REMSA 0836.02 (083602) Brake Pad Set, disc brake
REMSA 0836.02 (083602) Brake Pad Set, disc brake
by REMSAManufacturer Part Number: 0836.02 (083602)
Alternative REMSA part number(s): PCA083602, 23269, 23270, BPM0836.02
- Supplementary Article/Supplementary Info: with accessories
- Fitting Position: Front Axle
- Brake System: Ate-Teves
- Inspection Tag: E190R-01022/561
- Length [mm]: 161,4
- Height 1 [mm]: 72,8
- Height 2 [mm]: 74,5
- Thickness [mm]: 19,6
- Wear Warning Contact: incl. wear warning contact
- Number of wear indicators [per axle]: 2
- Warning Contact Length [mm]: 270
- Weight [kg]: 2,296
- Supplementary Article/Info 2: with adhesive film
- Supplementary Article/Supplementary Info: with spring
Product Details
| Brand | REMSA |
| REMSA article (MPN) | 0836.02 (083602) Alternative REMSA part number(s): PCA083602, 23269, 23270, BPM0836.02 |
| Vehicle subsystem | Brake System |
Original (OEM) part numbers
Suitable for FORD, VAG vehicles
| OE manufacturer | OEM reference numbers |
|---|---|
| FORD | 1133446, 1205696, 1237133, YM21K021BA, YM2J2K021BA, YM212K21BA |
| VAG | 7M3698151A |
Aftermarket cross reference / interchange guide
The aftermarket competitive interchanges for REMSA 0836.02 (083602) Brake Pad Set, disc brake offered by A.B.S., ACDelco, APEC braking, ATE, AUTOMEGA, BARUM, BENDIX, BOSCH, Brake ENGINEERING, BREMBO, BSF, CIFAM, DELPHI, DENCKERMANN, E.T.F., FEBI BILSTEIN, FENOX, FERODO, fri.tech., FTE, GALFER, GIRLING, GKN-SPIDAN, HANS PRIES, HELLA, HELLA PAGID, HP, ICER, JP GROUP, JURID, KAMOKA, KRAFT, LEMFÖRDER, LPR, MAGNETI MARELLI, MAPCO, MAXGEAR, METELLI, METZGER, MEYLE, MGA, MINTEX, MOTAQUIP, NECTO, NIBK, NK, OPTIMAL, PAGID, PATRON, PEX, PROCODIS FRANCE, PROTECHNIC, QUINTON HAZELL, REMSA, ROADHOUSE, ROULUNDS RUBBER, sbs, STELLOX, SWAG, TEXTAR, TRISCAN, TRUSTING, TRW, VAICO, VALEO, WAGNER LOCKHEED, WOKING, ZIMMERMANN manufacturers
| Manufacturer | Reference numbers |
|---|---|
| A.B.S. | 37240, 37240OE |
| ACDelco | AC601781D |
| APEC braking | PAD1184 |
| ATE | 13.0460-7153.2 |
| AUTOMEGA | 3069801517M3A, 3169801517M3A |
| BARUM | BA2318 |
| BENDIX | 573047B, 573047 |
| BOSCH | 0986494035, 0986424777 |
| Brake ENGINEERING | PA1339 |
| BREMBO | P85061 |
| BSF | 10553 |
| CIFAM | 8225510 |
| DELPHI | LP1801 |
| DENCKERMANN | B111103 |
| E.T.F. | 121076 |
| FEBI BILSTEIN | 16629 |
| FENOX | BP43113 |
| FERODO | FQT1497, FDB1497, FVR1497 |
| fri.tech. | 5670 |
| FTE | BL1774A2 |
| GALFER | 23.075.00, B1G10205802 |
| GIRLING | 6114602 |
| GKN-SPIDAN | 32476 |
| HANS PRIES | 109467 |
| HELLA | 8DB355008921 |
| HELLA PAGID | 8DB355008921 |
| HP | 7354 |
| ICER | 181395 |
| JP GROUP | 1163604310, 698373002, 1163604319 |
| JURID | 573047J-AS, 573047J |
| KAMOKA | JQ101198 |
