NK 203731 Brake Disc

NK part 203731 Brake Disc
NK part 203731 Brake Disc
NK part 203731 Brake Disc

NK 203731 Brake Disc

by NK

Manufacturer Part Number: 203731

Сharacteristics:
  • Brake Disc Type: Solid
  • Rim Hole Number: 5
  • Weight [kg]: 7,42
  • Diameter [mm]: 280
  • Height [mm]: 82
  • Brake Disc Thickness [mm]: 16
  • Minimum thickness [mm]: 14,2
  • Centering Diameter [mm]: 72

Product Details

BrandNK
NK article (MPN)203731
Vehicle subsystemBrake System

Original (OEM) part numbers

Suitable for CITROEN / PEUGEOT, FIAT / LANCIA / ALFA vehicles

OE manufacturerOEM reference numbers
CITROEN / PEUGEOT4246Y9, 1606306680, 4246Y7, E169247
FIAT / LANCIA / ALFA4249E6, 71740118, 46833806, 4249L0

Aftermarket cross reference / interchange guide

The aftermarket competitive interchanges for NK 203731 Brake Disc offered by A.B.S., ATE, BENDIX, BORG & BECK, BOSCH, Brake ENGINEERING, BREMBO, BREMSI, CASALS, CIFAM, DELPHI, DENCKERMANN, Dr!ve+, EUROBRAKE, FENOX, FERODO, FIRST LINE, FOMAR, FREMAX, fri.tech., FTE, GALFER, GIRLING, HANS PRIES, HELLA, HELLA PAGID, JP GROUP, JURID, KAGER, KEY PARTS, MAPCO, METELLI, METZGER, MGA, MINTEX, NECTO, NK, PAGID, PILENGA, QUINTON HAZELL, REMSA, ROTINGER, ROULUNDS BRAKING, SASIC, sbs, TEMPLIN, TEXTAR, TRISCAN, TRUSTING, TRW, VAICO, WAGNER LOCKHEED, ZIMMERMANN manufacturers

ManufacturerReference numbers
A.B.S.17461
ATE24.0116-0124.1, 24.0116-0115.1
BENDIX562215, 562215B
BORG & BECKBBD4404
BOSCH0986479065
Brake ENGINEERINGDI956239S
BREMBO08.8094.30
BREMSIDBB144S
CASALS55404, 55562, 55408
CIFAM800731
DELPHIBG3853
DENCKERMANNB130442
Dr!ve+DP1010110234
EUROBRAKE5815203731
FENOXTB218029
FERODODDF1144, DDF11441
FIRST LINEFBD1436
FOMARFO2791
FREMAXBD-3806
fri.tech.BD0114
FTEBS5364, BS5364B
GALFERB1.G216-0124.1
GIRLING6044814
HANS PRIES721183
HELLA8DD355108961
HELLA PAGID8DD355108-961
JP GROUP4163200409
JURID562215J, 562215, 562215JC
KAGER371053, 371198
KEY PARTSKBD4404
MAPCO15416
METELLI23-0731
METZGER14807, 6110446
MGAD1457
MINTEXMDC1650
NECTOWN1165
NK313731
PAGID54161
PILENGA5042
QUINTON HAZELLBDC5364
REMSABDM7176.10
ROTINGERRT1602T5, RT1602
ROULUNDS BRAKINGD2655
SASIC2464Y94J
sbs1815203731, 1815313731
TEMPLIN0311081185, 0311081180
TEXTAR982001161, 92116100, 92116103
TRISCAN8120-10176
TRUSTINGDF114
TRWDF4481, DF4481S
VAICOV42-40006
WAGNER LOCKHEEDWGR11441
ZIMMERMANN180301920, 180301900

