QUINTON HAZELL QCP3620HP Water Pump
QUINTON HAZELL QCP3620HP Water Pump
by QUINTON HAZELLManufacturer Part Number: QCP3620HP
- Water Pump Type: for toothed belt drive
- Reinforced Version:
- This product must be fitted and used in accordance with vehi cle manufacturers manual.
- When fitting the water pump QCP3620 (20 teeth pulley) in replacement of the water pump with 18 teeth, the teeth pulley on the camshaft (OE number 023109111D) must also be replaced on petrol-driven engine. This is a VW instruction and is also valid for the original pump.
- When a waterpump is replaced, Quinton Hazell recommends the renewal of the timing belt or multirib belt.
Product Details
| Brand | QUINTON HAZELL |
| QUINTON HAZELL article (MPN) | QCP3620HP |
| Vehicle subsystem | Cooling System |
Original (OEM) part numbers
Suitable for VAG, VOLVO vehicles
| OE manufacturer | OEM reference numbers |
|---|---|
| VAG | 046121004D*, 046121004DX*, 074121004, 074121004A, 074121004AV, 074121004AX, 074121004F*, 074121004FX*, 074121004V, 074121004X, 074121005M*, 074121005MV*, 074121005MX*, 074121005N, 074121005NV*, 074121005NX, 074121005NY, 076121005*, 076121005A, 076121005AX* |
| VOLVO | 2717684, 274155 |
Aftermarket cross reference / interchange guide
The aftermarket competitive interchanges for QUINTON HAZELL QCP3620HP Water Pump offered by AIRTEX, AUTOMEGA, BEHR HELLA SERVICE, BORG & BECK, CAR, CIFAM, FEBI BILSTEIN, FENOX, GRAF, HANS PRIES, HELLA, HEPU, HUTCHINSON, JP GROUP, KAGER, KEY PARTS, KWP, LPR, METELLI, MEYLE, MGA, OPEN PARTS, OPTIMAL, RUVILLE, STARLINE, SWAG, TRISCAN, VALEO, WILMINK GROUP manufacturers
| Manufacturer | Reference numbers |
|---|---|
| AIRTEX | 9274R |
| AUTOMEGA | 301210005074N, 301210004046D |
| BEHR HELLA SERVICE | 8MP376800281 |
| BORG & BECK | BWP1710, BWP1515 |
| CAR | 330523 |
| CIFAM | 824758 |
| FEBI BILSTEIN | 22206, 22256, 09518, 02086 |
| FENOX | HB1247, HB1219 |
| GRAF | PA758 |
| HANS PRIES | 101575 |
| HELLA | 8MP376800-281 |
| HEPU | P574, PK05748, PK05747 |
| HUTCHINSON | WP148 |
| JP GROUP | 1114110409 |
| KAGER | 330423 |
| KEY PARTS | KCP1710, KCP1515 |
| KWP | 10758 |
| LPR | WP0289 |
| METELLI | 240758 |
| MEYLE | 1132200022 |
| MGA | PA758, W758 |
| OPEN PARTS | WAP832500 |
| OPTIMAL | AQ1085 |
| RUVILLE | 65426 |
| STARLINE | VPSK112 |
| SWAG | 30150017, 32150005, 30922206 |
| TRISCAN | 860029025 |
| VALEO | 506488 |
| WILMINK GROUP | WG1097007 |
Vehicle fitment / QUINTON HAZELL QCP3620HP Water Pump compatibility
