TRW DF1118 Brake Disc

TRW part DF1118 Brake Disc

TRW DF1118 Brake Disc

by TRW

Manufacturer Part Number: DF1118

Сharacteristics:
  • Surface: Painted
  • Brake Disc Type: Solid
  • Diameter [mm]: 256
  • Brake Disc Thickness [mm]: 16
  • Minimum thickness [mm]: 13,5
  • Centering Diameter [mm]: 73
  • Height [mm]: 64
  • Number of Holes: 5
  • Thread Size: 15,5
  • Bolt Hole Circle Ø [mm]: 118
  • Colour: Black

Product Details

BrandTRW
TRW article (MPN)DF1118
Vehicle subsystemBrake System

Original (OEM) part numbers

Suitable for CITROEN / PEUGEOT, FIAT / LANCIA / ALFA vehicles

OE manufacturerOEM reference numbers
CITROEN / PEUGEOT7531819, 424695, 4246B4, 4246N5, ZF93500520, 424693
FIAT / LANCIA / ALFA7568440, 7531819, 71740116, 93500520

Aftermarket cross reference / interchange guide

The aftermarket competitive interchanges for TRW DF1118 Brake Disc offered by ABEX, A.B.S., ACDelco, ALANKO, AP, APEC braking, ATE, BARUM, BENDIX, BORG & BECK, BOSCH, Brake ENGINEERING, BRECO, BREMBO, BREMSI, BSF, CAR, CIFAM, DELPHI, DENCKERMANN, DJ AUTO, FAG, FARCOM, FEBI BILSTEIN, FENOX, FERODO, FIRST LINE, FOMAR, fri.tech., FTE, GIRLING, GRAF, HELLA, HELLA PAGID, HP, ICER, JURID, KAGER, KAWE, KLAXCAR FRANCE, KRAFT, LEMFÖRDER, LPR, MAGNETI MARELLI, MAPCO, METELLI, METZGER, MGA, MINTEX, MOTAQUIP, NATIONAL, NECTO, NK, OPEN PARTS, OPTIMAL, PAGID, PATRON, PETERS ENNEPETAL, PEX, PILENGA, PROFIT, PROTECHNIC, QUINTON HAZELL, R BRAKE, REMSA, ROADHOUSE, ROTINGER, ROULUNDS RUBBER, SASIC, sbs, SWAG, TEMPLIN, TEXTAR, TRISCAN, TRUSTING, VALEO, VEMA, VILLAR, WAGNER LOCKHEED, WOKING, ZIMMERMANN manufacturers

ManufacturerReference numbers
ABEXW0380
A.B.S.15045
ACDelcoAC2018D
ALANKO305415, 304193, 304136
AP14828E, 14075E
APEC brakingDSK548
ATE24011601051, 416105
BARUMBAR16105
BENDIX338638, 561321BC, 561321B
BORG & BECKBBD4616
BOSCH0986479B24, 0986478200, 986478200, 986478203
Brake ENGINEERINGDI951139, 951138
BRECOBS7649, BS7322
BREMBO08.3069.14, 08306910, 08960114
BREMSIDBA063S
BSF11026
CARHPD176, 142176
CIFAM800134
DELPHI14075, BS3434, 815272707, 815272709, BG2253, 50902, BDC3434, 3223, 98200034401, BG2353, 186206, 2302354, 616900, BG253, DF29134, 561321J, 272707
DENCKERMANNB130004
DJ AUTOBD1467
FAGBS3434
FARCOM230756
FEBI BILSTEIN07922
FENOXTB215040
FERODODDF0631, DDF063
FIRST LINEFBD169
FOMARFO2018
fri.tech.BD0167
FTEBS3434
GIRLING6011183
GRAFDF29134
HELLA8DD355101121
HELLA PAGID8DD355101121
HP53095
ICER78BD46932, 78BD78142
JURID561321JC, 561321J
KAGER370381
KAWE616900
KLAXCAR FRANCE25013Z
KRAFT6043030
LEMFÖRDER1257001
LPRC1191P
MAGNETI MARELLI431602040540, 360406020900, 353611510140
MAPCO15024
METELLI230134
METZGER14075E, 6110341
MGAD934
MINTEXMDC333
MOTAQUIPLVBD303Z
NATIONALNBD132
NECTOWN380
NK319908, 209908
OPEN PARTSBDA113610
OPTIMALBS-1690
PAGID50902
PATRONPBD1118
PETERS ENNEPETAL23602000A
PEX140150
PILENGA5040
PROFIT50100063
PROTECHNICPRD1132
QUINTON HAZELL53095, BDC3434, BSF3434, 814300
R BRAKE78RBD27814, 78RBD24693
REMSA616900, 814300
ROADHOUSE616900, 814300
ROTINGERRT1273T5, RT1273
ROULUNDS RUBBERD2018
SASIC2464954J
sbs1815209908, 1815319908
SWAG70907922
TEMPLIN0311080170
TEXTAR92034400, 98200034401
TRISCAN812028104, 812028103, 812010111
TRUSTINGDF167
VALEO186206
VEMA98037
VILLAR6280808
WAGNER LOCKHEEDWGR00631
WOKINGP616900, D616900
ZIMMERMANN230235400, 230235420, 2302354, 230235450