Vehicle fitment / NK 203731 Brake Disc compatibility

This product fits the following models: CITROËN JUMPER, CITROËN RELAY, FIAT DUCATO, PEUGEOT BOXER, etc. See all vehicles this product (NK 203731) fits below to verify fitment for your vehicle.
MakeModelVariantPeriodEngineDriveBody Style
CITROËNJUMPER
230
230L
230P
244
244
Z
1.9 D
1.9 TD
2.0
2.0 bivalent
2.0 HDi
2.2 HDi
2.5 D
2.5 D 4x4
2.8 D
2.8 HDi
2.8 HDi 4x4
1994/02 - 4HY(DW12UTED) 101 hp 74 kW 2.2 L Diesel
8140.43N 146 hp 107 kW 2.8 L Diesel
8140.43S 128 hp 94 kW 2.8 L Diesel
8140.43S 128 hp 94 kW 2.8 L Diesel
8140.63(F28D) 87 hp 64 kW 2.8 L Diesel
D8C(XUD9UTF) 90 hp 66 kW 1.9 L Diesel
D8C(XUD9UTF) 92 hp 68 kW 1.9 L Diesel
DHX(XUD9TF/BTF) 90 hp 66 kW 1.9 L Diesel
D9B(XUD9A/U) 69 hp 51 kW 1.9 L Diesel
D9B(XUD9A/U) 69 hp 51 kW 1.9 L Diesel
DJY(XUD9A) 68 hp 50 kW 1.9 L Diesel
F28TDCR 128 hp 94 kW 2.8 L Diesel
RHV(DW10TD) 84 hp 62 kW 2 L Diesel
RHV(DW10UTD) 84 hp 62 kW 2 L Diesel
RHV(DW10UTD) 84 hp 62 kW 2 L Diesel
T9A(DJ5) 86 hp 63 kW 2.5 L Diesel
XU10J2 110 hp 81 kW 2 L Petrol
AWD / 4WD
Front wheel
Front wheel
AWD / 4WD
LCV / Van / Cargo
Passenger Van / Wagon / Minibus
With flatbed/undercarriage
CITROËNRELAY
230
230L
230P
244
244
Z
1.9 D
1.9 TD
2.0
2.0 bivalent
2.0 HDi
2.2 HDi
2.5 D
2.5 D 4x4
2.8 D
2.8 HDi
2.8 HDi 4x4
1994/02 - 4HY(DW12UTED) 101 hp 74 kW 2.2 L Diesel
8140.43N 146 hp 107 kW 2.8 L Diesel
8140.43S 128 hp 94 kW 2.8 L Diesel
8140.43S 128 hp 94 kW 2.8 L Diesel
8140.63(F28D) 87 hp 64 kW 2.8 L Diesel
D8C(XUD9UTF) 90 hp 66 kW 1.9 L Diesel
D8C(XUD9UTF) 92 hp 68 kW 1.9 L Diesel
DHX(XUD9TF/BTF) 90 hp 66 kW 1.9 L Diesel
D9B(XUD9A/U) 69 hp 51 kW 1.9 L Diesel
D9B(XUD9A/U) 69 hp 51 kW 1.9 L Diesel
DJY(XUD9A) 68 hp 50 kW 1.9 L Diesel
F28TDCR 128 hp 94 kW 2.8 L Diesel
RHV(DW10TD) 84 hp 62 kW 2 L Diesel
RHV(DW10UTD) 84 hp 62 kW 2 L Diesel
RHV(DW10UTD) 84 hp 62 kW 2 L Diesel
T9A(DJ5) 86 hp 63 kW 2.5 L Diesel
XU10J2 110 hp 81 kW 2 L Petrol
AWD / 4WD
Front wheel
Front wheel
AWD / 4WD
LCV / Van / Cargo
Passenger Van / Wagon / Minibus
With flatbed/undercarriage
FIATDUCATO
230
230L
244
244
Z
2.0
2.0 4x4
2.0 Bipower
2.0 JTD
2.3 JTD
2.5 TD
2.5 TD 4x4
2.5 TDI
2.8 D
2.8 JTD
2.8 JTD 4x4
2.8 JTD Power
1994/03 - 8140.43N 146 hp 107 kW 2.8 L Diesel
8140.43S 128 hp 94 kW 2.8 L Diesel
8140.47 109 hp 80 kW 2.5 L Diesel
8140.47R 109 hp 80 kW 2.5 L Diesel
8140.63 87 hp 64 kW 2.8 L Diesel
F1AE0481C 110 hp 81 kW 2.3 L Diesel
RFL 110 hp 81 kW 2 L Petrol
RHV(DW10) 84 hp 62 kW 2 L Diesel
AWD / 4WD
Front wheel
LCV / Van / Cargo
Passenger Van / Wagon / Minibus
With flatbed/undercarriage
PEUGEOTBOXER
230L
230P
244
244
Z
ZCT
1.9 D
2.0
2.0 BiFuel
2.0 HDi
2.0 HDI
2.2 HDi
2.5 TDI
2.8 HDi
2.8 HDi 4x4
1994/03 - 110 hp 81 kW 2 L Petrol
4HY(DW12UTED) 101 hp 74 kW 2.2 L Diesel
8140.43N 145 hp 107 kW 2.8 L Diesel
8140.43S(F28DTCR) 128 hp 94 kW 2.8 L Diesel
8140.43N 146 hp 107 kW 2.8 L Diesel
8140.43S(F28DTCR) 128 hp 94 kW 2.8 L Diesel
8140.43S(F28DTCR) 128 hp 94 kW 2.8 L Diesel
D9B(XUD9AU) 69 hp 51 kW 1.9 L Diesel
RFL(XU10J2U) 110 hp 81 kW 2 L Petrol
RHV(DW10TD) 84 hp 62 kW 2 L Diesel
RHV(DW10UTD) 84 hp 62 kW 2 L Diesel
RHV(DW10UTD) 84 hp 62 kW 2 L Diesel
THX(DJ5TED) 107 hp 79 kW 2.5 L Diesel
AWD / 4WD
Front wheel
LCV / Van / Cargo
Passenger Van / Wagon / Minibus
With flatbed/undercarriage