This product fits the following models: AUDI 100, AUDI A6, VW CRAFTER 30-35, VW CRAFTER 30-50, VW EURO CARAVELLE IV, VW EURO IV, VW LT 28-35 I, VW LT 28-35 II, VW LT 28-46 II, VW LT28-50 , VW LT 40-55 I, VW LTII, VW TRANER CARAVELLEIV, VW TRANER CARAVELLE IV, VW TRANER IV, VW TRANERIV, VW TRANER MULTI IV, VW TRANER T4, etc. See all vehicles this product (QUINTON HAZELL QCP3620HP) fits below to verify fitment for your vehicle.| Make | Model | Variant | Period | Engine | Drive | Body Style |
|---|---|---|---|---|---|---|
| AUDI | 100 4A C4 | 2.4 D 2.5 TDI | 1990/12 - 1994/06 | AAS 82 hp 60 kW 2.4 L Diesel AAT 115 hp 85 kW 2.5 L Diesel ABP 115 hp 85 kW 2.5 L Diesel | Front wheel | Estate / Turnier / Vario / Wagon Sedan / Saloon |
| AUDI | A6 4A C4 | 2.5 TDI 2.5 TDI quattro | 1994/06 - 1997/12 | AAT 114 hp 84 kW 2.5 L Diesel AAT 116 hp 85 kW 2.5 L Diesel AEL 140 hp 103 kW 2.5 L Diesel AEL 140 hp 103 kW 2.5 L Diesel | AWD / 4WD Front wheel | Estate / Turnier / Vario / Wagon Sedan / Saloon |
| VW | CRAFTER 30-35 2E | 2.5 TDI | 2006/04 - | BJJ 88 hp 65 kW 2.5 L Diesel BJK 109 hp 80 kW 2.5 L Diesel BJL 136 hp 100 kW 2.5 L Diesel BJM 163 hp 120 kW 2.5 L Diesel CEBA 88 hp 65 kW 2.5 L Diesel CEBB 109 hp 80 kW 2.5 L Diesel CECA 136 hp 100 kW 2.5 L Diesel CECB 163 hp 120 kW 2.5 L Diesel | Rear wheel | Passenger Van / Wagon / Minibus |
| VW | CRAFTER 30-50 2E 2F | 2.5 TDI | 2006/04 - | BJJ 88 hp 65 kW 2.5 L Diesel BJK 109 hp 80 kW 2.5 L Diesel BJL 136 hp 100 kW 2.5 L Diesel BJM 163 hp 120 kW 2.5 L Diesel CEBA 88 hp 65 kW 2.5 L Diesel CEBB 109 hp 80 kW 2.5 L Diesel CECA 136 hp 100 kW 2.5 L Diesel CECB 163 hp 120 kW 2.5 L Diesel | Rear wheel | LCV / Van / Cargo With flatbed/undercarriage |
| VW | EURO CARAVELLE IV 70XB 70XC 7DB 7DW 7DK | 2.4 D 2.4 D Syncro 2.5 2.5 Syncro 2.5 TDI 2.5 TDI Syncro | 1990/09 - 2003/04 | AAB 78 hp 57 kW 2.4 L Diesel AAB 78 hp 57 kW 2.4 L Diesel AJA 75 hp 55 kW 2.4 L Diesel AAF 110 hp 81 kW 2.5 L Petrol ACU 110 hp 81 kW 2.5 L Petrol AEN 110 hp 81 kW 2.5 L Petrol AET 115 hp 85 kW 2.5 L Petrol AEU 110 hp 81 kW 2.5 L Petrol APL 115 hp 85 kW 2.5 L Petrol AVT 115 hp 85 kW 2.5 L Petrol ACV 102 hp 75 kW 2.5 L Diesel AHY 151 hp 111 kW 2.5 L Diesel AJT 88 hp 65 kW 2.5 L Diesel AUF 102 hp 75 kW 2.5 L Diesel AXG 151 hp 111 kW 2.5 L Diesel AYC 102 hp 75 kW 2.5 L Diesel AYY 88 hp 65 kW 2.5 L Diesel ACV 102 hp 75 kW 2.5 L Diesel AXL 102 hp 75 kW 2.5 L Diesel | AWD / 4WD Front wheel | Passenger Van / Wagon / Minibus |
