NK 203734 Brake Disc

NK part 203734 Brake Disc
NK part 203734 Brake Disc
NK part 203734 Brake Disc

NK 203734 Brake Disc

by NK

Manufacturer Part Number: 203734

Сharacteristics:
  • Brake Disc Type: Vented
  • Weight [kg]: 9,78
  • Rim Hole Number: 5
  • Weight [kg]: 9,84
  • Diameter [mm]: 304
  • Height [mm]: 48,5
  • Brake Disc Thickness [mm]: 28
  • Minimum thickness [mm]: 26
  • Centering Diameter [mm]: 71

Product Details

BrandNK
NK article (MPN)203734
Vehicle subsystemBrake System

Original (OEM) part numbers

Suitable for CITROEN / PEUGEOT, FIAT / LANCIA / ALFA, TOYOTA vehicles

OE manufacturerOEM reference numbers
CITROEN / PEUGEOT424925, 424992, 424993, 4249K0, 424924
FIAT / LANCIA / ALFA9467548587, 1440027088
TOYOTASU001A1064

Aftermarket cross reference / interchange guide

The aftermarket competitive interchanges for NK 203734 Brake Disc offered by A.B.S., ATE, BLUE PRINT, BORG & BECK, BOSCH, Brake ENGINEERING, BREMBO, BREMSI, CIFAM, DELPHI, DENCKERMANN, Dr!ve+, EUROBRAKE, FERODO, FIRST LINE, FOMAR, fri.tech., FTE, GIRLING, HANS PRIES, HELLA, HELLA PAGID, ICER, JURID, KAGER, KAMOKA, KEY PARTS, KRAFT, MAGNETI MARELLI, MAPCO, MAXGEAR, METELLI, METZGER, MEYLE, MGA, MINTEX, NATIONAL, NK, OPTIMAL, PAGID, PROFIT, QUINTON HAZELL, R BRAKE, ROTINGER, SASIC, sbs, STARLINE, TEMPLIN, TEXTAR, TRISCAN, TRUSTING, TRW, VAICO, VALEO, WAGNER LOCKHEED, ZIMMERMANN manufacturers

ManufacturerReference numbers
A.B.S.17773
ATE24.0128-0216.1
BLUE PRINTADT343299
BORG & BECKBBD5815S
BOSCH0986479380
Brake ENGINEERINGDI956684
BREMBO09.A430.10
BREMSIDBB615V
CIFAM800886C
DELPHIBG4083
DENCKERMANNB130503
Dr!ve+DP1010110544
EUROBRAKE5815203734
FERODODDF1615, DDF16151, DDF611
FIRST LINEFBD1722
FOMARFO4110
fri.tech.BD1222
FTEBS7211, BS7211B
GIRLING6048495
HANS PRIES722488
HELLA8DD355113671
HELLA PAGID8DD355113-671
ICER78BD47552
JURID562622JC
KAGER370792
KAMOKA1031053
KEY PARTSKBD5815S
KRAFT6045671
MAGNETI MARELLI360704010200
MAPCO15330
MAXGEAR191877
METELLI230886C
METZGER6105410, 6110318
MEYLE2155210032, 2155210032/PD
MGAD1726
MINTEXMDC2293, MDC1848
NATIONALNBD1438
NK313734
OPTIMALBS-8390
PAGID54570
PROFIT50101615
QUINTON HAZELLBDC5741, BDC5660
R BRAKE78RBD24755
ROTINGERRT20652, RT20652T5
SASIC6100013
sbs1815313734, 1815203734
STARLINEPB20652C
TEMPLIN0311080385, 0311080380
TEXTAR92157000, 92157003
TRISCAN8120101014, 812028134c
TRUSTINGDF167, DF1222
TRWDF4849S
VAICOV4280004
VALEO197133
WAGNER LOCKHEEDWGR16151
ZIMMERMANN440311700

