BREMBO 09.A386.10 (09A38610) Brake Disc

BREMBO part 09.A386.10 (09A38610) Brake Disc

BREMBO 09.A386.10 (09A38610) Brake Disc

by BREMBO

Manufacturer Part Number: 09.A386.10 (09A38610)

Сharacteristics:
  • for article number: 09.A386.10
  • Brake Disc Type: Internally Vented
  • Diameter [mm]: 275
  • Brake Disc Thickness [mm]: 28
  • Minimum thickness [mm]: 26
  • Height [mm]: 49,2
  • Centering Diameter [mm]: 62
  • Number of Holes: 5
  • Tightening Torque [Nm]: 103

Product Details

BrandBREMBO
BREMBO article (MPN)09.A386.10 (09A38610)
Vehicle subsystemBrake System

Original (OEM) part numbers

Suitable for TOYOTA vehicles

OE manufacturerOEM reference numbers
TOYOTA43512-06040, 43512-07020, 43512-33040, 43512-33041, 43512-44020, 43512-44021, 43512-33042, 43512-33060, 43512-33090, 4351244010

Aftermarket cross reference / interchange guide

The aftermarket competitive interchanges for BREMBO 09.A386.10 (09A38610) Brake Disc offered by A.B.S., ADVICS / SUMITOMO, AP, ASHUKI, ATE, BENDIX, BLUE PRINT, BORG & BECK, BOSCH, Brake ENGINEERING, BRECO, BREMBO, BREMSI, CIFAM, DELPHI, DENCKERMANN, Dr!ve+, FERODO, FOMAR, fri.tech., FTE, GIRLING, G.U.D, HELLA, HELLA PAGID, HERTH+BUSS JAKOPARTS, JP GROUP, JURID, KAGER, KAVO PARTS, KAWE, LPR, LUCAS ELECTRICAL, MAGNETI MARELLI, MAPCO, METELLI, METZGER, MEYLE, MINTEX, MOTAQUIP, NECTO, NIPPARTS, OPEN PARTS, OPTIMAL, PAGID, PATRON, PILENGA, PROTECHNIC, QUINTON HAZELL, REMSA, ROADHOUSE, ROTINGER, SAKURA, SASIC, sbs, STELLOX, TEMPLIN, TEXTAR, TRISCAN, TRUSTING, TRW, VALEO, WOKING, ZIMMERMANN manufacturers

ManufacturerReference numbers
A.B.S.16220
ADVICS / SUMITOMOA6F188
AP25079
ASHUKIT60125, T60125G
ATE24.0128-0115.1
BENDIX561676B, 561676BC
BLUE PRINTADT343191, ADT34378
BORG & BECKBBD4309
BOSCH0986478632, 0986AB9507
Brake ENGINEERINGDI955331
BRECOBS8687
BREMBO09A38611
BREMSIDBA501V
CIFAM8001028
DELPHIBG2782
DENCKERMANNB130388
Dr!ve+DP1010110661
FERODODRF501, DDF501, DDF5011
FOMARFO2509
fri.tech.BD1063
FTEBS7694
GIRLING6014311
G.U.DGDB128115
HELLA8DD355104931, 8DD355104921
HELLA PAGID8DD355104921, 8DD355104931
HERTH+BUSS JAKOPARTSJ3302091
JP GROUP4863102309
JURID561676JC, 561676J
KAGER370067
KAVO PARTSBR9501, BR9357C, BR9501C, BR9442, BR9357, BR9442C
KAWE684210
LPRT2981V
LUCAS ELECTRICALDF1431
MAGNETI MARELLI360406047100, 353615275240
MAPCO45570
METELLI231028
METZGER6110624, 684210
MEYLE30-155210031/PD, 30155210031, 30155210090
MINTEXMDC898
MOTAQUIPLVBD1265Z, LVBD876Z
NECTOWN642
NIPPARTSJ3302075
OPEN PARTSBDR187620, BDA187620, BDRS187625
OPTIMALBS-7160
PAGID53625
PATRONPBD1434, PBD1431
PILENGAV660
PROTECHNICPRD2208
QUINTON HAZELLBDC4422
REMSA6842.10
ROADHOUSE684210
ROTINGERRT2209, RT2209T5
SAKURA604203785
SASIC6106063
sbs18152045117, 1815204549, 1815204547, 17618, 16220, 1815204596
STELLOX60201137VSX
TEMPLIN0311027570, 0311027575
TEXTAR92077700, 92077703, 92135400, 98200077701
TRISCAN812013182
TRUSTINGDF1063
TRWDF1431
VALEO197166
WOKINGD684210
ZIMMERMANN590255600, 590255620

