NK 203645 Brake Disc

NK part 203645 Brake Disc
NK part 203645 Brake Disc
NK part 203645 Brake Disc

NK 203645 Brake Disc

by NK

Manufacturer Part Number: 203645

Сharacteristics:
  • Brake Disc Type: Vented
  • Rim Hole Number: 5
  • Weight [kg]: 6,7
  • for article number: 89011666 Bolt
  • Diameter [mm]: 285
  • Height [mm]: 42
  • Brake Disc Thickness [mm]: 25
  • Minimum thickness [mm]: 22
  • Centering Diameter [mm]: 70

Product Details

BrandNK
NK article (MPN)203645
Vehicle subsystemBrake System

Original (OEM) part numbers

Suitable for FIAT / LANCIA / ALFA, OPEL, SAAB vehicles

OE manufacturerOEM reference numbers
FIAT / LANCIA / ALFA46836491, 46844071, 468364910
OPEL93171497, 569003, 0569003
SAAB9156807

Aftermarket cross reference / interchange guide

The aftermarket competitive interchanges for NK 203645 Brake Disc offered by A.B.S., ATE, AUTOMEGA, BARUM, BENDIX, BORG & BECK, BOSCH, Brake ENGINEERING, BRECO, BREMBO, BREMSI, CIFAM, DELPHI, DENCKERMANN, Dr!ve+, EUROBRAKE, FEBI BILSTEIN, FERODO, FI.BA, FIRST LINE, FOMAR, FREMAX, fri.tech., FTE, GALFER, GIRLING, G.U.D, HANS PRIES, HELLA, HELLA PAGID, JP GROUP, JURID, KAGER, KAWE, KEY PARTS, KRAFT, LEMFÖRDER, LUCAS ELECTRICAL, MAGNETI MARELLI, MAPCO, MAXGEAR, METELLI, METZGER, MEYLE, MGA, MINTEX, NATIONAL, NECTO, NIBK, NK, OPTIMAL, PAGID, PATRON, PILENGA, PROFIT, QUINTON HAZELL, REMSA, ROADHOUSE, ROTINGER, sbs, SWAG, TEMPLIN, TEXTAR, TRISCAN, TRUSTING, TRW, VAICO, VALEO, WAGNER LOCKHEED, WOKING, ZIMMERMANN manufacturers

ManufacturerReference numbers
A.B.S.17368
ATE24.0125-0141.1, 24.0325-0141.1, 24112501411
AUTOMEGA1005690003, 1305690003, 3105690003
BARUMBAR25141
BENDIX562216B, 562216, 562216BC
BORG & BECKBBD4318
BOSCH0986478303
Brake ENGINEERINGDI956243
BRECOBS8470
BREMBO09.9165.14
BREMSIDBB191V
CIFAM800608C
DELPHIBG3713C, BG3713
DENCKERMANNB130273
Dr!ve+DP1010110371
EUROBRAKE5815203645
FEBI BILSTEIN23549
FERODODDF1191C, DDF11911, DDF1191, DDF1191C1
FI.BAFBD162
FIRST LINEFBD1328
FOMARFO2686
FREMAXBD9003
fri.tech.BD0974
FTEBS5412HB, BS5412, BS5412B
GALFERB1G22501411
GIRLING6042931
G.U.DGDB125141
HANS PRIES206511
HELLA8DD355122552, 8DD355109241, 8DD355109231
HELLA PAGID8DD355109-231, 8DD355122552, 8DD355109241
JP GROUP1263100300, 1263100309
JURID562216JC, 562216, 562216J
KAGER371391, 371099
KAWE668910
KEY PARTSKBD4318
KRAFT6041731
LEMFÖRDER2962001
LUCAS ELECTRICALDF4293
MAGNETI MARELLI360704007000
MAPCO257082, 25708
MAXGEAR190812, 190812MAX
METELLI230608C, 23-0608
METZGER6110156, 24846V
MEYLE6155216024, 6155216024/PD
MGAD1447
MINTEXMDC1632, MDK0193
NATIONALNBD1168
NECTOWN1218
NIBKRN1390
NK313645
OPTIMALBS-7908, BS7908C
PAGID54187
PATRONPBD4293
PILENGAV764
PROFIT50101191
QUINTON HAZELLBDC5412
REMSABDM6991.20, 668910
ROADHOUSE668910
ROTINGERRT20163, RT20163T5
sbs1815313645, 1815203645
SWAG40923549
TEMPLIN0311024220, 0311024225
TEXTAR92118703, 89016500, 98200118701, 92118700
TRISCAN8120-65112, 8120-24143
TRUSTINGDF974
TRWDF4293
VAICOV40-80048
VALEO186881
WAGNER LOCKHEEDWGR11911
WOKINGD668910
ZIMMERMANN430149800, 430.1498.20, 430149852

