MEYLE 5145210001 Brake Disc

MEYLE part 5145210001 Brake Disc

MEYLE 5145210001 Brake Disc

by MEYLE

Manufacturer Part Number: 5145210001
Alternative MEYLE part number(s): MBD1141

Сharacteristics:
  • Fitting Position: Front Axle
  • Outer diameter [mm]: 305
  • Height [mm]: 50,3
  • Brake Disc Thickness [mm]: 27,9
  • Minimum thickness [mm]: 25
  • Centering Diameter [mm]: 68
  • Bolt Hole Circle Ø [mm]: 108
  • Wheel Bolt Bore Ø [mm]: 16,5
  • Number of Holes: 5
  • Brake Disc Type: Vented

Product Details

BrandMEYLE
MEYLE article (MPN)5145210001 Alternative MEYLE part number(s): MBD1141
Vehicle subsystemBrake System

Original (OEM) part numbers

Suitable for VOLVO vehicles

OE manufacturerOEM reference numbers
VOLVO274170, 272404, 274559, 9492715, 2724045, 2741702, 31262716

Aftermarket cross reference / interchange guide

The aftermarket competitive interchanges for MEYLE 5145210001 Brake Disc offered by A.B.S., APEC braking, ATE, BARUM, BENDIX, BOSCH, Brake ENGINEERING, BREMBO, CIFAM, DELPHI, DENCKERMANN, Dr!ve+, FEBI BILSTEIN, FERODO, FIRST LINE, FOMAR, fri.tech., GIRLING, HELLA PAGID, ICER, JP GROUP, JURID, LPR, MAGNETI MARELLI, MAPCO, METELLI, METZGER, MEYLE, MINTEX, NK, OPEN PARTS, OPTIMAL, PAGID, REMSA, ROTINGER, sbs, SWAG, TEMPLIN, TEXTAR, TRUSTING, TRW, VAICO, VALEO, ZIMMERMANN manufacturers

ManufacturerReference numbers
A.B.S.17012
APEC brakingDSK974
ATE428123, 24.0328-0123.1, 24.0128-0123.1
BARUMBAR28123
BENDIX562173BC, 562173B
BOSCH0986478494
Brake ENGINEERINGDI955887
BREMBO09.9130.10, 09.9130.75, 09.9130.11
CIFAM800561C
DELPHIBG9514C, BG9514
DENCKERMANNB130135
Dr!ve+DP1010110787
FEBI BILSTEIN18050
FERODODDF1078C-1, DDF1078-1
FIRST LINEFBD1245
FOMARFO1423
fri.tech.BD0554
GIRLING6040535
HELLA PAGID8DD355107-071, 8DD355107-061
ICER78BD4045
JP GROUP4963101009
JURID562173J, 562173JC
LPRV1483V
MAGNETI MARELLI431602042710, 353616029240, 360406051800
MAPCO15966
METELLI23-0561C
METZGER6110222, 24845V
MEYLE5145210001/PD, 5155210001/PD
MINTEXMDC1433
NK344842, 204842, 314842
OPEN PARTSBDRS1846.25, BDR1846.20
OPTIMALBS-5910, BS-5910C
PAGID50283
REMSA6591.10
ROTINGERRT2799, RT2799T5
sbs5815204842, 1815314842, 1815344842, 1815204842
SWAG55918050
TEMPLIN0311029695, 0311029690
TEXTAR92100600, 92100603, 98200100601
TRUSTINGDF554
TRWDF4053S
VAICOV95-80005
VALEO186741
ZIMMERMANN610.3702.52, 610.3702.70, 610.3702.20

Vehicle fitment / MEYLE 5145210001 Brake Disc compatibility

This product fits the following models: VOLVO S60 I, VOLVO S80 I, VOLVO V70  , VOLVO V70 I, VOLVO V70 II, VOLVO V70II, VOLVO V70 XC, VOLVO XC70 CROSS COUNTRY, etc. See all vehicles this product (MEYLE 5145210001) fits below to verify fitment for your vehicle.
MakeModelVariantPeriodEngineDriveBody Style
VOLVOS60 I
2.0 T
2.3 T5
2.4
2.4 Bifuel
2.4 D
2.4 D5
2.4 T
2.4 T5
2.4 T AWD
2.5 T
2.5 T AWD
T5

