DELPHI BG4032 Brake Disc

DELPHI part BG4032 Brake Disc

DELPHI BG4032 Brake Disc

by DELPHI

Manufacturer Part Number: BG4032

Сharacteristics:
  • Diameter [mm]: 300
  • Brake Disc Type: Vented
  • Brake Disc Thickness [mm]: 28
  • Minimum thickness [mm]: 25
  • Number of Holes: 6
  • Centering Diameter [mm]: 85
  • Mounting Type: Bolted
  • Depth [mm]: 68,5

Product Details

BrandDELPHI
DELPHI article (MPN)BG4032
Vehicle subsystemBrake System

Original (OEM) part numbers

Suitable for FIAT / LANCIA / ALFA, MERCEDES-BENZ, VAG vehicles

OE manufacturerOEM reference numbers
FIAT / LANCIA / ALFABR8738
MERCEDES-BENZ9064210112, 9064210212, A9064210012, 9O6421OO12, 9O6421O112, 9064210012, A9064210112, A9064210212, A9O6421OO12, A9O6421O112, A9O6421O212, 9O6421O212
VAG2EO6153O1, 2E0615301

Aftermarket cross reference / interchange guide

The aftermarket competitive interchanges for DELPHI BG4032 Brake Disc offered by A.B.S., APEC braking, ATE, BENDIX, BERAL, BORG & BECK, BOSCH, Brake ENGINEERING, BRECK, BREMBO, BREMSI, BSF, CASALS, CIFAM, COMLINE, DENCKERMANN, DON, Dr!ve+, E.T.F., EUROBRAKE, FEBI BILSTEIN, FENOX, FERODO, FOMAR, fri.tech., FTE, GALFER, GIRLING, G.U.D, HANS PRIES, HELLA, HELLA PAGID, ICER, JP GROUP, JURATEK, JURID, KAGER, KAMOKA, KEY PARTS, KRAFT, LEMFÖRDER, LPR, MENSAN, METELLI, METZGER, MEYLE, MGA, MINTEX, MOTAQUIP, NATIONAL, NIBK, NK, OPEN PARTS, OPTIMAL, PAGID, PATRON, PROTECHNIC, QUINTON HAZELL, R BRAKE, ROADHOUSE, ROTINGER, SASIC, sbs, SWAG, TEMPLIN, TEXTAR, TRUSTING, TRW, VAICO, WAGNER LOCKHEED, WOKING, ZIMMERMANN manufacturers

ManufacturerReference numbers
A.B.S.17730
APEC brakingDSK2448
ATE24.0128-0203.1
BENDIX569136B, 562485B
BERALBCR310A
BORG & BECKBBD4570
BOSCH0986479R78, 0986479294, O986479294
Brake ENGINEERINGDI956432, DI956432S
BRECKBR352VA100
BREMBO09.9508.14, O9.95O8.1O, O9.95O8.14, 09.9508.10
BREMSIDB0310V
BSF11498V
CASALS55495
CIFAM800881
COMLINEADC164OV, ADC1640V
DENCKERMANNB130452
DONCVD655
Dr!ve+DP1010110497
E.T.F.192114
EUROBRAKE58152047123
FEBI BILSTEIN27698
FENOXTB219352
FERODOFCR310A, FCR31OA
FOMARFO2701
fri.tech.BD1046, DF1O46, DF1046
FTEBS7130B, BS7130
GALFERB1G22802031
GIRLING6048225
G.U.DGDB128203
HANS PRIES111652
HELLA8DD355123162, 8DD355117-621
HELLA PAGID8DD355123162, 8DD355117621
ICER78BD01902
JP GROUP1163107000, 1163107009
JURATEKMER137
JURID569136J
KAGER371191
KAMOKA103143, 1032092
KEY PARTSKBD4570
KRAFT6041414
LEMFÖRDER31214, 31214O1, 3121401
LPRM2042V, M2O42V
MENSAN030205
METELLI230881
METZGER6110151
MEYLEO1552121O1, 0155212101
MGAD1622
MINTEXMDC1771
MOTAQUIPLVBD1217Z
NATIONALNBD1421
NIBKRN1382
NK2047123, 3147123, 203396, 2O47123
OPEN PARTSBDA232420
OPTIMALBS-8166
PAGID59432, 54932
PATRONPBD4822
PROTECHNICPRD2326
QUINTON HAZELLBDC5552
R BRAKE78RBD20190
ROADHOUSE61O34.1O, 61034.10
ROTINGERRT20455, RT20455T5
SASIC6106070
sbs18152O47123, 18153147123, 18152047123, 1815203396
SWAG10927698
TEMPLIN031101926410, 0311082750
TEXTAR93143203, 982OO1432, 93143205, 93143200, 982001432
TRUSTINGDF1046, DF1O46
TRWDF4822S
VAICOV10-80087, V1O-8OO87
WAGNER LOCKHEEDWGR63101
WOKINGP61034.10
ZIMMERMANN4OO.6476.OO, 400647620, 400.6476.00

