BREMBO 09.9468.20 (09946820) Brake Disc

BREMBO part 09.9468.20 (09946820) Brake Disc

BREMBO 09.9468.20 (09946820) Brake Disc

by BREMBO

Manufacturer Part Number: 09.9468.20 (09946820)

Сharacteristics:
  • for article number: 09.9468.20
  • Brake Disc Type: Internally Vented
  • Diameter [mm]: 300
  • Brake Disc Thickness [mm]: 25
  • Minimum thickness [mm]: 23
  • Height [mm]: 48,5
  • Machining: High-carbon
  • Centering Diameter [mm]: 72
  • Number of Holes: 5
  • Tightening Torque [Nm]: 103

Product Details

BrandBREMBO
BREMBO article (MPN)09.9468.20 (09946820)
Vehicle subsystemBrake System

Original (OEM) part numbers

Suitable for MAZDA vehicles

OE manufacturerOEM reference numbers
MAZDABP6Y-33-25XD, BP6Y-33-25XE, BP6Y-33-25XF, C26Y3325XC, C26Y3325XA, C26Y3325XB

Aftermarket cross reference / interchange guide

The aftermarket competitive interchanges for BREMBO 09.9468.20 (09946820) Brake Disc offered by A.B.S., AP, ASHUKI, ATE, BENDIX, BLUE PRINT, BORG & BECK, BOSCH, Brake ENGINEERING, BRECO, BREMBO, BREMSI, BSF, CIFAM, DELPHI, DENCKERMANN, DIRECT PARTS, Dr!ve+, E.T.F., FARCOM, FEBI BILSTEIN, FENOX, FERODO, FOMAR, fri.tech., GALFER, GIRLING, HELLA, HELLA PAGID, HERTH+BUSS JAKOPARTS, JP GROUP, JURATEK, JURID, KAGER, KAMOKA, KAVO PARTS, KAWE, KORTEX, LPR, MAGNETI MARELLI, MAPCO, MAXGEAR, MENSAN, METELLI, METZGER, MEYLE, MINTEX, MOTAQUIP, NATIONAL, NECTO, NIPPARTS, NK, OPEN PARTS, OPTIMAL, PAGID, PATRON, PILENGA, PROTECHNIC, REMSA, ROADHOUSE, ROTINGER, SAKURA, SASIC, sbs, STOP, SWAG, TEMPLIN, TEXTAR, TRISCAN, TRUSTING, TRW, VALEO, WOKING, ZIMMERMANN manufacturers

ManufacturerReference numbers
A.B.S.17637
AP24958
ASHUKIM60636HD, M60636
ATE24.0125-0170.1
BENDIX562635BC
BLUE PRINTADM54382
BORG & BECKBBD4449
BOSCH0986AB6162, 0986479183
Brake ENGINEERINGDI956351
BRECOBS8577
BREMBO09946876, 09946821
BREMSIDBB312V
BSF11623V
CIFAM800730C
DELPHIBG3928
DENCKERMANNB130284
DIRECT PARTSBP6Y-33-25XF, DP104A059
Dr!ve+DP1010110859
E.T.F.193273
FARCOM231265
FEBI BILSTEIN32770
FENOXTB219121
FERODODDF13121, DDF1312
FOMARFO2929
fri.tech.BD0988
GALFERB1.G225-0170.1
GIRLING6043851
HELLA8DD355111201, 8DD355111202, 8DD355122031, 8DD355111191
HELLA PAGID8DD355111201, 8DD355111202, 8DD355111191, 8DD355122031
HERTH+BUSS JAKOPARTSJ3303084
JP GROUP3863100809
JURATEKMAZ126
JURID562635JC
KAGER370831, 371366
KAMOKA1031123
KAVO PARTSBR4764, BR4764C
KAWE667210
KORTEXKD0108
LPRM5006V
MAGNETI MARELLI600000088180, 360406056800
MAPCO25575
MAXGEAR191268
MENSAN350213
METELLI230730C
METZGER6110229, 6672.10
MEYLE35155210029, 35155210029PD
MINTEXMDC2249
MOTAQUIPLVBD1029Z
NATIONALNBD1321
NECTOWN1318
NIPPARTSJ3303084
NK203253, 313253
OPEN PARTSBDA215620, BDR215620, BDRS215625
OPTIMALBS-7756
PAGID54326
PATRONPBD4385
PILENGAV523
PROTECHNICPRD2438
REMSA667210
ROADHOUSE667210
ROTINGERRT2964, RT2964T5
SAKURA604303691
SASIC6106113
sbs1815313253, 1815203253, 17637, 1815203252
STOP562635S
SWAG83932770
TEMPLIN0311022215, 0311022210
TEXTAR92130400, 92132605, 92132600, 92132603
TRISCAN812050142
TRUSTINGDF988
TRWDF4385
VALEO197365
WOKINGD667210
ZIMMERMANN370307720, 370307752, 370307700