Vehicle fitment / BREMBO 09.A386.10 (09A38610) Brake Disc compatibility

This product fits the following models: LEXUS ES, TOYOTA AVENSIS VERSO, TOYOTA CAMRY, TOYOTA ESTIMA, TOYOTA IPSUM, TOYOTA PICNIC, TOYOTA PREVIA, TOYOTA SCEPTER, TOYOTA TARAGO, TOYOTA VERSO, etc. See all vehicles this product (BREMBO 09.A386.10 (09A38610)) fits below to verify fitment for your vehicle.
MakeModelVariantPeriodEngineDriveBody Style
LEXUSES
VCV10
F1
VZV21
F2
300
MCV10
VCV10
1991/09 - 1997/123VZ-FE 188 hp 138 kW 3 L Petrol
Rear wheel
Sedan / Saloon
TOYOTAAVENSIS VERSO
CLM2
ACM2
2.0 D-4D
2.0 VVT-i
2.4 VVTi 4WD
2.4 VVTi GLS
2001/08 - 2009/111AZ-FE 150 hp 110 kW 2 L Petrol
1CD-FTV 116 hp 85 kW 2 L Diesel
2AZ-FE 156 hp 115 kW 2.4 L Petrol
AWD / 4WD
Front wheel
MPV / Van / Minivan
TOYOTACAMRY
CV1
XV1
V1
CV2
XV2
MCV3
ACV3
XV3
XV1
CV1
V10
2.2
2.4 VVT-i
3.0
3.0 24V
3.0 V6
3.0 VIENTA

MCV20
SXV10
SXV20
VCV10
VDV10
1991/06 - 2006/111MZ-FE 183 hp 135 kW 3 L Petrol
3VZ-FE 185 hp 136 kW 3 L Petrol
1MZ-FE 184 hp 135 kW 3 L Petrol
1MZ-FE 190 hp 140 kW 3 L Petrol
2AZ-FE 152 hp 112 kW 2.4 L Petrol
3VZ-FE 188 hp 138 kW 3 L Petrol
3VZ-FE 190 hp 140 kW 3 L Petrol
5S-FE 126 hp 93 kW 2.2 L Petrol
5S-FE 131 hp 96 kW 2.2 L Petrol
5S-FE 136 hp 100 kW 2.2 L Petrol
Front wheel
Estate / Turnier / Vario / Wagon
Sedan / Saloon
TOYOTAESTIMA
MCR3
ACR3
CLR3
2.0 D-4D
2.4
2.4 16V

ACR30
2000/08 - 2006/011CD-FTV 116 hp 85 kW 2 L Diesel
2AZ-FE 156 hp 115 kW 2.4 L Petrol
Front wheel
MPV / Van / Minivan
TOYOTAIPSUM
CLM2
ACM2
2.0 D-4D
2.0 VVT-i
2.4 VVTi 4WD
2.4 VVTi GLS
2001/08 - 2009/111AZ-FE 150 hp 110 kW 2 L Petrol
1CD-FTV 116 hp 85 kW 2 L Diesel
2AZ-FE 156 hp 115 kW 2.4 L Petrol
AWD / 4WD
Front wheel
MPV / Van / Minivan
TOYOTAPICNIC
CLM2
ACM2
2.0 D-4D
2.0 VVT-i
2.4 VVTi 4WD
2.4 VVTi GLS
2001/08 - 2009/111AZ-FE 150 hp 110 kW 2 L Petrol
1CD-FTV 116 hp 85 kW 2 L Diesel
2AZ-FE 156 hp 115 kW 2.4 L Petrol
AWD / 4WD
Front wheel
MPV / Van / Minivan
TOYOTAPREVIA
MCR3
ACR3
CLR3
2.0 D-4D
2.4
2.4 16V

ACR30
2000/08 - 2006/011CD-FTV 116 hp 85 kW 2 L Diesel
2AZ-FE 156 hp 115 kW 2.4 L Petrol
Front wheel
MPV / Van / Minivan
TOYOTASCEPTER
CV1
XV1
V1
XV1
CV1
V10
2.2
3.0

SXV10
VCV10
1991/06 - 1996/081MZ-FE 183 hp 135 kW 3 L Petrol
3VZ-FE 185 hp 136 kW 3 L Petrol
3VZ-FE 188 hp 138 kW 3 L Petrol
5S-FE 126 hp 93 kW 2.2 L Petrol
5S-FE 136 hp 100 kW 2.2 L Petrol
Front wheel
Estate / Turnier / Vario / Wagon
Sedan / Saloon
TOYOTATARAGO
MCR3
ACR3
CLR3
2.0 D-4D
2.4
2.4 16V

ACR30
2000/08 - 2006/011CD-FTV 116 hp 85 kW 2 L Diesel
2AZ-FE 156 hp 115 kW 2.4 L Petrol
Front wheel
MPV / Van / Minivan
TOYOTAVERSO
CLM2
ACM2
2.0 D-4D
2.0 VVT-i
2.4 VVTi 4WD
2.4 VVTi GLS
2001/08 - 2009/111AZ-FE 150 hp 110 kW 2 L Petrol
1CD-FTV 116 hp 85 kW 2 L Diesel
2AZ-FE 156 hp 115 kW 2.4 L Petrol
AWD / 4WD
Front wheel
MPV / Van / Minivan
