DELPHI BG3236 Brake Disc

DELPHI part BG3236 Brake Disc

DELPHI BG3236 Brake Disc

by DELPHI

Manufacturer Part Number: BG3236

Сharacteristics:
  • Diameter [mm]: 276
  • Brake Disc Type: Vented
  • Brake Disc Thickness [mm]: 22
  • Minimum thickness [mm]: 19
  • Number of Holes: 5
  • Centering Diameter [mm]: 85
  • Mounting Type: Bolted
  • Depth [mm]: 77

Product Details

BrandDELPHI
DELPHI article (MPN)BG3236
Vehicle subsystemBrake System

Original (OEM) part numbers

Suitable for FIAT / LANCIA / ALFA, MERCEDES-BENZ, VAG vehicles

OE manufacturerOEM reference numbers
FIAT / LANCIA / ALFABT8248
MERCEDES-BENZ9024210912, 9024216012, 9024210712, A9024210912, A9024216012, A9O2421O712, A9O24216O12, A9O2421O312, A9O2421O412, A9O2421O612, A9O2421O912, 9024210312, 9024210412, 9024210612, 9014210312, A9024210712, 9O2421O712, 9O24216O12, 9O2421O312, 9O2421O412, 9O2421O612, 9O2421O912, A9024210312, A9024210412, A9024210612
VAG2D0615301D, 2D0615301A, 2DO6153O1D, 2DO6153O1A, 2D0615301B, 2DO6153O1B, 2D0615301C, 2DO6153O1C

Aftermarket cross reference / interchange guide

The aftermarket competitive interchanges for DELPHI BG3236 Brake Disc offered by A.B.S., ACDelco, AP, APEC braking, ATE, AUTOMEGA, BARUM, BENDIX, BERAL, BORG & BECK, BOSCH, Brake ENGINEERING, BRECK, BREMBO, BREMSI, BSF, CAR, CASALS, CEI, CIFAM, COMLINE, Dr!ve+, DURON, E.T.F., EUROBRAKE, FEBI BILSTEIN, FENOX, FERODO, FOMAR, FREMAX, fri.tech., FTE, GALFER, GIRLING, GRAF, G.U.D, HANS PRIES, HELLA, HELLA PAGID, ICER, JP GROUP, JURID, KAGER, KAMOKA, KEY PARTS, KLAXCAR FRANCE, KRAFT, LEMFÖRDER, LPR, LUCAS ELECTRICAL, MAGNETI MARELLI, MENSAN, METELLI, METZGER, MEYLE, MGA, MINTEX, MOTAQUIP, NATIONAL, NIBK, NK, OPEN PARTS, OPTIMAL, PAGID, PATRON, PEX, PILENGA, PROFIT, QUINTON HAZELL, R BRAKE, REMSA, ROADHOUSE, ROTINGER, ROULUNDS BRAKING, SASIC, sbs, STELLOX, SWAG, TEMPLIN, TEXTAR, TRUSTING, TRW, VAICO, VALEO, WAGNER LOCKHEED, WINNARD, WOKING, ZIMMERMANN manufacturers

