TRW DF1688 Brake Disc

TRW part DF1688 Brake Disc

TRW DF1688 Brake Disc

by TRW

Manufacturer Part Number: DF1688

Сharacteristics:
  • Brake Disc Type: Vented
  • Diameter [mm]: 287
  • Brake Disc Thickness [mm]: 22
  • Minimum thickness [mm]: 20
  • Centering Diameter [mm]: 68
  • Height [mm]: 56
  • Number of Holes: 5
  • Thread Size: 13,9
  • Bolt Hole Circle Ø [mm]: 108
  • Colour: Black
  • Surface: Painted

Product Details

BrandTRW
TRW article (MPN)DF1688
Vehicle subsystemBrake System

Original (OEM) part numbers

Suitable for VOLVO vehicles

OE manufacturerOEM reference numbers
VOLVO1359908, 1329765, 1359020, 13599089, 1359909, 270878, 2708782

Aftermarket cross reference / interchange guide

The aftermarket competitive interchanges for TRW DF1688 Brake Disc offered by ABEX, A.B.S., ACDelco, ALANKO, AP, APEC braking, ATE, BENDIX, BORG & BECK, BOSCH, Brake ENGINEERING, BRECO, BREMBO, BREMSI, CAR, CIFAM, DELPHI, DJ AUTO, FAG, FARCOM, FEBI BILSTEIN, FERODO, FIRST LINE, FOMAR, fri.tech., FTE, GIRLING, GRAF, HELLA, HELLA PAGID, HP, JURID, KAWE, KRAFT, LEMFÖRDER, LPR, MAGNETI MARELLI, MAPCO, METELLI, METZGER, MEYLE, MGA, MINTEX, MOTAQUIP, NATIONAL, NECTO, NK, OPEN PARTS, OPTIMAL, PAGID, PEX, PILENGA, PROTECHNIC, QUINTON HAZELL, REMSA, ROADHOUSE, ROTINGER, ROULUNDS RUBBER, sbs, STELLOX, SWAG, TEXTAR, TRISCAN, TRUSTING, VALEO, VEMA, VILLAR, WOKING, ZIMMERMANN manufacturers

ManufacturerReference numbers
ABEXW0458
A.B.S.15932
ACDelcoAC2092D
ALANKO303025, 304740
AP29008E
APEC brakingDSK917
ATE422137, 24112201371, 24012201371
BENDIX561470BC, 561470B, 561445B, 345036
BORG & BECKBBD4038
BOSCHF026A01272, 0986478388, 986478388
Brake ENGINEERING955022, DI955022
BRECOBS7942
BREMBO09503610, 09.5036.14
BREMSIDBA194V
CARHPD658, 142658
CIFAM800201
DELPHIBG2426, 561470J, DF29201, 6101187, 186264, 98200051301, 632510, BDC3570, 54014, 29008, BG426, BS3570
DJ AUTOBD1827
FAGBS3570
FARCOM230856
FEBI BILSTEIN11448, 11451
FERODODDF1941, DDF194, DDF434
FIRST LINEFBD035, FBD052
FOMARFO2092
fri.tech.BD0251
FTEBS3570B, BS3570, BS3459
GIRLING6016881
GRAFDF29201
HELLA8DD355102251
HELLA PAGID8DD355102251
HP57294
JURID561470J, 561470JC, 561445J
KAWE632510
KRAFT6046340
LEMFÖRDER1909201, 1909701
LPRV1181V
MAGNETI MARELLI353616018240
MAPCO15960
METELLI230201
METZGER29008E
MEYLE5155215010, 5155215010/PD
MGAD1001
MINTEXMDC735, MDC546
MOTAQUIPLVBD418Z
NATIONALNBD090
NECTOWN458
NK204826, 314826
OPEN PARTSBDA160820
OPTIMALBS-3250, BS3250C
PAGID54014
PEX140657, 140654
PILENGAV169
PROTECHNICPRD2188
QUINTON HAZELLBDC3459, BSF3570, BDC3717, BDC3570, BSF3459, 57294
REMSA632510
ROADHOUSE632510
ROTINGERRT2018, RT2018T5
ROULUNDS RUBBERD2092
sbs1815314826, 1815204826
STELLOX60204826VSX
SWAG55911448
TEXTAR98200051301, 92051300, 92031200
TRISCAN812027111
TRUSTINGDF945, DF251
VALEO186264, 186262
VEMA98594, 98589
VILLAR6281618
WOKINGP632510, D632510
ZIMMERMANN610118750, 610118700, 6101187

