TRW DB4162 Brake Drum
TRW DB4162 Brake Drum
by TRWManufacturer Part Number: DB4162
- Total Br. Drum Height [mm]: 98
- Centering Diameter [mm]: 79
- Thread Measurement 1: 17,5
- Thread Measurement 2: 8,7
- Drum Diameter: 254,0
- Max.skimmed drum measure [mm]: 255,6
- Inner Brake Drum Height [mm]: 64,5
- Number of Holes: 5
- Bolt Hole Circle Ø [mm]: 130
Product Details
| Brand | TRW |
| TRW article (MPN) | DB4162 |
| Vehicle subsystem | Brake System |
Original (OEM) part numbers
Suitable for CITROEN / PEUGEOT, FIAT / LANCIA / ALFA vehicles
| OE manufacturer | OEM reference numbers |
|---|---|
| CITROEN / PEUGEOT | 424738, 424737 |
| FIAT / LANCIA / ALFA | 1311823080, 1306211080, 1471288080 |
Aftermarket cross reference / interchange guide
The aftermarket competitive interchanges for TRW DB4162 Brake Drum offered by A.B.S., ALANKO, APEC braking, ATE, BENDIX, BORG & BECK, BOSCH, Brake ENGINEERING, BREMBO, BREMSI, CAR, CIFAM, DELPHI, FEBI BILSTEIN, FERODO, FIRST LINE, FTE, HANS PRIES, HELLA, HELLA PAGID, HP, JP GROUP, JURID, KAGER, KAMOKA, KAWE, LPR, METELLI, METZGER, MGA, MINTEX, NK, OPEN PARTS, PAGID, PATRON, PEX, QUINTON HAZELL, REMSA, ROTINGER, sbs, SWAG, TEXTAR, TRICLO, TRISCAN, VALEO, VEMA, ZIMMERMANN manufacturers
| Manufacturer | Reference numbers |
|---|---|
| A.B.S. | 2509S |
| ALANKO | 305913 |
| APEC braking | DRM9709 |
| ATE | 24022550031, 24.0225-4005.1 |
| BENDIX | 329012B, 329011B |
| BORG & BECK | BBR7101 |
| BOSCH | 0986477098, 0986477144 |
| Brake ENGINEERING | DR962178 |
| BREMBO | 14707610, 14.7077.10 |
| BREMSI | DR5255 |
| CAR | 433076 |
| CIFAM | 700016 |
| DELPHI | BF327, BF325, 98100014601, BG327 |
| FEBI BILSTEIN | 10664 |
| FERODO | FDR329011 |
| FIRST LINE | FBR776, FBR775 |
| FTE | BT1001, BT1002 |
| HANS PRIES | 721192 |
| HELLA | 8DT355302191 |
| HELLA PAGID | 8DT355302191 |
| HP | 66329, 66328 |
| JP GROUP | 3163500309 |
| JURID | 329011J, 329012J |
| KAGER | 360040 |
| KAMOKA | 104001 |
| KAWE | 7D0255 |
| LPR | 7D0255 |
| METELLI | 180016, 180017 |
| METZGER | BT237, BT236 |
| MGA | T7500 |
| MINTEX | MBD037, MBD034 |
| NK | 261902, 261901 |
| OPEN PARTS | BAD902410 |
| PAGID | 60606, 62935 |
| PATRON | PDR1216 |
| PEX | 150007, 150008 |
| QUINTON HAZELL | BDR280, 66329, BTF281, BTF280, BDR281, BDR138, 66328 |
| REMSA | 707800 |
| ROTINGER | RT6998 |
| sbs | 1825261901, 1825261902 |
| SWAG | 70910664 |
| TEXTAR | 98100014601, 94015000, 94014600 |
| TRICLO | 842046, 842050 |
| TRISCAN | 812010209 |
| VALEO | 237028 |
| VEMA | 801003 |
| ZIMMERMANN | 440180300 |
Vehicle fitment / TRW DB4162 Brake Drum compatibility
This product fits the following models: CITROËN JUMPER, CITROËN RELAY, FIAT DUCATO, PEUGEOT BOXER, etc. See all vehicles this product (TRW DB4162) fits below to verify fitment for your vehicle.| Make | Model | Variant | Period | Engine | Drive | Body Style |