Vehicle fitment / NK 203645 Brake Disc compatibility

This product fits the following models: CHEVROLET VECTRA, CITROËN BX, FIAT CROMA, OPEL SIGNUM, OPEL VECTRA C, OPEL VECTRA C GTS, SAAB 9-3, SAAB 9-3X, VAUXHALL ASTRAIV, VAUXHALL SIGNUM, VAUXHALL VECTRAII, etc. See all vehicles this product (NK 203645) fits below to verify fitment for your vehicle.
MakeModelVariantPeriodEngineDriveBody Style
CHEVROLETVECTRA
2.2
2002/04 - 2006/07Z22SE 147 hp 108 kW 2.2 L Petrol
Z22YH 155 hp 114 kW 2.2 L Petrol
Front wheel
Sedan / Saloon
CITROËNBX
XB-
19 4x4
1989/06 - 1991/05D2E 107 hp 78 kW 1.9 L Petrol
AWD / 4WD
Estate / Turnier / Vario / Wagon
FIATCROMA
194
1.8 16V
1.9 D Multijet
2.2 16V
2005/06 - 194A1.000 147 hp 108 kW 2.2 L Petrol
939A1.000 120 hp 88 kW 1.9 L Diesel
939A7.000 115 hp 85 kW 1.9 L Diesel
939A8.000 136 hp 100 kW 1.9 L Diesel
939A4.000 140 hp 103 kW 1.8 L Petrol
Front wheel
Estate / Turnier / Vario / Wagon
OPELSIGNUM
1.8
1.9 CDTI
2.0 DTI
2.2 direct
2.2 DTI
2003/05 - Y20DTH 100 hp 74 kW 2 L Diesel
Y22DTR 125 hp 92 kW 2.2 L Diesel
Z18XE 122 hp 90 kW 1.8 L Petrol
Z18XER 140 hp 103 kW 1.8 L Petrol
Z19DT 100 hp 74 kW 1.9 L Diesel
Z19DT 120 hp 88 kW 1.9 L Diesel
Z19DTH 150 hp 110 kW 1.9 L Diesel
Z22YH 155 hp 114 kW 2.2 L Petrol
Front wheel
Hatchback / Sportback / Sport hatch
OPELVECTRA C
1.6
1.6 16V
1.8
1.8 16V
1.9 CDTI
2.0 DTI
2.0 DTI 16V
2.2 16V
2.2 direct
2.2 DTI
2.2 DTI 16V
2002/04 - Y20DTH 100 hp 74 kW 2 L Diesel
Y20DTH 101 hp 74 kW 2 L Diesel
Y22DTR 117 hp 86 kW 2.2 L Diesel
Y22DTR 125 hp 92 kW 2.2 L Diesel
Y22DTR 125 hp 92 kW 2.2 L Diesel
Z16XE 100 hp 74 kW 1.6 L Petrol
Z16XEP 105 hp 77 kW 1.6 L Petrol
Z18XE 122 hp 90 kW 1.8 L Petrol
Z18XE 122 hp 90 kW 1.8 L Petrol
Z18XER 140 hp 103 kW 1.8 L Petrol
Z18XEL 110 hp 81 kW 1.8 L Petrol
Z18XER 140 hp 103 kW 1.8 L Petrol
Z19DT 100 hp 74 kW 1.9 L Diesel
Z19DT 120 hp 88 kW 1.9 L Diesel
Z19DTH 150 hp 110 kW 1.9 L Diesel
Z19DT 120 hp 88 kW 1.9 L Diesel
Z19DTH 150 hp 110 kW 1.9 L Diesel
Z19DTL 100 hp 74 kW 1.9 L Diesel
Z22SE 147 hp 108 kW 2.2 L Petrol
Z22YH 155 hp 114 kW 2.2 L Petrol
Front wheel
