TRW DB4316 Brake Drum

TRW part DB4316 Brake Drum

TRW DB4316 Brake Drum

by TRW

Manufacturer Part Number: DB4316

Сharacteristics:
  • Drum Diameter: 280
  • Max.skimmed drum measure [mm]: 282
  • Inner Brake Drum Height [mm]: 78
  • Number of Holes: 5
  • Bolt Hole Circle Ø [mm]: 160

Product Details

BrandTRW
TRW article (MPN)DB4316
Vehicle subsystemBrake System

Original (OEM) part numbers

Suitable for FORD vehicles

OE manufacturerOEM reference numbers
FORD4078769, 3C111126AA, 4041429, 4446218, 4519396

Aftermarket cross reference / interchange guide

The aftermarket competitive interchanges for TRW DB4316 Brake Drum offered by A.B.S., ALANKO, APEC braking, ATE, BENDIX, BORG & BECK, BOSCH, Brake ENGINEERING, BREMBO, BREMSI, CASALS, CIFAM, DELPHI, DENCKERMANN, FENOX, FIRST LINE, FTE, HANS PRIES, HELLA, HELLA PAGID, HP, JP GROUP, JURATEK, JURID, KAGER, KAWE, KRAFT, LPR, MAXGEAR, METELLI, METZGER, MEYLE, MGA, MINTEX, NATIONAL, NK, OPEN PARTS, PAGID, PILENGA, PROFIT, PROTECHNIC, QUINTON HAZELL, REMSA, ROADHOUSE, ROTINGER, sbs, STELLOX, TEXTAR, TRISCAN, VALEO, VEMA, WOKING, ZIMMERMANN manufacturers

ManufacturerReference numbers
A.B.S.2734S
ALANKO305850
APEC brakingDRM9919
ATE24.0228-0004.1
BENDIX329741B
BORG & BECKBBR7186
BOSCH0986477203
Brake ENGINEERINGDR962364
BREMBO14A69210, 14C01710
BREMSIDR5646
CASALS55254
CIFAM700419, 700367
DELPHIBF478
DENCKERMANNB140001
FENOXTO216137
FIRST LINEFBR987
FTEBT628
HANS PRIES303979
HELLA8DT355300451
HELLA PAGID8DT355300451
HP66429
JP GROUP1563500400, 1563500409
JURATEKFOR108D
JURID329741J
KAGER360393
KAWE7D0646
KRAFT6062150
LPR7D0646
MAXGEAR191031
METELLI180367, 180419
METZGER230714
MEYLE7155237041
MGAT7632, T7576
MINTEXMBD057
NATIONALNDR331
NK262511
OPEN PARTSBAD907410
PAGID61246
PILENGAV253
PROFIT50200031
PROTECHNICPRT037
QUINTON HAZELL66429
REMSA709900
ROADHOUSE709900
ROTINGERRT6408
sbs1825262511
STELLOX60262511SX
TEXTAR94024600
TRISCAN812016225
VALEO237048
VEMA801484
WOKINGB709900
ZIMMERMANN250177100

Vehicle fitment / TRW DB4316 Brake Drum compatibility

This product fits the following models: FORD TRANSIT, FORD AUSTRALIA TRANSIT, etc. See all vehicles this product (TRW DB4316) fits below to verify fitment for your vehicle.
MakeModelVariantPeriodEngineDriveBody Style
FORDTRANSIT
FA
FD
FB
FS
FZ
FC
FM
FN
2.0 DI
2.0 TDCi
2.3
2.3 16V [RWD]
2.4 DI
2.4 DI [RWD]
2.4 TD
2.4 TDCi
2.4 TDdi
2.4 TDE

FAA
FAB
FAC
FAA
FAB
FAC
FAD
FAE
FAF
FAG
FA
FB
FC
FD
FB
FC
FB
FC
FA
FC
FB
FA
FE
FF
FE
FF
FG
2000/01 - 2006/05ABFA 100 hp 74 kW 2 L Diesel
ABFA 100 hp 74 kW 2 L Diesel
D3FA 75 hp 55 kW 2 L Diesel
D2FA 90 hp 66 kW 2.4 L Diesel
D2FB 90 hp 66 kW 2.4 L Diesel
D2FE 90 hp 66 kW 2.4 L Diesel
D2FA 90 hp 66 kW 2.4 L Diesel
D2FB 90 hp 66 kW 2.4 L Diesel
D2FE 90 hp 66 kW 2.4 L Diesel
D4FA 120 hp 88 kW 2.4 L Diesel
F4FA 75 hp 55 kW 2.4 L Diesel
D2FE 90 hp 66 kW 2.4 L Diesel
D4FA 120 hp 88 kW 2.4 L Diesel
D3FA 75 hp 55 kW 2 L Diesel
D4FA 120 hp 88 kW 2.4 L Diesel
D4FA 120 hp 88 kW 2.4 L Diesel
F4FA 75 hp 55 kW 2.4 L Diesel
DOFA 125 hp 92 kW 2.4 L Diesel
DOFA 125 hp 92 kW 2.4 L Diesel
FXFA 115 hp 85 kW 2.4 L Diesel
E5FA 145 hp 107 kW 2.3 L Petrol
E5FA 145 hp 107 kW 2.3 L Petrol
E5FC 143 hp 105 kW 2.3 L Petrol
E5FA 146 hp 107 kW 2.3 L Petrol
E5FC 146 hp 107 kW 2.3 L Petrol
F4FA 75 hp 55 kW 2.4 L Diesel
FIFA 125 hp 92 kW 2 L Diesel
FXFA 115 hp 85 kW 2.4 L Diesel
H9FA 137 hp 101 kW 2.4 L Diesel
Front wheel
Front wheel
AWD / 4WD
Rear wheel
LCV / Van / Cargo
Passenger Van / Wagon / Minibus
With flatbed/undercarriage
FORD AUSTRALIATRANSIT
VH
VJ
2.3
2.4 D
2000/01 - 2006/09120 hp 88 kW 2.4 L Diesel
D2FA 90 hp 66 kW 2.4 L Diesel
DOFA 125 hp 92 kW 2.4 L Diesel
120 hp 88 kW 2.4 L Diesel
D2FA 90 hp 66 kW 2.4 L Diesel
DOFA 125 hp 92 kW 2.4 L Diesel
F4FA 75 hp 55 kW 2.4 L Diesel
FXFA 115 hp 85 kW 2.4 L Diesel
H9FA 137 hp 101 kW 2.4 L Diesel
D2FA 90 hp 66 kW 2.4 L Diesel
D4FA 120 hp 88 kW 2.4 L Diesel
DOFA 125 hp 92 kW 2.4 L Diesel
F4FA 75 hp 55 kW 2.4 L Diesel
FXFA 115 hp 85 kW 2.4 L Diesel
H9FA 137 hp 101 kW 2.4 L Diesel
E5FA 146 hp 107 kW 2.3 L Petrol
E5FA 146 hp 107 kW 2.3 L Petrol
E5FC 146 hp 107 kW 2.3 L Petrol
Front wheel
Rear wheel
Rear wheel
LCV / Van / Cargo
Passenger Van / Wagon / Minibus
With flatbed/undercarriage