ManufacturerReference numbers
A.B.S.16453
ACDelcoAC2331D
AP24867E
APEC brakingDSK771
ATE24.O122-O161.1, 24.0322-0161.1, 422161, 24.0122-0161.1, 24-0122-0161-1-01, 24-O122-O161-1-O1
AUTOMEGA3061503012D0D
BARUMBAR22161
BENDIX56776OB, 562O86B, 562086, 562O86, 562086B, 569122B, 567760B
BERALBCR153A, BCR228A
BORG & BECKBBD5134
BOSCH0986479075, O986478849, O986479O75, 0986478849
Brake ENGINEERINGDI955555, 955555, DI956329
BRECKBR325VA100
BREMBO09.7314.14, O9.9618.14, O9.7314.2O, 09.9618.24, 09.9618.14, O9.6916.1O, 09.7314.24, DP50010, O9.7314.24, O9.7314.1O, DP5OO1O, 09.7314.10, 09.6916.10, O9.9618.24, 09.7314.20, O9.7314.14
BREMSIDBB013V, DBA859V
BSF11224V
CAR142.432
CASALS55147
CEI215063
CIFAM8OO-418, 800-418
COMLINEADC161OV, ADC1610V
Dr!ve+DP1010110735
DURONDCR153A
E.T.F.19-0181, 190186, 19-O181
EUROBRAKE5815203397
FEBI BILSTEIN22857, 07517, O7517
FENOXTB217282
FERODOFCR153A, FCR228A
FOMARFO2331
FREMAXBD-0186, BD-0181, BD-O186, BD-O181
fri.tech.DF1O45, DF1045, BD0506
FTEBS4544B, BS4544
GALFERB1G22201611
GIRLING6O279O1, 6O43213, 6027901, 6043213
GRAFDF29418
G.U.DGDB122161
HANS PRIES107687
HELLA8DD355111001, 8DD355110991
HELLA PAGID8DD355111001, 8DD355110991
ICER78BD01861, 78BD01811
JP GROUP1163101909, 1163101900
JURID567760J, 56776OJ, 561965J, 569122J
KAGER37-O3OO, 37-0300
KAMOKA103306
KEY PARTSKBD5134
KLAXCAR FRANCE25871Z
KRAFT6041410
LEMFÖRDER3123301, 22220, 3O868O1, 3086801, 3O868, 2222O, 30868, 2222OO3, 2222003
LPRM2561V
LUCAS ELECTRICALDF2790
MAGNETI MARELLI360406085700, 35361283724O, 353612837240, 431602041000
MENSAN030254
METELLI23-0418, 23-O418
METZGER646110, 6110142
MEYLE0155212038, 0155212032, O155212O32
MGAD1466, D1218
MINTEXMDC1037, MDK0066, MDC1O37
MOTAQUIPVBD822
NATIONALNBD79O, NBD790
NIBKRN1388
NK203397, 2O3397, 2O3334, 313397, 203334
OPEN PARTSBDA170620
OPTIMALBS-7290, BS-4611
PAGID54315, 52143
PATRONPBD2790
PEX14.O334, 14.0334
PILENGAV282
PROFIT50101013
QUINTON HAZELLBDC4544HC, BSF4544, BDC4544P, BDC4547, BDC4544
R BRAKE78RBD10186, 78RBD10181
REMSA67O6.2O, 6706.20, 6461.1O, 6461.10
ROADHOUSE6461.10, 6461.1O
ROTINGERRT2539T5, RT2539
ROULUNDS BRAKINGD2331
SASIC9004846J, 6106101
sbs1815313397, 18152O3334, 1815203334, 1815203397
STELLOX60203334VSX
SWAG10922857, 10907517
TEMPLIN0311082680, 0311082685
TEXTAR982000735, 92131503, 921315OO, 92131500, 92131505, 982OOO735
TRUSTINGDF506, DF1O45, DF1045
TRWDF2790S, DF279OS, DF279O, DF2790, RCDI01590
VAICOV1O-8OO13, V3O-8OO53, V30-80053, V10-80013
VALEO187121, 186774, 186553
WAGNER LOCKHEEDWGR62281
WINNARDMNE1061
WOKINGP6461.1O, P6461.10
ZIMMERMANN400.6470.00, 4OO.647O.OO, 4OO.1439.OO, 4OO.1441.OO, 400.6470.20, 400.1439.00, 400.1441.00

Vehicle fitment / DELPHI BG3236 Brake Disc compatibility

This product fits the following models: MERCEDES-BENZ SPRINTER 2-T, MERCEDES-BENZ SPRINTER 3-T, MERCEDES-BENZ SPRINTER 4-T, NISSAN BLUEBIRD, VW LT 28-35 II, VW LT 28-46 II, VW LTII, etc. See all vehicles this product (DELPHI BG3236) fits below to verify fitment for your vehicle.
MakeModelVariantPeriodEngineDriveBody Style
MERCEDES-BENZSPRINTER 2-T
901
902
208 CDI
208 D
210 D
211 CDI
212 D
213 CDI
214
216 CDI
1995/01 - 2006/05M111.979 143 hp 105 kW 2.3 L Petrol
M111.979 143 hp 105 kW 2.3 L Petrol
M111.984 143 hp 105 kW 2.3 L Petrol
OM601.943 79 hp 58 kW 2.3 L Diesel
OM601.943 79 hp 58 kW 2.3 L Diesel
OM601.943 82 hp 60 kW 2.3 L Diesel
OM602.980 102 hp 75 kW 2.9 L Diesel
OM602.980 122 hp 90 kW 2.9 L Diesel
OM611.981 109 hp 80 kW 2.1 L Diesel
OM611.981 129 hp 95 kW 2.1 L Diesel
OM611.987 82 hp 60 kW 2.1 L Diesel
OM612.981 156 hp 115 kW 2.7 L Diesel
Rear wheel
LCV / Van / Cargo
Passenger Van / Wagon / Minibus
With flatbed/undercarriage
MERCEDES-BENZSPRINTER 3-T
903
308 CDI
308 D
308 D 2.3
310 D
310 D 2.9
310 D 4x4
311 CDI
311 CDI 4x4
312 D 2.9
312 D 2.9 4x4
313 CDI
313 CDI 4x4
314
316 CDI
316 CDI 4x4

