BREMBO 09.A430.10 (09A43010) Brake Disc

BREMBO part 09.A430.10 (09A43010) Brake Disc

BREMBO 09.A430.10 (09A43010) Brake Disc

by BREMBO

Manufacturer Part Number: 09.A430.10 (09A43010)

Сharacteristics:
  • for article number: 09.A430.10
  • Brake Disc Type: Internally Vented
  • Diameter [mm]: 304
  • Brake Disc Thickness [mm]: 28
  • Minimum thickness [mm]: 26
  • Height [mm]: 48
  • Centering Diameter [mm]: 71
  • Number of Holes: 5
  • Tightening Torque [Nm]: 90
  • Supplementary Article/Info 2: with screws

Product Details

BrandBREMBO
BREMBO article (MPN)09.A430.10 (09A43010)
Vehicle subsystemBrake System

Original (OEM) part numbers

Suitable for CITROEN / PEUGEOT, FIAT / LANCIA / ALFA, TOYOTA vehicles

OE manufacturerOEM reference numbers
CITROEN / PEUGEOT424924, 424925, 424992, 4249K0
FIAT / LANCIA / ALFA1440027088, 9467548587, 9467548588
TOYOTASU001A1064

Aftermarket cross reference / interchange guide

The aftermarket competitive interchanges for BREMBO 09.A430.10 (09A43010) Brake Disc offered by A.B.S., ATE, BENDIX, BLUE PRINT, BORG & BECK, BOSCH, Brake ENGINEERING, BREMSI, CIFAM, DELPHI, DENCKERMANN, Dr!ve+, E.T.F., EUROBRAKE, FERODO, FOMAR, fri.tech., GIRLING, HANS PRIES, HELLA, HELLA PAGID, ICER, JP GROUP, JURID, KAGER, KAWE, KEY PARTS, KRAFT, LPR, MAGNETI MARELLI, MALÒ, MAPCO, METELLI, METZGER, MINTEX, MOTAQUIP, NATIONAL, NK, OPEN PARTS, OPTIMAL, PAGID, PROFIT, PROTECHNIC, R BRAKE, REMSA, ROADHOUSE, ROTINGER, sbs, STARLINE, TEMPLIN, TEXTAR, TRUSTING, TRW, VALEO, WAGNER LOCKHEED, WOKING, ZIMMERMANN manufacturers

ManufacturerReference numbers
A.B.S.17773
ATE24012802161
BENDIX562622BC
BLUE PRINTADT343299
BORG & BECKBBD5815S
BOSCH0986479380, 0986479C53
Brake ENGINEERINGDI956684
BREMSIDBB615V
CIFAM800886C
DELPHIBG4083
DENCKERMANNB130503
Dr!ve+DP1010110544
E.T.F.197417
EUROBRAKE5815203734
FERODODDF1615, DDF16151
FOMARFO4110
fri.tech.BD1222
GIRLING6048495
HANS PRIES722488
HELLA8DD355113671
HELLA PAGID8DD355113671
ICER78BD47552
JP GROUP4163101809
JURID562622JC
KAGER370792
KAWE6105410
KEY PARTSKBD5815S
KRAFT6045671
LPRC1009V
MAGNETI MARELLI361302040114, 360406075700
MALÒ1110124
MAPCO15330
METELLI230886C
METZGER6110318, 6105410
MINTEXMDC1848
MOTAQUIPLVBD1288
NATIONALNBD1438
NK203734, 313734
OPEN PARTSBDR238320, BDA238320
OPTIMALBS-8390
PAGID54570
PROFIT50101615
PROTECHNICPRD2536
R BRAKE78RBD24755
REMSA6105410
ROADHOUSE6105410
ROTINGERRT20652, RT20652T5
sbs1815203734, 17773, 1815203736, 1815313734
STARLINEPB20652C, PB4001
TEMPLIN0311080385, 0311080380
TEXTAR92157000, 92157003
TRUSTINGDF1222
TRWDF4849S
VALEO197133
WAGNER LOCKHEEDWGR16151
WOKINGD6105410
ZIMMERMANN440311720, 440311700