Vehicle fitment / BREMBO 09.9468.20 (09946820) Brake Disc compatibility

This product fits the following models: MAZDA 3, MAZDA 5, MAZDA AXELA, MAZDA PREMACY, etc. See all vehicles this product (BREMBO 09.9468.20 (09946820)) fits below to verify fitment for your vehicle.
MakeModelVariantPeriodEngineDriveBody Style
MAZDA3
BK
BL
2.0
2.0 MZR
2.0 MZR-CD
2.0 MZR DISI
2.2 MZR CD
2.3
2.3 MZR
2.3 MZR Sport
2.5
2003/10 - L3-VE 156 hp 115 kW 2.3 L Petrol
L3-VE 160 hp 118 kW 2.3 L Petrol
L3YS 171 hp 126 kW 2.3 L Petrol
L3YT 171 hp 126 kW 2.3 L Petrol
L5-VE 166 hp 122 kW 2.5 L Petrol
LF17 141 hp 104 kW 2 L Petrol
LF17 150 hp 110 kW 2 L Petrol
LF17 150 hp 110 kW 2 L Petrol
LF17 150 hp 110 kW 2 L Petrol
LF5H 147 hp 108 kW 2 L Petrol
LF-DE 150 hp 110 kW 2 L Petrol
LF17 150 hp 110 kW 2 L Petrol
LF-DE 150 hp 110 kW 2 L Petrol
LF5H 151 hp 111 kW 2 L Petrol
LF5W 151 hp 111 kW 2 L Petrol
R2AA 150 hp 110 kW 2.2 L Diesel
R2AA 185 hp 136 kW 2.2 L Diesel
RF7J 143 hp 105 kW 2 L Diesel
Front wheel
Hatchback / Sportback / Sport hatch
Sedan / Saloon
MAZDA5
CR19
CW
1.6 CD
1.8
1.8 MZR
2.0
2.0 CD
2.3
2005/02 - 166 hp 122 kW 2.3 L Petrol
L823 116 hp 85 kW 1.8 L Petrol
L850 116 hp 85 kW 1.8 L Petrol
LF5H 150 hp 110 kW 2 L Petrol
LFZB 144 hp 106 kW 2 L Petrol
LFZB 147 hp 108 kW 2 L Petrol
PE-VPS 151 hp 111 kW 2 L Petrol
LFF7 146 hp 107 kW 2 L Petrol
RF7J 110 hp 81 kW 2 L Diesel
RF7J 143 hp 105 kW 2 L Diesel
Y650 116 hp 85 kW 1.6 L Diesel
Y655 116 hp 85 kW 1.6 L Diesel
Front wheel
MPV / Van / Minivan
MAZDAAXELA
BK
2.0
2.0 MZR-CD
2.3
2004/02 - 2009/06L3-VE 160 hp 118 kW 2.3 L Petrol
LF17 141 hp 104 kW 2 L Petrol
LF17 150 hp 110 kW 2 L Petrol
RF7J 143 hp 105 kW 2 L Diesel
Front wheel
Sedan / Saloon
MAZDAPREMACY
CP
CW
1.6 CD
1.8 MZR
2.0
2005/02 - L850 116 hp 85 kW 1.8 L Petrol
LF5H 150 hp 110 kW 2 L Petrol
LFZB 144 hp 106 kW 2 L Petrol
LFZB 147 hp 108 kW 2 L Petrol
PE-VPS 151 hp 111 kW 2 L Petrol
LFF7 145 hp 107 kW 2 L Petrol
Y650 116 hp 85 kW 1.6 L Diesel
Y655 116 hp 85 kW 1.6 L Diesel
Front wheel
MPV / Van / Minivan