Vehicle fitment / NK 203734 Brake Disc compatibility

This product fits the following models: CITROËN C4 GRAND PICASSO II, CITROËN C4 PICASSO II, CITROËN C5 III, CITROËN DISPATCH, CITROËN JUMPY, FIAT SCUDO, PEUGEOT 308 II, PEUGEOT 308 SW II, PEUGEOT 407, PEUGEOT 407 SW, PEUGEOT 508, PEUGEOT 508 SW, PEUGEOT EXPERT, PEUGEOT EXPERT TEPEE, TOYOTA PROACE, etc. See all vehicles this product (NK 203734) fits below to verify fitment for your vehicle.
MakeModelVariantPeriodEngineDriveBody Style
CITROËNC4 GRAND PICASSO II
1.2 THP 130
1.6 BlueHDi 100
1.6 BlueHDi 120
1.6 THP 150
1.6 THP 165
2.0 BlueHDi 135
2013/09 - 5FX(EP6DT) 150 hp 110 kW 1.6 L Petrol
5GZ(EP6FDT) 165 hp 121 kW 1.6 L Petrol
AHV(DW10FDD) 136 hp 100 kW 2 L Diesel
BHY(DV6FD) 99 hp 73 kW 1.6 L Diesel
BHZ(DV6FC) 120 hp 88 kW 1.6 L Diesel
HNY(EB2DTS) 130 hp 96 kW 1.2 L Petrol
Front wheel
MPV / Van / Minivan
CITROËNC4 PICASSO II
1.6 THP 150
2.0 BlueHDi 135
2.0 BlueHDi 150
2013/09 - 5FX(EP6DT) 150 hp 110 kW 1.6 L Petrol
AHV(DW10FDD) 136 hp 100 kW 2 L Diesel
AHX(DW10FD) 150 hp 110 kW 2 L Diesel
Front wheel
MPV / Van / Minivan
CITROËNC5 III
RD
TD
1.6 HDi
1.6 HDi 110
1.6 HDi 115
1.6 THP 150
1.6 THP 155
1.6 VTi 120
1.6 VTI 120
1.8 16V
2.0 16V
2.0 16V BioFlex
2.0 HDi
2.0 HDi 140
2.0 HDi 150 / BlueHDi 150
2.0 HDi 165
2008/02 - 5FN(EP6CDT) 150 hp 110 kW 1.6 L Petrol
5FS(EP6C) 120 hp 88 kW 1.6 L Petrol
5FV(EP6CDT) 156 hp 115 kW 1.6 L Petrol
6FY(EW7A) 125 hp 92 kW 1.8 L Petrol
9HL(DV6C) 112 hp 82 kW 1.6 L Diesel
9HR(DV6C) 112 hp 82 kW 1.6 L Diesel
9HL(DV6C) 114 hp 84 kW 1.6 L Diesel
9HR(DV6C) 114 hp 84 kW 1.6 L Diesel
9HZ(DV6TED4) 109 hp 80 kW 1.6 L Diesel
AHR(DW10FD) 150 hp 110 kW 2 L Diesel
RHE(DW10CTED4) 150 hp 110 kW 2 L Diesel
RFJ(EW10A) 140 hp 103 kW 2 L Petrol
RHF(DW10BTED4) 136 hp 100 kW 2 L Diesel
RHR(DW10BTED4) 136 hp 100 kW 2 L Diesel
RHF(DW10BTED4) 140 hp 103 kW 2 L Diesel
RHH(DW10CTED4) 163 hp 120 kW 2 L Diesel
RHR(DW10BTED4) 136 hp 100 kW 2 L Diesel
Front wheel
Estate / Turnier / Vario / Wagon
Sedan / Saloon
CITROËNDISPATCH
1.6 HDi 90 16V
1.6 HDi 90 8V
2.0 HDi 120
2.0 HDi 120 4x4
2.0 HDi 125
2.0 HDi 140
2.0 HDi 165
2.0 HDi 95
2.0 i
2007/01 - 128 hp 94 kW 2 L Diesel
9HH(DV6DUM) 90 hp 66 kW 1.6 L Diesel
9HM(DV6UC) 90 hp 66 kW 1.6 L Diesel
9HU(DV6UTED4) 90 hp 66 kW 1.6 L Diesel
AHY(DW10CE) 98 hp 72 kW 2 L Diesel
AHZ(DW10CD) 128 hp 94 kW 2 L Diesel
RFH(EW10A) 140 hp 103 kW 2 L Petrol
RHH(DW10CTED4) 163 hp 120 kW 2 L Diesel
RHK(DW10UTED4) 120 hp 88 kW 2 L Diesel
RHR(DW10BTED4) 136 hp 100 kW 2 L Diesel
AWD / 4WD
Front wheel
LCV / Van / Cargo
MPV / Van / Minivan
With flatbed/undercarriage
CITROËNJUMPY
1.6 HDi 90 16V
1.6 HDi 90 8V
2.0 HDi 120
2.0 HDi 120 4x4
2.0 HDi 125
2.0 HDi 140
2.0 HDi 165
2.0 HDi 95
2.0 i
2007/01 - 128 hp 94 kW 2 L Diesel
9HH(DV6DUM) 90 hp 66 kW 1.6 L Diesel
9HM(DV6UC) 90 hp 66 kW 1.6 L Diesel