| VW | EURO IV 70XA | 2.4 D 2.4 D Syncro 2.5 2.5 Syncro 2.5 TDI 2.5 TDI Syncro | 1990/07 - 2003/04 | AAB 78 hp 57 kW 2.4 L Diesel AAB 78 hp 57 kW 2.4 L Diesel AJA 75 hp 55 kW 2.4 L Diesel AAF 110 hp 81 kW 2.5 L Petrol ACU 110 hp 81 kW 2.5 L Petrol AEN 110 hp 81 kW 2.5 L Petrol AET 115 hp 85 kW 2.5 L Petrol AEU 110 hp 81 kW 2.5 L Petrol APL 115 hp 85 kW 2.5 L Petrol AVT 115 hp 85 kW 2.5 L Petrol ACV 102 hp 75 kW 2.5 L Diesel AJT 88 hp 65 kW 2.5 L Diesel AUF 102 hp 75 kW 2.5 L Diesel AXG 151 hp 111 kW 2.5 L Diesel AYC 102 hp 75 kW 2.5 L Diesel AYY 88 hp 65 kW 2.5 L Diesel ACV 102 hp 75 kW 2.5 L Diesel AXL 102 hp 75 kW 2.5 L Diesel | AWD / 4WD Front wheel | LCV / Van / Cargo |
| VW | LT 28-35 I 281-363 | 2.4 D 2.4 TD 2.4 TD Syncro | 1989/08 - 1996/06 | 1S 69 hp 51 kW 2.4 L Diesel ACT 69 hp 51 kW 2.4 L Diesel 1S 70 hp 51 kW 2.4 L Diesel ACT 70 hp 51 kW 2.4 L Diesel ACL 95 hp 70 kW 2.4 L Diesel | AWD / 4WD Rear wheel | LCV / Van / Cargo Passenger Van / Wagon / Minibus With flatbed/undercarriage |
| VW | LT 28-35 II 2DB 2DE 2DK | 2.5 SDI 2.5 TDI | 1996/05 - 2006/07 | AGX 75 hp 55 kW 2.5 L Diesel AHD 102 hp 75 kW 2.5 L Diesel ANJ 109 hp 80 kW 2.5 L Diesel APA 90 hp 66 kW 2.5 L Diesel AVR 109 hp 80 kW 2.5 L Diesel BBE 83 hp 61 kW 2.5 L Diesel BBF 95 hp 70 kW 2.5 L Diesel | Rear wheel | Passenger Van / Wagon / Minibus |
| VW | LT 28-46 II 2DA 2DD 2DH 2DC 2DF 2 | 2.5 SDI 2.5 TDI | 1996/05 - 2006/07 | AGX 75 hp 55 kW 2.5 L Diesel AHD 102 hp 75 kW 2.5 L Diesel ANJ 109 hp 80 kW 2.5 L Diesel APA 90 hp 66 kW 2.5 L Diesel AVR 109 hp 80 kW 2.5 L Diesel BBE 83 hp 61 kW 2.5 L Diesel BBF 95 hp 70 kW 2.5 L Diesel | Rear wheel | LCV / Van / Cargo With flatbed/undercarriage |
| VW | LT28-50 281-363 | 2.4 D 2.4 TD 2.4 TD Syncro | 1989/08 - 1996/06 | 1S 69 hp 51 kW 2.4 L Diesel ACT 69 hp 51 kW 2.4 L Diesel 1S 70 hp 51 kW 2.4 L Diesel ACT 70 hp 51 kW 2.4 L Diesel ACL 95 hp 70 kW 2.4 L Diesel | AWD / 4WD Rear wheel | LCV / Van / Cargo Passenger Van / Wagon / Minibus With flatbed/undercarriage |
| VW | LT 40-55 I 291-512 293-909 | 2.4 D 2.4 TD 2.4 TD Syncro | 1990/07 - 1996/06 | 1S 69 hp 51 kW 2.4 L Diesel ACT 69 hp 51 kW 2.4 L Diesel ACL 95 hp 70 kW 2.4 L Diesel | AWD / 4WD Rear wheel | LCV / Van / Cargo With flatbed/undercarriage |
| VW | LTII 2DA 2DD 2DH 2DB 2DE 2DK 2DC 2DF 2DG | 2.5 SDI 2.5 TDI | 1996/05 - 2006/07 | AGX 75 hp 55 kW 2.5 L Diesel AHD 102 hp 75 kW 2.5 L Diesel ANJ 109 hp 80 kW 2.5 L Diesel APA 90 hp 66 kW 2.5 L Diesel AVR 109 hp 80 kW 2.5 L Diesel BBE 83 hp 61 kW 2.5 L Diesel BBF 95 hp 70 kW 2.5 L Diesel | Rear wheel | LCV / Van / Cargo Passenger Van / Wagon / Minibus With flatbed/undercarriage |
