LYNXauto C8469 Control Arm-/Trailing Arm Bush

LYNXauto part C8469 Control Arm-/Trailing Arm Bush

LYNXauto C8469 Control Arm-/Trailing Arm Bush

Manufacturer Part Number: C8469

Сharacteristics:

Bearing Type: Rubber-metal Bearing
Steering arm type: for control arm
Fitting Position: Lower Front Axle
Fitting Position: Front

Product Details

Brand	LYNXauto
LYNXauto article (MPN)	C8469
Vehicle subsystem	Wheel Suspension

Original (OEM) part numbers

Suitable for MITSUBISHI, VOLVO vehicles

OE manufacturer	OEM reference numbers
MITSUBISHI	MR130983, MR241341, MR241342, MR439701, MR439702
VOLVO	30818467

Aftermarket cross reference / interchange guide

The aftermarket competitive interchanges for LYNXauto C8469 Control Arm-/Trailing Arm Bush offered by ASHUKI, AYWIPARTS, BLUE PRINT, FEBEST, FEBI BILSTEIN, FENOX, MOOG, SIDEM, SWAG, TRW manufacturers

Manufacturer	Reference numbers
ASHUKI	14708005, 14738005
AYWIPARTS	AW1420990
BLUE PRINT	ADC486100C, ADC486122, ADC48648, ADC48699C, ADC48647
FEBEST	MAB-070, MAB-DA1S
FEBI BILSTEIN	28200, 41274, 15401, 41238, 41212, 41237
FENOX	CAB10044
MOOG	VV-SB-3633
SIDEM	867607
SWAG	55600012, 80941238, 80941237, 80941274, 80941212, 80928200
TRW	JBU535

Vehicle fitment / LYNXauto C8469 Control Arm-/Trailing Arm Bush compatibility

This product fits the following models: MITSUBISHI CARISMA, MITSUBISHI COLT IV, MITSUBISHI COLTIV, MITSUBISHI COLT V, MITSUBISHI COLTV, MITSUBISHI MIRAGE V, VOLVO S40 I, VOLVO V40, etc. See all vehicles this product (LYNXauto C8469) fits below to verify fitment for your vehicle.

