BREMBO 09.8931.20 (09893120) Brake Disc

BREMBO part 09.8931.20 (09893120) Brake Disc

BREMBO 09.8931.20 (09893120) Brake Disc

by BREMBO

Manufacturer Part Number: 09.8931.20 (09893120)

Сharacteristics:
  • for article number: 09.8931.20
  • Brake Disc Type: Internally Vented
  • Diameter [mm]: 280
  • Brake Disc Thickness [mm]: 24
  • Minimum thickness [mm]: 21,9
  • Height [mm]: 67,5
  • Centering Diameter [mm]: 73
  • Number of Holes: 5
  • Tightening Torque [Nm]: 100
  • Pillar venting technology. The innovative Brembo patented pillar venting technology boosts overall disc cooling and increases up to more than 40% resistance to thermal cracking

Product Details

BrandBREMBO
BREMBO article (MPN)09.8931.20 (09893120)
Vehicle subsystemBrake System

Original (OEM) part numbers

Suitable for CITROEN / PEUGEOT, FIAT / LANCIA / ALFA vehicles

OE manufacturerOEM reference numbers
CITROEN / PEUGEOT4246Y1, 4246X9, 424926, 424999, 1607872080, 4249K3, 424927
FIAT / LANCIA / ALFA1341044080, 51728377, 51740244, 51848618, 51848619, 71738905, 46806233

Aftermarket cross reference / interchange guide

The aftermarket competitive interchanges for BREMBO 09.8931.20 (09893120) Brake Disc offered by A.B.S., AP, ATE, BARUM, BENDIX, BORG & BECK, BOSCH, Brake ENGINEERING, BRECO, BREMSI, CASALS, CIFAM, DELPHI, Dr!ve+, FEBI BILSTEIN, FERODO, FOMAR, GALFER, GIRLING, HANS PRIES, JP GROUP, KAGER, KEY PARTS, MAGNETI MARELLI, MALÒ, METELLI, OPEN PARTS, OPTIMAL, PATRON, ROTINGER, SASIC, STELLOX, SWAG, TEMPLIN, TEXTAR, TRW, VALEO, ZIMMERMANN manufacturers

ManufacturerReference numbers
A.B.S.16291
AP25255
ATE24012401271
BARUMBAR24127
BENDIX561984B, 561984BC
BORG & BECKBBD4801, BBD5094
BOSCH0986479312, 0986479297
Brake ENGINEERINGDI955505S
BRECOBS8865
BREMSIDBB809V
CASALS55406
CIFAM800340
DELPHIBG3841, BG2846
Dr!ve+DP1010110543, DP1010110792
FEBI BILSTEIN10564
FERODODDF18091, DDF1809, DDF1170
FOMARFO2178
GALFERB1G22401271
GIRLING6027211, 6047695
HANS PRIES722454
JP GROUP4163100909
KAGER370341
KEY PARTSKBD5094
MAGNETI MARELLI361302040168, 360406023800
MALÒ1110123, 1110193
METELLI230340
OPEN PARTSBDA115120
OPTIMALBS8380, BS4760
PATRONPBD2721
ROTINGERRT2823T5, RT2823
SASIC2464L24J
STELLOX60201136VSX
SWAG70910564
TEMPLIN0311080240, 0311080245
TEXTAR92073800, 92116600
TRWDF4769S, DF2721
VALEO197043, 186418
ZIMMERMANN180301320, 180301352, 180301300

Vehicle fitment / BREMBO 09.8931.20 (09893120) Brake Disc compatibility

This product fits the following models: CITROËN JUMPER, CITROËN RELAY, FIAT DUCATO, PEUGEOT BOXER, PEUGEOT MANAGER, etc. See all vehicles this product (BREMBO 09.8931.20 (09893120)) fits below to verify fitment for your vehicle.
MakeModelVariantPeriodEngineDriveBody Style
CITROËNJUMPER

