TRW DB4029 Brake Drum

TRW part DB4029 Brake Drum

TRW DB4029 Brake Drum

by TRW

Manufacturer Part Number: DB4029

Сharacteristics:
  • Total Br. Drum Height [mm]: 72,2
  • Centering Diameter [mm]: 50,2
  • Br. Drum outer diameter [mm]: 212,5
  • Thread Measurement 1: M12 x 1,5
  • Drum Diameter: 203,0
  • Max.skimmed drum measure [mm]: 204
  • Inner Brake Drum Height [mm]: 48
  • Number of Holes: 4
  • Bolt Hole Circle Ø [mm]: 108

Product Details

BrandTRW
TRW article (MPN)DB4029
Vehicle subsystemBrake System

Original (OEM) part numbers

Suitable for FORD vehicles

OE manufacturerOEM reference numbers
FORD6176744, 6560027, 89FB1113BC, 6492328

Aftermarket cross reference / interchange guide

The aftermarket competitive interchanges for TRW DB4029 Brake Drum offered by A.B.S., ALANKO, APEC braking, ATE, BENDIX, BORG & BECK, BOSCH, Brake ENGINEERING, BREMBO, CIFAM, DELPHI, FIRST LINE, FTE, HELLA, HELLA PAGID, HP, JP GROUP, JURID, KAGER, KAWE, KRAFT, LPR, METELLI, METZGER, MGA, MINTEX, NK, PAGID, PEX, QUINTON HAZELL, REMSA, ROTINGER, sbs, TEXTAR, TRICLO, TRISCAN, VEMA, ZIMMERMANN manufacturers

ManufacturerReference numbers
A.B.S.2404S
ALANKO306043
APEC brakingDRM9101
ATE24022030022
BENDIX329183B
BORG & BECKBBR7054, BBR7081
BOSCH0986477259, 0986477049, 0986477258
Brake ENGINEERINGDR961971
BREMBO14572310, 14572350
CIFAM700275
DELPHIBDR134, BT133, BF230, 98100018401, BF1230
FIRST LINEFBR746
FTEBT133, BT1006
HELLA8DT355300191
HELLA PAGID8DT355300191
HP66281
JP GROUP1563500609
JURID329195J, 329183J
KAGER360108
KAWE7D0059
KRAFT6062060
LPR7D0059
METELLI180275, 180275K, 180287, 180287K
METZGERBT1022
MGATR7448
MINTEXMBD045
NK252527, 252529
PAGID61010
PEX150148
QUINTON HAZELLBDR134, BDR133, BTF133, 66281, BTF190, BDR190
REMSA705400
ROTINGERRT6929
sbs1825252527
TEXTAR94018400, 98100018401
TRICLO848046, 848048
TRISCAN812016217, 812016216
VEMA801150, 801166
ZIMMERMANN250176000

Vehicle fitment / TRW DB4029 Brake Drum compatibility

This product fits the following models: FORD COURIER, FORD FIESTA, FORD FIESTA III, FORD FIESTAIII, FORD FIESTA IV, FORD FIESTAIV, etc. See all vehicles this product (TRW DB4029) fits below to verify fitment for your vehicle.
MakeModelVariantPeriodEngineDriveBody Style
FORDCOURIER
F3L
F5L
1.3
1.8 D
1991/09 - 1996/02J6B 60 hp 44 kW 1.3 L Petrol
RTC 60 hp 44 kW 1.8 L Diesel
RTD 60 hp 44 kW 1.8 L Diesel
RTG 60 hp 44 kW 1.8 L Diesel
Front wheel
LCV / Van / Cargo
FORDFIESTA
F3L
F5L
FVD
1.3
1.8 D