Vehicle fitment / TRW DF1118 Brake Disc compatibility

This product fits the following models: ALFA ROMEO AR 6, CITROËN C25, FIAT DUCATO, FIAT DUCATO PANORAMA, FIAT TALENTO, PEUGEOT J5, TALBOT EXPRESS 1000 -1500, etc. See all vehicles this product (TRW DF1118) fits below to verify fitment for your vehicle.
MakeModelVariantPeriodEngineDriveBody Style
ALFA ROMEOAR 6
280
1.9 D
2.4 D
2.4 TD
2.5 D
1985/04 - 1989/12160D100 69 hp 51 kW 1.9 L Diesel
8144.21.220 92 hp 68 kW 2.4 L Diesel
8144.61.200 72 hp 53 kW 2.4 L Diesel
8144.67.220 75 hp 55 kW 2.5 L Diesel
Front wheel
LCV / Van / Cargo
Passenger Van / Wagon / Minibus
CITROËNC25
280
290
1.8
1.8 E
1.9 D
1.9 D 1400
2.0
2.0 4x4
2.0 E
2.5 D
2.5 D 4x4
2.5 D Turbo
1981/09 - 1994/03169(XM7T) 68 hp 50 kW 1.8 L Petrol
169(XM7T) 69 hp 51 kW 1.8 L Petrol
170A(XN1T) 79 hp 58 kW 2 L Petrol
170B(XN1T) 79 hp 58 kW 2 L Petrol
170C(XN1T) 84 hp 62 kW 2 L Petrol
170C(XN1T) 84 hp 62 kW 2 L Petrol
78 hp 57 kW 2 L Petrol
75 hp 55 kW 2.5 L Diesel
84 hp 62 kW 2 L Petrol
CRD93LS(U25-673) 95 hp 70 kW 2.5 L Diesel
CRD93L(U25-661) 73 hp 54 kW 2.5 L Diesel
CRD93L(U25-661) 75 hp 55 kW 2.5 L Diesel
D9B(XUD9A/U) 69 hp 51 kW 1.9 L Diesel
DJY(XUD9A) 69 hp 51 kW 1.9 L Diesel
AWD / 4WD
Front wheel
LCV / Van / Cargo
Passenger Van / Wagon / Minibus
With flatbed/undercarriage
FIATDUCATO
230
280
290
1.8
1.9 D
1.9 TD
2.0
2.0 4x4
2.4 D
2.5 D
2.5 D 4x4
2.5 TD
1982/01 - 2002/04149B1.000 69 hp 51 kW 1.9 L Diesel
149B1.000 71 hp 52 kW 1.9 L Diesel
169B 67 hp 49 kW 1.8 L Petrol
170B 75 hp 55 kW 2 L Petrol
170D 84 hp 62 kW 2 L Petrol
XN1T 75 hp 55 kW 2 L Petrol
170B 75 hp 55 kW 2 L Petrol
170D 84 hp 62 kW 2 L Petrol
XN1T 79 hp 58 kW 2 L Petrol
170D 84 hp 62 kW 2 L Petrol
170D 86 hp 63 kW 2 L Petrol
280A1.000 82 hp 60 kW 1.9 L Diesel
8140.27 92 hp 68 kW 2.5 L Diesel
8144.21 92 hp 68 kW 2.5 L Diesel
8140.27 95 hp 70 kW 2.5 L Diesel
8140.61 72 hp 53 kW 2.5 L Diesel
8140.61 75 hp 55 kW 2.5 L Diesel
8144.61 75 hp 55 kW 2.5 L Diesel
8144.67 75 hp 55 kW 2.5 L Diesel
8140.61 75 hp 55 kW 2.5 L Diesel
8144.67 75 hp 55 kW 2.5 L Diesel
CRD93L(U25-661) 75 hp 55 kW 2.5 L Diesel
8144.61 72 hp 53 kW 2.4 L Diesel
8144.67 75 hp 55 kW 2.5 L Diesel