9HU(DV6UTED4) 90 hp 66 kW 1.6 L Diesel
AHY(DW10CE) 98 hp 72 kW 2 L Diesel
AHZ(DW10CD) 128 hp 94 kW 2 L Diesel
RFH(EW10A) 140 hp 103 kW 2 L Petrol
RHH(DW10CTED4) 163 hp 120 kW 2 L Diesel
RHK(DW10UTED4) 120 hp 88 kW 2 L Diesel
RHR(DW10BTED4) 136 hp 100 kW 2 L Diesel
AWD / 4WD
Front wheel
LCV / Van / Cargo
MPV / Van / Minivan
With flatbed/undercarriage
FIATSCUDO
272
270
1.6 D Multijet
2.0 D Multijet
2.0 D Multijet 4x4
2007/01 - 9HU 90 hp 66 kW 1.6 L Diesel
DW10BTED4 136 hp 100 kW 2 L Diesel
RH02 128 hp 94 kW 2 L Diesel
RH02 163 hp 120 kW 2 L Diesel
RHH 163 hp 120 kW 2 L Diesel
RHK 120 hp 88 kW 2 L Diesel
RHR 136 hp 100 kW 2 L Diesel
RH02 128 hp 94 kW 2 L Diesel
RH02 163 hp 120 kW 2 L Diesel
RHH 163 hp 120 kW 2 L Diesel
RHK 120 hp 88 kW 2 L Diesel
RHR 136 hp 100 kW 2 L Diesel
RH02 128 hp 94 kW 2 L Diesel
RHK 120 hp 88 kW 2 L Diesel
RHK 120 hp 88 kW 2 L Diesel
AWD / 4WD
Front wheel
LCV / Van / Cargo
MPV / Van / Minivan
With flatbed/undercarriage
PEUGEOT308 II
1.2 THP 110
1.2 THP 130
1.6 BlueHDi 120
1.6 GTi
2.0 BlueHDi 150
2013/11 - 150 hp 110 kW 2 L Diesel
250 hp 184 kW 1.6 L Petrol
5GN(EP6FDTR) 272 hp 200 kW 1.6 L Petrol
BHZ(DV6FC) 120 hp 88 kW 1.6 L Diesel
HNY(EB2DTS) 131 hp 96 kW 1.2 L Petrol
HNZ(EB2DT) 110 hp 81 kW 1.2 L Petrol
Front wheel
Hatchback / Sportback / Sport hatch
PEUGEOT308 SW II
1.2 THP 110
1.2 THP 130
1.6 BlueHDi 120
1.6 HDi 92
1.6 HDi / BlueHDi 115
1.6 THP 125
1.6 THP 155
1.6 VTi
2.0 BlueHDi 150
2014/03 - 115 hp 85 kW 1.6 L Petrol
125 hp 92 kW 1.6 L Petrol
150 hp 110 kW 2 L Diesel
5FV(EP6DT) 156 hp 115 kW 1.6 L Petrol
92 hp 68 kW 1.6 L Diesel
9HC(DV6C) 115 hp 85 kW 1.6 L Diesel
BHZ(DV6FC) 115 hp 85 kW 1.6 L Diesel
BHZ(DV6FC) 120 hp 88 kW 1.6 L Diesel
HNY(EB2DTS) 131 hp 96 kW 1.2 L Petrol
HNZ(EB2DT) 110 hp 81 kW 1.2 L Petrol
Front wheel
Estate / Turnier / Vario / Wagon
PEUGEOT407
6C
6D
2.0 HDi
2010/02 - RHE(DW10CTED4) 150 hp 110 kW 2 L Diesel
Front wheel
Coupe / Sports car / Grand tourer / Speedster / Roadster
Sedan / Saloon
PEUGEOT407 SW
6E
2.0 HDi
2008/08 - RHE(DW10CTED4) 150 hp 110 kW 2 L Diesel
RHR(DW10BTED4) 140 hp 103 kW 2 L Diesel
Front wheel
Estate / Turnier / Vario / Wagon
PEUGEOT508
1.6
1.6 BlueHDi 120
1.6 HDi
2.0 BlueHDi 150
2.0 BlueHDi 180
2011/09 - 165 hp 121 kW 1.6 L Petrol
5GZ(EP6FDT) 163 hp 120 kW 1.6 L Petrol
AHW(DW10FC) 180 hp 133 kW 2 L Diesel
AHX(DW10FD) 150 hp 110 kW 2 L Diesel
BHX(DV6FC) 116 hp 85 kW 1.6 L Diesel
BHZ(DV6FC) 120 hp 88 kW 1.6 L Diesel
Front wheel
Sedan / Saloon
PEUGEOT508 SW
1.6
1.6 BlueHDi 120
1.6 HDi
2.0 BlueHDi 150
2.0 BlueHDi 180
2.0 HDi 180 RXH
2012/02 - 165 hp 121 kW 1.6 L Petrol
181 hp 133 kW 2 L Hybrid
AHW(DW10FC) 180 hp 133 kW 2 L Diesel
AHX(DW10FD) 150 hp 110 kW 2 L Diesel
BHX(DV6FC) 116 hp 85 kW 1.6 L Diesel
BHZ(DV6FC) 120 hp 88 kW 1.6 L Diesel
Front wheel
Estate / Turnier / Vario / Wagon
PEUGEOTEXPERT

