BREMBO 09.A428.14 (09A42814) Brake Disc

BREMBO part 09.A428.14 (09A42814) Brake Disc

BREMBO 09.A428.14 (09A42814) Brake Disc

by BREMBO

Manufacturer Part Number: 09.A428.14 (09A42814)

Сharacteristics:
  • for article number: 09.A428.14
  • Brake Disc Type: Internally Vented
  • Diameter [mm]: 288
  • Brake Disc Thickness [mm]: 25
  • Minimum thickness [mm]: 23
  • Height [mm]: 46,2
  • Machining: High-carbon
  • Centering Diameter [mm]: 68
  • Number of Holes: 5
  • Tightening Torque [Nm]: 120

Product Details

BrandBREMBO
BREMBO article (MPN)09.A428.14 (09A42814)
Vehicle subsystemBrake System

Original (OEM) part numbers

Suitable for VAG vehicles

OE manufacturerOEM reference numbers
VAG4B0615301B

Aftermarket cross reference / interchange guide

The aftermarket competitive interchanges for BREMBO 09.A428.14 (09A42814) Brake Disc offered by A.B.S., AP, ATE, AUTOMEGA, BARUM, BENDIX, BORG & BECK, BOSCH, Brake ENGINEERING, BRECK, BRECO, BREMBO, BREMSI, BSG, CIFAM, DELPHI, DENCKERMANN, Dr!ve+, FEBI BILSTEIN, FERODO, FOMAR, GALFER, GIRLING, G.U.D, HANS PRIES, HELLA, HELLA PAGID, ICER, JURID, KAGER, KAWE, KEY PARTS, KRAFT, LPR, MAPCO, METELLI, METZGER, MINTEX, OPEN PARTS, OPTIMAL, PAGID, PATRON, PILENGA, PROTECHNIC, R BRAKE, REMSA, ROADHOUSE, ROTINGER, sbs, SWAG, TEMPLIN, TEXTAR, TRUSTING, TRW, VAICO, VALEO, WAGNER LOCKHEED, WOKING, ZIMMERMANN manufacturers

ManufacturerReference numbers
A.B.S.17527
AP25104E
ATE24.0125-0171-1, 24032501711
AUTOMEGA1061503014B0B, 3061503014B0B
BARUMBAR25171
BENDIX561548B, 561548BC
BORG & BECKBBD4948
BOSCH0986479157, 0986479S19
Brake ENGINEERINGDI956802
BRECKBR336VA100
BRECOBS8713
BREMBO09.A428.11
BREMSIDBB706V
BSGBSG90210003
CIFAM800745C
DELPHIBG2745, BG2745C
DENCKERMANNB130440
Dr!ve+DP1010110599
FEBI BILSTEIN28505
FERODODDF1677, DDF1706C, DDF1706, DDF17061, DDF1706C1
FOMARFO2136, FO2679
GALFERB1G22501711
GIRLING6048161, 6026521
G.U.DGDB125171
HANS PRIES110420
HELLA8DD355109621, 8DD355109622, 8DD355109611
HELLA PAGID8DD355109621, 8DD355109622, 8DD355109611
ICER78BD10682
JURID561548JC, 561548J
KAGER371420, 371035
KAWE6122710
KEY PARTSKBD4948
KRAFT6040333
LPRV2004V
MAPCO25870
METELLI230745C
METZGER6110080
MINTEXMDC2338
OPEN PARTSBDR228020, BDRS228025
OPTIMALBS7532, BS7532C
PAGID54210
PATRONPBD4816
PILENGAV228
PROTECHNICPRD2483
R BRAKE78RBD21068
REMSA6122710
ROADHOUSE6122710
ROTINGERRT20363T5, RT20363
sbs17527, 1815204773
SWAG30928505
TEMPLIN0311030350, 0311030355
TEXTAR92121005, 92121000, 92121003
TRUSTINGDF1604
TRWDF2652, DF4295, DF4816
VAICOV1080098
VALEO186271, 197222
WAGNER LOCKHEEDWGR17061
WOKINGD6122710
ZIMMERMANN600.3236.20, 600.3236.52

