BREMBO 09.9508.11 (09950811) Brake Disc

BREMBO part 09.9508.11 (09950811) Brake Disc

BREMBO 09.9508.11 (09950811) Brake Disc

Manufacturer Part Number: 09.9508.11 (09950811)

Сharacteristics:

for article number: 09.9508.11
Brake Disc Type: Internally Vented
Diameter [mm]: 300
Brake Disc Thickness [mm]: 28
Minimum thickness [mm]: 25
Height [mm]: 68,5
Machining: High-carbon
Centering Diameter [mm]: 85
Number of Holes: 6
Tightening Torque [Nm]: 175
Surface: Coated
Supplementary Article/Info 2: with screws
Pillar venting technology. The innovative Brembo patented pillar venting technology boosts overall disc cooling and increases up to more than 40% resistance to thermal cracking

Product Details

Brand	BREMBO
BREMBO article (MPN)	09.9508.11 (09950811)
Vehicle subsystem	Brake System

Original (OEM) part numbers

Suitable for MERCEDES-BENZ, VAG vehicles

OE manufacturer	OEM reference numbers
MERCEDES-BENZ	9064210012, 9064210112, 9064210212
VAG	2E0615301

Aftermarket cross reference / interchange guide

The aftermarket competitive interchanges for BREMBO 09.9508.11 (09950811) Brake Disc offered by A.B.S., AP, ATE, BENDIX, BOSCH, Brake ENGINEERING, BRECO, CASALS, CIFAM, DON, FEBI BILSTEIN, FERODO, GIRLING, G.U.D, HANS PRIES, HELLA, HELLA PAGID, JURID, METELLI, MINTEX, OPTIMAL, PAGID, sbs, SWAG, TEXTAR, TRISCAN, TRW, VALEO, ZIMMERMANN manufacturers

Manufacturer	Reference numbers
A.B.S.	17730
AP	25053E, 25053V
ATE	24012802031
BENDIX	562485B
BOSCH	0986479294
Brake ENGINEERING	DI956432
BRECO	BV8649, BS8649
CASALS	55495
CIFAM	800881
DON	CVD655
FEBI BILSTEIN	27698
FERODO	FCR310A
GIRLING	6048225
G.U.D	GDB128203
HANS PRIES	111652
HELLA	8DD355123162, 8DD355117621
HELLA PAGID	8DD355123162, 8DD355117621
JURID	569136J
METELLI	230881
MINTEX	MDC1771
OPTIMAL	BS8166
PAGID	59432
sbs	1815203344, 1815203396, 17730
SWAG	10927698
TEXTAR	93143203, 93143205, 93143200
TRISCAN	812010196C
TRW	DF4822S
VALEO	187141
ZIMMERMANN	400647600

Vehicle fitment / BREMBO 09.9508.11 (09950811) Brake Disc compatibility

This product fits the following models: MERCEDES-BENZ SPRINTER 3,5-T, MERCEDES-BENZ SPRINTER 3-T, MERCEDES-BENZ SPRINTER 4,6-T, MERCEDES-BENZ SPRINTER 5-T, VW CRAFTER 30-35, VW CRAFTER 30-50, etc. See all vehicles this product (BREMBO 09.9508.11 (09950811)) fits below to verify fitment for your vehicle.