| KRAFT | 6000327 |
| LEMFÖRDER | 2647001 |
| LPR | 05P971 |
| MAGNETI MARELLI | 363702161228, 363700201195, 363702161212 |
| MAPCO | 6553 |
| MAXGEAR | 190665 |
| METELLI | 2205510 |
| METZGER | 083602, 1170342 |
| MEYLE | 0252326920PD, 0252326920/W |
| MGA | 668 |
| MINTEX | MDB2126 |
| MOTAQUIP | LVXL1043 |
| NECTO | FD7015V, FD7015A |
| NIBK | PN0224W |
| NK | 224769, 224754 |
| OPTIMAL | 83602 |
| PAGID | T1195 |
| PATRON | PBP1497 |
| PEX | 7613 |
| PROCODIS FRANCE | PF1256 |
| PROTECHNIC | PRP04213M, PRP0421 |
| QUINTON HAZELL | BP1313, MBP1313, 7354 |
| REMSA | D880ES7757, D8807757, BPM0836.02 |
| ROADHOUSE | 283602 |
| ROULUNDS RUBBER | 601781 |
| sbs | 1501224754 |
| STELLOX | 847002BSX |
| SWAG | 30916629 |
| TEXTAR | 2367916104T4047, 2326920105, 2326903 |
| TRISCAN | 811010525 |
| TRUSTING | 567.0 |
| TRW | GDB1460 |
| VAICO | V108151 |
| VALEO | 597375, 301565, 598565 |
| WAGNER LOCKHEED | WBP23269B |
| WOKING | P9363.02 |
| ZIMMERMANN | 23269.195.1 |
Vehicle fitment / REMSA 0836.02 (083602) Brake Pad Set, disc brake compatibility
This product fits the following models: FORD GALAXY, SEAT ALHAMBRA, VW EURO CARAVELLE IV, VW EURO IV, VW SHARAN, VW TRANER CARAVELLEIV, VW TRANER CARAVELLE IV, VW TRANER IV, VW TRANERIV, VW TRANER MULTI IV, VW TRANER T4, etc. See all vehicles this product (REMSA 0836.02 (083602)) fits below to verify fitment for your vehicle.| Make | Model | Variant | Period | Engine | Drive | Body Style |
|---|---|---|---|---|---|---|
| FORD | GALAXY WGR | 1.9 TDI 2.0 i 2.3 16V 2.8 V6 | 1995/11 - 2006/05 | ASZ 130 hp 96 kW 1.9 L Diesel AUY 115 hp 85 kW 1.9 L Diesel BTB 150 hp 110 kW 1.9 L Diesel AYL 204 hp 150 kW 2.8 L Petrol E5SA 146 hp 107 kW 2.3 L Petrol E5SB 140 hp 103 kW 2.3 L Petrol Y5B 146 hp 107 kW 2.3 L Petrol NSE 116 hp 85 kW 2 L Petrol ZVSA 116 hp 85 kW 2 L Petrol | Front wheel | MPV / Van / Minivan |
| SEAT | ALHAMBRA 7V8 7V9 | 1.8 T 20V 1.9 TDI 1.9 TDI 4motion 1.9 Tdi 4x4 2.0 i 2.0 TDI 2.8 V6 2.8 V6 4motion | 1996/04 - 2010/03 | ADY 115 hp 85 kW 2 L Petrol ATM 115 hp 85 kW 2 L Petrol AJH 150 hp 110 kW 1.8 L Petrol AWC 150 hp 110 kW 1.8 L Petrol ASZ 131 hp 96 kW 1.9 L Diesel ASZ 131 hp 96 kW 1.9 L Diesel AUY 115 hp 85 kW 1.9 L Diesel BTB 150 hp 110 kW 1.9 L Diesel BVK 115 hp 85 kW 1.9 L Diesel AUE 204 hp 150 kW 2.8 L Petrol AYL 204 hp 150 kW 2.8 L Petrol AUY 115 hp 85 kW 1.9 L Diesel BVK 115 hp 85 kW 1.9 L Diesel BRT 140 hp 103 kW 2 L Diesel | AWD / 4WD Front wheel | MPV / Van / Minivan |