CNG
LPG
2000/07 - 2010/04B5204T5 180 hp 132 kW 2 L Petrol
B5234T3 250 hp 184 kW 2.3 L Petrol
B5234T7 265 hp 195 kW 2.3 L Petrol
B5244S 170 hp 125 kW 2.4 L Petrol
B5244S2 140 hp 103 kW 2.4 L Petrol
B5244SG 140 hp 103 kW 2.4 L Petrol
B5244SG2 140 hp 103 kW 2.4 L Petrol
B5244T3 200 hp 147 kW 2.4 L Petrol
B5244T5 260 hp 191 kW 2.4 L Petrol
B5254T2 210 hp 154 kW 2.5 L Petrol
D5244T 163 hp 120 kW 2.4 L Diesel
D5244T4 185 hp 136 kW 2.4 L Diesel
D5244T2 130 hp 96 kW 2.4 L Diesel
D5244T5 163 hp 120 kW 2.4 L Diesel
D5244T7 126 hp 93 kW 2.4 L Diesel
AWD / 4WD
Front wheel
Sedan / Saloon
VOLVOS80 I
TS
XY
2.0
2.0 T
2.4
2.4 Bifuel
2.4 D
2.4 D5
2.4 T
2.4 T5 AWD
2.5 T
2.5 T AWD
2.5 TDI
2.8 T6
2.9
3.0
3.0 T6

CNG
LPG
1998/05 - 2006/07B5204T3 226 hp 166 kW 2 L Petrol
B5204T5 180 hp 132 kW 2 L Petrol
B5204T4 163 hp 120 kW 2 L Petrol
B5244S 170 hp 125 kW 2.4 L Petrol
B5244S2 140 hp 103 kW 2.4 L Petrol
B5244SG 140 hp 103 kW 2.4 L Petrol
B5244SG2 140 hp 103 kW 2.4 L Petrol
B5244T3 200 hp 147 kW 2.4 L Petrol
B5254T2 210 hp 154 kW 2.5 L Petrol
B6284T 272 hp 200 kW 2.8 L Petrol
B6294S 200 hp 147 kW 2.9 L Petrol
B6304S3 204 hp 150 kW 2.9 L Petrol
B6294S2 196 hp 144 kW 3 L Petrol
B6294T 272 hp 200 kW 3 L Petrol
D5244T 163 hp 120 kW 2.4 L Diesel
D5244T2 131 hp 96 kW 2.4 L Diesel
D5252T 140 hp 103 kW 2.5 L Diesel
AWD / 4WD
Front wheel
Sedan / Saloon
VOLVOV70
LV
2.3 Turbo
2.5 Turbo AWD
1997/01 - 2000/05B5234FT+ 250 hp 184 kW 2.3 L Petrol
B5244T 193 hp 142 kW 2.5 L Petrol
B5254T 193 hp 142 kW 2.5 L Petrol
AWD / 4WD
Front wheel
Estate / Turnier / Vario / Wagon
VOLVOV70 I
LV
2.3 Turbo
2.5 Turbo AWD
1997/01 - 2000/05B5234FT+ 250 hp 184 kW 2.3 L Petrol
B5244T 193 hp 142 kW 2.5 L Petrol
B5254T 193 hp 142 kW 2.5 L Petrol
AWD / 4WD
Front wheel
Estate / Turnier / Vario / Wagon
VOLVOV70 II
SW
2.0 T
2.3
2.3 T5
2.4
2.4 AWD
2.4 Bifuel
2.4 D
2.4 D5
2.4 D5 AWD
2.4 T
2.4 T5
2.4 T AWD
2.5 T
2.5 T AWD
2.5 TDI
R 2
5 T
R 2
5 T AWD