Vehicle fitment / BREMBO 09.A430.10 (09A43010) Brake Disc compatibility

This product fits the following models: CITROËN C5 III, CITROËN DISPATCH, CITROËN JUMPY, FIAT SCUDO, PEUGEOT 407, PEUGEOT EXPERT, PEUGEOT EXPERT TEPEE, TOYOTA PROACE, etc. See all vehicles this product (BREMBO 09.A430.10 (09A43010)) fits below to verify fitment for your vehicle.
MakeModelVariantPeriodEngineDriveBody Style
CITROËNC5 III
RD
TD
1.6 HDi
1.6 HDi 110
1.6 HDi 115
1.6 THP 150
1.6 THP 155
1.6 VTi 120
1.6 VTI 120
1.8 16V
2.0 16V
2.0 16V BioFlex
2.0 HDi
2.0 HDi 140
2.0 HDi 150 / BlueHDi 150
2.0 HDi 165
2008/02 - 5FN(EP6CDT) 150 hp 110 kW 1.6 L Petrol
5FS(EP6C) 120 hp 88 kW 1.6 L Petrol
5FV(EP6CDT) 156 hp 115 kW 1.6 L Petrol
6FY(EW7A) 125 hp 92 kW 1.8 L Petrol
9HL(DV6C) 112 hp 82 kW 1.6 L Diesel
9HR(DV6C) 112 hp 82 kW 1.6 L Diesel
9HL(DV6C) 114 hp 84 kW 1.6 L Diesel
9HR(DV6C) 114 hp 84 kW 1.6 L Diesel
9HZ(DV6TED4) 109 hp 80 kW 1.6 L Diesel
AHR(DW10FD) 150 hp 110 kW 2 L Diesel
RHE(DW10CTED4) 150 hp 110 kW 2 L Diesel
RFJ(EW10A) 140 hp 103 kW 2 L Petrol
RHF(DW10BTED4) 136 hp 100 kW 2 L Diesel
RHR(DW10BTED4) 136 hp 100 kW 2 L Diesel
RHF(DW10BTED4) 140 hp 103 kW 2 L Diesel
RHH(DW10CTED4) 163 hp 120 kW 2 L Diesel
RHR(DW10BTED4) 136 hp 100 kW 2 L Diesel
Front wheel
Estate / Turnier / Vario / Wagon
Sedan / Saloon
CITROËNDISPATCH
1.6 HDi 90 16V
1.6 HDi 90 8V
2.0 HDi 120
2.0 HDi 120 4x4
2.0 HDi 125
2.0 HDi 140
2.0 HDi 165
2.0 HDi 95
2.0 i
2007/01 - 9HH(DV6DUM) 90 hp 66 kW 1.6 L Diesel
9HM(DV6UC) 90 hp 66 kW 1.6 L Diesel
9HU(DV6UTED4) 90 hp 66 kW 1.6 L Diesel
AHY(DW10CE) 98 hp 72 kW 2 L Diesel
AHZ(DW10CD) 128 hp 94 kW 2 L Diesel
RFH(EW10A) 140 hp 103 kW 2 L Petrol
RHH(DW10CTED4) 163 hp 120 kW 2 L Diesel
RHK(DW10UTED4) 120 hp 88 kW 2 L Diesel
RHR(DW10BTED4) 136 hp 100 kW 2 L Diesel
AWD / 4WD
Front wheel
LCV / Van / Cargo
MPV / Van / Minivan
CITROËNJUMPY
1.6 HDi 90 16V
1.6 HDi 90 8V
2.0 HDi 120
2.0 HDi 120 4x4
2.0 HDi 125
2.0 HDi 140
2.0 HDi 165
2.0 HDi 95
2.0 i
2007/01 - 9HH(DV6DUM) 90 hp 66 kW 1.6 L Diesel
9HM(DV6UC) 90 hp 66 kW 1.6 L Diesel
9HU(DV6UTED4) 90 hp 66 kW 1.6 L Diesel
AHY(DW10CE) 98 hp 72 kW 2 L Diesel
AHZ(DW10CD) 128 hp 94 kW 2 L Diesel
RFH(EW10A) 140 hp 103 kW 2 L Petrol
RHH(DW10CTED4) 163 hp 120 kW 2 L Diesel
RHK(DW10UTED4) 120 hp 88 kW 2 L Diesel
RHR(DW10BTED4) 136 hp 100 kW 2 L Diesel
AWD / 4WD
Front wheel
LCV / Van / Cargo
MPV / Van / Minivan
FIATSCUDO
272
270
1.6 D Multijet
2.0 D Multijet
2.0 D Multijet 4x4
2007/01 - 9HU 90 hp 66 kW 1.6 L Diesel
DW10BTED4 136 hp 100 kW 2 L Diesel
RH02 128 hp 94 kW 2 L Diesel
RH02 163 hp 120 kW 2 L Diesel
RHH 163 hp 120 kW 2 L Diesel
RHK 120 hp 88 kW 2 L Diesel
RHR 136 hp 100 kW 2 L Diesel
RH02 128 hp 94 kW 2 L Diesel
RH02 163 hp 120 kW 2 L Diesel
RHH 163 hp 120 kW 2 L Diesel
RHK 120 hp 88 kW 2 L Diesel
RHR 136 hp 100 kW 2 L Diesel
RH02 128 hp 94 kW 2 L Diesel
RHK 120 hp 88 kW 2 L Diesel
RHK 120 hp 88 kW 2 L Diesel
AWD / 4WD
Front wheel
LCV / Van / Cargo
MPV / Van / Minivan
With flatbed/undercarriage
PEUGEOT407
6D
2.0 HDi
2.0 HDi 135
2004/05 - RHF(DW10BTED4) 140 hp 103 kW 2 L Diesel
RHR(DW10BTED4) 136 hp 100 kW 2 L Diesel
Front wheel
Sedan / Saloon
PEUGEOTEXPERT