| VW | EURO CARAVELLE IV 70XB 70XC 7DB 7DW 7DK | 2.4 D Syncro 2.5 Syncro 2.5 TDI 2.5 TDI Syncro 2.8 VR 6 2.8 VR6 | 1992/10 - 2003/04 | AAB 78 hp 57 kW 2.4 L Diesel AAF 110 hp 81 kW 2.5 L Petrol ACU 110 hp 81 kW 2.5 L Petrol AEN 110 hp 81 kW 2.5 L Petrol AET 115 hp 85 kW 2.5 L Petrol AEU 110 hp 81 kW 2.5 L Petrol APL 115 hp 85 kW 2.5 L Petrol AVT 115 hp 85 kW 2.5 L Petrol ACV 102 hp 75 kW 2.5 L Diesel AXL 102 hp 75 kW 2.5 L Diesel AES 140 hp 103 kW 2.8 L Petrol AHY 151 hp 111 kW 2.5 L Diesel AXG 151 hp 111 kW 2.5 L Diesel AMV 204 hp 150 kW 2.8 L Petrol | AWD / 4WD Front wheel | Passenger Van / Wagon / Minibus |
| VW | EURO IV 70XA | 2.4 D Syncro 2.5 Syncro 2.5 TDI 2.5 TDI Syncro 2.8 VR6 | 1992/10 - 2003/04 | AAB 78 hp 57 kW 2.4 L Diesel AAF 110 hp 81 kW 2.5 L Petrol ACU 110 hp 81 kW 2.5 L Petrol AEN 110 hp 81 kW 2.5 L Petrol AET 115 hp 85 kW 2.5 L Petrol AEU 110 hp 81 kW 2.5 L Petrol APL 115 hp 85 kW 2.5 L Petrol AVT 115 hp 85 kW 2.5 L Petrol ACV 102 hp 75 kW 2.5 L Diesel AXL 102 hp 75 kW 2.5 L Diesel AES 140 hp 103 kW 2.8 L Petrol AMV 204 hp 150 kW 2.8 L Petrol AXG 151 hp 111 kW 2.5 L Diesel | AWD / 4WD Front wheel | LCV / Van / Cargo |
| VW | SHARAN 7M8 7M9 7M6 | 1.8 T 20V 1.9 TDI 1.9 TDI 4motion 2.0 LPG 2.0 TDI 2.8 V6 24V 2.8 V6 24V 4motion 2.8 VR6 | 1995/09 - 2010/03 | AAA 174 hp 128 kW 2.8 L Petrol AMY 174 hp 128 kW 2.8 L Petrol AJH 150 hp 110 kW 1.8 L Petrol AWC 150 hp 110 kW 1.8 L Petrol ASZ 130 hp 96 kW 1.9 L Diesel AUY 115 hp 85 kW 1.9 L Diesel BTB 150 hp 110 kW 1.9 L Diesel BVK 115 hp 85 kW 1.9 L Diesel ATM 115 hp 85 kW 2 L Petrol AUY 115 hp 85 kW 1.9 L Diesel BVK 115 hp 85 kW 1.9 L Diesel AYL 204 hp 150 kW 2.8 L Petrol BRT 140 hp 103 kW 2 L Diesel | AWD / 4WD Front wheel | MPV / Van / Minivan |
| VW | TRANER CARAVELLEIV 70XB 70XC 7DB 7DW | 2.4 D Syncro 2.5 Syncro 2.5 TDI 2.5 TDI Syncro 2.8 VR 6 2.8 VR6 | 1992/10 - 2003/04 | AAB 78 hp 57 kW 2.4 L Diesel AAF 110 hp 81 kW 2.5 L Petrol ACU 110 hp 81 kW 2.5 L Petrol AEN 110 hp 81 kW 2.5 L Petrol AET 115 hp 85 kW 2.5 L Petrol AEU 110 hp 81 kW 2.5 L Petrol APL 115 hp 85 kW 2.5 L Petrol AVT 115 hp 85 kW 2.5 L Petrol ACV 102 hp 75 kW 2.5 L Diesel AXL 102 hp 75 kW 2.5 L Diesel AES 140 hp 103 kW 2.8 L Petrol AHY 151 hp 111 kW 2.5 L Diesel AXG 151 hp 111 kW 2.5 L Diesel AMV 204 hp 150 kW 2.8 L Petrol | AWD / 4WD Front wheel | Passenger Van / Wagon / Minibus |
| VW | TRANER CARAVELLE IV 70XB 70XC 7DB 7DW 7D | 2.4 D Syncro 2.5 Syncro 2.5 TDI 2.5 TDI Syncro 2.8 VR 6 2.8 VR6 | 1992/10 - 2003/04 | AAB 78 hp 57 kW 2.4 L Diesel AAF 110 hp 81 kW 2.5 L Petrol ACU 110 hp 81 kW 2.5 L Petrol AEN 110 hp 81 kW 2.5 L Petrol AET 115 hp 85 kW 2.5 L Petrol AEU 110 hp 81 kW 2.5 L Petrol APL 115 hp 85 kW 2.5 L Petrol AVT 115 hp 85 kW 2.5 L Petrol ACV 102 hp 75 kW 2.5 L Diesel AXL 102 hp 75 kW 2.5 L Diesel AES 140 hp 103 kW 2.8 L Petrol AHY 151 hp 111 kW 2.5 L Diesel AXG 151 hp 111 kW 2.5 L Diesel AMV 204 hp 150 kW 2.8 L Petrol | AWD / 4WD Front wheel | Passenger Van / Wagon / Minibus |
