BREMBO 09.A386.11 (09A38611) Brake Disc

BREMBO part 09.A386.11 (09A38611) Brake Disc

BREMBO 09.A386.11 (09A38611) Brake Disc

by BREMBO

Manufacturer Part Number: 09.A386.11 (09A38611)

Сharacteristics:
  • for article number: 09.A386.11
  • Brake Disc Type: Internally Vented
  • Diameter [mm]: 275
  • Brake Disc Thickness [mm]: 28
  • Minimum thickness [mm]: 26
  • Height [mm]: 49,2
  • Centering Diameter [mm]: 62
  • Number of Holes: 5
  • Tightening Torque [Nm]: 103
  • Surface: Coated

Product Details

BrandBREMBO
BREMBO article (MPN)09.A386.11 (09A38611)
Vehicle subsystemBrake System

Original (OEM) part numbers

Suitable for TOYOTA vehicles

OE manufacturerOEM reference numbers
TOYOTA4351206040, 4351207020, 4351233040, 4351233041, 4351233042, 4351233060, 4351233090, 4351244010, 4351244020, 4351244021

Aftermarket cross reference / interchange guide

The aftermarket competitive interchanges for BREMBO 09.A386.11 (09A38611) Brake Disc offered by A.B.S., AP, ASHUKI, ATE, BENDIX, BLUE PRINT, BORG & BECK, BOSCH, Brake ENGINEERING, BRECO, BREMBO, CIFAM, DELPHI, Dr!ve+, FERODO, FOMAR, FTE, GIRLING, G.U.D, HELLA, HELLA PAGID, HERTH+BUSS JAKOPARTS, JP GROUP, JURID, KAGER, MAGNETI MARELLI, METELLI, MINTEX, NIPPARTS, OPEN PARTS, OPTIMAL, PAGID, ROTINGER, SAKURA, sbs, STARLINE, TEMPLIN, TEXTAR, TRISCAN, TRW, VALEO, VILLAR, ZIMMERMANN manufacturers

ManufacturerReference numbers
A.B.S.16220
AP25079, 25079V
ASHUKIT60125, T60125G
ATE24012801151
BENDIX561676B, 561676BC
BLUE PRINTADT34378, ADT343191
BORG & BECKBBD5034, BBD4309
BOSCH0986AB9507, 0986478632
Brake ENGINEERINGDI955331
BRECOBS8687, BV8687
BREMBO09A38610
CIFAM8001028
DELPHIBG2782
Dr!ve+DP1010110661
FERODODRF501, DDF501
FOMARFO2509
FTEBS7694
GIRLING6014311
G.U.DGDB128115
HELLA8DD355104921, 8DD355104931, 8DD355111611, 8DD355111601
HELLA PAGID8DD355111611, 8DD355111601, 8DD355104921, 8DD355104931
HERTH+BUSS JAKOPARTSJ3302091
JP GROUP4863102309
JURID561676J
KAGER370067
MAGNETI MARELLI360406047100
METELLI231028
MINTEXMDC2257, MDC898
NIPPARTSJ3302075
OPEN PARTSBDA187620, BDR187620, BDRS187625
OPTIMALBS7160
PAGID54354, 53625
ROTINGERRT2209T5, RT2209
SAKURA604203785
sbs16220, 1815204547, 18152045117, 17618, 1815204549, 1815204596
STARLINEPB2209C
TEMPLIN0311027570, 0311027575
TEXTAR92135400, 92135403, 92077700, 92077703
TRISCAN812013135C
TRWDF1431
VALEO197166
VILLAR6282093
ZIMMERMANN590255620, 590255600

Vehicle fitment / BREMBO 09.A386.11 (09A38611) Brake Disc compatibility

This product fits the following models: LEXUS ES, TOYOTA AVENSIS VERSO, TOYOTA CAMRY, TOYOTA ESTIMA, TOYOTA IPSUM, TOYOTA PICNIC, TOYOTA PREVIA, TOYOTA SCEPTER, TOYOTA TARAGO, TOYOTA VERSO, etc. See all vehicles this product (BREMBO 09.A386.11 (09A38611)) fits below to verify fitment for your vehicle.
MakeModelVariantPeriodEngineDriveBody Style
LEXUSES
VCV10
F1
VZV21
F2
300
MCV10
VCV10
1991/09 - 1997/123VZ-FE 188 hp 138 kW 3 L Petrol
Rear wheel
Sedan / Saloon
TOYOTAAVENSIS VERSO
CLM2
ACM2
2.0 D-4D
2.0 VVT-i
2.4 VVTi 4WD
2.4 VVTi GLS
2001/08 - 2009/111AZ-FE 150 hp 110 kW 2 L Petrol
1CD-FTV 116 hp 85 kW 2 L Diesel
2AZ-FE 156 hp 115 kW 2.4 L Petrol
AWD / 4WD
Front wheel
MPV / Van / Minivan
TOYOTACAMRY
CV1
XV1
V1
CV2
XV2
MCV3
ACV3
XV3
XV1
CV1
V10
2.2
2.4 VVT-i
3.0
3.0 24V
3.0 V6
3.0 VIENTA

