NK 203736 Brake Disc

NK part 203736 Brake Disc
NK part 203736 Brake Disc
NK part 203736 Brake Disc

NK 203736 Brake Disc

by NK

Manufacturer Part Number: 203736

Сharacteristics:
  • Brake Disc Type: Solid
  • Weight [kg]: 5,7
  • Rim Hole Number: 5
  • Weight [kg]: 5,72
  • Diameter [mm]: 290
  • Height [mm]: 49,7
  • Brake Disc Thickness [mm]: 14
  • Minimum thickness [mm]: 13
  • Centering Diameter [mm]: 71

Product Details

BrandNK
NK article (MPN)203736
Vehicle subsystemBrake System

Original (OEM) part numbers

Suitable for CITROEN / PEUGEOT, FIAT / LANCIA / ALFA, TOYOTA vehicles

OE manufacturerOEM reference numbers
CITROEN / PEUGEOT424923, 424991, 424922
FIAT / LANCIA / ALFA9467548487
TOYOTASU001A1062

Aftermarket cross reference / interchange guide

The aftermarket competitive interchanges for NK 203736 Brake Disc offered by A.B.S., ATE, BLUE PRINT, BORG & BECK, BOSCH, Brake ENGINEERING, BREMBO, BREMSI, CIFAM, DELPHI, EUROBRAKE, FERODO, FIRST LINE, fri.tech., FTE, GIRLING, HANS PRIES, HELLA, HELLA PAGID, JP GROUP, JURID, MAPCO, MAXGEAR, METELLI, METZGER, MEYLE, MGA, MINTEX, NATIONAL, NK, OPTIMAL, PAGID, QUINTON HAZELL, ROTINGER, SASIC, sbs, STARLINE, TEMPLIN, TEXTAR, TRISCAN, TRUSTING, TRW, VAICO, VALEO, WAGNER LOCKHEED, ZIMMERMANN manufacturers

ManufacturerReference numbers
A.B.S.17774
ATE24.0114-0116.1
BLUE PRINTADT343300
BORG & BECKBBD4667
BOSCH0986479379
Brake ENGINEERINGDI956685
BREMBO08.A456.10
BREMSIDBB589V
CIFAM800888C
DELPHIBG4085
EUROBRAKE5815203736
FERODODDF1589C, DDF1589, DDF1589C1, DDF15891
FIRST LINEFBD1751
fri.tech.BD1178
FTEBS7210, BS7210B
GIRLING6049454
HANS PRIES722487
HELLA8DD355113681
HELLA PAGID8DD355113-681
JP GROUP4163200809
JURID562578JC
MAPCO15335
MAXGEAR191878
METELLI230888C
METZGER6105300, 6110422
MEYLE2155230029
MGAD1710
MINTEXMDC1836
NATIONALNBD1440
NK313736
OPTIMALBS-8410
PAGID54571
QUINTON HAZELLBDC5591
ROTINGERRT1746, RT1746T5
SASIC6100015
sbs1815313736, 1815203736
STARLINEPB1746C
TEMPLIN0311080350
TEXTAR92157100
TRISCAN8120101013
TRUSTINGDF1178
TRWDF4945, DF6046
VAICOV4240007
VALEO197099
WAGNER LOCKHEEDWGR15891
ZIMMERMANN440311800, 440311820