VF3A
VF3U
VF3X
1.6 HDi 90
1.6 HDi 90 16V
1.6 HDi 90 8V
2.0 16V
2.0 HDi 100
2.0 HDi 120
2.0 HDi 120 4x4
2.0 HDi 130
2.0 HDi 130 4x4
2.0 HDi 140
2.0 HDi 165
2007/01 - 98 hp 72 kW 2 L Diesel
9HH(DV6DUM) 90 hp 66 kW 1.6 L Diesel
9HM(DV6UC) 90 hp 66 kW 1.6 L Diesel
9HU(DV6UTED4) 90 hp 66 kW 1.6 L Diesel
AHZ(DW10CD) 128 hp 94 kW 2 L Diesel
RFH(EW10A) 140 hp 103 kW 2 L Petrol
RFJ(EW10A) 140 hp 103 kW 2 L Petrol
RHH(DW10CTED4) 163 hp 120 kW 2 L Diesel
RHK(DW10UTED4) 120 hp 88 kW 2 L Diesel
RHR(DW10BTED4) 136 hp 100 kW 2 L Diesel
AWD / 4WD
Front wheel
LCV / Van / Cargo
With flatbed/undercarriage
PEUGEOTEXPERT TEPEE
VF3V
1.6 HDi 90 16V
1.6 HDi 90 8V
2.0 16V
2.0 HDi 100
2.0 HDi 120
2.0 HDi 120 4x4
2.0 HDi 130
2.0 HDi 130 4x4
2.0 HDi 140
2.0 HDi 165
2007/01 - 9HH(DV6DUM) 90 hp 66 kW 1.6 L Diesel
9HM(DV6UC) 90 hp 66 kW 1.6 L Diesel
9HU(DV6UTED4) 90 hp 66 kW 1.6 L Diesel
AHY(DW10CE) 98 hp 72 kW 2 L Diesel
AHZ(DW10CD) 128 hp 94 kW 2 L Diesel
RFH(EW10A) 140 hp 103 kW 2 L Petrol
RFJ(EW10A) 140 hp 103 kW 2 L Petrol
RHH(DW10CTED4) 163 hp 120 kW 2 L Diesel
RHK(DW10UTED4) 120 hp 88 kW 2 L Diesel
RHR(DW10BTED4) 136 hp 100 kW 2 L Diesel
AWD / 4WD
Front wheel
MPV / Van / Minivan
TOYOTAPROACE
1.6 D-4D
2.0 D-4D
2013/06 - 3WZ-TV 90 hp 66 kW 1.6 L Diesel
4WZ-FHV 163 hp 120 kW 2 L Diesel
4WZ-FTV 128 hp 94 kW 2 L Diesel
Front wheel
LCV / Van / Cargo / Small truck