Estate / Turnier / Vario / Wagon
Sedan / Saloon
OPELVECTRA C GTS
1.6
1.8
1.8 16V
1.9 CDTI
2.0 DTI 16V
2.2 16V
2.2 direct
2.2 DTI 16V
2002/08 - Y20DTH 101 hp 74 kW 2 L Diesel
Y22DTR 117 hp 86 kW 2.2 L Diesel
Y22DTR 125 hp 92 kW 2.2 L Diesel
Z16XE 100 hp 74 kW 1.6 L Petrol
Z16XEP 105 hp 77 kW 1.6 L Petrol
Z18XE 122 hp 90 kW 1.8 L Petrol
Z18XEL 110 hp 81 kW 1.8 L Petrol
Z18XER 140 hp 103 kW 1.8 L Petrol
Z19DT 120 hp 88 kW 1.9 L Diesel
Z19DTH 150 hp 110 kW 1.9 L Diesel
Z19DTL 100 hp 74 kW 1.9 L Diesel
Z22SE 147 hp 108 kW 2.2 L Petrol
Z22YH 155 hp 114 kW 2.2 L Petrol
Front wheel
Hatchback / Sportback / Sport hatch
SAAB9-3
YS3F
1.8 i
1
8t
1.8t 2.0
1
8t BioPower
1.9 TiD
1.9 TTiD
2.0 t
2.0 t Bio Power
2.0 t BioPower
2.0 t Bio Power XWD
2.0 t BioPower XWD
2.0 Turbo XWD
2.0 t XWD
2.2 TiD
2.8 Turbo V6
2002/09 - A19DTR 130 hp 96 kW 1.9 L Diesel
A19DTR 160 hp 118 kW 1.9 L Diesel
A19DTR 180 hp 132 kW 1.9 L Diesel
Z19DTR 180 hp 132 kW 1.9 L Diesel
A19DTR 130 hp 96 kW 1.9 L Diesel
A19DTR 160 hp 118 kW 1.9 L Diesel
Z19DTR 180 hp 132 kW 1.9 L Diesel
A20NFT 220 hp 162 kW 2 L Petrol
B207E 150 hp 110 kW 2 L Petrol
B207G 163 hp 120 kW 2 L Petrol
B207L 175 hp 129 kW 2 L Petrol
B207M 200 hp 147 kW 2 L Petrol
B207R 209 hp 154 kW 2 L Petrol
B207R 241 hp 177 kW 2 L Petrol
A20NFT 220 hp 162 kW 2 L Petrol
B207E 150 hp 110 kW 2 L Petrol
B207H 163 hp 120 kW 2 L Petrol
B207L 175 hp 129 kW 2 L Petrol
B207R 197 hp 145 kW 2 L Petrol
A20NFT 220 hp 162 kW 2 L Petrol
B207G 163 hp 120 kW 2 L Petrol
B207L 175 hp 129 kW 2 L Petrol
B207R 210 hp 154 kW 2 L Petrol
A20NFT 220 hp 162 kW 2 L Petrol
B207G 163 hp 120 kW 2 L Petrol
B207L 175 hp 129 kW 2 L Petrol
B207R 210 hp 154 kW 2 L Petrol
B207R 241 hp 177 kW 2 L Petrol
A20NFT 220 hp 162 kW 2 L Petrol
B207G 163 hp 120 kW 2 L Petrol
B207R 209 hp 154 kW 2 L Petrol
A20NFT 220 hp 162 kW 2 L Petrol
B207G 163 hp 120 kW 2 L Petrol
B207R 241 hp 177 kW 2 L Petrol
A20NFT 220 hp 162 kW 2 L Petrol
B207H 163 hp 120 kW 2 L Petrol
A20NFT 220 hp 162 kW 2 L Petrol
B207H 163 hp 120 kW 2 L Petrol
B207L 175 hp 129 kW 2 L Petrol
B207M 200 hp 147 kW 2 L Petrol
A20NFT 220 hp 162 kW 2 L Petrol