Make	Model	Variant	Period	Engine	Drive	Body Style
MERCEDES-BENZ	SPRINTER 3,5-T 906	2500 CDI 309 CDI 310 CDI 311 CDI 311 CDI 4x4 313 CDI 313 CDI 4x4 315 CDI 315 CDI 4x4 316 316 CDI 316 CDI 4x4 316 LGT 316 NGT 318 CDI 318 CDI 4x4 319 CDI / BlueTEC 319 CDI / BlueTEC 4x4 324 906.131 906.133 906.135... 906.131 906.133 906.135 906.231... 906.131 906.133 906.135 906.231 906.233... 906.133 906.135 906.233 906.235 906.631 906.633 906.635 906.637 906.633 906.635 906.633 906.635 906.637 906.663 906.635 906.731 906.733 906.735 906.733 906.735	2006/06 -	M271.951 156 hp 115 kW 1.8 L Petrol M272.979 258 hp 190 kW 3.5 L Petrol OM642.896 184 hp 135 kW 3 L Diesel OM642.992 184 hp 135 kW 3 L Diesel OM642.993 184 hp 135 kW 3 L Diesel OM642.896 190 hp 140 kW 3 L Diesel OM642.898 190 hp 140 kW 3 L Diesel OM642.992 190 hp 140 kW 3 L Diesel OM646.984 88 hp 65 kW 2.1 L Diesel OM646.985 109 hp 80 kW 2.1 L Diesel OM646.986 129 hp 95 kW 2.1 L Diesel OM651.955 129 hp 95 kW 2.1 L Diesel OM651.956 129 hp 95 kW 2.1 L Diesel OM646.989 150 hp 110 kW 2.1 L Diesel OM646.990 150 hp 110 kW 2.1 L Diesel OM651.955 129 hp 95 kW 2.1 L Diesel OM651.956 129 hp 95 kW 2.1 L Diesel OM651.955 163 hp 120 kW 2.1 L Diesel OM651.957 163 hp 120 kW 2.1 L Diesel OM651.955 95 hp 70 kW 2.1 L Diesel OM651.955 95 hp 70 kW 2.1 L Diesel OM651.956 95 hp 70 kW 2.1 L Diesel OM651.957 163 hp 120 kW 2.1 L Diesel	AWD / 4WD Rear wheel	LCV / Van / Cargo Passenger Van / Wagon / Minibus With flatbed/undercarriage
MERCEDES-BENZ	SPRINTER 3-T 906	209 CDI 210 CDI 211 CDI 213 CDI 215 CDI 216 216 CDI 218 CDI 219 CDI / BlueTEC 224 906.111 906.113 906.211 906.213 906.113 906.213 906.611 906.613 906.613 906.711 906.713 906.713	2006/06 -	M271.951 156 hp 115 kW 1.8 L Petrol M272.979 258 hp 190 kW 3.5 L Petrol OM642.896 184 hp 135 kW 3 L Diesel OM642.992 184 hp 135 kW 3 L Diesel OM642.896 184 hp 135 kW 3 L Diesel OM642.992 184 hp 135 kW 3 L Diesel OM642.993 184 hp 135 kW 3 L Diesel OM642.896 190 hp 140 kW 3 L Diesel OM642.992 190 hp 140 kW 3 L Diesel OM646.984 88 hp 65 kW 2.1 L Diesel OM646.985 109 hp 80 kW 2.1 L Diesel OM646.986 129 hp 95 kW 2.1 L Diesel OM651.955 129 hp 95 kW 2.1 L Diesel OM651.956 129 hp 95 kW 2.1 L Diesel OM646.986 129 hp 95 kW 2.1 L Diesel OM651.956 129 hp 95 kW 2.1 L Diesel OM646.986 150 hp 110 kW 2.1 L Diesel OM646.989 150 hp 110 kW 2.1 L Diesel OM646.990 150 hp 110 kW 2.1 L Diesel OM646.989 150 hp 110 kW 2.1 L Diesel OM646.990 150 hp 110 kW 2.1 L Diesel OM651.955 129 hp 95 kW 2.1 L Diesel OM651.956 129 hp 95 kW 2.1 L Diesel OM651.955 163 hp 120 kW 2.1 L Diesel OM651.957 163 hp 120 kW 2.1 L Diesel OM651.955 95 hp 70 kW 2.1 L Diesel OM651.957 163 hp 120 kW 2.1 L Diesel	Rear wheel	LCV / Van / Cargo Passenger Van / Wagon / Minibus With flatbed/undercarriage
