NIPPARTS N3302174 Brake Disc

NIPPARTS N3302174 Brake Disc

Manufacturer Part Number: N3302174

Сharacteristics:

Diameter [mm]: 297
Height [mm]: 67,3
Brake Disc Type: Internally Vented
Brake Disc Thickness [mm]: 25
Minimum thickness [mm]: 23
Number of Holes: 6
Bolt Hole Circle Ø [mm]: 139,7
Hub Diameter [mm]: 180
Centering Diameter [mm]: 108

Product Details

Brand	NIPPARTS
NIPPARTS article (MPN)	N3302174
Vehicle subsystem	Brake System

Original (OEM) part numbers

Suitable for TOYOTA vehicles

OE manufacturer	OEM reference numbers
TOYOTA	435120K060, 435120K070

Aftermarket cross reference / interchange guide

The aftermarket competitive interchanges for NIPPARTS N3302174 Brake Disc offered by A.B.S., ASHIKA, ASHUKI, BLUE PRINT, BORG & BECK, BOSCH, Brake ENGINEERING, BREMBO, CIFAM, COMLINE, DELPHI, HELLA, HELLA PAGID, HERTH+BUSS JAKOPARTS, JAPANPARTS, JAPKO, KAVO PARTS, MAGNETI MARELLI, MDR, METELLI, MEYLE, MINTEX, NK, PAGID, sbs, TEMPLIN, TEXTAR, TRISCAN, ZIMMERMANN manufacturers

Manufacturer	Reference numbers
A.B.S.	18062
ASHIKA	60-02-2008
ASHUKI	T60340
BLUE PRINT	ADT343211
BORG & BECK	BBD4815
BOSCH	00986AB9825
Brake ENGINEERING	DI956799
BREMBO	09.A634.11
CIFAM	8001077C
COMLINE	ADC01169V
DELPHI	BG4211
HELLA	8DD355116-821
HELLA PAGID	8DD355116821
HERTH+BUSS JAKOPARTS	J3302001
JAPANPARTS	DI-2008
JAPKO	602008
KAVO PARTS	BR9470C, BR-9470
MAGNETI MARELLI	600000086860
MDR	MFD22008
METELLI	231077C
MEYLE	30155210096PD, 30155210096
MINTEX	MDC2184
NK	2045140, 3145140
PAGID	55226
sbs	18152045140
TEMPLIN	0311028940
TEXTAR	92222600
TRISCAN	8120131024
ZIMMERMANN	590282020

Vehicle fitment / NIPPARTS N3302174 Brake Disc compatibility

This product fits the following models: TOYOTA FORTUNER, TOYOTA HILUX, TOYOTA HILUX II, TOYOTA HILUX III, TOYOTA SW4, TOYOTA TACOMA II, etc. See all vehicles this product (NIPPARTS N3302174) fits below to verify fitment for your vehicle.

Make	Model	Variant	Period	Engine	Drive	Body Style
TOYOTA	FORTUNER TGN6 KUN6 GGN6 TGN5 LAN5 KUN5 GGN5	2.5 D-4D 4WD 3.0 D	2009/01 - 2015/05	1KD-FTV 163 hp 120 kW 3 L Diesel 2KD-FTV 144 hp 106 kW 2.5 L Diesel	AWD / 4WD Rear wheel	Full-size SUV / Compact SUV / Mid-size SUV / Compact SUV / Crossover SUV
TOYOTA	HILUX VIGO III KUN TGN LAN GGN	2.5 D-4D 4WD 2.5 D 4WD 3.0 D 3.0 D-4D 4WD 3.0 D 4WD KUN16 KUN26	2004/11 -	1KD-FTV 163 hp 120 kW 3 L Diesel 1KD-FTV 163 hp 120 kW 3 L Diesel 1KD-FTV 171 hp 126 kW 3 L Diesel 1KD-FTV 171 hp 126 kW 3 L Diesel 1KD-FTV 197 hp 145 kW 3 L Diesel 2KD-FTV 102 hp 75 kW 2.5 L Diesel 2KD-FTV 120 hp 88 kW 2.5 L Diesel 2KD-FTV 128 hp 94 kW 2.5 L Diesel 2KD-FTV 144 hp 106 kW 2.5 L Diesel	AWD / 4WD Rear wheel	Pickup truck / Pickup
TOYOTA	HILUX II LN8 RN5 LN6 YN6 YN5 LN5 RN6	2.5 D-4D 4WD	2001/11 - 2005/07	2KD-FTV 102 hp 75 kW 2.5 L Diesel	AWD / 4WD	Pickup truck / Pickup
TOYOTA	HILUX III KUN1 TGN3 KUN TGN LAN GGN	2.5 D-4D 4WD 2.5 D 4WD 3.0 D 3.0 D-4D 4WD 3.0 D 4WD KUN16 KUN26	2004/11 -	1KD-FTV 163 hp 120 kW 3 L Diesel 1KD-FTV 163 hp 120 kW 3 L Diesel 1KD-FTV 171 hp 126 kW 3 L Diesel 1KD-FTV 171 hp 126 kW 3 L Diesel 1KD-FTV 171 hp 126 kW 3 L Diesel 1KD-FTV 197 hp 145 kW 3 L Diesel 2KD-FTV 102 hp 75 kW 2.5 L Diesel 2KD-FTV 120 hp 88 kW 2.5 L Diesel 2KD-FTV 128 hp 94 kW 2.5 L Diesel 2KD-FTV 144 hp 106 kW 2.5 L Diesel	AWD / 4WD Rear wheel	Pickup truck / Pickup With flatbed/undercarriage
TOYOTA	SW4 TGN6 KUN6 GGN6 TGN5 LAN5 KUN5 GGN5	2.5 D-4D 4WD 3.0 D	2009/01 - 2015/05	1KD-FTV 163 hp 120 kW 3 L Diesel 2KD-FTV 144 hp 106 kW 2.5 L Diesel	AWD / 4WD Rear wheel	Full-size SUV / Compact SUV / Mid-size SUV / Compact SUV / Crossover SUV
TOYOTA	TACOMA II LN8 RN5 LN6 YN6 YN5 LN5 RN6	2.5 D-4D 4WD	2001/11 - 2005/07	2KD-FTV 102 hp 75 kW 2.5 L Diesel	AWD / 4WD	Pickup truck / Pickup
