ICER 180748 Brake Pad Set, disc brake

ICER part 180748 Brake Pad Set, disc brake

ICER 180748 Brake Pad Set, disc brake

by ICER

Manufacturer Part Number: 180748
Alternative ICER part number(s): 21550, 21551, D348-7240

Сharacteristics:
  • Brake Type: Disc Brake
  • Length [mm]: 103
  • Height [mm]: 53,89
  • Thickness [mm]: 15
  • Quality: 300
  • Weight [kg]: 1.128
  • Axle Version: Front
  • Technical Information Number: 180748
  • Brake System: Akebono
  • Wear Warning Contact: incl. wear warning contact
  • Length 2 [mm]: 116
  • Height 2 [mm]: 49,25

Product Details

BrandICER
ICER article (MPN)180748 Alternative ICER part number(s): 21550, 21551, D348-7240
Vehicle subsystemBrake System

Original (OEM) part numbers

Suitable for MAZDA vehicles

OE manufacturerOEM reference numbers
MAZDABG12-49-280

Aftermarket cross reference / interchange guide

The aftermarket competitive interchanges for ICER 180748 Brake Pad Set, disc brake offered by A.B.S., AKEBONO, BENDIX, BOSCH, BREMBO, BREMSI, CIFAM, DELPHI, DON, E.T.F., FERODO, FIRST LINE, fri.tech., GIRLING, GKN-SPIDAN, HELLA PAGID, HP, JURID, LÖBRO, LPR, LUCAS DIESEL, LUCAS ELECTRICAL, LUCAS ENGINE DRIVE, LUCAS TVS, MAGNETI MARELLI, METELLI, MGA, MINTEX, MK Kashiyama, NECTO, OPTIMAL, PAGID, PROTECHNIC, QH International, REMSA, ROADHOUSE, ROULUNDS RUBBER, SACHS, TRUSTING, TRW, WOKING manufacturers

ManufacturerReference numbers
A.B.S.36620
AKEBONOA-220WK
BENDIX572239, 572239B
BOSCH0986424006
BREMBOP49008
BREMSIBP2352
CIFAM8223860
DELPHILP552
DONNDB157
E.T.F.120352
FERODOFDB479
FIRST LINE1298
fri.tech.395.0
GIRLING6107359
GKN-SPIDAN31455
HELLA PAGIDT3062
HPHP2511, 2511
JURID572239J, 572239
LÖBRO31455
LPR05P034
LUCAS DIESELGDB735
LUCAS ELECTRICALGDB735
LUCAS ENGINE DRIVEGDB735
LUCAS TVSGDB735
MAGNETI MARELLIBP0890
METELLI2203860
MGA257, MGA257
MINTEXMDB1347
MK KashiyamaD03040
NECTOFD6346A
OPTIMAL9463
PAGIDT3062
PROTECHNICPRP0661
QH InternationalHP2511
REMSA2234.02, 234.02
ROADHOUSE2234.02
ROULUNDS RUBBER655581
SACHS111_1031, 111_1031
TRUSTING3950
TRWGDB735
WOKING334302

Vehicle fitment / ICER 180748 Brake Pad Set, disc brake compatibility

This product fits the following models: FORD ASIA / OZEANIA LASER, MAZDA 323 III, MAZDA 323III, MAZDA ETUDE III, MAZDA FAMILIA III, etc. See all vehicles this product (ICER 180748) fits below to verify fitment for your vehicle.
MakeModelVariantPeriodEngineDriveBody Style
FORD ASIA / OZEANIALASER
BA3
BF3
BF4
BG3
BJ4
1.6 GTX
1.6 Turbo
1986/05 - 1989/05B616 105 hp 77 kW 1.6 L Petrol
B695 150 hp 110 kW 1.6 L Petrol
Front wheel
Hatchback / Sportback / Sport hatch
MAZDA323 III
BF
BW
1.6
1.6 GT
1986/09 - 1995/10B65M 86 hp 63 kW 1.6 L Petrol
B6E 86 hp 63 kW 1.6 L Petrol
B6(SOHC) 86 hp 63 kW 1.6 L Petrol
B6(SOHC) 85 hp 63 kW 1.6 L Petrol
Front wheel
Estate / Turnier / Vario / Wagon
Sedan / Saloon
MAZDA323III
BF
BW
1.6
1.6 GT
1986/09 - 1995/10B65M 86 hp 63 kW 1.6 L Petrol
B6E 86 hp 63 kW 1.6 L Petrol
B6(SOHC) 86 hp 63 kW 1.6 L Petrol
B6(SOHC) 85 hp 63 kW 1.6 L Petrol
Front wheel
Estate / Turnier / Vario / Wagon
Sedan / Saloon
MAZDAETUDE III
BF
1.6 GT
1986/11 - 1989/10B6(SOHC) 85 hp 63 kW 1.6 L Petrol
Front wheel
Sedan / Saloon
MAZDAFAMILIA III
BF
BW
1.6
1.6 GT
1986/09 - 1995/10B65M 86 hp 63 kW 1.6 L Petrol
B6E 86 hp 63 kW 1.6 L Petrol
B6(SOHC) 86 hp 63 kW 1.6 L Petrol
B6(SOHC) 85 hp 63 kW 1.6 L Petrol
Front wheel
Estate / Turnier / Vario / Wagon
Sedan / Saloon