| VW | TRANER IV 70XA 70XB 70XC 7DB 7DW 7DK 70XD | 2.4 D Syncro 2.5 Syncro 2.5 TDI 2.5 TDI Syncro 2.8 2.8 VR 6 2.8 VR6 | 1992/10 - 2003/04 | AAB 78 hp 57 kW 2.4 L Diesel AAF 110 hp 81 kW 2.5 L Petrol ACU 110 hp 81 kW 2.5 L Petrol AEN 110 hp 81 kW 2.5 L Petrol AET 115 hp 85 kW 2.5 L Petrol AEU 110 hp 81 kW 2.5 L Petrol APL 115 hp 85 kW 2.5 L Petrol AVT 115 hp 85 kW 2.5 L Petrol ACV 102 hp 75 kW 2.5 L Diesel AXL 102 hp 75 kW 2.5 L Diesel AES 140 hp 103 kW 2.8 L Petrol AES 140 hp 103 kW 2.8 L Petrol AMV 204 hp 150 kW 2.8 L Petrol AHY 151 hp 111 kW 2.5 L Diesel AXG 151 hp 111 kW 2.5 L Diesel AMV 204 hp 150 kW 2.8 L Petrol AXG 151 hp 111 kW 2.5 L Diesel | AWD / 4WD Front wheel | LCV / Van / Cargo Passenger Van / Wagon / Minibus With flatbed/undercarriage |
| VW | TRANERIV 70XA 70XD | 2.4 D Syncro 2.5 Syncro 2.5 TDI 2.5 TDI Syncro 2.8 2.8 VR6 | 1992/10 - 2003/04 | AAB 78 hp 57 kW 2.4 L Diesel AAF 110 hp 81 kW 2.5 L Petrol ACU 110 hp 81 kW 2.5 L Petrol AEN 110 hp 81 kW 2.5 L Petrol AET 115 hp 85 kW 2.5 L Petrol AEU 110 hp 81 kW 2.5 L Petrol APL 115 hp 85 kW 2.5 L Petrol AVT 115 hp 85 kW 2.5 L Petrol ACV 102 hp 75 kW 2.5 L Diesel AXL 102 hp 75 kW 2.5 L Diesel AES 140 hp 103 kW 2.8 L Petrol AES 140 hp 103 kW 2.8 L Petrol AMV 204 hp 150 kW 2.8 L Petrol AMV 204 hp 150 kW 2.8 L Petrol AXG 151 hp 111 kW 2.5 L Diesel | AWD / 4WD Front wheel | LCV / Van / Cargo With flatbed/undercarriage |
| VW | TRANER MULTI IV 70XB 70XC 7DB 7DW 7DK | 2.4 D Syncro 2.5 Syncro 2.5 TDI 2.5 TDI Syncro 2.8 VR 6 2.8 VR6 | 1992/10 - 2003/04 | AAB 78 hp 57 kW 2.4 L Diesel AAF 110 hp 81 kW 2.5 L Petrol ACU 110 hp 81 kW 2.5 L Petrol AEN 110 hp 81 kW 2.5 L Petrol AET 115 hp 85 kW 2.5 L Petrol AEU 110 hp 81 kW 2.5 L Petrol APL 115 hp 85 kW 2.5 L Petrol AVT 115 hp 85 kW 2.5 L Petrol ACV 102 hp 75 kW 2.5 L Diesel AXL 102 hp 75 kW 2.5 L Diesel AES 140 hp 103 kW 2.8 L Petrol AHY 151 hp 111 kW 2.5 L Diesel AXG 151 hp 111 kW 2.5 L Diesel AMV 204 hp 150 kW 2.8 L Petrol | AWD / 4WD Front wheel | Passenger Van / Wagon / Minibus |
| VW | TRANER T4 70XA 70XB 70XC 7DB 7DW 7DK 70XD | 2.4 D Syncro 2.5 Syncro 2.5 TDI 2.5 TDI Syncro 2.8 2.8 VR 6 2.8 VR6 | 1992/10 - 2003/04 | AAB 78 hp 57 kW 2.4 L Diesel AAF 110 hp 81 kW 2.5 L Petrol ACU 110 hp 81 kW 2.5 L Petrol AEN 110 hp 81 kW 2.5 L Petrol AET 115 hp 85 kW 2.5 L Petrol AEU 110 hp 81 kW 2.5 L Petrol APL 115 hp 85 kW 2.5 L Petrol AVT 115 hp 85 kW 2.5 L Petrol ACV 102 hp 75 kW 2.5 L Diesel AXL 102 hp 75 kW 2.5 L Diesel AES 140 hp 103 kW 2.8 L Petrol AES 140 hp 103 kW 2.8 L Petrol AMV 204 hp 150 kW 2.8 L Petrol AHY 151 hp 111 kW 2.5 L Diesel AXG 151 hp 111 kW 2.5 L Diesel AMV 204 hp 150 kW 2.8 L Petrol AXG 151 hp 111 kW 2.5 L Diesel | AWD / 4WD Front wheel | LCV / Van / Cargo Passenger Van / Wagon / Minibus With flatbed/undercarriage |