| VW | TRANER CARAVELLEIV 70XB 70XC 7DB 7DW | 2.4 D 2.4 D Syncro 2.5 2.5 Syncro 2.5 TDI 2.5 TDI Syncro | 1990/09 - 2003/04 | AAB 78 hp 57 kW 2.4 L Diesel AAB 78 hp 57 kW 2.4 L Diesel AJA 75 hp 55 kW 2.4 L Diesel AAF 110 hp 81 kW 2.5 L Petrol ACU 110 hp 81 kW 2.5 L Petrol AEN 110 hp 81 kW 2.5 L Petrol AET 115 hp 85 kW 2.5 L Petrol AEU 110 hp 81 kW 2.5 L Petrol APL 115 hp 85 kW 2.5 L Petrol AVT 115 hp 85 kW 2.5 L Petrol ACV 102 hp 75 kW 2.5 L Diesel AHY 151 hp 111 kW 2.5 L Diesel AJT 88 hp 65 kW 2.5 L Diesel AUF 102 hp 75 kW 2.5 L Diesel AXG 151 hp 111 kW 2.5 L Diesel AYC 102 hp 75 kW 2.5 L Diesel AYY 88 hp 65 kW 2.5 L Diesel ACV 102 hp 75 kW 2.5 L Diesel AXL 102 hp 75 kW 2.5 L Diesel | AWD / 4WD Front wheel | Passenger Van / Wagon / Minibus |
| VW | TRANER CARAVELLE IV 70XB 70XC 7DB 7DW 7D | 2.4 D 2.4 D Syncro 2.5 2.5 Syncro 2.5 TDI 2.5 TDI Syncro | 1990/09 - 2003/04 | AAB 78 hp 57 kW 2.4 L Diesel AAB 78 hp 57 kW 2.4 L Diesel AJA 75 hp 55 kW 2.4 L Diesel AAF 110 hp 81 kW 2.5 L Petrol ACU 110 hp 81 kW 2.5 L Petrol AEN 110 hp 81 kW 2.5 L Petrol AET 115 hp 85 kW 2.5 L Petrol AEU 110 hp 81 kW 2.5 L Petrol APL 115 hp 85 kW 2.5 L Petrol AVT 115 hp 85 kW 2.5 L Petrol ACV 102 hp 75 kW 2.5 L Diesel AHY 151 hp 111 kW 2.5 L Diesel AJT 88 hp 65 kW 2.5 L Diesel AUF 102 hp 75 kW 2.5 L Diesel AXG 151 hp 111 kW 2.5 L Diesel AYC 102 hp 75 kW 2.5 L Diesel AYY 88 hp 65 kW 2.5 L Diesel ACV 102 hp 75 kW 2.5 L Diesel AXL 102 hp 75 kW 2.5 L Diesel | AWD / 4WD Front wheel | Passenger Van / Wagon / Minibus |
| VW | TRANER IV 70XA 70XB 70XC 7DB 7DW 7DK 70XD | 2.4 D 2.4 D Syncro 2.5 2.5 Syncro 2.5 TDI 2.5 TDI Syncro | 1990/07 - 2003/04 | AAB 78 hp 57 kW 2.4 L Diesel AAB 78 hp 57 kW 2.4 L Diesel AJA 75 hp 55 kW 2.4 L Diesel AAF 110 hp 81 kW 2.5 L Petrol ACU 110 hp 81 kW 2.5 L Petrol AEN 110 hp 81 kW 2.5 L Petrol AET 115 hp 85 kW 2.5 L Petrol AEU 110 hp 81 kW 2.5 L Petrol APL 115 hp 85 kW 2.5 L Petrol AVT 115 hp 85 kW 2.5 L Petrol ACV 102 hp 75 kW 2.5 L Diesel AHY 151 hp 111 kW 2.5 L Diesel AJT 88 hp 65 kW 2.5 L Diesel AUF 102 hp 75 kW 2.5 L Diesel AXG 151 hp 111 kW 2.5 L Diesel AYC 102 hp 75 kW 2.5 L Diesel AYY 88 hp 65 kW 2.5 L Diesel ACV 102 hp 75 kW 2.5 L Diesel AJT 88 hp 65 kW 2.5 L Diesel AUF 102 hp 75 kW 2.5 L Diesel AXG 151 hp 111 kW 2.5 L Diesel AYC 102 hp 75 kW 2.5 L Diesel AYY 88 hp 65 kW 2.5 L Diesel ACV 102 hp 75 kW 2.5 L Diesel AJT 88 hp 65 kW 2.5 L Diesel AUF 102 hp 75 kW 2.5 L Diesel AYC 102 hp 75 kW 2.5 L Diesel AYY 88 hp 65 kW 2.5 L Diesel ACV 102 hp 75 kW 2.5 L Diesel AXL 102 hp 75 kW 2.5 L Diesel | AWD / 4WD Front wheel | LCV / Van / Cargo Passenger Van / Wagon / Minibus With flatbed/undercarriage |
