NIPPARTS J3302075 Brake Disc

NIPPARTS part J3302075 Brake Disc

NIPPARTS J3302075 Brake Disc

by NIPPARTS

Manufacturer Part Number: J3302075

Сharacteristics:
  • Diameter [mm]: 275
  • Height [mm]: 49,2
  • Brake Disc Type: Internally Vented
  • Brake Disc Thickness [mm]: 28
  • Minimum thickness [mm]: 26
  • Number of Holes: 5
  • Bolt Hole Circle Ø [mm]: 114,3
  • Hub Diameter [mm]: 151
  • Centering Diameter [mm]: 62

Product Details

BrandNIPPARTS
NIPPARTS article (MPN)J3302075
Vehicle subsystemBrake System

Original (OEM) part numbers

Suitable for TOYOTA vehicles

OE manufacturerOEM reference numbers
TOYOTA43512-06020, 43512-06030, 43512-06040, 43512-07020, 43512-33040, 43512-33041, 43512-44020, 43512-44021, 43512-33042, 43512-33060

Aftermarket cross reference / interchange guide

The aftermarket competitive interchanges for NIPPARTS J3302075 Brake Disc offered by A.B.S., ASHIKA, ASHUKI, ATE, BENDIX, BLUE PRINT, BORG & BECK, BOSCH, Brake ENGINEERING, BREMBO, CIFAM, COMLINE, DELPHI, Dr!ve+, FERODO, FOMAR, fri.tech., FTE, GIRLING, HELLA, HELLA PAGID, HERTH+BUSS JAKOPARTS, HP, JAPANPARTS, JAPKO, JP GROUP, JURID, KAGER, KAVO PARTS, KORTEX, LEMFÖRDER, LPR, LUCAS ELECTRICAL, MAGNETI MARELLI, MAPCO, MDR, METELLI, METZGER, MEYLE, MINTEX, NK, NPS, PAGID, PATRON, PEX, PILENGA, PROFIT, QUINTON HAZELL, ROTINGER, SAKURA, sbs, TEMPLIN, TEXTAR, TRISCAN, TRUSTING, TRW, VALEO, ZIMMERMANN manufacturers

ManufacturerReference numbers
A.B.S.16220
ASHIKA60-02-275, 60-02-213, 60-02-2002, 6102225
ASHUKIT60125, T60125G
ATE24.0128-0115.1
BENDIX561676B, 561676BC
BLUE PRINTADT343191, ADT343173, ADT34378
BORG & BECKBBD5034
BOSCH0986478632
Brake ENGINEERINGDI955331
BREMBO09.A386.10, 09.A386.11, 09.5624.10
CIFAM8001028
COMLINEADC01143V, ADC0145V
DELPHIBG2782
Dr!ve+DP1010110661
FERODODRF501, DDF501
FOMARFO2509
fri.tech.BD1063
FTEBS4422
GIRLING6014311
HELLA8DD355104-921, 8DD355111611, 8DD355104-931
HELLA PAGID8DD355104921, 8DD355104931
HERTH+BUSS JAKOPARTSJ3302075
HP57473
JAPANPARTSDI-213, JDI-213, DI-275, DP225, JDI-275, DI2002
JAPKO602002, 60213, 60275, 61225
JP GROUP4863102309
JURID561676J
KAGER370067
KAVO PARTSBR9501, BR9501C, BR9357C, BR9357
KORTEXKD0161
LEMFÖRDER28975
LPRT2981V
LUCAS ELECTRICALDF1431
MAGNETI MARELLI600000087080, 353615275240
MAPCO15557, 45570
MDRMFD2275, MFD2213
METELLI231028
METZGER6110624, 684210, 24379
MEYLE30155210031
MINTEXMDC898
NK204549, 314549
NPST330A91
PAGID53625
PATRONPBD1434, PBD1431
PEX14.0579
PILENGAV660
PROFIT50100501
QUINTON HAZELLBDC4422, BSF4422
ROTINGERRT2209, RT2209T5
SAKURA604203785
sbs1815204549
TEMPLIN0311027575, 0311027570
TEXTAR92077700, 92077703, 98200077701
TRISCAN812013182, 812013135
TRUSTINGDF1063
TRWDF1431
VALEO197279, 197166
ZIMMERMANN590255620

Vehicle fitment / NIPPARTS J3302075 Brake Disc compatibility

This product fits the following models: LEXUS ES, TOYOTA AVENSIS VERSO, TOYOTA CAMRY, TOYOTA ESTIMA, TOYOTA IPSUM, TOYOTA PICNIC, TOYOTA PREVIA, TOYOTA SCEPTER, TOYOTA TARAGO, TOYOTA VERSO, TOYOTA WINDOM, etc. See all vehicles this product (NIPPARTS J3302075) fits below to verify fitment for your vehicle.
MakeModelVariantPeriodEngineDriveBody Style
LEXUSES
VCV10
F1
VZV21
F2
300
MCV10
VCV10
1991/09 - 1997/123VZ-FE 188 hp 138 kW 3 L Petrol
Rear wheel
Sedan / Saloon
TOYOTAAVENSIS VERSO
CLM2
ACM2
2.0 D-4D
2.0 VVT-i
2.4 VVTi 4WD
2.4 VVTi GLS
2001/08 - 2009/111AZ-FE 150 hp 110 kW 2 L Petrol
1CD-FTV 116 hp 85 kW 2 L Diesel
2AZ-FE 156 hp 115 kW 2.4 L Petrol
AWD / 4WD
Front wheel
MPV / Van / Minivan
TOYOTACAMRY
CV1
XV1
V1
CV2
XV2
MCV3
ACV3
XV3
XV1
CV1
V10
2.2
2.4 VVT-i
2.4 VVTi
2.4 VVTi Hybrid
2.5
3.0
3.0 24V
3.0 VIENTA