Vehicle fitment / DELPHI BG4032 Brake Disc compatibility

This product fits the following models: MERCEDES-BENZ SPRINTER 3,5-T, MERCEDES-BENZ SPRINTER 3-T, MERCEDES-BENZ SPRINTER 4,6-T, MERCEDES-BENZ SPRINTER 5-T, VW CRAFTER 30-35, VW CRAFTER 30-50, etc. See all vehicles this product (DELPHI BG4032) fits below to verify fitment for your vehicle.
MakeModelVariantPeriodEngineDriveBody Style
MERCEDES-BENZSPRINTER 3,5-T
906
2500 CDI
309 CDI
310 CDI
311 CDI
311 CDI 4x4
313 CDI
315 CDI
315 CDI 4x4
316
316 CDI
316 CDI 4x4
316 NGT
318 CDI
318 CDI 4x4
319 CDI / BlueTEC
324
906.131
906.133
906.135
906.231...
906.131
906.133
906.135
906.231
906.233...
906.133
906.135
906.233
906.235
906.631
906.633
906.635
906.637
906.633
906.635
906.633
906.635
906.637
906.663
906.635
906.731
906.733
906.735
906.733
906.735
2006/06 - M271.951 156 hp 115 kW 1.8 L Petrol
M272.979 258 hp 190 kW 3.5 L Petrol
OM642.896 184 hp 135 kW 3 L Diesel
OM642.992 184 hp 135 kW 3 L Diesel
OM642.993 184 hp 135 kW 3 L Diesel
OM642.896 190 hp 140 kW 3 L Diesel
OM642.898 190 hp 140 kW 3 L Diesel
OM642.992 190 hp 140 kW 3 L Diesel
OM646.984 88 hp 65 kW 2.1 L Diesel
OM646.985 109 hp 80 kW 2.1 L Diesel
OM646.986 129 hp 95 kW 2.1 L Diesel
OM646.989 150 hp 110 kW 2.1 L Diesel
OM646.990 150 hp 110 kW 2.1 L Diesel
OM651.955 163 hp 120 kW 2.1 L Diesel
OM651.957 163 hp 120 kW 2.1 L Diesel
OM651.955 95 hp 70 kW 2.1 L Diesel
OM651.955 95 hp 70 kW 2.1 L Diesel
OM651.956 95 hp 70 kW 2.1 L Diesel
OM651.957 163 hp 120 kW 2.1 L Diesel
AWD / 4WD
Rear wheel
LCV / Van / Cargo
Passenger Van / Wagon / Minibus
With flatbed/undercarriage
MERCEDES-BENZSPRINTER 3-T
906
209 CDI
210 CDI
211 CDI
213 CDI
215 CDI
216
216 CDI
218 CDI
219 CDI / BlueTEC
224
906.111
906.113
906.211
906.213
906.113
906.213
906.611
906.613
906.613
906.711
906.713
906.713
2006/06 - M271.951 156 hp 115 kW 1.8 L Petrol
M272.979 258 hp 190 kW 3.5 L Petrol
OM642.896 184 hp 135 kW 3 L Diesel
OM642.992 184 hp 135 kW 3 L Diesel
OM642.896 184 hp 135 kW 3 L Diesel
OM642.992 184 hp 135 kW 3 L Diesel
OM642.993 184 hp 135 kW 3 L Diesel
OM642.896 190 hp 140 kW 3 L Diesel
OM642.992 190 hp 140 kW 3 L Diesel
OM646.984 88 hp 65 kW 2.1 L Diesel
OM646.985 109 hp 80 kW 2.1 L Diesel
OM646.986 129 hp 95 kW 2.1 L Diesel
OM646.986 129 hp 95 kW 2.1 L Diesel
OM651.956 129 hp 95 kW 2.1 L Diesel
OM646.986 150 hp 110 kW 2.1 L Diesel
OM646.989 150 hp 110 kW 2.1 L Diesel
OM646.990 150 hp 110 kW 2.1 L Diesel
OM646.989 150 hp 110 kW 2.1 L Diesel
OM646.990 150 hp 110 kW 2.1 L Diesel
OM651.955 163 hp 120 kW 2.1 L Diesel