B207H 163 hp 120 kW 2 L Petrol
B207R 210 hp 154 kW 2 L Petrol
B207E 150 hp 110 kW 2 L Petrol
B207E 150 hp 110 kW 2 L Petrol
B207L 175 hp 129 kW 2 L Petrol
B207H 163 hp 120 kW 2 L Petrol
B207L 175 hp 129 kW 2 L Petrol
B207M 200 hp 147 kW 2 L Petrol
B207R 197 hp 145 kW 2 L Petrol
B207R 210 hp 154 kW 2 L Petrol
B207M 200 hp 147 kW 2 L Petrol
B207R 209 hp 154 kW 2 L Petrol
B207R 210 hp 154 kW 2 L Petrol
B284L 256 hp 188 kW 2.8 L Petrol
LP9 230 hp 169 kW 2.8 L Petrol
LP9 250 hp 184 kW 2.8 L Petrol
D223L 125 hp 92 kW 2.2 L Diesel
LP9 230 hp 169 kW 2.8 L Petrol
LP9 250 hp 184 kW 2.8 L Petrol
Z18XE 122 hp 90 kW 1.8 L Petrol
Z19DT 120 hp 88 kW 1.9 L Diesel
Z19DTH 150 hp 110 kW 1.9 L Diesel
Z19DTH 150 hp 110 kW 1.9 L Diesel
AWD / 4WD
Front wheel
Convertible / cabrio
Estate / Turnier / Vario / Wagon
Sedan / Saloon
SAAB9-3X
1.9 TTiD
2.0 t BioPower XWD
2.0 t XWD
2009/02 - A19DTR 180 hp 132 kW 1.9 L Diesel
Z19DTR 180 hp 132 kW 1.9 L Diesel
B207R 209 hp 154 kW 2 L Petrol
AWD / 4WD
Front wheel
Estate / Turnier / Vario / Wagon
VAUXHALLASTRAIV
G
2.0 DTI 16V
1999/08 - 2005/05X20DTH 101 hp 74 kW 2 L Diesel
Y20DTH 101 hp 74 kW 2 L Diesel
Front wheel
Hatchback / Sportback / Sport hatch
VAUXHALLSIGNUM
1.8
1.9 CDTI
1.9 CDTI 16V
1.9 Turbo
2.0 DTI
2.2 DTI
2.2 i
2003/05 - 2008/05Y20DTH 100 hp 74 kW 2 L Diesel
Y22DTR 125 hp 92 kW 2.2 L Diesel
Z18XE 122 hp 90 kW 1.8 L Petrol
Z18XER 140 hp 103 kW 1.8 L Petrol
Z19DT 120 hp 88 kW 1.9 L Diesel
Z19DTH 150 hp 110 kW 1.9 L Diesel
Z19DTL 101 hp 74 kW 1.9 L Diesel
Z22YH 155 hp 114 kW 2.2 L Petrol
Front wheel
Hatchback / Sportback / Sport hatch
VAUXHALLVECTRAII
C
C GTS
C
1.8
1.8 16V
1.8 16V Dualfuel
1.9 CDTI
1.9 CDTI 16V
2.0 DTI 16V
2.2 16V
2.2 direct
2.2 DTI 16V
2002/01 - 2008/10Y20DTH 101 hp 74 kW 2 L Diesel
Y22DTR 125 hp 92 kW 2.2 L Diesel
Z18XE 122 hp 90 kW 1.8 L Petrol
Z18XER 140 hp 103 kW 1.8 L Petrol
Z19DT 120 hp 88 kW 1.9 L Diesel
Z19DTH 150 hp 110 kW 1.9 L Diesel
Z22SE 147 hp 108 kW 2.2 L Petrol
Z22YH 155 hp 114 kW 2.2 L Petrol
Front wheel
Estate / Turnier / Vario / Wagon
Hatchback / Sportback / Sport hatch
Sedan / Saloon