VF3A
VF3U
VF3X
1.6 HDi 90
1.6 HDi 90 16V
1.6 HDi 90 8V
2.0 16V
2.0 HDi 100
2.0 HDi 120
2.0 HDi 120 4x4
2.0 HDi 130
2.0 HDi 140
2.0 HDi 165
2007/01 - 98 hp 72 kW 2 L Diesel
9HH(DV6DUM) 90 hp 66 kW 1.6 L Diesel
9HM(DV6UC) 90 hp 66 kW 1.6 L Diesel
9HU(DV6UTED4) 90 hp 66 kW 1.6 L Diesel
AHZ(DW10CD) 128 hp 94 kW 2 L Diesel
RFH(EW10A) 140 hp 103 kW 2 L Petrol
RFJ(EW10A) 140 hp 103 kW 2 L Petrol
RHH(DW10CTED4) 163 hp 120 kW 2 L Diesel
RHK(DW10UTED4) 120 hp 88 kW 2 L Diesel
RHR(DW10BTED4) 136 hp 100 kW 2 L Diesel
AWD / 4WD
Front wheel
LCV / Van / Cargo
With flatbed/undercarriage
PEUGEOTEXPERT TEPEE
VF3V
1.6 HDi 90 16V
1.6 HDi 90 8V
2.0 16V
2.0 HDi 100
2.0 HDi 120
2.0 HDi 120 4x4
2.0 HDi 130
2.0 HDi 140
2.0 HDi 165
2007/01 - 9HH(DV6DUM) 90 hp 66 kW 1.6 L Diesel
9HM(DV6UC) 90 hp 66 kW 1.6 L Diesel
9HU(DV6UTED4) 90 hp 66 kW 1.6 L Diesel
AHY(DW10CE) 98 hp 72 kW 2 L Diesel
AHZ(DW10CD) 128 hp 94 kW 2 L Diesel
RFH(EW10A) 140 hp 103 kW 2 L Petrol
RFJ(EW10A) 140 hp 103 kW 2 L Petrol
RHH(DW10CTED4) 163 hp 120 kW 2 L Diesel
RHK(DW10UTED4) 120 hp 88 kW 2 L Diesel
RHR(DW10BTED4) 136 hp 100 kW 2 L Diesel
AWD / 4WD
Front wheel
MPV / Van / Minivan
TOYOTAPROACE
1.6 D-4D
2.0 D-4D
2013/06 - 3WZ-TV 90 hp 66 kW 1.6 L Diesel
4WZ-FHV 163 hp 120 kW 2 L Diesel
4WZ-FTV 128 hp 94 kW 2 L Diesel
Front wheel
LCV / Van / Cargo / Small truck
