NIPPARTS N3302176 Brake Disc

NIPPARTS part N3302176 Brake Disc

NIPPARTS N3302176 Brake Disc

by NIPPARTS

Manufacturer Part Number: N3302176

Сharacteristics:
  • Diameter [mm]: 257
  • Height [mm]: 58,2
  • Brake Disc Type: Internally Vented
  • Brake Disc Thickness [mm]: 28
  • Minimum thickness [mm]: 26
  • Number of Holes: 5
  • Bolt Hole Circle Ø [mm]: 114,3
  • Hub Diameter [mm]: 157
  • Centering Diameter [mm]: 62

Product Details

BrandNIPPARTS
NIPPARTS article (MPN)N3302176
Vehicle subsystemBrake System

Original (OEM) part numbers

Suitable for TOYOTA vehicles

OE manufacturerOEM reference numbers
TOYOTA435120K010, 435120K030, 43512-0K080

Aftermarket cross reference / interchange guide

The aftermarket competitive interchanges for NIPPARTS N3302176 Brake Disc offered by A.B.S., ASHIKA, ATE, BLUE PRINT, BORG & BECK, BOSCH, BREMBO, CIFAM, COMLINE, DELPHI, HELLA, HELLA PAGID, HERTH+BUSS JAKOPARTS, JAPANPARTS, JAPKO, MAGNETI MARELLI, MDR, METELLI, MINTEX, NK, PAGID, PROTECHNIC, sbs, TEMPLIN, TEXTAR manufacturers

ManufacturerReference numbers
A.B.S.17957
ASHIKA60-02-2009
ATE24012802491
BLUE PRINTADT343210, ADT343233
BORG & BECKBBD5256
BOSCH0986479152
BREMBO09.A130.20
CIFAM8001481C
COMLINEADC2504V
DELPHIBG4181
HELLA8DD355117-821, 8DD355117-001
HELLA PAGID8DD355117001, 8DD355117821
HERTH+BUSS JAKOPARTSJ3302138
JAPANPARTSDI-2009
JAPKO602009
MAGNETI MARELLI600000087470
MDRMFD22009
METELLI231481C
MINTEXMDC2303, MDC2322
NK3145138, 2045138, 3145137, 2045137
PAGID55360, 55252
PROTECHNICPRD2805
sbs18152045137
TEMPLIN0311028955, 0311028950
TEXTAR92236003, 92225200

Vehicle fitment / NIPPARTS N3302176 Brake Disc compatibility

This product fits the following models: TOYOTA CONDOR, TOYOTA HILUX, TOYOTA HILUX III, TOYOTA INNOVA, TOYOTA KIJANG INNOVA, TOYOTA QUALIS, TOYOTA ZACE, etc. See all vehicles this product (NIPPARTS N3302176) fits below to verify fitment for your vehicle.
MakeModelVariantPeriodEngineDriveBody Style
TOYOTACONDOR
TGN4
KUN4
2.5 D-4D
2004/08 - 2KD-FTV 102 hp 75 kW 2.5 L Diesel
Front wheel
MPV / Van / Minivan
TOYOTAHILUX
VIGO III KUN
TGN
LAN
GGN
2.0
2.5 D-4D
2.5 D-4D 4WD
2.5 D 4WD
2.7
2.7 4WD
3.0 D
3.0 D-4D 4WD
3.0 D 4WD
4.0
4.0 4WD

KUN16
KUN26
2004/11 - 1AZ-FSE 147 hp 108 kW 2 L Petrol
1TR-FE 133 hp 98 kW 2 L Petrol
1GR-FE 238 hp 175 kW 4 L Petrol
1KD-FTV 163 hp 120 kW 3 L Diesel
1KD-FTV 163 hp 120 kW 3 L Diesel
1KD-FTV 171 hp 126 kW 3 L Diesel
1KD-FTV 171 hp 126 kW 3 L Diesel
1KD-FTV 197 hp 145 kW 3 L Diesel
2KD-FTV 102 hp 75 kW 2.5 L Diesel
2KD-FTV 102 hp 75 kW 2.5 L Diesel
2KD-FTV 120 hp 88 kW 2.5 L Diesel
2KD-FTV 144 hp 106 kW 2.5 L Diesel
2KD-FTV 120 hp 88 kW 2.5 L Diesel
2KD-FTV 128 hp 94 kW 2.5 L Diesel
2KD-FTV 144 hp 106 kW 2.5 L Diesel
2TR-FE 160 hp 118 kW 2.7 L Petrol
AWD / 4WD
AWD / 4WD
Rear wheel
Rear wheel
Pickup truck / Pickup
TOYOTAHILUX III
KUN1
TGN3

KUN
TGN
LAN
GGN
2.0
2.5 D-4D
2.5 D-4D 4WD
2.5 D 4WD
2.7
2.7 4WD
3.0 D
3.0 D-4D 4WD
3.0 D 4WD
4.0
4.0 4WD

KUN16
KUN26
2004/11 - 1AZ-FSE 147 hp 108 kW 2 L Petrol
1TR-FE 133 hp 98 kW 2 L Petrol
1GR-FE 238 hp 175 kW 4 L Petrol
1KD-FTV 163 hp 120 kW 3 L Diesel
1KD-FTV 163 hp 120 kW 3 L Diesel
1KD-FTV 171 hp 126 kW 3 L Diesel
1KD-FTV 171 hp 126 kW 3 L Diesel
1KD-FTV 171 hp 126 kW 3 L Diesel
1KD-FTV 197 hp 145 kW 3 L Diesel
2KD-FTV 102 hp 75 kW 2.5 L Diesel
2KD-FTV 102 hp 75 kW 2.5 L Diesel
2KD-FTV 120 hp 88 kW 2.5 L Diesel
2KD-FTV 144 hp 106 kW 2.5 L Diesel
2KD-FTV 120 hp 88 kW 2.5 L Diesel
2KD-FTV 128 hp 94 kW 2.5 L Diesel
2KD-FTV 144 hp 106 kW 2.5 L Diesel
2TR-FE 160 hp 118 kW 2.7 L Petrol
AWD / 4WD
AWD / 4WD
Rear wheel
Rear wheel
Pickup truck / Pickup
With flatbed/undercarriage
TOYOTAINNOVA
TGN4
KUN4
2.5 D-4D
2004/08 - 2KD-FTV 102 hp 75 kW 2.5 L Diesel
Front wheel
MPV / Van / Minivan
TOYOTAKIJANG INNOVA
TGN4
KUN4
2.5 D-4D
2004/08 - 2KD-FTV 102 hp 75 kW 2.5 L Diesel
Front wheel
MPV / Van / Minivan
TOYOTAQUALIS
TGN4
KUN4
2.5 D-4D
2004/08 - 2KD-FTV 102 hp 75 kW 2.5 L Diesel
Front wheel
MPV / Van / Minivan
TOYOTAZACE
TGN4
KUN4
2.5 D-4D
2004/08 - 2KD-FTV 102 hp 75 kW 2.5 L Diesel
Front wheel
MPV / Van / Minivan