Vehicle fitment / TRW DF1688 Brake Disc compatibility

This product fits the following models: VOLVO 740, VOLVO 740 RURAL, VOLVO 760, VOLVO 780, VOLVO 940, VOLVO 960, etc. See all vehicles this product (TRW DF1688) fits below to verify fitment for your vehicle.
MakeModelVariantPeriodEngineDriveBody Style
VOLVO740
744
745
2.0
2.0 16V
2.0 GLE
2.0 Turbo
2.3
2.3 Turbo
2.4 TD
2.4 TD Interc.
2.4 Turbo-Diesel
1983/04 - 1992/08B19E 116 hp 85 kW 2 L Petrol
B204E 140 hp 103 kW 2 L Petrol
B19ET 150 hp 110 kW 2 L Petrol
B200ET 160 hp 118 kW 2 L Petrol
B200F 111 hp 82 kW 2 L Petrol
B204FTE 200 hp 147 kW 2 L Petrol
B200ET 156 hp 115 kW 2 L Petrol
B200ET 165 hp 121 kW 2 L Petrol
B200FT 155 hp 114 kW 2 L Petrol
B200FT 155 hp 114 kW 2 L Petrol
B204E 136 hp 100 kW 2 L Petrol
B204E 140 hp 103 kW 2 L Petrol
B204FTE 200 hp 147 kW 2 L Petrol
B230ET 182 hp 134 kW 2.3 L Petrol
B230FT 156 hp 115 kW 2.3 L Petrol
B230FT 165 hp 121 kW 2.3 L Petrol
B230FT 170 hp 125 kW 2.3 L Petrol
B230FT 190 hp 140 kW 2.3 L Petrol
B230GT 165 hp 121 kW 2.3 L Petrol
B230GT 170 hp 125 kW 2.3 L Petrol
B230ET 182 hp 134 kW 2.3 L Petrol
B230FT 156 hp 115 kW 2.3 L Petrol
B230FT 165 hp 121 kW 2.3 L Petrol
B230FT 170 hp 125 kW 2.3 L Petrol
B230FT 190 hp 140 kW 2.3 L Petrol
B230GT 170 hp 125 kW 2.3 L Petrol
B230FB 136 hp 100 kW 2.3 L Petrol
B234F 156 hp 114 kW 2.3 L Petrol
B230FB 136 hp 100 kW 2.3 L Petrol
B234F 156 hp 114 kW 2.3 L Petrol
B23E 129 hp 95 kW 2.3 L Petrol
D24T 109 hp 80 kW 2.4 L Diesel
D24T 109 hp 80 kW 2.4 L Diesel
D24TIC 122 hp 90 kW 2.4 L Diesel
D24TIC 122 hp 90 kW 2.4 L Diesel
Rear wheel
Estate / Turnier / Vario / Wagon
Sedan / Saloon
VOLVO740 RURAL
745
2.0
2.0 16V
2.0 GLE
2.0 Turbo
2.3
2.3 Turbo
2.4 TD Interc.
2.4 Turbo-Diesel
1985/05 - 1992/08B200ET 156 hp 115 kW 2 L Petrol
B200ET 165 hp 121 kW 2 L Petrol
B200FT 155 hp 114 kW 2 L Petrol
B204E 136 hp 100 kW 2 L Petrol
B204E 140 hp 103 kW 2 L Petrol
B204FTE 200 hp 147 kW 2 L Petrol
B230ET 182 hp 134 kW 2.3 L Petrol
B230FT 156 hp 115 kW 2.3 L Petrol
B230FT 165 hp 121 kW 2.3 L Petrol
B230FT 170 hp 125 kW 2.3 L Petrol
B230FT 190 hp 140 kW 2.3 L Petrol
B230GT 165 hp 121 kW 2.3 L Petrol
B230GT 170 hp 125 kW 2.3 L Petrol
B230FB 136 hp 100 kW 2.3 L Petrol
B234F 156 hp 114 kW 2.3 L Petrol
D24T 109 hp 80 kW 2.4 L Diesel
D24TIC 122 hp 90 kW 2.4 L Diesel
Rear wheel
Estate / Turnier / Vario / Wagon
VOLVO760
704
764
704
765
2.3
2.3 Turbo
2.4 D
2.4 TD Interc.
2.4 Turbo Diesel
2.8

