TRW DF1523 Brake Disc

TRW part DF1523 Brake Disc

TRW DF1523 Brake Disc

by TRW

Manufacturer Part Number: DF1523

Сharacteristics:
  • Brake Disc Type: Solid
  • Diameter [mm]: 281
  • Brake Disc Thickness [mm]: 19,9
  • Minimum thickness [mm]: 18,5
  • Centering Diameter [mm]: 91
  • Height [mm]: 80,4
  • Number of Holes: 5
  • Thread Size: M14 x 1,50
  • Bolt Hole Circle Ø [mm]: 115

Product Details

BrandTRW
TRW article (MPN)DF1523
Vehicle subsystemBrake System

Original (OEM) part numbers

Suitable for VAG vehicles

OE manufacturerOEM reference numbers
VAG281615283A

Aftermarket cross reference / interchange guide

The aftermarket competitive interchanges for TRW DF1523 Brake Disc offered by ABEX, A.B.S., ACDelco, ALANKO, AP, APEC braking, ATE, BARUM, BENDIX, BORG & BECK, BOSCH, Brake ENGINEERING, BRECO, BREMBO, BREMSI, BSF, CASALS, CIFAM, DELPHI, DENCKERMANN, DJ AUTO, FAG, FARCOM, FEBI BILSTEIN, FERODO, FIRST LINE, FOMAR, fri.tech., FTE, GIRLING, GRAF, HELLA, HELLA PAGID, HP, ICER, JP GROUP, JURID, KAGER, KAWE, KRAFT, LEMFÖRDER, LPR, MAGNETI MARELLI, MAXGEAR, METELLI, METZGER, MGA, MINTEX, NATIONAL, NECTO, NK, OPEN PARTS, OPTIMAL, PAGID, PATRON, PEX, PILENGA, PROTECHNIC, QUINTON HAZELL, R BRAKE, REMSA, ROADHOUSE, ROTINGER, ROULUNDS RUBBER, sbs, SWAG, TEMPLIN, TEXTAR, TRISCAN, TRUSTING, VALEO, VILLAR, WOKING, ZIMMERMANN manufacturers

ManufacturerReference numbers
ABEXW0370
A.B.S.15786
ACDelcoAC2248D
ALANKO304860, 303230
AP14070
APEC brakingDSK648
ATE420114, 24012001141, 24012001142
BARUMBAR20114
BENDIX561308BC, 561308B, 333732
BORG & BECKBBD5849S
BOSCH0986478138, 986478138
Brake ENGINEERING951126
BRECOBS7314
BREMBO08298210
BREMSIDBA058S
BSF11342
CASALS55238
CIFAM800291
DELPHI186250, 14070, BDC3585, BG163, BS3585, BG2163, 654300, DF2929LL, 53906, 424204, 561252J, 7128, 6001593, 98200031501
DENCKERMANNB130042
DJ AUTOBD1500
FAGBS3585
FARCOM230232
FEBI BILSTEIN11393
FERODODDF0581, DDF058
FIRST LINEFBD272
FOMARFO2248
fri.tech.BD0758
FTEBS3585
GIRLING6015233
GRAFDF2929LL
HELLA8DD355100901
HELLA PAGID8DD355100901
HP57128
ICER78BD30171
JP GROUP1163106509
JURID561308J, 561252J, 561308JC
KAGER370309
KAWE654300
KRAFT6040200
LEMFÖRDER1448602
LPRV2101P
MAGNETI MARELLI360406048000, 353615810150
MAXGEAR190980
METELLI230291
METZGER14070, 6110419
MGAD1091
MINTEXMDC750
NATIONALNBD149
NECTOWN370
NK314721, 204721
OPEN PARTSBDR157810
OPTIMALBS5430
PAGID53906
PATRONPBD1523
PEX140618
PILENGA5870
PROTECHNICPRD1207
QUINTON HAZELLBSF3585, BDC3585, 57128
R BRAKE78RBD13017
REMSA654300
ROADHOUSE654300
ROTINGERRT1535T5, RT1535
ROULUNDS RUBBERD2248
sbs1815314721, 1815204721
SWAG30911393
TEMPLIN0311084830
TEXTAR98200031501, 92031500
TRISCAN812029128
TRUSTINGDF758
VALEO186250
VILLAR6281746
WOKINGP654300, D654300
ZIMMERMANN6001593, 600159300

