BREMBO 09.A866.10 (09A86610) Brake Disc

BREMBO part 09.A866.10 (09A86610) Brake Disc

BREMBO 09.A866.10 (09A86610) Brake Disc

by BREMBO

Manufacturer Part Number: 09.A866.10 (09A86610)

Сharacteristics:
  • for article number: 09.A866.10
  • Brake Disc Type: Internally Vented
  • Diameter [mm]: 293
  • Brake Disc Thickness [mm]: 28
  • Minimum thickness [mm]: 26
  • Height [mm]: 47,2
  • Centering Diameter [mm]: 64,2
  • Number of Holes: 5
  • Tightening Torque [Nm]: 108
  • Supplementary Article/Info 2: with screws

Product Details

BrandBREMBO
BREMBO article (MPN)09.A866.10 (09A86610)
Vehicle subsystemBrake System

Original (OEM) part numbers

Suitable for HONDA vehicles

OE manufacturerOEM reference numbers
HONDA45251-SWW-G01, 45251T1EG00, 45251T1EG01

Aftermarket cross reference / interchange guide

The aftermarket competitive interchanges for BREMBO 09.A866.10 (09A86610) Brake Disc offered by A.B.S., ADVICS / SUMITOMO, ASHUKI, ATE, BLUE PRINT, BORG & BECK, BOSCH, Brake ENGINEERING, BREMSI, BSF, CIFAM, DELPHI, Dr!ve+, E.T.F., FENOX, FERODO, FOMAR, fri.tech., GIRLING, G.U.D, HELLA, HELLA PAGID, HERTH+BUSS JAKOPARTS, JURID, KAGER, KAVO PARTS, KAWE, KORTEX, LPR, MAGNETI MARELLI, MAPCO, METELLI, METZGER, MEYLE, MINTEX, MOTAQUIP, NIPPARTS, OPEN PARTS, OPTIMAL, PAGID, PATRON, PROTECHNIC, QUINTON HAZELL, REMSA, ROADHOUSE, ROTINGER, STELLOX, TEXTAR, TRUSTING, TRW, VAICO, WOKING, ZIMMERMANN manufacturers

ManufacturerReference numbers
A.B.S.17962
ADVICS / SUMITOMOC6F129
ASHUKIH03778
ATE24-0128-0217-1
BLUE PRINTADH243104
BORG & BECKBBD4639
BOSCH0986479456
Brake ENGINEERINGDI956788
BREMSIDBB820V
BSF11692V
CIFAM8001338C
DELPHIBG4250
Dr!ve+DP1010110627
E.T.F.195253
FENOXTB219308
FERODODDF18201, DDF1820C, DDF1820
FOMARFO2695
fri.tech.BD1349
GIRLING6048575
G.U.DGDB128217
HELLA8DD355115941
HELLA PAGID8DD355115941
HERTH+BUSS JAKOPARTSJ3304053
JURID562746JC
KAGER371212
KAVO PARTSBR-2261, BR2261C
KAWE6135810
KORTEXKD0144
LPRH1029V
MAGNETI MARELLI600000088520, 360406079100
MAPCO25210
METELLI231338C
METZGER61358.10, 6110584
MEYLE31155210034PD
MINTEXMDC2104
MOTAQUIPLVBD1316
NIPPARTSN3304050
OPEN PARTSBDR251620
OPTIMALBS-8286
PAGID54848
PATRONPBD4857
PROTECHNICPRD2712
QUINTON HAZELLBDC5802
REMSA6135810
ROADHOUSE6135810
ROTINGERRT4501T5, RT4501
STELLOX60201079VSX
TEXTAR92184803
TRUSTINGDF1349
TRWDF4857S
VAICOV2680020
WOKINGD6135810
ZIMMERMANN280317552, 280.3175.20

Vehicle fitment / BREMBO 09.A866.10 (09A86610) Brake Disc compatibility

This product fits the following models: HONDA CR-V III, HONDA CR-VIII, HONDA CR-V IV, etc. See all vehicles this product (BREMBO 09.A866.10 (09A86610)) fits below to verify fitment for your vehicle.
MakeModelVariantPeriodEngineDriveBody Style
HONDACR-V III
RE
2.0 i 4WD
2.2 i-CTDi 4WD
2.2 i-DTEC 4WD
2.4
2.4 4WD
2.4 i-Vtec 4WD
2.4 i-VTEC 4WD
2006/09 - K24A1 170 hp 125 kW 2.4 L Petrol
K24A 168 hp 124 kW 2.4 L Petrol
K24Z1 168 hp 124 kW 2.4 L Petrol
K24Z1 160 hp 118 kW 2.4 L Petrol
K24Z1 166 hp 122 kW 2.4 L Petrol
K24Z4 166 hp 122 kW 2.4 L Petrol
K24Z1 170 hp 125 kW 2.4 L Petrol
N22A2 140 hp 103 kW 2.2 L Diesel
N22B3 150 hp 110 kW 2.2 L Diesel
R20A2 150 hp 110 kW 2 L Petrol
AWD / 4WD
Front wheel
Full-size SUV / Compact SUV / Mid-size SUV / Compact SUV / Crossover SUV
HONDACR-VIII
RE
2.0 i 4WD
2.2 i-CTDi 4WD
2.2 i-DTEC 4WD
2.4
2.4 4WD
2.4 i-Vtec 4WD
2.4 i-VTEC 4WD
2006/09 - K24A1 170 hp 125 kW 2.4 L Petrol
K24A 168 hp 124 kW 2.4 L Petrol
K24Z1 168 hp 124 kW 2.4 L Petrol
K24Z1 160 hp 118 kW 2.4 L Petrol
K24Z1 166 hp 122 kW 2.4 L Petrol
K24Z4 166 hp 122 kW 2.4 L Petrol
K24Z1 170 hp 125 kW 2.4 L Petrol
N22A2 140 hp 103 kW 2.2 L Diesel
N22B3 150 hp 110 kW 2.2 L Diesel
R20A2 150 hp 110 kW 2 L Petrol
AWD / 4WD
Front wheel
Full-size SUV / Compact SUV / Mid-size SUV / Compact SUV / Crossover SUV
HONDACR-V IV
RE
RM
RE
1.6 i-DTEC
2.0
2.0 AWD
2012/01 - N16A1 120 hp 88 kW 1.6 L Diesel
R20A 150 hp 110 kW 2 L Petrol
R20A9 155 hp 114 kW 2 L Petrol
R20A9 155 hp 114 kW 2 L Petrol
AWD / 4WD
Front wheel
Full-size SUV / Compact SUV / Mid-size SUV / Compact SUV / Crossover SUV