| VW | TRANERIV 70XA 70XD | 2.4 D 2.4 D Syncro 2.5 2.5 Syncro 2.5 TDI 2.5 TDI Syncro | 1990/07 - 2003/04 | AAB 78 hp 57 kW 2.4 L Diesel AAB 78 hp 57 kW 2.4 L Diesel AJA 75 hp 55 kW 2.4 L Diesel AAF 110 hp 81 kW 2.5 L Petrol ACU 110 hp 81 kW 2.5 L Petrol AEN 110 hp 81 kW 2.5 L Petrol AET 115 hp 85 kW 2.5 L Petrol AEU 110 hp 81 kW 2.5 L Petrol APL 115 hp 85 kW 2.5 L Petrol AVT 115 hp 85 kW 2.5 L Petrol ACV 102 hp 75 kW 2.5 L Diesel AJT 88 hp 65 kW 2.5 L Diesel AUF 102 hp 75 kW 2.5 L Diesel AXG 151 hp 111 kW 2.5 L Diesel AYC 102 hp 75 kW 2.5 L Diesel AYY 88 hp 65 kW 2.5 L Diesel ACV 102 hp 75 kW 2.5 L Diesel AJT 88 hp 65 kW 2.5 L Diesel AUF 102 hp 75 kW 2.5 L Diesel AYC 102 hp 75 kW 2.5 L Diesel AYY 88 hp 65 kW 2.5 L Diesel ACV 102 hp 75 kW 2.5 L Diesel AXL 102 hp 75 kW 2.5 L Diesel | AWD / 4WD Front wheel | LCV / Van / Cargo With flatbed/undercarriage |
| VW | TRANER MULTI IV 70XB 70XC 7DB 7DW 7DK | 2.4 D 2.4 D Syncro 2.5 2.5 Syncro 2.5 TDI 2.5 TDI Syncro | 1990/09 - 2003/04 | AAB 78 hp 57 kW 2.4 L Diesel AAB 78 hp 57 kW 2.4 L Diesel AJA 75 hp 55 kW 2.4 L Diesel AAF 110 hp 81 kW 2.5 L Petrol ACU 110 hp 81 kW 2.5 L Petrol AEN 110 hp 81 kW 2.5 L Petrol AET 115 hp 85 kW 2.5 L Petrol AEU 110 hp 81 kW 2.5 L Petrol APL 115 hp 85 kW 2.5 L Petrol AVT 115 hp 85 kW 2.5 L Petrol ACV 102 hp 75 kW 2.5 L Diesel AHY 151 hp 111 kW 2.5 L Diesel AJT 88 hp 65 kW 2.5 L Diesel AUF 102 hp 75 kW 2.5 L Diesel AXG 151 hp 111 kW 2.5 L Diesel AYC 102 hp 75 kW 2.5 L Diesel AYY 88 hp 65 kW 2.5 L Diesel ACV 102 hp 75 kW 2.5 L Diesel AXL 102 hp 75 kW 2.5 L Diesel | AWD / 4WD Front wheel | Passenger Van / Wagon / Minibus |
| VW | TRANER T4 70XA 70XB 70XC 7DB 7DW 7DK 70XD | 2.4 D 2.4 D Syncro 2.5 2.5 Syncro 2.5 TDI 2.5 TDI Syncro | 1990/07 - 2003/04 | AAB 78 hp 57 kW 2.4 L Diesel AAB 78 hp 57 kW 2.4 L Diesel AJA 75 hp 55 kW 2.4 L Diesel AAF 110 hp 81 kW 2.5 L Petrol ACU 110 hp 81 kW 2.5 L Petrol AEN 110 hp 81 kW 2.5 L Petrol AET 115 hp 85 kW 2.5 L Petrol AEU 110 hp 81 kW 2.5 L Petrol APL 115 hp 85 kW 2.5 L Petrol AVT 115 hp 85 kW 2.5 L Petrol ACV 102 hp 75 kW 2.5 L Diesel AHY 151 hp 111 kW 2.5 L Diesel AJT 88 hp 65 kW 2.5 L Diesel AUF 102 hp 75 kW 2.5 L Diesel AXG 151 hp 111 kW 2.5 L Diesel AYC 102 hp 75 kW 2.5 L Diesel AYY 88 hp 65 kW 2.5 L Diesel ACV 102 hp 75 kW 2.5 L Diesel AJT 88 hp 65 kW 2.5 L Diesel AUF 102 hp 75 kW 2.5 L Diesel AXG 151 hp 111 kW 2.5 L Diesel AYC 102 hp 75 kW 2.5 L Diesel AYY 88 hp 65 kW 2.5 L Diesel ACV 102 hp 75 kW 2.5 L Diesel AJT 88 hp 65 kW 2.5 L Diesel AUF 102 hp 75 kW 2.5 L Diesel AYC 102 hp 75 kW 2.5 L Diesel AYY 88 hp 65 kW 2.5 L Diesel ACV 102 hp 75 kW 2.5 L Diesel AXL 102 hp 75 kW 2.5 L Diesel | AWD / 4WD Front wheel | LCV / Van / Cargo Passenger Van / Wagon / Minibus With flatbed/undercarriage |
