GIRLING 6049171 Brake Disc

GIRLING part 6049171 Brake Disc
GIRLING part 6049171 Brake Disc

GIRLING 6049171 Brake Disc

by GIRLING

Manufacturer Part Number: 6049171

Сharacteristics:
  • Surface: Painted
  • Minimum thickness [mm]: 23
  • Height [mm]: 69,4
  • Centering Diameter [mm]: 108
  • Thread Size: 14,4
  • Brake Disc Type: Vented
  • Brake Disc Thickness [mm]: 25
  • Diameter [mm]: 297
  • Bolt Hole Circle Ø [mm]: 140
  • Number of Holes: 6
  • Colour: Black

Product Details

BrandGIRLING
GIRLING article (MPN)6049171
Vehicle subsystemBrake System

Original (OEM) part numbers

Suitable for TOYOTA vehicles

OE manufacturerOEM reference numbers
TOYOTA435120K060, 435120K070

Aftermarket cross reference / interchange guide

The aftermarket competitive interchanges for GIRLING 6049171 Brake Disc offered by ABE, A.B.S., ASHUKI, BENDIX, BLUE PRINT, BORG & BECK, BOSCH, Brake ENGINEERING, BREMBO, CAR, DELPHI, FIRST LINE, FOMAR, HELLA, HERTH+BUSS JAKOPARTS, JAPKO, MAGNETI MARELLI, METELLI, MEYLE, NK, PAGID, PROTECHNIC, REMSA, ROTINGER, sbs, TEMPLIN, TEXTAR, TRISCAN, TRUSTING, TRW, ZIMMERMANN manufacturers

ManufacturerReference numbers
ABEC32163ABE
A.B.S.18062
ASHUKIT60340
BENDIX562861BC
BLUE PRINTADT343211
BORG & BECKBBD4815
BOSCH0986AB9775, 0986BB4315, 0986479A96, 0986479T10, 0986AB9825, 0986479A62
Brake ENGINEERINGDI956799
BREMBO09A63410, 09A63411
CAR1421609
DELPHIBG4211
FIRST LINEFBD1908
FOMARFO4083
HELLA8DD355116-821
HERTH+BUSS JAKOPARTSJ3302001
JAPKODI2008
MAGNETI MARELLI600000086860
METELLI231077C
MEYLE30155210096PD, 30155210096
NK3145140, 2045140
PAGID55226
PROTECHNICPRD2585
REMSA6120510
ROTINGERRT20410T5, RT20410
sbs18152045140
TEMPLIN0311028940
TEXTAR92222600
TRISCAN8120131024
TRUSTINGDF1289
TRWDF4917
ZIMMERMANN590282020

Vehicle fitment / GIRLING 6049171 Brake Disc compatibility

This product fits the following models: TOYOTA FORTUNER, TOYOTA HILUX, TOYOTA HILUX III, TOYOTA SW4, etc. See all vehicles this product (GIRLING 6049171) fits below to verify fitment for your vehicle.
MakeModelVariantPeriodEngineDriveBody Style
TOYOTAFORTUNER
TGN6
KUN6
GGN6
TGN5
LAN5
KUN5
GGN5
2.5 D-4D 4WD
3.0 D 4WD
2004/06 - 2015/051KD-FTV 163 hp 120 kW 3 L Diesel
2KD-FTV 144 hp 106 kW 2.5 L Diesel
AWD / 4WD
Full-size SUV / Compact SUV / Mid-size SUV / Compact SUV / Crossover SUV
TOYOTAHILUX
VIGO III KUN
TGN
LAN
GGN
2.5 D-4D
2.5 D-4D 4WD
2.5 D 4WD
3.0 D
3.0 D-4D 4WD
3.0 D 4WD

KUN26
2005/07 - 1KD-FTV 163 hp 120 kW 3 L Diesel
1KD-FTV 171 hp 126 kW 3 L Diesel
1KD-FTV 197 hp 145 kW 3 L Diesel
2KD-FTV 102 hp 75 kW 2.5 L Diesel
2KD-FTV 102 hp 75 kW 2.5 L Diesel
2KD-FTV 144 hp 106 kW 2.5 L Diesel
2KD-FTV 120 hp 88 kW 2.5 L Diesel
2KD-FTV 144 hp 106 kW 2.5 L Diesel
AWD / 4WD
Rear wheel
Pickup truck / Pickup
TOYOTAHILUX III
KUN
TGN
LAN
GGN
2.5 D-4D
2.5 D-4D 4WD
2.5 D 4WD
3.0 D
3.0 D-4D 4WD
3.0 D 4WD

KUN26
2005/07 - 1KD-FTV 163 hp 120 kW 3 L Diesel
1KD-FTV 171 hp 126 kW 3 L Diesel
1KD-FTV 197 hp 145 kW 3 L Diesel
2KD-FTV 102 hp 75 kW 2.5 L Diesel
2KD-FTV 102 hp 75 kW 2.5 L Diesel
2KD-FTV 144 hp 106 kW 2.5 L Diesel
2KD-FTV 120 hp 88 kW 2.5 L Diesel
2KD-FTV 144 hp 106 kW 2.5 L Diesel
AWD / 4WD
Rear wheel
Pickup truck / Pickup
TOYOTASW4
TGN6
KUN6
GGN6
TGN5
LAN5
KUN5
GGN5
2.5 D-4D 4WD
3.0 D 4WD
2004/06 - 2015/051KD-FTV 163 hp 120 kW 3 L Diesel
2KD-FTV 144 hp 106 kW 2.5 L Diesel
AWD / 4WD
Full-size SUV / Compact SUV / Mid-size SUV / Compact SUV / Crossover SUV
