BREMBO 09.A185.11 (09A18511) Brake Disc

BREMBO part 09.A185.11 (09A18511) Brake Disc

BREMBO 09.A185.11 (09A18511) Brake Disc

by BREMBO

Manufacturer Part Number: 09.A185.11 (09A18511)

Сharacteristics:
  • for article number: 09.A185.11
  • Brake Disc Type: Internally Vented
  • Diameter [mm]: 302
  • Brake Disc Thickness [mm]: 26
  • Minimum thickness [mm]: 24
  • Height [mm]: 34,2
  • Machining: High-carbon
  • Centering Diameter [mm]: 66
  • Number of Holes: 4
  • Tightening Torque [Nm]: 90
  • Surface: Coated
  • Supplementary Article/Info 2: with screws
  • Pillar venting technology. The innovative Brembo patented pillar venting technology boosts overall disc cooling and increases up to more than 40% resistance to thermal cracking

Product Details

BrandBREMBO
BREMBO article (MPN)09.A185.11 (09A18511)
Vehicle subsystemBrake System

Original (OEM) part numbers

Suitable for CITROEN / PEUGEOT vehicles

OE manufacturerOEM reference numbers
CITROEN / PEUGEOT424981, 424986, 424964, 4249.80, 4249J8

Aftermarket cross reference / interchange guide

The aftermarket competitive interchanges for BREMBO 09.A185.11 (09A18511) Brake Disc offered by A.B.S., AP, ATE, BENDIX, BLUE PRINT, BORG & BECK, BOSCH, Brake ENGINEERING, BRECO, BREMBO, CIFAM, DELPHI, E.T.F., FERODO, FOMAR, fri.tech., GIRLING, HELLA, HELLA PAGID, ICER, KAGER, KAMOKA, LPR, MAGNETI MARELLI, METELLI, MINTEX, OPEN PARTS, OPTIMAL, PAGID, PATRON, R BRAKE, ROTINGER, sbs, TEXTAR, TRUSTING, TRW, VALEO manufacturers

ManufacturerReference numbers
A.B.S.17818
AP25100E, 25100V
ATE24.0126-0159.1
BENDIX562641BC
BLUE PRINTADP154308
BORG & BECKBBD4717
BOSCH0986479548, 0986479C72, 0986479376
Brake ENGINEERINGDI956673
BRECOBV8709, BS8709
BREMBO09A1851X, 09.A185.14
CIFAM800985C
DELPHIBG4166
E.T.F.192613
FERODODDF1797, DDF1676
FOMARFO4137
fri.tech.BD1256
GIRLING6049625
HELLA8DD355119161, 8DD355114721
HELLA PAGID8DD355114-721, 8DD355119161
ICER78BD50172
KAGER370794
KAMOKA103263
LPRP1010VR
MAGNETI MARELLI360406070000
METELLI230985C
MINTEXMDC2032
OPEN PARTSBDA245320, BDR245320
OPTIMALBS-8438
PAGID54685
PATRONPBD4962
R BRAKE78RBD25017
ROTINGERRT20781T5, RT20781
sbs1815202336, 17818, 1815203053
TEXTAR92168500, 92168503
TRUSTINGDF1256
TRWDF4962S
VALEO197189