Vehicle fitment / TRW DF1523 Brake Disc compatibility

This product fits the following models: VW LT 28-35 I, VW LT28-50  , VW LT 40-55 I, etc. See all vehicles this product (TRW DF1523) fits below to verify fitment for your vehicle.
MakeModelVariantPeriodEngineDriveBody Style
VWLT 28-35 I
281-363
2.0
2.4
2.4 D
2.4 i
2.4 TD
2.4 TD Syncro
1975/04 - 1996/061E 94 hp 69 kW 2.4 L Petrol
1G 92 hp 68 kW 2.4 L Diesel
ACL 95 hp 70 kW 2.4 L Diesel
DV 102 hp 75 kW 2.4 L Diesel
1S 69 hp 51 kW 2.4 L Diesel
ACT 69 hp 51 kW 2.4 L Diesel
CP 75 hp 55 kW 2.4 L Diesel
DW 75 hp 55 kW 2.4 L Diesel
1S 70 hp 51 kW 2.4 L Diesel
ACT 70 hp 51 kW 2.4 L Diesel
CP 75 hp 55 kW 2.4 L Diesel
DW 75 hp 55 kW 2.4 L Diesel
ACL 95 hp 70 kW 2.4 L Diesel
CH 75 hp 55 kW 2 L Petrol
DL 90 hp 66 kW 2.4 L Petrol
AWD / 4WD
Rear wheel
LCV / Van / Cargo
Passenger Van / Wagon / Minibus
With flatbed/undercarriage
VWLT28-50
281-363
2.0
2.4
2.4 D
2.4 i
2.4 TD
2.4 TD Syncro
1975/04 - 1996/061E 94 hp 69 kW 2.4 L Petrol
1G 92 hp 68 kW 2.4 L Diesel
ACL 95 hp 70 kW 2.4 L Diesel
DV 102 hp 75 kW 2.4 L Diesel
1S 69 hp 51 kW 2.4 L Diesel
ACT 69 hp 51 kW 2.4 L Diesel
CP 75 hp 55 kW 2.4 L Diesel
DW 75 hp 55 kW 2.4 L Diesel
1S 70 hp 51 kW 2.4 L Diesel
ACT 70 hp 51 kW 2.4 L Diesel
CP 75 hp 55 kW 2.4 L Diesel
DW 75 hp 55 kW 2.4 L Diesel
ACL 95 hp 70 kW 2.4 L Diesel
CH 75 hp 55 kW 2 L Petrol
DL 90 hp 66 kW 2.4 L Petrol
AWD / 4WD
Rear wheel
LCV / Van / Cargo
Passenger Van / Wagon / Minibus
With flatbed/undercarriage
VWLT 40-55 I
291-512
293-909
2.0
2.4
2.4 4WD
2.4 D
2.4 D 4WD
2.4 i
2.4 Syncro
2.4 TD
2.4 TD 4WD
1975/04 - 1996/061E 94 hp 69 kW 2.4 L Petrol
1E 95 hp 70 kW 2.4 L Petrol
DL 90 hp 66 kW 2.4 L Petrol
1G 92 hp 68 kW 2.4 L Diesel
ACL 95 hp 70 kW 2.4 L Diesel
DV 102 hp 75 kW 2.4 L Diesel
1S 69 hp 51 kW 2.4 L Diesel
ACT 69 hp 51 kW 2.4 L Diesel
1S 69 hp 51 kW 2.4 L Diesel
ACT 69 hp 51 kW 2.4 L Diesel
CP 75 hp 55 kW 2.4 L Diesel
DW 75 hp 55 kW 2.4 L Diesel
CH 75 hp 55 kW 2 L Petrol
DL 90 hp 66 kW 2.4 L Petrol
DV 102 hp 75 kW 2.4 L Diesel
DW 75 hp 55 kW 2.4 L Diesel
AWD / 4WD
Rear wheel
LCV / Van / Cargo
With flatbed/undercarriage
