MEYLE 1155231011 Brake Drum
MEYLE 1155231011 Brake Drum
by MEYLEManufacturer Part Number: 1155231011
Alternative MEYLE part number(s): MDR0011
- Fitting Position: Rear Axle
- Br. Drum outer diameter [mm]: 285,5
- Inner Br. Drum Diam. [mm]: 252
- Max.skimmed drum measure [mm]: 253,5
- Inner Brake Drum Height [mm]: 64
- Total Br. Drum Height [mm]: 77,5
- Centering Diameter [mm]: 65
- Bolt Hole Circle Ø [mm]: 112
- Number of Holes: 5
Product Details
| Brand | MEYLE |
| MEYLE article (MPN) | 1155231011 Alternative MEYLE part number(s): MDR0011 |
| Vehicle subsystem | Brake System |
Original (OEM) part numbers
Suitable for VAG vehicles
| OE manufacturer | OEM reference numbers |
|---|---|
| VAG | 251609615 |
Aftermarket cross reference / interchange guide
The aftermarket competitive interchanges for MEYLE 1155231011 Brake Drum offered by A.B.S., ATE, BORG & BECK, BOSCH, Brake ENGINEERING, BREMBO, DELPHI, FEBI BILSTEIN, FENOX, HANS PRIES, HELLA, JP GROUP, JURID, METZGER, NK, QUINTON HAZELL, SWAG, TEXTAR, TRISCAN, TRW, VAICO, ZIMMERMANN manufacturers
| Manufacturer | Reference numbers |
|---|---|
| A.B.S. | 7170S |
| ATE | 480046, 24.0225-2002.2 |
| BORG & BECK | BBR7047 |
| BOSCH | 0986477033 |
| Brake ENGINEERING | DR960230 |
| BREMBO | 14.5495.10 |
| DELPHI | BF184 |
| FEBI BILSTEIN | 14062 |
| FENOX | TO216166 |
| HANS PRIES | 103281 |
| HELLA | 8DT355301-641 |
| JP GROUP | 1163500109, 1163500900 |
| JURID | 329131J |
| METZGER | BT725 |
| NK | 264706 |
| QUINTON HAZELL | BDR242 |
| SWAG | 32914062 |
| TEXTAR | 98100008301, 94008300 |
| TRISCAN | 812029209 |
| TRW | DB4053 |
| VAICO | V10-60003 |
| ZIMMERMANN | 600.1952.00 |
Vehicle fitment / MEYLE 1155231011 Brake Drum compatibility
This product fits the following models: VW AGON III, VW CARAVELLE III, VW TRANER CARAVELLE III, VW TRANER CARAVELLEIII, VW TRANER III, VW TRANERIII, VW TRANER T3, etc. See all vehicles this product (MEYLE 1155231011) fits below to verify fitment for your vehicle.| Make | Model | Variant | Period | Engine | Drive | Body Style |
|---|---|---|---|---|---|---|