|---|---|---|---|---|---|---|
| CITROËN | JUMPER 230 230L 230P 244 | 2.0 2.5 D 2.5 D 4x4 2.5 DT 4x4 2.5 TD 2.5 TD 4x4 2.5 TDi 2.5 TDi 4x4 2.5 TDI 4x4 2.8 D 2.8 HDi 2.8 HDi 4x4 | 1994/02 - | 8140.43S 126 hp 93 kW 2.8 L Diesel 8140.43S 128 hp 94 kW 2.8 L Diesel 8140.43S 128 hp 94 kW 2.8 L Diesel 8140.63(F28D) 87 hp 64 kW 2.8 L Diesel F28TDCR 128 hp 94 kW 2.8 L Diesel RFW(XU10J2U) 109 hp 80 kW 2 L Petrol T8A(DJ5T) 103 hp 76 kW 2.5 L Diesel T9A(DJ5) 86 hp 63 kW 2.5 L Diesel THX(DJ5TED) 107 hp 79 kW 2.5 L Diesel THZ(DJ5T) 103 hp 76 kW 2.5 L Diesel | AWD / 4WD Front wheel | LCV / Van / Cargo Passenger Van / Wagon / Minibus With flatbed/undercarriage |
| CITROËN | RELAY 230 230L 230P 244 | 2.0 2.5 D 2.5 D 4x4 2.5 DT 4x4 2.5 TD 2.5 TD 4x4 2.5 TDi 2.5 TDi 4x4 2.5 TDI 4x4 2.8 D 2.8 HDi 2.8 HDi 4x4 | 1994/02 - | 8140.43S 126 hp 93 kW 2.8 L Diesel 8140.43S 128 hp 94 kW 2.8 L Diesel 8140.43S 128 hp 94 kW 2.8 L Diesel 8140.63(F28D) 87 hp 64 kW 2.8 L Diesel F28TDCR 128 hp 94 kW 2.8 L Diesel RFW(XU10J2U) 109 hp 80 kW 2 L Petrol T8A(DJ5T) 103 hp 76 kW 2.5 L Diesel T9A(DJ5) 86 hp 63 kW 2.5 L Diesel THX(DJ5TED) 107 hp 79 kW 2.5 L Diesel THZ(DJ5T) 103 hp 76 kW 2.5 L Diesel | AWD / 4WD Front wheel | LCV / Van / Cargo Passenger Van / Wagon / Minibus With flatbed/undercarriage |
| FIAT | DUCATO 230 230L | 2.0 JTD 2.0 Panorama/Combinato 2.5 D 2.5 D 4x4 2.5 D Combinato 2.5 TD 2.5 TD 4x4 2.5 TDI 2.5 TDI 4x4 2.5 TDI Panorama/Combinato 2.8 D 2.8 iDTD 4x4 2.8 JTD 2.8 TD 4x4 2.8 TDI 2.8 TDI 4x4 | 1994/03 - 2002/04 | 8140.43 122 hp 90 kW 2.8 L Diesel 8140.43S 128 hp 94 kW 2.8 L Diesel 8140.47 109 hp 80 kW 2.5 L Diesel 8140.47 109 hp 80 kW 2.5 L Diesel 8140.47 116 hp 85 kW 2.5 L Diesel 8140.47 116 hp 85 kW 2.5 L Diesel 8140.47 116 hp 85 kW 2.5 L Diesel 8140.47R 109 hp 80 kW 2.5 L Diesel 8140.63 87 hp 64 kW 2.8 L Diesel 8140.67 84 hp 62 kW 2.5 L Diesel RFW 109 hp 80 kW 2 L Petrol RHV(DW10) 84 hp 62 kW 2 L Diesel | AWD / 4WD Front wheel | LCV / Van / Cargo Passenger Van / Wagon / Minibus With flatbed/undercarriage |
| PEUGEOT | BOXER 230L 230P 244 ZCT | 2.0 4x4 2.0 i 2.0 i 4x4 2.5 D 2.5 D 4x4 2.5 DT 2.5 TD 2.5 TD 4x4 2.5 TDI 2.5 TDI 4x4 2.8 D 2.8 DTiC 2.8 HDi 2.8 HDI 2.8 HDi 4x4 2.8 TD | 1994/03 - 2005/03 | 109 hp 80 kW 2 L Petrol 8140.43(F28DT) 122 hp 90 kW 2.8 L Diesel 8140.43S(F28DTCR) 126 hp 93 kW 2.8 L Diesel 8140.43S(F28DTCR) 126 hp 93 kW 2.8 L Diesel 8140.43S(F28DTCR) 128 hp 94 kW 2.8 L Diesel 8140.43S(F28DTCR) 128 hp 94 kW 2.8 L Diesel 8140.63(F28D) 87 hp 64 kW 2.8 L Diesel 84 hp 62 kW 2.5 L Diesel RFW(XU10J2) 109 hp 80 kW 2 L Petrol T8A(DJ5T) 103 hp 76 kW 2.5 L Diesel T9A(DJ5) 86 hp 63 kW 2.5 L Diesel THX(DJ5TED) 107 hp 79 kW 2.5 L Diesel | AWD / 4WD Front wheel Front wheel AWD / 4WD | LCV / Van / Cargo Passenger Van / Wagon / Minibus With flatbed/undercarriage |