MERCEDES-BENZ	SPRINTER 4,6-T 906	411 CDI 413 CDI 415 CDI 416 CDI 418 CDI 419 CDI 424 906.153 906.155 906.253 906.255 906.653 906.655 906.657 906.655 906.657 906.653	2006/06 -	M272.979 258 hp 190 kW 3.5 L Petrol OM642.896 184 hp 135 kW 3 L Diesel OM642.992 184 hp 135 kW 3 L Diesel OM642.896 184 hp 135 kW 3 L Diesel OM642.992 184 hp 135 kW 3 L Diesel OM642.993 184 hp 135 kW 3 L Diesel OM642.896 190 hp 140 kW 3 L Diesel OM642.898 190 hp 140 kW 3 L Diesel OM642.992 190 hp 140 kW 3 L Diesel OM642.992 190 hp 140 kW 3 L Diesel OM646.985 109 hp 80 kW 2.1 L Diesel OM646.986 129 hp 95 kW 2.1 L Diesel OM646.989 150 hp 110 kW 2.1 L Diesel OM646.990 150 hp 110 kW 2.1 L Diesel OM651.957 163 hp 120 kW 2.1 L Diesel	Rear wheel	LCV / Van / Cargo With flatbed/undercarriage
MERCEDES-BENZ	SPRINTER 5-T 906	3500 509 CDI 510 CDI 511 CDI 511 CDI 4x4 513 CDI 513 CDI 4x4 515 CDI 515 CDI 4x4 516 516 CDI 516 CDI 4x4 516 NGT 518 CDI 518 CDI 4x4 519 CDI / BlueTEC 519 CDI / BlueTEC 4x4 524 906.135 906.155 906.253 906.255 906.153 906.155 906.253 906.255 906.153 906.155 906.255 906.653 906.6355 906.657 906.653 906.655 906.657	2006/06 -	M271.951 156 hp 115 kW 1.8 L Petrol M272.979 258 hp 190 kW 3.5 L Petrol OM642.896 184 hp 135 kW 3 L Diesel OM642.992 184 hp 135 kW 3 L Diesel OM642.993 184 hp 135 kW 3 L Diesel OM642.896 190 hp 140 kW 3 L Diesel OM642.898 190 hp 140 kW 3 L Diesel OM642.992 190 hp 140 kW 3 L Diesel OM646.984 88 hp 65 kW 2.1 L Diesel OM646.985 109 hp 80 kW 2.1 L Diesel OM646.986 129 hp 95 kW 2.1 L Diesel OM651.955 129 hp 95 kW 2.1 L Diesel OM651.956 129 hp 95 kW 2.1 L Diesel OM646.986 129 hp 95 kW 2.1 L Diesel OM651.956 129 hp 95 kW 2.1 L Diesel OM646.986 150 hp 110 kW 2.1 L Diesel OM646.989 150 hp 110 kW 2.1 L Diesel OM646.990 150 hp 110 kW 2.1 L Diesel OM646.989 150 hp 110 kW 2.1 L Diesel OM646.990 150 hp 110 kW 2.1 L Diesel OM651.955 129 hp 95 kW 2.1 L Diesel OM651.956 129 hp 95 kW 2.1 L Diesel OM651.955 163 hp 120 kW 2.1 L Diesel OM651.957 163 hp 120 kW 2.1 L Diesel OM651.955 95 hp 70 kW 2.1 L Diesel OM651.956 129 hp 95 kW 2.1 L Diesel	AWD / 4WD Rear wheel	LCV / Van / Cargo With flatbed/undercarriage
VW	CRAFTER 30-35 2E	2.0 TDI 2.0 TDI 4motion 2.5 TDI	2006/04 -	BJJ 88 hp 65 kW 2.5 L Diesel BJK 109 hp 80 kW 2.5 L Diesel BJL 136 hp 100 kW 2.5 L Diesel BJM 163 hp 120 kW 2.5 L Diesel CEBA 88 hp 65 kW 2.5 L Diesel CEBB 109 hp 80 kW 2.5 L Diesel CECA 136 hp 100 kW 2.5 L Diesel CECB 163 hp 120 kW 2.5 L Diesel CKTB 109 hp 80 kW 2 L Diesel CKTC 136 hp 100 kW 2 L Diesel CKUB 163 hp 120 kW 2 L Diesel CKUC 142 hp 105 kW 2 L Diesel CSLB 114 hp 84 kW 2 L Diesel CSNA 163 hp 120 kW 2 L Diesel CKUB 163 hp 120 kW 2 L Diesel CSNA 163 hp 120 kW 2 L Diesel	AWD / 4WD Rear wheel	Passenger Van / Wagon / Minibus
VW	CRAFTER 30-50 2E 2F	2.0 TDI 2.0 TDI 4motion 2.5 TDI	2006/04 -	BJJ 88 hp 65 kW 2.5 L Diesel BJK 109 hp 80 kW 2.5 L Diesel BJL 136 hp 100 kW 2.5 L Diesel BJM 163 hp 120 kW 2.5 L Diesel CEBA 88 hp 65 kW 2.5 L Diesel CEBB 109 hp 80 kW 2.5 L Diesel CECA 136 hp 100 kW 2.5 L Diesel CECB 163 hp 120 kW 2.5 L Diesel CKTB 109 hp 80 kW 2 L Diesel CKTC 136 hp 100 kW 2 L Diesel CKUB 163 hp 120 kW 2 L Diesel CKUC 142 hp 105 kW 2 L Diesel CSLB 114 hp 84 kW 2 L Diesel CSNA 163 hp 120 kW 2 L Diesel CKUB 163 hp 120 kW 2 L Diesel CSNA 163 hp 120 kW 2 L Diesel	AWD / 4WD Rear wheel	LCV / Van / Cargo With flatbed/undercarriage