244
244
Z
2.0
2.0 bivalent
2.0 BlueHDi 110
2.0 BlueHDi 130
2.0 BlueHDi 160
2.0 HDi
2.2 HDi
2.2 HDi 100
2.2 HDi 110
2.2 HDi 120
2.2 HDi 130
2.2 HDi 150
2.8 HDi
2.8 HDi 4x4
3.0 HDi 145
3.0 HDi 155
3.0 HDi 160
3.0 HDi 180
2002/02 - 110 hp 81 kW 2 L Diesel
4HG(P22DTE) 110 hp 81 kW 2.2 L Diesel
4HH(P22DTE) 130 hp 96 kW 2.2 L Diesel
4HJ(P22DTE) 150 hp 110 kW 2.2 L Diesel
4HU(P22DTE) 120 hp 88 kW 2.2 L Diesel
4HV(P22DTE) 101 hp 74 kW 2.2 L Diesel
4HY(DW12UTED) 101 hp 74 kW 2.2 L Diesel
8140.43N 146 hp 107 kW 2.8 L Diesel
8140.43S 128 hp 94 kW 2.8 L Diesel
8140.43S 128 hp 94 kW 2.8 L Diesel
AHN(DW10FUD) 130 hp 96 kW 2 L Diesel
AHP(DW10FUC) 163 hp 120 kW 2 L Diesel
F1CE0481D(F30DT) 156 hp 115 kW 3 L Diesel
F1CE0481D(F30DT) 157 hp 115 kW 3 L Diesel
F1CE0481D(F30DT) 157 hp 116 kW 3 L Diesel
F1CE0481D(F30DT) 177 hp 130 kW 3 L Diesel
F1CE3481N 146 hp 107 kW 3 L Diesel
F28TDCR 128 hp 94 kW 2.8 L Diesel
RHV(DW10TD) 84 hp 62 kW 2 L Diesel
RHV(DW10UTD) 84 hp 62 kW 2 L Diesel
RHV(DW10UTD) 84 hp 62 kW 2 L Diesel
XU10J2 110 hp 81 kW 2 L Petrol
AWD / 4WD
Front wheel
Front wheel
AWD / 4WD
LCV / Van / Cargo
Passenger Van / Wagon / Minibus
With flatbed/undercarriage
CITROËNRELAY