| VW | AGON III | 1.6 1.6 D 1.6 TD 1.6 TD Syncro 1.7 D 1.9 1.9 Syncro 2.0 2.1 2.1 i 2.1 KAT 2.1 Syncro | 1979/05 - 1992/07 | CS 50 hp 37 kW 1.6 L Diesel CT 50 hp 37 kW 1.6 L Petrol CU 70 hp 51 kW 2 L Petrol CV 70 hp 51 kW 2 L Petrol DF 60 hp 44 kW 1.9 L Petrol DG 78 hp 57 kW 1.9 L Petrol DH 83 hp 61 kW 1.9 L Petrol GW 90 hp 66 kW 1.9 L Petrol DG 78 hp 57 kW 1.9 L Petrol DJ 112 hp 82 kW 2.1 L Petrol MV 95 hp 70 kW 2.1 L Petrol SR 87 hp 64 kW 2.1 L Petrol JX 70 hp 51 kW 1.6 L Diesel KY 57 hp 42 kW 1.7 L Diesel MV 95 hp 70 kW 2.1 L Petrol SS 92 hp 68 kW 2.1 L Petrol | AWD / 4WD Rear wheel | Passenger Van / Wagon / Minibus |
| VW | CARAVELLE III | 1.6 1.6 D 1.6 TD 1.6 TD Syncro 1.7 D 1.9 1.9 Syncro 2.0 2.1 2.1 i 2.1 KAT 2.1 Syncro | 1979/05 - 1992/07 | CS 50 hp 37 kW 1.6 L Diesel CT 50 hp 37 kW 1.6 L Petrol CU 70 hp 51 kW 2 L Petrol CV 70 hp 51 kW 2 L Petrol DF 60 hp 44 kW 1.9 L Petrol DG 78 hp 57 kW 1.9 L Petrol DH 83 hp 61 kW 1.9 L Petrol GW 90 hp 66 kW 1.9 L Petrol DG 78 hp 57 kW 1.9 L Petrol DJ 112 hp 82 kW 2.1 L Petrol MV 95 hp 70 kW 2.1 L Petrol SR 87 hp 64 kW 2.1 L Petrol JX 70 hp 51 kW 1.6 L Diesel KY 57 hp 42 kW 1.7 L Diesel MV 95 hp 70 kW 2.1 L Petrol SS 92 hp 68 kW 2.1 L Petrol | AWD / 4WD Rear wheel | Passenger Van / Wagon / Minibus |
| VW | TRANER CARAVELLE III | 1.6 1.6 D 1.6 TD 1.6 TD Syncro 1.7 D 1.9 1.9 Syncro 2.0 2.1 2.1 i 2.1 KAT 2.1 Syncro | 1979/05 - 1992/07 | CS 50 hp 37 kW 1.6 L Diesel CT 50 hp 37 kW 1.6 L Petrol CU 70 hp 51 kW 2 L Petrol CV 70 hp 51 kW 2 L Petrol DF 60 hp 44 kW 1.9 L Petrol DG 78 hp 57 kW 1.9 L Petrol DH 83 hp 61 kW 1.9 L Petrol GW 90 hp 66 kW 1.9 L Petrol DG 78 hp 57 kW 1.9 L Petrol DJ 112 hp 82 kW 2.1 L Petrol MV 95 hp 70 kW 2.1 L Petrol SR 87 hp 64 kW 2.1 L Petrol JX 70 hp 51 kW 1.6 L Diesel KY 57 hp 42 kW 1.7 L Diesel MV 95 hp 70 kW 2.1 L Petrol SS 92 hp 68 kW 2.1 L Petrol | AWD / 4WD Rear wheel | Passenger Van / Wagon / Minibus |
| VW | TRANER CARAVELLEIII | 1.6 1.6 D 1.6 TD 1.6 TD Syncro 1.7 D 1.9 1.9 Syncro 2.0 2.1 2.1 i 2.1 KAT 2.1 Syncro | 1979/05 - 1992/07 | CS 50 hp 37 kW 1.6 L Diesel CT 50 hp 37 kW 1.6 L Petrol CU 70 hp 51 kW 2 L Petrol CV 70 hp 51 kW 2 L Petrol DF 60 hp 44 kW 1.9 L Petrol DG 78 hp 57 kW 1.9 L Petrol DH 83 hp 61 kW 1.9 L Petrol GW 90 hp 66 kW 1.9 L Petrol DG 78 hp 57 kW 1.9 L Petrol DJ 112 hp 82 kW 2.1 L Petrol MV 95 hp 70 kW 2.1 L Petrol SR 87 hp 64 kW 2.1 L Petrol JX 70 hp 51 kW 1.6 L Diesel KY 57 hp 42 kW 1.7 L Diesel MV 95 hp 70 kW 2.1 L Petrol SS 92 hp 68 kW 2.1 L Petrol | AWD / 4WD Rear wheel | Passenger Van / Wagon / Minibus |