Make	Model	Variant	Period	Engine	Drive	Body Style
MITSUBISHI	CARISMA DA	1.6 1.8 16V GDI 1.8 GDI 1.9 DI-D 1.9 TD 2.0 16V GT EVO VI/VII DA1A DA2A DA4A DA5A	1995/07 - 2006/06	4G63Turbo 280 hp 206 kW 2 L Petrol 4G92(SOHC16V) 103 hp 76 kW 1.6 L Petrol 4G92(SOHC16V) 90 hp 66 kW 1.6 L Petrol 4G92(SOHC16V) 95 hp 70 kW 1.6 L Petrol 4G92(SOHC16V) 99 hp 73 kW 1.6 L Petrol 4G93(GDI) 122 hp 90 kW 1.8 L Petrol 4G93(GDI) 125 hp 92 kW 1.8 L Petrol F8QT 90 hp 66 kW 1.9 L Diesel F9Q1 102 hp 75 kW 1.9 L Diesel F9Q2 115 hp 85 kW 1.9 L Diesel	AWD / 4WD Front wheel	Hatchback / Sportback / Sport hatch Sedan / Saloon
MITSUBISHI	COLT IV CAA	1.3 GLi 12V 1.6 1.6 4WD 1.6 GLXi 16V 1.8 GTi 16V CA1A CA4A CA5A CC4A	1992/04 - 1996/04	4G13(12V) 75 hp 55 kW 1.3 L Petrol 4G92(SOHC16V) 113 hp 83 kW 1.6 L Petrol 4G92(SOHC16V) 114 hp 84 kW 1.6 L Petrol 4G92(SOHC16V) 90 hp 66 kW 1.6 L Petrol 4G93(DOHC16V) 140 hp 103 kW 1.8 L Petrol	AWD / 4WD Front wheel	Hatchback / Sportback / Sport hatch
MITSUBISHI	COLTIV CAA	1.3 GLi 12V 1.6 1.6 4WD 1.6 GLXi 16V 1.8 GTi 16V CA1A CA4A CA5A CC4A	1992/04 - 1996/04	4G13(12V) 75 hp 55 kW 1.3 L Petrol 4G92(SOHC16V) 113 hp 83 kW 1.6 L Petrol 4G92(SOHC16V) 114 hp 84 kW 1.6 L Petrol 4G92(SOHC16V) 90 hp 66 kW 1.6 L Petrol 4G93(DOHC16V) 140 hp 103 kW 1.8 L Petrol	AWD / 4WD Front wheel	Hatchback / Sportback / Sport hatch
MITSUBISHI	COLT V CJ CP	1.3 1300 1300 GL GLX 1.5 1.5 16V 1600 1600 GLX 1600 GLX 16V CJ1A CJ2A CJ4A	1995/09 - 2003/09	4G13(12V) 75 hp 55 kW 1.3 L Petrol 4G13(16V) 82 hp 60 kW 1.3 L Petrol 4G15(16V) 110 hp 81 kW 1.5 L Petrol 4G15(16V) 94 hp 69 kW 1.5 L Petrol 4G19 90 hp 66 kW 1.3 L Petrol 4G92(SOHC16V) 103 hp 76 kW 1.6 L Petrol 4G92(SOHC16V) 90 hp 66 kW 1.6 L Petrol	Front wheel	Hatchback / Sportback / Sport hatch
MITSUBISHI	COLTV CJ CP	1.3 1300 1300 GL GLX 1.5 1.5 16V 1600 1600 GLX 1600 GLX 16V CJ1A CJ2A CJ4A	1995/09 - 2003/09	4G13(12V) 75 hp 55 kW 1.3 L Petrol 4G13(16V) 82 hp 60 kW 1.3 L Petrol 4G15(16V) 110 hp 81 kW 1.5 L Petrol 4G15(16V) 94 hp 69 kW 1.5 L Petrol 4G19 90 hp 66 kW 1.3 L Petrol 4G92(SOHC16V) 103 hp 76 kW 1.6 L Petrol 4G92(SOHC16V) 90 hp 66 kW 1.6 L Petrol	Front wheel	Hatchback / Sportback / Sport hatch
MITSUBISHI	MIRAGE V CJ CP	1.3 1300 1300 GL GLX 1.5 1.5 16V 1600 1600 GLX 1600 GLX 16V CJ1A CJ2A CJ4A	1995/09 - 2003/09	4G13(12V) 75 hp 55 kW 1.3 L Petrol 4G13(16V) 82 hp 60 kW 1.3 L Petrol 4G15(16V) 110 hp 81 kW 1.5 L Petrol 4G15(16V) 94 hp 69 kW 1.5 L Petrol 4G19 90 hp 66 kW 1.3 L Petrol 4G92(SOHC16V) 103 hp 76 kW 1.6 L Petrol 4G92(SOHC16V) 90 hp 66 kW 1.6 L Petrol	Front wheel	Hatchback / Sportback / Sport hatch
VOLVO	S40 I VS	1.6 1.8 1.8 16V 1.8 i 1.9 DI 1.9 T4 1.9 TD 2.0 2.0 T 2.0 T4	1995/07 - 2003/12	B4164S 105 hp 77 kW 1.6 L Petrol B4164S2 109 hp 80 kW 1.6 L Petrol B4184S 115 hp 85 kW 1.8 L Petrol B4184S2 116 hp 85 kW 1.8 L Petrol B4184S2 122 hp 90 kW 1.8 L Petrol B4184S3 115 hp 85 kW 1.8 L Petrol B4184S9 122 hp 90 kW 1.8 L Petrol B4184SJ 122 hp 90 kW 1.8 L Petrol B4184SJ 122 hp 90 kW 1.8 L Petrol B4184SM 125 hp 92 kW 1.8 L Petrol B4194T 200 hp 147 kW 1.9 L Petrol B4194T2 200 hp 147 kW 1.9 L Petrol B4204S 136 hp 100 kW 2 L Petrol B4204S 140 hp 103 kW 2 L Petrol B4204S2 136 hp 100 kW 2 L Petrol B4204T 160 hp 118 kW 2 L Petrol B4204T2 165 hp 121 kW 2 L Petrol B4204T3 163 hp 120 kW 2 L Petrol B4204T3 165 hp 121 kW 2 L Petrol B4204T5 200 hp 147 kW 2 L Petrol D4192T2 95 hp 70 kW 1.9 L Diesel D4192T3 115 hp 85 kW 1.9 L Diesel D4192T4 102 hp 75 kW 1.9 L Diesel D4192T 90 hp 66 kW 1.9 L Diesel	Front wheel	Sedan / Saloon
VOLVO	V40 VW	1.6 1.8 1.8 i 1.9 DI 1.9 T4 1.9 TD 2.0 2.0 T 2.0 T4	1995/07 - 2004/06	B4164S 105 hp 77 kW 1.6 L Petrol B4164S2 109 hp 80 kW 1.6 L Petrol B4184S 115 hp 85 kW 1.8 L Petrol B4184S2 122 hp 90 kW 1.8 L Petrol B4184S3 115 hp 85 kW 1.8 L Petrol B4184S9 122 hp 90 kW 1.8 L Petrol B4184SJ 122 hp 90 kW 1.8 L Petrol B4184SM 125 hp 92 kW 1.8 L Petrol B4194T 200 hp 147 kW 1.9 L Petrol B4204S 136 hp 100 kW 2 L Petrol B4204S 140 hp 103 kW 2 L Petrol B4204S2 136 hp 100 kW 2 L Petrol B4204T 160 hp 118 kW 2 L Petrol B4204T2 165 hp 121 kW 2 L Petrol B4204T3 163 hp 120 kW 2 L Petrol B4204T5 200 hp 147 kW 2 L Petrol D4192T2 95 hp 70 kW 1.9 L Diesel D4192T3 115 hp 85 kW 1.9 L Diesel D4192T4 102 hp 75 kW 1.9 L Diesel D4192T 90 hp 66 kW 1.9 L Diesel	Front wheel	Estate / Turnier / Vario / Wagon