903.371
903.372
903.373
1995/02 - 2006/05M111.979 143 hp 105 kW 2.3 L Petrol
M111.984 143 hp 105 kW 2.3 L Petrol
M111.984 143 hp 105 kW 2.3 L Petrol
OM601.943 79 hp 58 kW 2.3 L Diesel
OM601.943 79 hp 58 kW 2.3 L Diesel
OM601.943 82 hp 60 kW 2.3 L Diesel
OM602.980 102 hp 75 kW 2.9 L Diesel
OM602.980 122 hp 90 kW 2.9 L Diesel
OM611.981 109 hp 80 kW 2.1 L Diesel
OM611.981 109 hp 80 kW 2.1 L Diesel
OM611.981 129 hp 95 kW 2.1 L Diesel
OM611.981 129 hp 95 kW 2.1 L Diesel
OM611.987 82 hp 60 kW 2.1 L Diesel
OM612.981 156 hp 115 kW 2.7 L Diesel
AWD / 4WD
Rear wheel
LCV / Van / Cargo
Passenger Van / Wagon / Minibus
With flatbed/undercarriage
MERCEDES-BENZSPRINTER 4-T
904
408 CDI
408 D
410 D
410 D 4x4
411 CDI
411 CDI 4x4
412 D
412 D 4x4
413 CDI
413 CDI 4x4
414
414 4x4
416 CDI
416 CDI 4x4
1996/02 - 2006/05M111.979 143 hp 105 kW 2.3 L Petrol
OM601.943 79 hp 58 kW 2.3 L Diesel
OM602.980 102 hp 75 kW 2.9 L Diesel
OM602.980 115 hp 85 kW 2.9 L Diesel
OM602.980 122 hp 90 kW 2.9 L Diesel
OM611.981 109 hp 80 kW 2.1 L Diesel
OM611.981 129 hp 95 kW 2.1 L Diesel
OM611.987 82 hp 60 kW 2.1 L Diesel
OM612.981 156 hp 115 kW 2.7 L Diesel
AWD / 4WD
Rear wheel
LCV / Van / Cargo
Passenger Van / Wagon / Minibus
With flatbed/undercarriage
NISSANBLUEBIRD
910
W910
1.8 Turbo
2.0 D
2.0 i
2.0 TD
1980/01 - 1984/05135 hp 99 kW 1.8 L Petrol
LD20 60 hp 44 kW 2 L Diesel
LD20T 78 hp 57 kW 2 L Diesel
Z20E 109 hp 80 kW 2 L Petrol
Rear wheel
Estate / Turnier / Vario / Wagon
Sedan / Saloon
VWLT 28-35 II
2DB
2DE
2DK
2.3
2.5 TDI
2.8 TDI
1996/05 - 2006/07AGK 125 hp 92 kW 2.8 L Diesel
ATA 131 hp 96 kW 2.8 L Diesel
AUH 158 hp 116 kW 2.8 L Diesel
BCQ 158 hp 116 kW 2.8 L Diesel
AGL 143 hp 105 kW 2.3 L Petrol
AHD 102 hp 75 kW 2.5 L Diesel
ANJ 109 hp 80 kW 2.5 L Diesel
APA 90 hp 66 kW 2.5 L Diesel
AVR 109 hp 80 kW 2.5 L Diesel
BBE 83 hp 61 kW 2.5 L Diesel
BBF 95 hp 70 kW 2.5 L Diesel
Rear wheel
Passenger Van / Wagon / Minibus
VWLT 28-46 II
2DA
2DD
2DH
2DC
2DF
2
2.3
2.5 SDI
2.5 TDI
2.8 TDI
1996/05 - 2006/07AGK 125 hp 92 kW 2.8 L Diesel
ATA 130 hp 96 kW 2.8 L Diesel
AUH 158 hp 116 kW 2.8 L Diesel
BCQ 158 hp 116 kW 2.8 L Diesel
AGL 143 hp 105 kW 2.3 L Petrol
AGX 75 hp 55 kW 2.5 L Diesel
AHD 102 hp 75 kW 2.5 L Diesel
ANJ 109 hp 80 kW 2.5 L Diesel
APA 90 hp 66 kW 2.5 L Diesel
AVR 109 hp 80 kW 2.5 L Diesel
BBE 83 hp 61 kW 2.5 L Diesel
BBF 95 hp 70 kW 2.5 L Diesel
Rear wheel
LCV / Van / Cargo
With flatbed/undercarriage
VWLTII
2DA
2DD
2DH
2DB
2DE
2DK
2DC
2DF
2DG

2.3
2.5 SDI
2.5 TDI
2.8 TDI
1996/05 - 2006/07AGK 125 hp 92 kW 2.8 L Diesel
ATA 130 hp 96 kW 2.8 L Diesel
AUH 158 hp 116 kW 2.8 L Diesel
BCQ 158 hp 116 kW 2.8 L Diesel
AGK 125 hp 92 kW 2.8 L Diesel
ATA 131 hp 96 kW 2.8 L Diesel
AUH 158 hp 116 kW 2.8 L Diesel
BCQ 158 hp 116 kW 2.8 L Diesel
AGL 143 hp 105 kW 2.3 L Petrol
AGX 75 hp 55 kW 2.5 L Diesel
AHD 102 hp 75 kW 2.5 L Diesel
ANJ 109 hp 80 kW 2.5 L Diesel
APA 90 hp 66 kW 2.5 L Diesel
AVR 109 hp 80 kW 2.5 L Diesel
BBE 83 hp 61 kW 2.5 L Diesel
BBF 95 hp 70 kW 2.5 L Diesel
Rear wheel
LCV / Van / Cargo
Passenger Van / Wagon / Minibus
With flatbed/undercarriage