Vehicle fitment / NK 203736 Brake Disc compatibility

This product fits the following models: CITROËN DISPATCH, CITROËN JUMPY, FIAT SCUDO, PEUGEOT EXPERT, PEUGEOT EXPERT TEPEE, TOYOTA PROACE, etc. See all vehicles this product (NK 203736) fits below to verify fitment for your vehicle.
MakeModelVariantPeriodEngineDriveBody Style
CITROËNDISPATCH
1.6 HDi 90 16V
1.6 HDi 90 8V
2.0 HDi 120
2.0 HDi 120 4x4
2.0 HDi 125
2.0 HDi 140
2.0 HDi 165
2.0 HDi 95
2.0 i
2007/01 - 128 hp 94 kW 2 L Diesel
9HH(DV6DUM) 90 hp 66 kW 1.6 L Diesel
9HM(DV6UC) 90 hp 66 kW 1.6 L Diesel
9HU(DV6UTED4) 90 hp 66 kW 1.6 L Diesel
AHY(DW10CE) 98 hp 72 kW 2 L Diesel
AHZ(DW10CD) 128 hp 94 kW 2 L Diesel
RFH(EW10A) 140 hp 103 kW 2 L Petrol
RHH(DW10CTED4) 163 hp 120 kW 2 L Diesel
RHK(DW10UTED4) 120 hp 88 kW 2 L Diesel
RHR(DW10BTED4) 136 hp 100 kW 2 L Diesel
AWD / 4WD
Front wheel
LCV / Van / Cargo
MPV / Van / Minivan
With flatbed/undercarriage
CITROËNJUMPY
1.6 HDi 90 16V
1.6 HDi 90 8V
2.0 HDi 120
2.0 HDi 120 4x4
2.0 HDi 125
2.0 HDi 140
2.0 HDi 165
2.0 HDi 95
2.0 i
2007/01 - 128 hp 94 kW 2 L Diesel
9HH(DV6DUM) 90 hp 66 kW 1.6 L Diesel
9HM(DV6UC) 90 hp 66 kW 1.6 L Diesel
9HU(DV6UTED4) 90 hp 66 kW 1.6 L Diesel
AHY(DW10CE) 98 hp 72 kW 2 L Diesel
AHZ(DW10CD) 128 hp 94 kW 2 L Diesel
RFH(EW10A) 140 hp 103 kW 2 L Petrol
RHH(DW10CTED4) 163 hp 120 kW 2 L Diesel
RHK(DW10UTED4) 120 hp 88 kW 2 L Diesel
RHR(DW10BTED4) 136 hp 100 kW 2 L Diesel
AWD / 4WD
Front wheel
LCV / Van / Cargo
MPV / Van / Minivan
With flatbed/undercarriage
FIATSCUDO
272
270
1.6 D Multijet
2.0 D Multijet
2.0 D Multijet 4x4
2007/01 - 9HU 90 hp 66 kW 1.6 L Diesel
DW10BTED4 136 hp 100 kW 2 L Diesel
RH02 128 hp 94 kW 2 L Diesel
RH02 163 hp 120 kW 2 L Diesel
RHH 163 hp 120 kW 2 L Diesel
RHK 120 hp 88 kW 2 L Diesel
RHR 136 hp 100 kW 2 L Diesel
RH02 128 hp 94 kW 2 L Diesel
RH02 163 hp 120 kW 2 L Diesel
RHH 163 hp 120 kW 2 L Diesel
RHK 120 hp 88 kW 2 L Diesel
RHR 136 hp 100 kW 2 L Diesel
RH02 128 hp 94 kW 2 L Diesel
RHK 120 hp 88 kW 2 L Diesel
RHK 120 hp 88 kW 2 L Diesel
AWD / 4WD
Front wheel
LCV / Van / Cargo
MPV / Van / Minivan
With flatbed/undercarriage
PEUGEOTEXPERT

VF3A
VF3U
VF3X
1.6 HDi 90
1.6 HDi 90 16V
1.6 HDi 90 8V
2.0 16V
2.0 HDi 100
2.0 HDi 120
2.0 HDi 120 4x4
2.0 HDi 130
2.0 HDi 140
2.0 HDi 165
2007/01 - 98 hp 72 kW 2 L Diesel
9HH(DV6DUM) 90 hp 66 kW 1.6 L Diesel
9HM(DV6UC) 90 hp 66 kW 1.6 L Diesel
9HU(DV6UTED4) 90 hp 66 kW 1.6 L Diesel
AHZ(DW10CD) 128 hp 94 kW 2 L Diesel
RFH(EW10A) 140 hp 103 kW 2 L Petrol
RFJ(EW10A) 140 hp 103 kW 2 L Petrol
RHH(DW10CTED4) 163 hp 120 kW 2 L Diesel
RHK(DW10UTED4) 120 hp 88 kW 2 L Diesel
RHR(DW10BTED4) 136 hp 100 kW 2 L Diesel
AWD / 4WD
Front wheel
LCV / Van / Cargo
With flatbed/undercarriage
PEUGEOTEXPERT TEPEE
VF3V
1.6 HDi 90 16V
1.6 HDi 90 8V
2.0 16V
2.0 HDi 100
2.0 HDi 120
2.0 HDi 120 4x4
2.0 HDi 130
2.0 HDi 140
2.0 HDi 165
2007/01 - 9HH(DV6DUM) 90 hp 66 kW 1.6 L Diesel
9HM(DV6UC) 90 hp 66 kW 1.6 L Diesel
9HU(DV6UTED4) 90 hp 66 kW 1.6 L Diesel
AHY(DW10CE) 98 hp 72 kW 2 L Diesel
AHZ(DW10CD) 128 hp 94 kW 2 L Diesel
RFH(EW10A) 140 hp 103 kW 2 L Petrol
RFJ(EW10A) 140 hp 103 kW 2 L Petrol
RHH(DW10CTED4) 163 hp 120 kW 2 L Diesel
RHK(DW10UTED4) 120 hp 88 kW 2 L Diesel
RHR(DW10BTED4) 136 hp 100 kW 2 L Diesel
AWD / 4WD
Front wheel
MPV / Van / Minivan
TOYOTAPROACE
1.6 D-4D
2.0 D-4D
2013/06 - 3WZ-TV 90 hp 66 kW 1.6 L Diesel
4WZ-FHV 163 hp 120 kW 2 L Diesel
4WZ-FTV 128 hp 94 kW 2 L Diesel
Front wheel
LCV / Van / Cargo / Small truck