244
244
Z
2.0
2.0 bivalent
2.0 BlueHDi 110
2.0 BlueHDi 130
2.0 BlueHDi 160
2.0 HDi
2.2 HDi
2.2 HDi 100
2.2 HDi 110
2.2 HDi 120
2.2 HDi 130
2.2 HDi 150
2.8 HDi
2.8 HDi 4x4
3.0 HDi 145
3.0 HDi 155
3.0 HDi 160
3.0 HDi 180
2002/02 - 110 hp 81 kW 2 L Diesel
4HG(P22DTE) 110 hp 81 kW 2.2 L Diesel
4HH(P22DTE) 130 hp 96 kW 2.2 L Diesel
4HJ(P22DTE) 150 hp 110 kW 2.2 L Diesel
4HU(P22DTE) 120 hp 88 kW 2.2 L Diesel
4HV(P22DTE) 101 hp 74 kW 2.2 L Diesel
4HY(DW12UTED) 101 hp 74 kW 2.2 L Diesel
8140.43N 146 hp 107 kW 2.8 L Diesel
8140.43S 128 hp 94 kW 2.8 L Diesel
8140.43S 128 hp 94 kW 2.8 L Diesel
AHN(DW10FUD) 130 hp 96 kW 2 L Diesel
AHP(DW10FUC) 163 hp 120 kW 2 L Diesel
F1CE0481D(F30DT) 156 hp 115 kW 3 L Diesel
F1CE0481D(F30DT) 157 hp 115 kW 3 L Diesel
F1CE0481D(F30DT) 157 hp 116 kW 3 L Diesel
F1CE0481D(F30DT) 177 hp 130 kW 3 L Diesel
F1CE3481N 146 hp 107 kW 3 L Diesel
F28TDCR 128 hp 94 kW 2.8 L Diesel
RHV(DW10TD) 84 hp 62 kW 2 L Diesel
RHV(DW10UTD) 84 hp 62 kW 2 L Diesel
RHV(DW10UTD) 84 hp 62 kW 2 L Diesel
XU10J2 110 hp 81 kW 2 L Petrol
AWD / 4WD
Front wheel
Front wheel
AWD / 4WD
LCV / Van / Cargo
Passenger Van / Wagon / Minibus
With flatbed/undercarriage
FIATDUCATO
244
244
Z
250
290
100 Multijet 2
2 D
110 Multijet 2
3 D
115 Multijet 2
0 D
120 Multijet 2
3 D
120 Multijet 2
3 D 4x4
130 Multijet 2
3 D
140 Natural Power
150 Multijet 2
3 D
150 Multijet 3
0 D
160 Multijet 3
0 D
180 Multijet 3
0 D
2.0
2.0 4x4
2.0 Bipower
2.0 JTD
2.3 JTD
2.8 JTD
2.8 JTD 4x4
2.8 JTD Power
2.8 TD
2002/04 - 250A1.000 116 hp 85 kW 2 L Diesel
250A2.000 116 hp 85 kW 2 L Diesel
4HV 100 hp 74 kW 2.2 L Diesel
8140.43 122 hp 90 kW 2.8 L Diesel
8140.43N 145 hp 107 kW 2.8 L Diesel
8140.43S 128 hp 94 kW 2.8 L Diesel
8140.43N 146 hp 107 kW 2.8 L Diesel
8140.43S 128 hp 94 kW 2.8 L Diesel
F1AE0481C 110 hp 81 kW 2.3 L Diesel
F1AE0481D 120 hp 88 kW 2.3 L Diesel
F1AE0481D 120 hp 88 kW 2.3 L Diesel
FPT 120 hp 88 kW 2.3 L Diesel
F1AE0481N 131 hp 96 kW 2.3 L Diesel
F1AE0481T 126 hp 93 kW 2.3 L Diesel
F1AE3481D 131 hp 96 kW 2.3 L Diesel
F1AGL411D 131 hp 96 kW 2.3 L Diesel
F1AE0481N 131 hp 96 kW 2.3 L Diesel
F1AE3481D 131 hp 96 kW 2.3 L Diesel
F1AGL411D 131 hp 96 kW 2.3 L Diesel
F1AE3481D 131 hp 96 kW 2.3 L Diesel
F1AGL411D 131 hp 96 kW 2.3 L Diesel
F1AE3481E 148 hp 109 kW 2.3 L Diesel
F1AE3481E 148 hp 109 kW 2.3 L Diesel
F1AGL411A 150 hp 110 kW 2.3 L Diesel
F1AGL411C 150 hp 110 kW 2.3 L Diesel
F1AE3481G 113 hp 83 kW 2.3 L Diesel
F1CE0441A 136 hp 100 kW 3 L Petrol
F1CE0441A 136 hp 100 kW 3 L Petrol
F1CFA401A 136 hp 100 kW 3 L Petrol
F1CE0481D 156 hp 115 kW 3 L Diesel
F1CE0481D 158 hp 116 kW 3 L Diesel
F1CE3481M 158 hp 116 kW 3 L Diesel
F1CE0481D 158 hp 116 kW 3 L Diesel
F1CE3481M 156 hp 115 kW 3 L Diesel
F1CE3481E 177 hp 130 kW 3 L Diesel
F1CE3481N 146 hp 107 kW 3 L Diesel
RFL 110 hp 81 kW 2 L Petrol
RHV(DW10) 84 hp 62 kW 2 L Diesel
AWD / 4WD
Front wheel
LCV / Van / Cargo
Passenger Van / Wagon / Minibus
With flatbed/undercarriage
PEUGEOTBOXER