FVJ
1989/03 - 1996/02J6B 60 hp 44 kW 1.3 L Petrol
RTC 60 hp 43 kW 1.8 L Diesel
RTD 60 hp 43 kW 1.8 L Diesel
RTG 60 hp 43 kW 1.8 L Diesel
RTC 60 hp 44 kW 1.8 L Diesel
RTD 60 hp 44 kW 1.8 L Diesel
RTG 60 hp 44 kW 1.8 L Diesel
Front wheel
LCV / Van / Cargo
FORDFIESTA III
GFJ
1.0
1.1
1.3
1.3 KAT
1.4
1.4 KAT
1.6
1.6 Turbo
1.6 XR2i
1.8 16V
1.8 D
1.8 XR2i 16V

FBJT
1989/01 - 1997/0160 hp 44 kW 1.3 L Petrol
JBC 60 hp 44 kW 1.3 L Petrol
F4A 73 hp 54 kW 1.4 L Petrol
F6E 71 hp 52 kW 1.4 L Petrol
FUF 75 hp 55 kW 1.4 L Petrol
FUG 73 hp 54 kW 1.4 L Petrol
FUJ 73 hp 54 kW 1.4 L Petrol
G6A 50 hp 37 kW 1.1 L Petrol
GUD 55 hp 40 kW 1.1 L Petrol
GUE 55 hp 40 kW 1.1 L Petrol
J6B 60 hp 44 kW 1.3 L Petrol
LHA 131 hp 96 kW 1.6 L Petrol
LJC 110 hp 81 kW 1.6 L Petrol
LJD 103 hp 76 kW 1.6 L Petrol
LUH 88 hp 65 kW 1.6 L Petrol
LUH 90 hp 66 kW 1.6 L Petrol
RDB 105 hp 77 kW 1.8 L Petrol
RQC 130 hp 96 kW 1.8 L Petrol
RTC 60 hp 44 kW 1.8 L Diesel
RTD 60 hp 44 kW 1.8 L Diesel
RTG 60 hp 44 kW 1.8 L Diesel
TLB 45 hp 33 kW 1 L Petrol
Front wheel
Hatchback / Sportback / Sport hatch
FORDFIESTAIII
GFJ
1.0
1.1
1.3
1.3 KAT
1.4
1.4 KAT
1.6
1.6 Turbo
1.6 XR2i
1.8 16V
1.8 D
1.8 XR2i 16V

FBJT
1989/01 - 1997/0160 hp 44 kW 1.3 L Petrol
JBC 60 hp 44 kW 1.3 L Petrol
F4A 73 hp 54 kW 1.4 L Petrol
F6E 71 hp 52 kW 1.4 L Petrol
FUF 75 hp 55 kW 1.4 L Petrol
FUG 73 hp 54 kW 1.4 L Petrol
FUJ 73 hp 54 kW 1.4 L Petrol
G6A 50 hp 37 kW 1.1 L Petrol
GUD 55 hp 40 kW 1.1 L Petrol
GUE 55 hp 40 kW 1.1 L Petrol
J6B 60 hp 44 kW 1.3 L Petrol
LHA 131 hp 96 kW 1.6 L Petrol
LJC 110 hp 81 kW 1.6 L Petrol
LJD 103 hp 76 kW 1.6 L Petrol
LUH 88 hp 65 kW 1.6 L Petrol
LUH 90 hp 66 kW 1.6 L Petrol
RDB 105 hp 77 kW 1.8 L Petrol
RQC 130 hp 96 kW 1.8 L Petrol
RTC 60 hp 44 kW 1.8 L Diesel
RTD 60 hp 44 kW 1.8 L Diesel
RTG 60 hp 44 kW 1.8 L Diesel
TLB 45 hp 33 kW 1 L Petrol
Front wheel
Hatchback / Sportback / Sport hatch
FORDFIESTA IV
JA
JB
1.1
1995/09 - 1996/1250 hp 37 kW 1.1 L Petrol
Front wheel
Hatchback / Sportback / Sport hatch
FORDFIESTAIV
JA
JB
1.1
1995/09 - 1996/1250 hp 37 kW 1.1 L Petrol
Front wheel
Hatchback / Sportback / Sport hatch
