DELCO REMY 19024256 Starter

DELCO REMY 19024256 Starter

by DELCO REMY

Manufacturer Part Number: 19024256

Сharacteristics:

Version: Cat: JF Interch.
Flange Ø [mm]: 110
Voltage [V]: 24
Rated Power [kW]: 4
Rotation Direction: Clockwise rotation
Number of Teeth: 9
Material: Steel
Connector / Clamp: with 50(Jet) clamp
Number of Thread Bores: 0
Number of Bores: 3
Polarity: Grounded
Ground: G
Module: 3
Pressure Angle: 20
Switch Position: 30
SAE: Special
Offset: No
Mounting: Flange
Terminal 30: M10
Terminal 50: M4/L
A (mm): 110
B (mm): 265
C (mm): 27,5
D (mm): 185
E (mm): 75

Product Details

Brand	DELCO REMY
DELCO REMY article (MPN)	19024256
Vehicle subsystem	Starter System

Original (OEM) part numbers

Suitable for DAF, FIAT / LANCIA / ALFA, HONDA, IVECO, KHD, MAN, SCHMITZ CARGOBULL vehicles

OE manufacturer	OEM reference numbers
DAF	1516696R, 1516760R
FIAT / LANCIA / ALFA	4269114, 4716026, 4701920, 4744841, 42498212, 4232191, 77050562, 4187587, 77050262, 4699704, 4706008, 4737754, 4752403, 4807377, 4807378, 6706931, 77080561, 7740560, 77445430, 4172004, 4187590, 911330, 4716062, 4808379, 4231016, 4231018
HONDA	SM2510
IVECO	4737756, 2995104, 911330, 42498145, 611466632, 4807379, 04755111, 04807379, 611466612, 9124330, 4744841, 4755111
KHD	4716062, 04716062, 42498505, 1179470
MAN	500325137
SCHMITZ CARGOBULL	110518

Aftermarket cross reference / interchange guide

The aftermarket competitive interchanges for DELCO REMY 19024256 Starter offered by AES, AINDE, ALANKO, ARTEC, ATL Autotechnik, AUTOTEAM, BAUER PARTS, BOSCH, CASCO, CEVAM, CV PSH, DA SILVA, DELCO REMY, DRI, EAI, ELSTOCK, ERA, EUROTEC, FARCOM, FRIESEN, GKN-SPIDAN, HC-PARTS, HELLA, HERTH+BUSS ELPARTS, ISKRA, KAGER, LAUBER, LESTER (WAIglobal), LETRIKA, LUCAS ELECTRICAL, MAGNETI MARELLI, MESSMER, MONARK, PRESTOLITE ELECTRIC, SANDO, SNRA, STARLINE, TRISCAN, TRW, VALEO, WAI manufacturers