244
244
Z
2.0
2.0 BlueHDi 110
2.0 BlueHDi 130
2.0 BlueHDi 160
2.0 HDi
2.2 HDi
2.2 HDi 100
2.2 HDi 110
2.2 HDi 120
2.2 HDi 130
2.2 HDi 150
2.8 HDi
2.8 HDi 4x4
3.0 HDi
3.0 HDi 145
3.0 HDi 160
3.0 HDi 175
2002/04 - 110 hp 81 kW 2 L Diesel
120 hp 88 kW 2.2 L Diesel
130 hp 96 kW 2 L Diesel
146 hp 107 kW 3 L Diesel
163 hp 120 kW 2 L Diesel
4HG(P22DTE) 110 hp 81 kW 2.2 L Diesel
4HH(P22DTE) 131 hp 96 kW 2.2 L Diesel
4HJ(P22DTE) 150 hp 110 kW 2.2 L Diesel
4HU(P22DTE) 120 hp 88 kW 2.2 L Diesel
4HV(P22DTE) 101 hp 74 kW 2.2 L Diesel
4HY(DW12UTED) 101 hp 74 kW 2.2 L Diesel
8140.43N 145 hp 107 kW 2.8 L Diesel
8140.43S(F28DTCR) 128 hp 94 kW 2.8 L Diesel
8140.43N 146 hp 107 kW 2.8 L Diesel
8140.43S(F28DTCR) 126 hp 93 kW 2.8 L Diesel
8140.43S(F28DTCR) 128 hp 94 kW 2.8 L Diesel
8140.43N 146 hp 107 kW 2.8 L Diesel
8140.43S(F28DTCR) 128 hp 94 kW 2.8 L Diesel
8140.43S(F28DTCR) 128 hp 94 kW 2.8 L Diesel
F1CE0481D(F30DT) 156 hp 115 kW 3 L Diesel
F1CE0481D(F30DT) 156 hp 116 kW 3 L Diesel
F1CE0481D(F30DT) 177 hp 130 kW 3 L Diesel
RFL(XU10J2U) 110 hp 81 kW 2 L Petrol
RHV(DW10TD) 84 hp 62 kW 2 L Diesel
RHV(DW10UTD) 84 hp 62 kW 2 L Diesel
AWD / 4WD
Front wheel
LCV / Van / Cargo
Passenger Van / Wagon / Minibus
With flatbed/undercarriage
PEUGEOTMANAGER
2.0 BlueHDi 110
2.0 BlueHDi 130
2.0 BlueHDi 160
2.2 HDi 100
2.2 HDi 110
2.2 HDi 120
2.2 HDi 130
2.2 HDi 150
3.0 HDi
3.0 HDi 145
3.0 HDi 160
3.0 HDi 175
2006/04 - 110 hp 81 kW 2 L Diesel
120 hp 88 kW 2.2 L Diesel
130 hp 96 kW 2 L Diesel
146 hp 107 kW 3 L Diesel
163 hp 120 kW 2 L Diesel
4HG(P22DTE) 110 hp 81 kW 2.2 L Diesel
4HH(P22DTE) 131 hp 96 kW 2.2 L Diesel
4HJ(P22DTE) 150 hp 110 kW 2.2 L Diesel
4HU(P22DTE) 120 hp 88 kW 2.2 L Diesel
4HV(P22DTE) 101 hp 74 kW 2.2 L Diesel
F1CE0481D(F30DT) 156 hp 115 kW 3 L Diesel
F1CE0481D(F30DT) 156 hp 116 kW 3 L Diesel
F1CE0481D(F30DT) 177 hp 130 kW 3 L Diesel
Front wheel
LCV / Van / Cargo
Passenger Van / Wagon / Minibus
With flatbed/undercarriage