8144.67 75 hp 55 kW 2.5 L Diesel
CRD93L(U25-661) 75 hp 55 kW 2.5 L Diesel
AWD / 4WD
Front wheel
LCV / Van / Cargo
Passenger Van / Wagon / Minibus
With flatbed/undercarriage
FIATDUCATO PANORAMA
280
290
1.8
1.9 D
1.9 TD
2.0
2.0 4x4
2.4 D
2.5 D
2.5 D 4x4
2.5 TD
2.5 TD 4x4
1982/07 - 1994/05149B1.000 71 hp 52 kW 1.9 L Diesel
170B 75 hp 55 kW 2 L Petrol
170D 84 hp 62 kW 2 L Petrol
XN1T 79 hp 58 kW 2 L Petrol
170D 84 hp 62 kW 2 L Petrol
170D 86 hp 63 kW 2 L Petrol
170D 86 hp 63 kW 2 L Petrol
280A1.000 82 hp 60 kW 1.9 L Diesel
8140.27 92 hp 68 kW 2.5 L Diesel
8144.67 75 hp 55 kW 2.5 L Diesel
8140.27 92 hp 68 kW 2.5 L Diesel
8144.67 75 hp 55 kW 2.5 L Diesel
CRD93L(U25-661) 75 hp 55 kW 2.5 L Diesel
8140.27 95 hp 70 kW 2.5 L Diesel
8144.21.220 92 hp 68 kW 2.5 L Diesel
8144.21 92 hp 68 kW 2.5 L Diesel
8144.21 92 hp 68 kW 2.5 L Diesel
8144.61 72 hp 53 kW 2.4 L Diesel
8144.67 75 hp 55 kW 2.5 L Diesel
XM7T 69 hp 51 kW 1.8 L Petrol
AWD / 4WD
Front wheel
Passenger Van / Wagon / Minibus
FIATTALENTO
290
1.9 D
2.0
290U4
290UA4
290UAK
290UTK
290UEH4
290UEHK
290UK
1989/03 - 1994/03149B1.000 71 hp 52 kW 1.9 L Diesel
170B 75 hp 55 kW 2 L Petrol
Front wheel
LCV / Van / Cargo
Passenger Van / Wagon / Minibus
With flatbed/undercarriage
PEUGEOTJ5
280L
280P
290L
290P
1.8
1.9 D
2.0
2.5 D
2.5 D 4x4
2.5 DT
2.5 DT 4x4
2.5 TD
2.5 TD 4x4
1981/09 - 1994/03169B(XM7T) 69 hp 51 kW 1.8 L Petrol
170B(XN1T) 75 hp 55 kW 2 L Petrol
170(XN1T) 79 hp 58 kW 2 L Petrol
170D(XN1TACP) 84 hp 62 kW 2 L Petrol
69 hp 51 kW 1.8 L Petrol
CRD93 73 hp 54 kW 2.5 L Diesel
CRD93L 95 hp 70 kW 2.5 L Diesel
CRD93LS(U25/673) 95 hp 70 kW 2.5 L Diesel
CRD93(U25/661) 73 hp 54 kW 2.5 L Diesel
D9B(XUD9A) 69 hp 51 kW 1.9 L Diesel
XUD9 69 hp 51 kW 1.9 L Diesel
D9B(XUD9A) 70 hp 51 kW 1.9 L Diesel
XUD9 69 hp 51 kW 1.9 L Diesel
AWD / 4WD
Front wheel
Front wheel
AWD / 4WD
LCV / Van / Cargo
Passenger Van / Wagon / Minibus
With flatbed/undercarriage
TALBOTEXPRESS 1000 -1500
1.8
1.9 D
2.0
2.5 D
1982/07 - 1994/10CRD93 73 hp 54 kW 2.5 L Diesel
XM7T 69 hp 51 kW 1.8 L Petrol
XN1TA 78 hp 57 kW 2 L Petrol
XUD9A 69 hp 51 kW 1.9 L Diesel
Front wheel
Front wheel
AWD / 4WD
Passenger Van / Wagon / Minibus
With flatbed/undercarriage