| VW | TRANER III | 1.6 1.6 D 1.6 TD 1.6 TD Syncro 1.7 D 1.9 1.9 Syncro 2.0 2.1 2.1 i 2.1 KAT 2.1 Syncro | 1979/05 - 1992/07 | CS 50 hp 37 kW 1.6 L Diesel CT 50 hp 37 kW 1.6 L Petrol CU 69 hp 51 kW 2 L Petrol CU 70 hp 51 kW 2 L Petrol CV 70 hp 51 kW 2 L Petrol DF 60 hp 44 kW 1.9 L Petrol DG 78 hp 57 kW 1.9 L Petrol DH 83 hp 61 kW 1.9 L Petrol DF 60 hp 44 kW 1.9 L Petrol DG 78 hp 57 kW 1.9 L Petrol DH 83 hp 61 kW 1.9 L Petrol GW 90 hp 66 kW 1.9 L Petrol DG 78 hp 57 kW 1.9 L Petrol DJ 112 hp 82 kW 2.1 L Petrol MV 95 hp 70 kW 2.1 L Petrol DJ 112 hp 82 kW 2.1 L Petrol MV 95 hp 70 kW 2.1 L Petrol SR 87 hp 64 kW 2.1 L Petrol JX 69 hp 51 kW 1.6 L Diesel JX 70 hp 51 kW 1.6 L Diesel KY 57 hp 42 kW 1.7 L Diesel MV 95 hp 70 kW 2.1 L Petrol SS 92 hp 68 kW 2.1 L Petrol | AWD / 4WD Rear wheel | LCV / Van / Cargo Passenger Van / Wagon / Minibus With flatbed/undercarriage |
| VW | TRANERIII | 1.6 1.6 D 1.6 TD 1.6 TD Syncro 1.7 D 1.9 1.9 Syncro 2.0 2.1 2.1 i 2.1 Syncro | 1979/05 - 1992/07 | CS 50 hp 37 kW 1.6 L Diesel CT 50 hp 37 kW 1.6 L Petrol CU 69 hp 51 kW 2 L Petrol DF 60 hp 44 kW 1.9 L Petrol DG 78 hp 57 kW 1.9 L Petrol DH 83 hp 61 kW 1.9 L Petrol DF 60 hp 44 kW 1.9 L Petrol DG 78 hp 57 kW 1.9 L Petrol DH 83 hp 61 kW 1.9 L Petrol GW 90 hp 66 kW 1.9 L Petrol DG 78 hp 57 kW 1.9 L Petrol DJ 112 hp 82 kW 2.1 L Petrol MV 95 hp 70 kW 2.1 L Petrol JX 69 hp 51 kW 1.6 L Diesel JX 70 hp 51 kW 1.6 L Diesel KY 57 hp 42 kW 1.7 L Diesel SS 92 hp 68 kW 2.1 L Petrol | AWD / 4WD Rear wheel | LCV / Van / Cargo With flatbed/undercarriage |
| VW | TRANER T3 | 1.6 1.6 D 1.6 TD 1.6 TD Syncro 1.7 D 1.9 1.9 Syncro 2.0 2.1 2.1 i 2.1 KAT 2.1 Syncro | 1979/05 - 1992/07 | CS 50 hp 37 kW 1.6 L Diesel CT 50 hp 37 kW 1.6 L Petrol CU 69 hp 51 kW 2 L Petrol CU 70 hp 51 kW 2 L Petrol CV 70 hp 51 kW 2 L Petrol DF 60 hp 44 kW 1.9 L Petrol DG 78 hp 57 kW 1.9 L Petrol DH 83 hp 61 kW 1.9 L Petrol DF 60 hp 44 kW 1.9 L Petrol DG 78 hp 57 kW 1.9 L Petrol DH 83 hp 61 kW 1.9 L Petrol GW 90 hp 66 kW 1.9 L Petrol DG 78 hp 57 kW 1.9 L Petrol DJ 112 hp 82 kW 2.1 L Petrol MV 95 hp 70 kW 2.1 L Petrol DJ 112 hp 82 kW 2.1 L Petrol MV 95 hp 70 kW 2.1 L Petrol SR 87 hp 64 kW 2.1 L Petrol JX 69 hp 51 kW 1.6 L Diesel JX 70 hp 51 kW 1.6 L Diesel KY 57 hp 42 kW 1.7 L Diesel MV 95 hp 70 kW 2.1 L Petrol SS 92 hp 68 kW 2.1 L Petrol | AWD / 4WD Rear wheel | LCV / Van / Cargo Passenger Van / Wagon / Minibus With flatbed/undercarriage |