704
704
764
764
765
1981/08 - 1992/07B230ET 176 hp 130 kW 2.3 L Petrol
B230FT 165 hp 121 kW 2.3 L Petrol
B23ET 173 hp 127 kW 2.3 L Petrol
B230ET 182 hp 134 kW 2.3 L Petrol
B230FT 156 hp 115 kW 2.3 L Petrol
B230ET 182 hp 134 kW 2.3 L Petrol
B23ET 173 hp 127 kW 2.3 L Petrol
B230FT 156 hp 115 kW 2.3 L Petrol
B280E 156 hp 115 kW 2.8 L Petrol
B280F 143 hp 105 kW 2.8 L Petrol
B28A 130 hp 95 kW 2.8 L Petrol
B28E 156 hp 115 kW 2.8 L Petrol
B280E 156 hp 115 kW 2.8 L Petrol
B28E 156 hp 115 kW 2.8 L Petrol
B280E 170 hp 125 kW 2.8 L Petrol
B280E 170 hp 125 kW 2.8 L Petrol
B28A 130 hp 95 kW 2.8 L Petrol
B280F 143 hp 105 kW 2.8 L Petrol
B280F 147 hp 108 kW 2.8 L Petrol
D24 82 hp 60 kW 2.4 L Diesel
D24T 109 hp 80 kW 2.4 L Diesel
D24T 112 hp 82 kW 2.4 L Diesel
D24TIC 115 hp 85 kW 2.4 L Diesel
D24TIC 116 hp 85 kW 2.4 L Diesel
Rear wheel
Estate / Turnier / Vario / Wagon
Sedan / Saloon
VOLVO780
2.4 D
2.9
1986/04 - 1990/07B280E 156 hp 115 kW 2.9 L Petrol
B280F 147 hp 108 kW 2.9 L Petrol
D24TIC 122 hp 90 kW 2.4 L Diesel
Front wheel
Rear wheel
Coupe / Sports car / Grand tourer / Speedster / Roadster
VOLVO940
944
945
2.0
2.0 GL
2.0 Turbo
2.3
2.3 Turbo
2.4 D
2.4 TD Intercooler
2.4 Turbo Diesel
1990/08 - 1995/07B200E 121 hp 89 kW 2 L Petrol
B200F 112 hp 82 kW 2 L Petrol
B200G 121 hp 89 kW 2 L Petrol
B204FT 139 hp 102 kW 2 L Petrol
B200F 112 hp 82 kW 2 L Petrol
B200G 121 hp 89 kW 2 L Petrol
B200FT 155 hp 114 kW 2 L Petrol
B204E 140 hp 103 kW 2 L Petrol
B230FB 131 hp 96 kW 2.3 L Petrol
B230FD 116 hp 85 kW 2.3 L Petrol
B230FT 160 hp 118 kW 2.3 L Petrol
B230G 131 hp 96 kW 2.3 L Petrol
B234F 156 hp 114 kW 2.3 L Petrol
B234G 156 hp 114 kW 2.3 L Petrol
B230FB 131 hp 96 kW 2.3 L Petrol
B230FD 116 hp 85 kW 2.3 L Petrol
B234F 155 hp 114 kW 2.3 L Petrol
B230FT 165 hp 121 kW 2.3 L Petrol
B230FT 165 hp 121 kW 2.3 L Petrol
B230FT+ 190 hp 140 kW 2.3 L Petrol
D24 82 hp 60 kW 2.4 L Diesel
D24T 109 hp 80 kW 2.4 L Diesel
D24TIC 122 hp 90 kW 2.4 L Diesel
Rear wheel
Estate / Turnier / Vario / Wagon
Sedan / Saloon
VOLVO960
964
965
2.0
2.3 Turbo
2.4 Tdi
2.4 TD Interc.
2.8
2.8 GL
2.9
1990/08 - 1994/07B200F 111 hp 82 kW 2 L Petrol
B204E 140 hp 103 kW 2 L Petrol
B204FT 190 hp 140 kW 2 L Petrol
B204E 140 hp 103 kW 2 L Petrol
B204FT 190 hp 140 kW 2 L Petrol
B230FT 165 hp 121 kW 2.3 L Petrol
B280E 156 hp 115 kW 2.8 L Petrol
B280F 147 hp 108 kW 2.8 L Petrol
B280F 147 hp 108 kW 2.8 L Petrol
B6304F 204 hp 150 kW 2.9 L Petrol
B6304FS 204 hp 150 kW 2.9 L Petrol
B6304G 204 hp 150 kW 2.9 L Petrol
B6304F 204 hp 150 kW 2.9 L Petrol
B6304S 204 hp 150 kW 2.9 L Petrol
D24TIC 115 hp 85 kW 2.4 L Diesel
D24TIC 122 hp 90 kW 2.4 L Diesel
Rear wheel
Estate / Turnier / Vario / Wagon
Sedan / Saloon