Manufacturer	Reference numbers
AES	12130235, IS9445, IS0490, IS0216, IS0492, IS9446
AINDE	CGB50228
ALANKO	440167
ARTEC	48212551
ATL Autotechnik	A11330
AUTOTEAM	SBO734A, SMM602, SMM602R
BAUER PARTS	S511022
BOSCH	0001368019, 0986011311, 0986011950, IF(R)24V3, 0001360015, 0986011333, 0001231011, EVR24V40KW, JD(R)24V4KW, 0986011161, IF(R)24V3, 2KW, JDR24V40KW, 1133, 0001360063, 0001368020, JF(R)24V2, 8PS, JF(R)24V2, 1113, 0986011330, 0986011160, 0001360043, 0986011331, 0001363101, 0001363111, 0986011310, IFR24V40KW
CASCO	CST10734AS, CST30602OS, CST30602GS
CEVAM	8665
CV PSH	501002093
DA SILVA	D020505, 020505
DELCO REMY	19024256, DRS1310, 91315000, 90015000, 318.019.094, DRS1330, 19024232, DRS1160, 19024272, 19024273, 318.028.094, 19024242, 318.018.094
DRI	318028094
EAI	353ST33
ELSTOCK	450228
ERA	220267
EUROTEC	11011330
FARCOM	103440, 103441, 103429
FRIESEN	8011160, 8011280, 88-11.330, 88-11.310, 8011330, 88-11.160, 8811060, 8010160
GKN-SPIDAN	1546, 1549, 1548
HC-PARTS	110518
HELLA	8EA726031001, 8EA726030001, 8EA726142-001, 726030-001, 726031-001, 726142-001
HERTH+BUSS ELPARTS	42011330, 42001246, 42368019
ISKRA	AZJ3-515, IS9446, AZJ3-131
KAGER	720046
LAUBER	280232, 220231
LESTER (WAIglobal)	18033R, 18033N, 18033
LETRIKA	11130225, AZJ3-515, 11130490, 11130146, AZJ3546, AZJ3133, 11130124, IS0704, AZF3542, 11130492, IS0490, IS0216, AZJ3520, IS0492, 11130216, AZJ3542, AZJ3-131
LUCAS ELECTRICAL	LRS930, LRS481, LRS841, LRS00841
MAGNETI MARELLI	MSN2045, 063216727, MT67AB, 063216741, MT67AA, MT67AC, 063216731010, 063216748, 063217226010, 063216731, MT67AD, 063216740, MSN213, 063224580, 63216703, MT67CB, 063216725, 063522310100, MT67CA, 063217201, MSN521, 063217225, 063216741010, MT67C, 63217226, MT67A, 943217226, 063216747, 063522310110, 063216726
MESSMER	220267
MONARK	081388020
PRESTOLITE ELECTRIC	860817, 858320Z, 857472Z, 858320, 859542, ZB2998201
SANDO	60306021, 60306024, 60107340
SNRA	PL9020
STARLINE	SX5093
TRISCAN	IS0490, LRS841, MT67CA, AZJ3131, 0001360063, 0986011330, AZJ3515, 11130124, 63216740, MT67CB, 450228, 8EA726142001, 0001368020, 22318028094, 11130490
TRW	LRS842, LRS00841, LRS00839, LRS837, LRS839, LRS00837, LRS841, LRS946
VALEO	455518, 455517
WAI	18033N, 18030N, 18033, 18033R, 66-9303

Vehicle fitment / DELCO REMY 19024256 Starter compatibility

This product fits the following models: IVECO EUROCARGO, IVECO M, IVECO PPA, IVECO ZETA, SCANIA 2 -, SCANIA 3 -, SCANIA 4 -, etc. See all vehicles this product (DELCO REMY 19024256) fits below to verify fitment for your vehicle.