MCV20
SXV10
SXV20
VCV10
VDV10
1991/06 - 2006/111MZ-FE 183 hp 135 kW 3 L Petrol
3VZ-FE 185 hp 136 kW 3 L Petrol
1MZ-FE 190 hp 140 kW 3 L Petrol
2AZ-FE 152 hp 112 kW 2.4 L Petrol
2AZ-FE 163 hp 120 kW 2.4 L Petrol
2AZ-FXE 143 hp 105 kW 2.4 L Petrol
3VZ-FE 185 hp 136 kW 3 L Petrol
3VZ-FE 188 hp 138 kW 3 L Petrol
3VZ-FE 190 hp 140 kW 3 L Petrol
4VZ-FE 175 hp 129 kW 2.5 L Petrol
5S-FE 126 hp 93 kW 2.2 L Petrol
5S-FE 131 hp 96 kW 2.2 L Petrol
Front wheel
Estate / Turnier / Vario / Wagon
Sedan / Saloon
TOYOTAESTIMA
MCR3
ACR3
CLR3
2.0 D-4D
2.4
2.4 16V
2.4 4WD
3.0 VVTi
3.0 VVTi 4WD

ACR30
2000/02 - 2006/011CD-FTV 116 hp 85 kW 2 L Diesel
1MZ-FE 220 hp 162 kW 3 L Petrol
2AZ-FE 156 hp 115 kW 2.4 L Petrol
2AZ-FXE 131 hp 96 kW 2.4 L Petrol
AWD / 4WD
Front wheel
MPV / Van / Minivan
TOYOTAIPSUM
CLM2
ACM2
2.0 D-4D
2.0 VVT-i
2.4 VVTi 4WD
2.4 VVTi GLS
2001/08 - 2009/111AZ-FE 150 hp 110 kW 2 L Petrol
1CD-FTV 116 hp 85 kW 2 L Diesel
2AZ-FE 156 hp 115 kW 2.4 L Petrol
AWD / 4WD
Front wheel
MPV / Van / Minivan
TOYOTAPICNIC
CLM2
ACM2
2.0 D-4D
2.0 VVT-i
2.4 VVTi 4WD
2.4 VVTi GLS
2001/08 - 2009/111AZ-FE 150 hp 110 kW 2 L Petrol
1CD-FTV 116 hp 85 kW 2 L Diesel
2AZ-FE 156 hp 115 kW 2.4 L Petrol
AWD / 4WD
Front wheel
MPV / Van / Minivan
TOYOTAPREVIA
MCR3
ACR3
CLR3
2.0 D-4D
2.4
2.4 16V
2.4 4WD
3.0 VVTi
3.0 VVTi 4WD

ACR30
2000/02 - 2006/011CD-FTV 116 hp 85 kW 2 L Diesel
1MZ-FE 220 hp 162 kW 3 L Petrol
2AZ-FE 156 hp 115 kW 2.4 L Petrol
2AZ-FXE 131 hp 96 kW 2.4 L Petrol
AWD / 4WD
Front wheel
MPV / Van / Minivan
TOYOTASCEPTER
CV1
XV1
V1
XV1
CV1
V10
2.2
2.5
3.0

SXV10
VCV10
1991/06 - 1996/081MZ-FE 183 hp 135 kW 3 L Petrol
3VZ-FE 185 hp 136 kW 3 L Petrol
3VZ-FE 185 hp 136 kW 3 L Petrol
3VZ-FE 188 hp 138 kW 3 L Petrol
4VZ-FE 175 hp 129 kW 2.5 L Petrol
5S-FE 126 hp 93 kW 2.2 L Petrol
Front wheel
Estate / Turnier / Vario / Wagon
Sedan / Saloon
TOYOTATARAGO
MCR3
ACR3
CLR3
2.0 D-4D
2.4
2.4 16V
2.4 4WD
3.0 VVTi
3.0 VVTi 4WD

ACR30
2000/02 - 2006/011CD-FTV 116 hp 85 kW 2 L Diesel
1MZ-FE 220 hp 162 kW 3 L Petrol
2AZ-FE 156 hp 115 kW 2.4 L Petrol
2AZ-FXE 131 hp 96 kW 2.4 L Petrol
AWD / 4WD
Front wheel
MPV / Van / Minivan
TOYOTAVERSO
CLM2
ACM2
2.0 D-4D
2.0 VVT-i
2.4 VVTi 4WD
2.4 VVTi GLS
2001/08 - 2009/111AZ-FE 150 hp 110 kW 2 L Petrol
1CD-FTV 116 hp 85 kW 2 L Diesel
2AZ-FE 156 hp 115 kW 2.4 L Petrol
AWD / 4WD
Front wheel
MPV / Van / Minivan
TOYOTAWINDOM
MCV2
2.5
3.0
1996/10 - 2001/071MZ-FE 211 hp 155 kW 3 L Petrol
2MZ-FE 200 hp 147 kW 2.5 L Petrol
Front wheel
Sedan / Saloon