CNG
LPG
2000/03 - 2007/08B5204T5 180 hp 132 kW 2 L Petrol
B5234T3 250 hp 184 kW 2.3 L Petrol
B5234T7 265 hp 195 kW 2.3 L Petrol
B5244S 170 hp 125 kW 2.4 L Petrol
B5244S2 140 hp 103 kW 2.4 L Petrol
B5254S 165 hp 121 kW 2.4 L Petrol
B5244SG 140 hp 103 kW 2.4 L Petrol
B5244SG2 140 hp 103 kW 2.4 L Petrol
B5244T3 200 hp 147 kW 2.4 L Petrol
B5244T5 260 hp 191 kW 2.4 L Petrol
B5254S 165 hp 121 kW 2.4 L Petrol
B5254T2 209 hp 154 kW 2.5 L Petrol
B5254T4 300 hp 221 kW 2.5 L Petrol
D5244T 163 hp 120 kW 2.4 L Diesel
D5244T2 163 hp 120 kW 2.4 L Diesel
D5244T4 185 hp 136 kW 2.4 L Diesel
D5244T5 163 hp 120 kW 2.4 L Diesel
D5244T 163 hp 120 kW 2.4 L Diesel
D5244T4 185 hp 136 kW 2.4 L Diesel
D5244T5 163 hp 120 kW 2.4 L Diesel
D5244T2 131 hp 96 kW 2.4 L Diesel
D5244T7 126 hp 93 kW 2.4 L Diesel
D5252T 140 hp 103 kW 2.5 L Diesel
AWD / 4WD
Front wheel
Estate / Turnier / Vario / Wagon
VOLVOV70II
SW
2.0 T
2.3
2.3 T5
2.4
2.4 AWD
2.4 Bifuel
2.4 D
2.4 D5
2.4 D5 AWD
2.4 T
2.4 T5
2.4 T AWD
2.5 T
2.5 T AWD
2.5 TDI
R 2
5 T
R 2
5 T AWD

CNG
LPG
2000/03 - 2007/08B5204T5 180 hp 132 kW 2 L Petrol
B5234T3 250 hp 184 kW 2.3 L Petrol
B5234T7 265 hp 195 kW 2.3 L Petrol
B5244S 170 hp 125 kW 2.4 L Petrol
B5244S2 140 hp 103 kW 2.4 L Petrol
B5254S 165 hp 121 kW 2.4 L Petrol
B5244SG 140 hp 103 kW 2.4 L Petrol
B5244SG2 140 hp 103 kW 2.4 L Petrol
B5244T3 200 hp 147 kW 2.4 L Petrol
B5244T5 260 hp 191 kW 2.4 L Petrol
B5254S 165 hp 121 kW 2.4 L Petrol
B5254T2 209 hp 154 kW 2.5 L Petrol
B5254T4 300 hp 221 kW 2.5 L Petrol
D5244T 163 hp 120 kW 2.4 L Diesel
D5244T2 163 hp 120 kW 2.4 L Diesel
D5244T4 185 hp 136 kW 2.4 L Diesel
D5244T5 163 hp 120 kW 2.4 L Diesel
D5244T 163 hp 120 kW 2.4 L Diesel
D5244T4 185 hp 136 kW 2.4 L Diesel
D5244T5 163 hp 120 kW 2.4 L Diesel
D5244T2 131 hp 96 kW 2.4 L Diesel
D5244T7 126 hp 93 kW 2.4 L Diesel
D5252T 140 hp 103 kW 2.5 L Diesel
AWD / 4WD
Front wheel
Estate / Turnier / Vario / Wagon
VOLVOV70 XC
2.4 D5 AWD
2.4 D5 XC AWD
2.4 T XC AWD
2.5 T XC AWD
1997/11 - 2007/08B5244T3 200 hp 147 kW 2.4 L Petrol
B5254T 193 hp 142 kW 2.4 L Petrol
B5254T2 209 hp 154 kW 2.5 L Petrol
D5244T 163 hp 120 kW 2.4 L Diesel
D5244T4 185 hp 136 kW 2.4 L Diesel
AWD / 4WD
Estate / Turnier / Vario / Wagon
VOLVOXC70 CROSS COUNTRY
2.4 D5 AWD
2.4 D5 XC AWD
2.4 T XC AWD
2.5 T XC AWD
1997/11 - 2007/08B5244T3 200 hp 147 kW 2.4 L Petrol
B5254T 193 hp 142 kW 2.4 L Petrol
B5254T2 209 hp 154 kW 2.5 L Petrol
D5244T 163 hp 120 kW 2.4 L Diesel
D5244T4 185 hp 136 kW 2.4 L Diesel
AWD / 4WD
Estate / Turnier / Vario / Wagon