Make	Model	Variant	Period	Engine	Drive	Body Style
IVECO	EUROCARGO	100 E 15 100 E 15 P 100 E 15 K 100 E 18 100 E 18 P 100 E 18 K 100 E 21 100 E 21 P 120 E 15 120 E 15 K 120 E 18 120 E 18 P 120 E 18 H 120 E 18 K 120 E 23 120 E 23 P 120 E 23 FP 120 E 23 H 130 E 15 130 E 15 K 130 E 18 130 E 18 K 130 E 23 135 E 18 W 135 E 18 WR 135 E 23 W 135 E 23 WR 150 E 15 150 E 15 K 150 E 18 150 E 18 P 150 E 18 K 150 E 23 150 E 23 P 150 E 23 FP 170 E 18 180 E 18 170 E 18 K 180 E 18 K 170 E 23 180 E 23 170 E 23 K 180 E 23 K 180 E 21 T 260 E 23 260 E 23 KE 260 E 23 T 280 E 23 T 60 E 10 60 E 12 60 E 14 60 E 14 P 60 E 14 K 65 E 10 65 E 10 K 65 E 12 65 E 12 P 65 E 12 K 65 E 14 65 E 14 P 65 E 14 K 75 E 12 75 E 12 P 75 E 14 75 E 14 P 75 E 14 K 75 E 15 75 E 15 P 80 E 15 75 E 15 K 80 E 15 80 E 15 P 80 E 15 K 80 E 18 80 E 18 P 18 E 80 FP 80 E 18 K 80 E 21 80 E 21 P 21 E 80 FP 80 E 21 80 E 21 P 80 E 21 FP 95 E 15 W 95 E 21 W	1991/01 -	8040.25B.4200 102 hp 75 kW L Diesel 8040.25X.4000 116 hp 85 kW L Diesel 8040.45.4000 136 hp 100 kW L Diesel 8040.45.4000 136 hp 100 kW L Diesel 8040.45.4180 136 hp 100 kW L Diesel 8060.25R.4200 143 hp 105 kW L Diesel 8060.25R.4280 143 hp 105 kW L Diesel 8060.25R.4200LTC 143 hp 105 kW L Diesel 8060.25R.4200LTC 143 hp 105 kW L Diesel 8060.45R.5000 143 hp 105 kW L Diesel 8060.45R.5001 143 hp 105 kW L Diesel 8060.45R.5003 143 hp 105 kW L Diesel 8060.45R.5005 143 hp 105 kW L Diesel 8060.25R.4280 143 hp 105 kW L Diesel 8060.25R.4750 143 hp 105 kW L Diesel 8060.25R.4755 143 hp 105 kW L Diesel 8060.25R.4760 143 hp 105 kW L Diesel 8060.25R.4764 143 hp 105 kW L Diesel 8060.45R.5050 143 hp 105 kW L Diesel 8060.45R.5051 143 hp 105 kW L Diesel 8060.25V.4000 177 hp 130 kW L Diesel 8060.25V.4000 177 hp 130 kW L Diesel 8060.25V.4080 177 hp 130 kW L Diesel 8060.25V.4000 177 hp 130 kW L Diesel 8060.25V.4080 177 hp 130 kW L Diesel 8060.45B 177 hp 130 kW L Diesel 8060.25V.4080 177 hp 130 kW L Diesel 8060.25V.4080 177 hp 130 kW L Diesel 8060.45B.5100 177 hp 130 kW L Diesel 8060.25V.4800 177 hp 130 kW L Diesel 8060.45.4100TCA 207 hp 152 kW L Diesel 8060.45.4100TCA 207 hp 152 kW L Diesel 8060.45.4180 207 hp 152 kW L Diesel 8060.45.4700 207 hp 152 kW L Diesel 8060.45.4702 207 hp 152 kW L Diesel 8060.45.4704 207 hp 152 kW L Diesel 8060.45.4706 207 hp 152 kW L Diesel 8060.45.4708 207 hp 152 kW L Diesel 8060.45.5250 207 hp 152 kW L Diesel 8060.45.5251 207 hp 152 kW L Diesel 8060.45.5255 207 hp 152 kW L Diesel 8060.45.6090 227 hp 167 kW L Diesel 8060.45S.6000 227 hp 167 kW L Diesel 8060.45.6090 227 hp 167 kW L Diesel 8060.45S.6800 227 hp 167 kW L Diesel 