Vehicle fitment / BREMBO 09.A185.11 (09A18511) Brake Disc compatibility

This product fits the following models: CITROËN C4 II, CITROËN DS4, CITROËN DS5, PEUGEOT 208, PEUGEOT 3008, PEUGEOT 308, PEUGEOT 308 CC, PEUGEOT 308 SW, PEUGEOT 5008, etc. See all vehicles this product (BREMBO 09.A185.11 (09A18511)) fits below to verify fitment for your vehicle.
MakeModelVariantPeriodEngineDriveBody Style
CITROËNC4 II
B7
1.6 THP 155
2.0 BlueHDi 150
2009/11 - 5FV(EP6CDT) 156 hp 115 kW 1.6 L Petrol
RHE(DW10CTED4) 150 hp 110 kW 2 L Diesel
Front wheel
Hatchback / Sportback / Sport hatch
CITROËNDS4
1.6 THP 155
1.6 THP 160
1.6 THP 165
2.0 BlueHDi 150
2.0 BlueHDi 180
2.0 HDi 135
2.0 HDi 165
2011/04 - 2015/075FM(EP6DT) 163 hp 120 kW 1.6 L Petrol
5FM(EP6DT) 165 hp 121 kW 1.6 L Petrol
5GZ(EP6FDT) 165 hp 121 kW 1.6 L Petrol
5FV(EP6CDT) 156 hp 115 kW 1.6 L Petrol
AHW(DW10FC) 180 hp 133 kW 2 L Diesel
AHX(DW10FD) 150 hp 110 kW 2 L Diesel
RHE(DW10CTED4) 136 hp 100 kW 2 L Diesel
RHH(DW10CTED4) 163 hp 120 kW 2 L Diesel
Front wheel
Hatchback / Sportback / Sport hatch
CITROËNDS5
1.6 BlueHDi 120
1.6 HDi
1.6 HDi 110
1.6 HDi 115
1.6 THP 155
1.6 THP 165
1.6 THP 165 Hybrid
1.6 THP 200
2.0 BlueHDi 150
2.0 BlueHDi 180
2.0 HDi 135
2.0 HDi 150 Hybrid
2.0 HDi 165
2.0 HDi 165 Hybrid4 4x4
2.0 HDi 200 Hybrid4
2011/11 - 2015/07200 hp 147 kW 2 L Hybrid
5FM(EP6DT) 165 hp 121 kW 1.6 L Petrol
5GZ(EP6FDT) 165 hp 121 kW 1.6 L Petrol
5FU(EP6DTX) 200 hp 147 kW 1.6 L Petrol
5FV(EP6CDT) 156 hp 115 kW 1.6 L Petrol
5GZ(EP6FDT) 165 hp 121 kW 1.6 L Hybrid
9HD(DV6C) 114 hp 84 kW 1.6 L Diesel
9HR(DV6C) 112 hp 82 kW 1.6 L Diesel
AHW(DW10FC) 180 hp 133 kW 2 L Diesel
AHX(DW10FD) 150 hp 110 kW 2 L Diesel
AHX(DW10FD) 150 hp 110 kW 2 L Hybrid
BHX(DV6FC) 115 hp 85 kW 1.6 L Diesel
BHZ(DV6FC) 120 hp 88 kW 1.6 L Diesel
RHC(DW10CTED4) 163 hp 120 kW 2 L Hybrid
RHD(DW10CB) 136 hp 100 kW 2 L Diesel
RHH(DW10CTED4) 163 hp 120 kW 2 L Diesel
AWD / 4WD
Front wheel
Hatchback / Sportback / Sport hatch
PEUGEOT208
1.2 THP
1.6
1.6 BlueHDi 100
1.6 BlueHDi 120
1.6 GTi
1.6 HDi / BlueHDi 75
1.6 THP 165
2012/03 - 165 hp 121 kW 1.6 L Petrol
208 hp 153 kW 1.6 L Petrol
5FU(EP6CDTX) 200 hp 147 kW 1.6 L Petrol
5FV(EP6DT) 156 hp 115 kW 1.6 L Petrol
EP6CDT 156 hp 115 kW 1.6 L Petrol
9HK(DV6ETEDM) 75 hp 55 kW 1.6 L Diesel
BHW(DV6FE) 75 hp 55 kW 1.6 L Diesel
BHY(DV6FD) 100 hp 73 kW 1.6 L Diesel
BHZ(DV6FC) 120 hp 88 kW 1.6 L Diesel
HNZ(EB2DT) 110 hp 81 kW 1.2 L Petrol
Front wheel
Hatchback / Sportback / Sport hatch
PEUGEOT3008
1.6 THP
2.0 HDi
2.0 HDi 150 / BlueHDi 150
2.0 HDi Hybrid4
2009/06 - 136 hp 100 kW 2 L Diesel
RHH(DW10CTED4) 165 hp 120 kW 2 L Diesel
200 hp 147 kW 2 L Hybrid
RHC(DW10CTED4) 165 hp 120 kW 2 L Hybrid
5FV(EP6DT) 156 hp 115 kW 1.6 L Petrol
5FX(EP6DT) 150 hp 110 kW 1.6 L Petrol
AHX(DW10FD) 150 hp 110 kW 2 L Diesel
RHE(DW10CTED4) 150 hp 110 kW 2 L Diesel
AWD / 4WD
Front wheel
MPV / Van / Minivan
PEUGEOT308
4A
4C
1.6
1.6 16V
2.0 HDi
2007/09 - 5FV(EP6DT) 163 hp 120 kW 1.6 L Petrol
5FY(EP6DTS) 174 hp 128 kW 1.6 L Petrol
EP6CDT 156 hp 115 kW 1.6 L Petrol
RHE(DW10CTED4) 150 hp 110 kW 2 L Diesel
RHH(DW10CTED4) 163 hp 120 kW 2 L Diesel
RHR(DW10BTED4) 136 hp 100 kW 2 L Diesel
Front wheel
Hatchback / Sportback / Sport hatch
PEUGEOT308 CC
1.6 16V
2.0 HDi
2009/04 - 5FT(EP6DT) 140 hp 103 kW 1.6 L Petrol
5FX(EP6DT) 150 hp 110 kW 1.6 L Petrol
EP6CDT 156 hp 115 kW 1.6 L Petrol
RHF(DW10BTED4) 140 hp 103 kW 2 L Diesel
RHH(DW10CTED4) 163 hp 120 kW 2 L Diesel
RHR(DW10BTED4) 136 hp 100 kW 2 L Diesel
Front wheel
Convertible / cabrio
PEUGEOT308 SW
1.6 16V
2.0 Bioflex
2.0 HDi
2007/09 - 5FT(EP6DT) 140 hp 103 kW 1.6 L Petrol
5FX(EP6DT) 150 hp 110 kW 1.6 L Petrol
5FY(EP6DTS) 174 hp 128 kW 1.6 L Petrol
EP6CDT 156 hp 115 kW 1.6 L Petrol
RFJ(EW10A) 140 hp 103 kW 2 L Petrol
RHE(DW10CTED4) 150 hp 110 kW 2 L Diesel
RHH(DW10CTED4) 163 hp 120 kW 2 L Diesel
RHR(DW10BTED4) 136 hp 100 kW 2 L Diesel
RHR(DW10BTED4) 140 hp 103 kW 2 L Diesel
Front wheel
Estate / Turnier / Vario / Wagon
PEUGEOT5008
1.6
1.6 16V
1.6 THP 150
2.0 HDi
2.0 HDi 136 / BlueHDi 136
2.0 HDi 150 / BlueHDi 150
2009/06 - 150 hp 110 kW 1.6 L Petrol
5GZ(EP6FDT) 163 hp 120 kW 1.6 L Petrol
AHV(DW10FD) 136 hp 100 kW 2 L Diesel
RHD(DW10CTED4) 136 hp 100 kW 2 L Diesel
AHX(DW10FD) 150 hp 110 kW 2 L Diesel
RHE(DW10CTED4) 150 hp 110 kW 2 L Diesel
EP6CDT 156 hp 115 kW 1.6 L Petrol
RHH(DW10CTED4) 163 hp 120 kW 2 L Diesel
Front wheel
MPV / Van / Minivan