OM651.957 163 hp 120 kW 2.1 L Diesel
OM651.955 95 hp 70 kW 2.1 L Diesel
OM651.957 163 hp 120 kW 2.1 L Diesel
Rear wheel
LCV / Van / Cargo
Passenger Van / Wagon / Minibus
With flatbed/undercarriage
MERCEDES-BENZSPRINTER 4,6-T
906
413 CDI
415 CDI
416 CDI
418 CDI
419 CDI
424
906.153
906.155
906.253
906.255
906.653
906.655
906.657
906.655
906.657
906.653
2006/06 - M272.979 258 hp 190 kW 3.5 L Petrol
OM642.896 184 hp 135 kW 3 L Diesel
OM642.992 184 hp 135 kW 3 L Diesel
OM642.993 184 hp 135 kW 3 L Diesel
OM642.896 190 hp 140 kW 3 L Diesel
OM642.898 190 hp 140 kW 3 L Diesel
OM642.992 190 hp 140 kW 3 L Diesel
OM642.992 190 hp 140 kW 3 L Diesel
OM646.986 129 hp 95 kW 2.1 L Diesel
OM646.989 150 hp 110 kW 2.1 L Diesel
OM646.990 150 hp 110 kW 2.1 L Diesel
OM651.957 163 hp 120 kW 2.1 L Diesel
Rear wheel
LCV / Van / Cargo
With flatbed/undercarriage
MERCEDES-BENZSPRINTER 5-T
906
3500
509 CDI
510 CDI
511 CDI
513 CDI
515 CDI
516
516 CDI
516 NGT
518 CDI
519 CDI / BlueTEC
524
906.135
906.155
906.253
906.255
906.153
906.155
906.253
906.255
906.653
906.655
906.657
2006/06 - M271.951 156 hp 115 kW 1.8 L Petrol
M272.979 258 hp 190 kW 3.5 L Petrol
OM642.896 184 hp 135 kW 3 L Diesel
OM642.992 184 hp 135 kW 3 L Diesel
OM642.993 184 hp 135 kW 3 L Diesel
OM642.896 190 hp 140 kW 3 L Diesel
OM642.898 190 hp 140 kW 3 L Diesel
OM642.992 190 hp 140 kW 3 L Diesel
OM646.984 88 hp 65 kW 2.1 L Diesel
OM646.985 109 hp 80 kW 2.1 L Diesel
OM646.986 129 hp 95 kW 2.1 L Diesel
OM646.986 129 hp 95 kW 2.1 L Diesel
OM651.956 129 hp 95 kW 2.1 L Diesel
OM646.986 150 hp 110 kW 2.1 L Diesel
OM646.989 150 hp 110 kW 2.1 L Diesel
OM646.990 150 hp 110 kW 2.1 L Diesel
OM646.989 150 hp 110 kW 2.1 L Diesel
OM646.990 150 hp 110 kW 2.1 L Diesel
OM651.955 163 hp 120 kW 2.1 L Diesel
OM651.957 163 hp 120 kW 2.1 L Diesel
OM651.955 95 hp 70 kW 2.1 L Diesel
Rear wheel
LCV / Van / Cargo
With flatbed/undercarriage
VWCRAFTER 30-35
2E
2.5 TDI
2006/04 - BJJ 88 hp 65 kW 2.5 L Diesel
BJK 109 hp 80 kW 2.5 L Diesel
BJL 136 hp 100 kW 2.5 L Diesel
BJM 163 hp 120 kW 2.5 L Diesel
CEBA 88 hp 65 kW 2.5 L Diesel
CEBB 109 hp 80 kW 2.5 L Diesel
CECA 136 hp 100 kW 2.5 L Diesel
CECB 163 hp 120 kW 2.5 L Diesel
Rear wheel
Passenger Van / Wagon / Minibus
VWCRAFTER 30-50
2E
2F
2.5 TDI
2006/04 - BJJ 88 hp 65 kW 2.5 L Diesel
BJK 109 hp 80 kW 2.5 L Diesel
BJL 136 hp 100 kW 2.5 L Diesel
BJM 163 hp 120 kW 2.5 L Diesel
CEBA 88 hp 65 kW 2.5 L Diesel
CEBB 109 hp 80 kW 2.5 L Diesel
CECA 136 hp 100 kW 2.5 L Diesel
CECB 163 hp 120 kW 2.5 L Diesel
Rear wheel
LCV / Van / Cargo
With flatbed/undercarriage