8060.45.6090 227 hp 167 kW L Diesel 8060.45S.6800 227 hp 167 kW L Diesel 8060.45S.7200 227 hp 167 kW L Diesel 8060.45S.6000 227 hp 167 kW L Diesel 8060.45S.6000 227 hp 167 kW L Diesel 8060.45STCA 227 hp 167 kW L Diesel 8060.45STCA 227 hp 167 kW L Diesel	4x2 4x4 6x2 6x4	Dump truck: 10т. Dump truck: 11.99т. Dump truck: 13.35т. Dump truck: 15т. Dump truck: 18т. Dump truck: 26т. Dump truck: 6.7т. Dump truck: 6т. Dump truck: 7.49т. Dump truck: 7.49т. Dump truck: 8т. Flatbed Truck/Chassis: 10t. Flatbed Truck/Chassis: 11.99t. Flatbed Truck/Chassis: 13.35t. Flatbed Truck/Chassis: 13.5t. Flatbed Truck/Chassis: 14t. Flatbed Truck/Chassis: 15t. Flatbed Truck/Chassis: 18t. Flatbed Truck/Chassis: 6.7t. Flatbed Truck/Chassis: 6t. Flatbed Truck/Chassis: 7.49t. Flatbed Truck/Chassis: 7.49t. Flatbed Truck/Chassis: 8t. Flatbed Truck/Chassis: 8t. Heavy-duty truck / Truck Tractor / Semitrailer Truck : 12.5t. Heavy-duty truck / Truck Tractor / Semitrailer Truck : 14.5t. Heavy-duty truck / Truck Tractor / Semitrailer Truck : 26t. Heavy-duty truck / Truck Tractor / Semitrailer Truck : 7.49t.
IVECO	M	115-17 115-17 H 135-17 135-17 H 135-17 T 145-17 159-17 175-17	1982/07 - 1992/12	8060.24.601 169 hp 124 kW L Diesel 8060.25.600 177 hp 130 kW L Diesel 8060.25.600 177 hp 130 kW L Diesel 8360.05.254 169 hp 124 kW L Diesel	4x2	Dump truck: 11.5т. Dump truck: 13.3т. Flatbed Truck/Chassis: 12t. Flatbed Truck/Chassis: 13.3t. Flatbed Truck/Chassis: 14.5t. Flatbed Truck/Chassis: 16t. Flatbed Truck/Chassis: 17.5t. Heavy-duty truck / Truck Tractor / Semitrailer Truck : 12.5t.
IVECO	PPA	159-17 H	1982/07 - 1986/09	8360.05.254 169 hp 124 kW L Diesel	4x2	Dump truck: 16т.
IVECO	ZETA	109-14 109-14 H 50-10 50-10 H 50-10 V 50-8 50-8 H 50-8 V 50-9 50-9 H 50-9 V 60-10 60-10 H 60-10 V 60-11 60-11 V 60-8 65-10 65-10 H 65-10 V 65-12 65-12 H 65-12 V 65-9 79-10 79-10 H 79-10 V 79-12 79-12 H 79-12 V 79-13 79-14 79-14 H 79-14 V 95-14 95-14 H A 60-9 A 70-12 A 70-14	1979/01 - 1992/12	8040.04.200 86 hp 63 kW L Diesel 8040.05.200 88 hp 65 kW L Diesel 8040.05.203 88 hp 65 kW L Diesel 8040.05.230 88 hp 65 kW L Diesel 8040.25.200 116 hp 85 kW L Diesel 8040.25.200 116 hp 85 kW L Diesel 8040.25.220 116 hp 85 kW L Diesel 8040.25.230R 101 hp 74 kW L Diesel 8060.04.060 131 hp 96 kW L Diesel 8060.04.660 131 hp 96 kW L Diesel 8060.04.660 135 hp 99 kW L Diesel 8060.05.280 137 hp 101 kW L Diesel 8060.04.669 135 hp 99 kW L Diesel 8060.04.689 135 hp 99 kW L Diesel 8060.05.289 137 hp 101 kW L Diesel 8060.05.246 137 hp 101 kW L Diesel 8060.05.285 137 hp 101 kW L Diesel 8340.04.200 101 hp 74 kW L Diesel 