Vehicle fitment / BREMBO 09.A428.14 (09A42814) Brake Disc compatibility

This product fits the following models: SKODA SUPERB, VW PASSAT, etc. See all vehicles this product (BREMBO 09.A428.14 (09A42814)) fits below to verify fitment for your vehicle.
MakeModelVariantPeriodEngineDriveBody Style
SKODASUPERB
3U4
1.8 T
1.9 TDI
2.0
2001/12 - 2008/03AVB 101 hp 74 kW 1.9 L Diesel
AVF 130 hp 96 kW 1.9 L Diesel
AWX 130 hp 96 kW 1.9 L Diesel
BSV 105 hp 77 kW 1.9 L Diesel
AWT 150 hp 110 kW 1.8 L Petrol
AZM 115 hp 85 kW 2 L Petrol
Front wheel
Sedan / Saloon
VWPASSAT
3B2
3B3
3B5
3B6
1.6
1.8
1.8 4motion
1.8 T
1.8 T 20V
1.8 T 4motion
1.9 TDI
1.9 TDI 4motion
1.9 TDI Syncro/4motion
2.0
2.0 4motion
2.0 TDI
2.3 VR5
2.3 VR5 Syncro/4motion
2.5 TDI
2.5 TDI Syncro/4motion
2.8 Syncro
2.8 V6
2.8 V6 Syncro/4motion
1996/08 - 2005/08ACK 193 hp 142 kW 2.8 L Petrol
AGE 180 hp 132 kW 2.8 L Petrol
AHA 193 hp 142 kW 2.8 L Petrol
APR 193 hp 142 kW 2.8 L Petrol
AQD 193 hp 142 kW 2.8 L Petrol
ATX 190 hp 140 kW 2.8 L Petrol
BBG 190 hp 140 kW 2.8 L Petrol
ACK 193 hp 142 kW 2.8 L Petrol
AHA 193 hp 142 kW 2.8 L Petrol
ALG 193 hp 142 kW 2.8 L Petrol
APR 193 hp 142 kW 2.8 L Petrol
AQD 193 hp 142 kW 2.8 L Petrol
AEB 150 hp 110 kW 1.8 L Petrol
ANB 150 hp 110 kW 1.8 L Petrol
APU 150 hp 110 kW 1.8 L Petrol
AEB 152 hp 112 kW 1.8 L Petrol
AFB 150 hp 110 kW 2.5 L Diesel
AKN 150 hp 110 kW 2.5 L Diesel
AFN 110 hp 81 kW 1.9 L Diesel
AJM 115 hp 85 kW 1.9 L Diesel
ATJ 115 hp 85 kW 1.9 L Diesel
AVB 101 hp 74 kW 1.9 L Diesel
AVG 110 hp 81 kW 1.9 L Diesel
AFN 110 hp 81 kW 1.9 L Diesel
AVG 110 hp 81 kW 1.9 L Diesel
AGE 180 hp 132 kW 2.8 L Petrol
AGZ 150 hp 110 kW 2.3 L Petrol
ALT 130 hp 96 kW 2 L Petrol
AZM 115 hp 85 kW 2 L Petrol
ALT 130 hp 96 kW 2 L Petrol
AZM 115 hp 85 kW 2 L Petrol
BFF 115 hp 85 kW 2 L Petrol
ALZ 102 hp 75 kW 1.6 L Petrol
ASU 120 hp 88 kW 2 L Petrol
ASU 120 hp 88 kW 2 L Petrol
AUZ 120 hp 88 kW 2 L Petrol
ATJ 115 hp 85 kW 1.9 L Diesel
AVB 101 hp 74 kW 1.9 L Diesel
AVF 130 hp 96 kW 1.9 L Diesel
AWX 130 hp 96 kW 1.9 L Diesel
AVF 130 hp 96 kW 1.9 L Diesel
AWL 150 hp 110 kW 1.8 L Petrol
AWT 150 hp 110 kW 1.8 L Petrol
AWM 170 hp 125 kW 1.8 L Petrol
AWT 150 hp 110 kW 1.8 L Petrol
AZM 115 hp 85 kW 2 L Petrol
BGW 136 hp 100 kW 2 L Diesel
BHW 136 hp 100 kW 2 L Diesel
AWD / 4WD
Front wheel
Estate / Turnier / Vario / Wagon
Sedan / Saloon
