L Diesel
1ND-TV 90 hp 66 kW 1.4 L Diesel
1NZ-FE 105 hp 77 kW 1.5 L Petrol
1NZ-FE 106 hp 78 kW 1.5 L Petrol
1NZ-FE 150 hp 110 kW 1.5 L Petrol
1SZ-FE 65 hp 48 kW 1 L Petrol
1SZ-FE 68 hp 50 kW 1 L Petrol
2NZ-FE 86 hp 63 kW 1.3 L Petrol
2SZ-FE 86 hp 63 kW 1.3 L Petrol
2SZ-FE 87 hp 64 kW 1.3 L Petrol
Front wheel
Hatchback / Sportback / Sport hatch
TOYOTAYARIS VERSO
NLP2
NCP2
1.3
1.4 D-4D
1.5
1.5 4WD

NCP21
NCP22
NLP22
1999/08 - 2005/091ND-TV 75 hp 55 kW 1.4 L Diesel
1NZ-FE 105 hp 77 kW 1.5 L Petrol
1NZ-FE 106 hp 78 kW 1.5 L Petrol
1NZ-FE 106 hp 78 kW 1.5 L Petrol
2NZ-FE 84 hp 62 kW 1.3 L Petrol
2NZ-FE 86 hp 63 kW 1.3 L Petrol
AWD / 4WD
Front wheel
MPV / Van / Minivan
TOYOTAYARISVITZ
SCP1
NLP1
NCP1
1.0 16V
1.3
1.3 16V
1.4 D-4D
1.5 TS
1.5 VVT-i TS
1999/04 - 2005/091ND-TV 75 hp 55 kW 1.4 L Diesel
1ND-TV 90 hp 66 kW 1.4 L Diesel
1NZ-FE 105 hp 77 kW 1.5 L Petrol
1NZ-FE 106 hp 78 kW 1.5 L Petrol
1NZ-FE 150 hp 110 kW 1.5 L Petrol
1SZ-FE 65 hp 48 kW 1 L Petrol
1SZ-FE 68 hp 50 kW 1 L Petrol
2NZ-FE 86 hp 63 kW 1.3 L Petrol
2SZ-FE 86 hp 63 kW 1.3 L Petrol
2SZ-FE 87 hp 64 kW 1.3 L Petrol
Front wheel
Hatchback / Sportback / Sport hatch