8340.04.250 101 hp 74 kW L Diesel 8340.04.200 101 hp 74 kW L Diesel 8340.04.250 101 hp 74 kW L Diesel 8340.04.300 101 hp 74 kW L Diesel 8340.04.350 101 hp 74 kW L Diesel 8340.04.200 101 hp 74 kW L Diesel 8340.04.250 101 hp 74 kW L Diesel 8340.04.300 101 hp 74 kW L Diesel 8340.04.362 101 hp 74 kW L Diesel 8340.04.200 101 hp 74 kW L Diesel 8340.04.300 101 hp 74 kW L Diesel 8340.05.200 114 hp 84 kW L Diesel	4x2	BUS: 5.99t. BUS: 7.1t. Dump truck: 10.9т. Dump truck: 5.3т. Dump truck: 5.4т. Dump truck: 5.99т. Dump truck: 5.99т. Flatbed Truck/Chassis: 5.99t. Light truck / Medium-duty truck: 5.99t. Dump truck: 6.7т. Dump truck: 7.49т. Dump truck: 8.1т. Dump truck: 7.49т. Dump truck: 8т. Dump truck: 7.49т. Flatbed Truck/Chassis: 7.49t. Light truck / Medium-duty truck: 7.49t. Dump truck: 9.4т. Flatbed Truck/Chassis: 10.9t. Flatbed Truck/Chassis: 5.3t. Flatbed Truck/Chassis: 5.4t. Flatbed Truck/Chassis: 5.99t. Flatbed Truck/Chassis: 6.7t. Flatbed Truck/Chassis: 7.49t. Flatbed Truck/Chassis: 8.1t. Flatbed Truck/Chassis: 7.49t. Flatbed Truck/Chassis: 8t. Flatbed Truck/Chassis: 9.4t. Light truck / Medium-duty truck: 5.3t. Light truck / Medium-duty truck: 5.4t. Light truck / Medium-duty truck: 5.99t. Light truck / Medium-duty truck: 6.7t. Light truck / Medium-duty truck: 7.49t. Light truck / Medium-duty truck: 8.1t. Light truck / Medium-duty truck: 7.49t. Light truck / Medium-duty truck: 8t.
SCANIA	2 -	82 H/210 82 M/190 82 M/210 92 H/245 92 H/275 92 M/245 92 M/275	1981/01 - 1988/12	DS8.01 211 hp 155 kW L Diesel DS8.01B10 211 hp 155 kW L Diesel DS8.01B11 211 hp 155 kW L Diesel DS8.01B12 211 hp 155 kW L Diesel DS8.05 211 hp 155 kW L Diesel DS8 211 hp 155 kW L Diesel DS8.06 190 hp 140 kW L Diesel DS9.01 245 hp 180 kW L Diesel DSC9.01 275 hp 202 kW L Diesel	4x2 6x2 4x2 6x4 6x2 4x2	Flatbed Truck/Chassis: 16t. Flatbed Truck/Chassis: 16t. Flatbed Truck/Chassis: 17t. Flatbed Truck/Chassis: 16t. Flatbed Truck/Chassis: 17t. Flatbed Truck/Chassis: 22t. Flatbed Truck/Chassis: 23.4t. Heavy-duty truck / Truck Tractor / Semitrailer Truck : 16t. Heavy-duty truck / Truck Tractor / Semitrailer Truck : 17t. Flatbed Truck/Chassis: 16t. Flatbed Truck/Chassis: 22t. Flatbed Truck/Chassis: 16t. Flatbed Truck/Chassis: 22t. Heavy-duty truck / Truck Tractor / Semitrailer Truck : 16t.