MCV20
SXV10
SXV20
VCV10
VDV10
1991/06 - 2006/111MZ-FE 183 hp 135 kW 3 L Petrol
3VZ-FE 185 hp 136 kW 3 L Petrol
1MZ-FE 184 hp 135 kW 3 L Petrol
1MZ-FE 190 hp 140 kW 3 L Petrol
2AZ-FE 152 hp 112 kW 2.4 L Petrol
3VZ-FE 188 hp 138 kW 3 L Petrol
3VZ-FE 190 hp 140 kW 3 L Petrol
5S-FE 126 hp 93 kW 2.2 L Petrol
5S-FE 131 hp 96 kW 2.2 L Petrol
5S-FE 136 hp 100 kW 2.2 L Petrol
Front wheel
Estate / Turnier / Vario / Wagon
Sedan / Saloon
TOYOTAESTIMA
MCR3
ACR3
CLR3
2.0 D-4D
2.4
2.4 16V

ACR30
2000/08 - 2006/011CD-FTV 116 hp 85 kW 2 L Diesel
2AZ-FE 156 hp 115 kW 2.4 L Petrol
Front wheel
MPV / Van / Minivan
TOYOTAIPSUM
CLM2
ACM2
2.0 D-4D
2.0 VVT-i
2.4 VVTi 4WD
2.4 VVTi GLS
2001/08 - 2009/111AZ-FE 150 hp 110 kW 2 L Petrol
1CD-FTV 116 hp 85 kW 2 L Diesel
2AZ-FE 156 hp 115 kW 2.4 L Petrol
AWD / 4WD
Front wheel
MPV / Van / Minivan
TOYOTAPICNIC
CLM2
ACM2
2.0 D-4D
2.0 VVT-i
2.4 VVTi 4WD
2.4 VVTi GLS
2001/08 - 2009/111AZ-FE 150 hp 110 kW 2 L Petrol
1CD-FTV 116 hp 85 kW 2 L Diesel
2AZ-FE 156 hp 115 kW 2.4 L Petrol
AWD / 4WD
Front wheel
MPV / Van / Minivan
TOYOTAPREVIA
MCR3
ACR3
CLR3
2.0 D-4D
2.4
2.4 16V

ACR30
2000/08 - 2006/011CD-FTV 116 hp 85 kW 2 L Diesel
2AZ-FE 156 hp 115 kW 2.4 L Petrol
Front wheel
MPV / Van / Minivan
TOYOTASCEPTER
CV1
XV1
V1
XV1
CV1
V10
2.2
3.0

SXV10
VCV10
1991/06 - 1996/081MZ-FE 183 hp 135 kW 3 L Petrol
3VZ-FE 185 hp 136 kW 3 L Petrol
3VZ-FE 188 hp 138 kW 3 L Petrol
5S-FE 126 hp 93 kW 2.2 L Petrol
5S-FE 136 hp 100 kW 2.2 L Petrol
Front wheel
Estate / Turnier / Vario / Wagon
Sedan / Saloon
TOYOTATARAGO
MCR3
ACR3
CLR3
2.0 D-4D
2.4
2.4 16V

ACR30
2000/08 - 2006/011CD-FTV 116 hp 85 kW 2 L Diesel
2AZ-FE 156 hp 115 kW 2.4 L Petrol
Front wheel
MPV / Van / Minivan
TOYOTAVERSO
CLM2
ACM2
2.0 D-4D
2.0 VVT-i
2.4 VVTi 4WD
2.4 VVTi GLS
2001/08 - 2009/111AZ-FE 150 hp 110 kW 2 L Petrol
1CD-FTV 116 hp 85 kW 2 L Diesel
2AZ-FE 156 hp 115 kW 2.4 L Petrol
AWD / 4WD
Front wheel
MPV / Van / Minivan