SCANIA	3 -	93 H/220 93 H/250 93 H/280 93 M/210 93 M/220 93 M/230 93 M/250 93 M/280 T 93 H/250 T 93 H/280	1988/03 - 1996/12	DS9.05 252 hp 185 kW L Diesel DSC9.07 252 hp 185 kW L Diesel DS9.06 227 hp 167 kW L Diesel DS9.08 211 hp 155 kW L Diesel DSC9.02 282 hp 207 kW L Diesel DSC9.08 282 hp 207 kW L Diesel DSC9.10 220 hp 162 kW L Diesel	4x2 6x2/2/4 4x2 6x2 4x2 6x4 4x2 6x4 4x2 4x4 6x4 6x2/2/4 4x2 4x4 6x4 6x2/2/4 6x2 4x2	Concrete mixer: 26t. Dump truck: 17т. Dump truck: 18т. Dump truck: 24т. Dump truck: 26т. Flatbed Truck/Chassis: 18t. Flatbed Truck/Chassis: 26t. Concrete mixer: 26t. Dump truck: 18т. Dump truck: 26т. Flatbed Truck/Chassis: 17t. Flatbed Truck/Chassis: 18t. Flatbed Truck/Chassis: 24t. Flatbed Truck/Chassis: 25t. Flatbed Truck/Chassis: 26t. Heavy-duty truck / Truck Tractor / Semitrailer Truck : 17t. Heavy-duty truck / Truck Tractor / Semitrailer Truck : 18t. Concrete mixer: 26t. Dump truck: 18т. Dump truck: 26т. Flatbed Truck/Chassis: 18t. Flatbed Truck/Chassis: 26t. Concrete mixer: 26t. Dump truck: 26т. Flatbed Truck/Chassis: 17t. Flatbed Truck/Chassis: 18t. Flatbed Truck/Chassis: 24t. Flatbed Truck/Chassis: 25t. Flatbed Truck/Chassis: 26t. Heavy-duty truck / Truck Tractor / Semitrailer Truck : 17t. Heavy-duty truck / Truck Tractor / Semitrailer Truck : 18t. Dump truck: 26т. Flatbed Truck/Chassis: 18t. Flatbed Truck/Chassis: 26t. Flatbed Truck/Chassis: 17t. Flatbed Truck/Chassis: 17t. Flatbed Truck/Chassis: 18t. Flatbed Truck/Chassis: 24t. Flatbed Truck/Chassis: 25t. Heavy-duty truck / Truck Tractor / Semitrailer Truck : 17t. Heavy-duty truck / Truck Tractor / Semitrailer Truck : 18t. Flatbed Truck/Chassis: 18t. Flatbed Truck/Chassis: 18t. Flatbed Truck/Chassis: 25t. Heavy-duty truck / Truck Tractor / Semitrailer Truck : 18t.
SCANIA	4 -	94 C/260 94 C/310 94 D/220 94 D/260 94 D/310 94 G/220 94 G/260 94 G/310 94 L/310	1996/08 -	DC9.02 260 hp 191 kW L Diesel DC9.05 260 hp 191 kW L Diesel DSC9.12 260 hp 191 kW L Diesel DC9.02 260 hp 191 kW L Diesel DSC9.12 260 hp 191 kW L Diesel DSC9.11 220 hp 162 kW L Diesel DSC9.13 310 hp 228 kW L Diesel DSC9.15 310 hp 228 kW L Diesel	6x2/2/4 4x2 6x4 6x2/2/4 4x2 6x4 6x2 6x6 4x2 8x4/4 4x4 6x4 6x6 4x2 4x4 8x4/4	Dump truck: 18т. Dump truck: 26т. Dump truck: 32т. Flatbed Truck/Chassis: 18t. Flatbed Truck/Chassis: 26t. Dump truck: 18т. Dump truck: 26т. Dump truck: 32т. Flatbed Truck/Chassis: 18t. Flatbed Truck/Chassis: 26t. Heavy-duty truck / Truck Tractor / Semitrailer Truck : 18t. Flatbed Truck/Chassis: 18t. Flatbed Truck/Chassis: 25t. Heavy-duty truck / Truck Tractor / Semitrailer Truck : 18t. Flatbed Truck/Chassis: 18t. Flatbed Truck/Chassis: 26t. Heavy-duty truck / Truck Tractor / Semitrailer Truck : 18t. Flatbed Truck/Chassis: 18t. Flatbed Truck/Chassis: 26t. Heavy-duty truck / Truck Tractor / Semitrailer Truck : 18t. Heavy-duty truck / Truck Tractor / Semitrailer Truck : 26t.
