TRW DF3049 Brake Disc

TRW part DF3049 Brake Disc

TRW DF3049 Brake Disc

by TRW

Manufacturer Part Number: DF3049

Сharacteristics:
  • Brake Disc Type: Vented
  • Diameter [mm]: 257
  • Brake Disc Thickness [mm]: 22
  • Minimum thickness [mm]: 20,6
  • Centering Diameter [mm]: 88
  • Height [mm]: 36
  • Number of Holes: 6
  • Thread Size: M12 x 1.25
  • Bolt Hole Circle Ø [mm]: 109
  • Machining: High-carbon
  • Colour: Black
  • Surface: Painted

Product Details

BrandTRW
TRW article (MPN)DF3049
Vehicle subsystemBrake System

Original (OEM) part numbers

Suitable for ISUZU, OPEL, VAUXHALL vehicles

OE manufacturerOEM reference numbers
ISUZU8941723761, 8943724350, 8941733440, 94172376, 8943619271
OPEL569801, 94372435, 94172376
VAUXHALL94172376

Aftermarket cross reference / interchange guide

The aftermarket competitive interchanges for TRW DF3049 Brake Disc offered by ABEX, A.B.S., ACDelco, ADVICS / SUMITOMO, ALANKO, AP, APEC braking, ASHIKA, ATE, BENDIX, BLUE PRINT, BORG & BECK, BOSCH, Brake ENGINEERING, BRECO, BREMBO, BREMSI, BSF, CAR, CIFAM, DELPHI, DJ AUTO, E.T.F., FARCOM, FEBI BILSTEIN, FERODO, FIRST LINE, FOMAR, fri.tech., FTE, GIRLING, HELLA, HELLA PAGID, HERTH+BUSS JAKOPARTS, HP, ICER, JAPANPARTS, JAPKO, JURID, KAGER, KAVO PARTS, KAWE, KLAXCAR FRANCE, LEMFÖRDER, LPR, MAGNETI MARELLI, MAPCO, MDR, METELLI, MEYLE, MGA, MINTEX, MOTAQUIP, NATIONAL, NECTO, NIBK, NIPPARTS, NK, OPEN PARTS, OPTIMAL, PAGID, PEX, PILENGA, PROTECHNIC, QUINTON HAZELL, R BRAKE, REMSA, ROADHOUSE, ROTINGER, ROULUNDS RUBBER, sbs, SWAG, TEMPLIN, TEXTAR, TRISCAN, TRUSTING, VAICO, VALEO, VEMA, VILLAR, WOKING, ZIMMERMANN manufacturers

ManufacturerReference numbers
ABEXW0703
A.B.S.15971
ACDelcoAC2457D
ADVICS / SUMITOMOJ6F172
ALANKO305322, 304038
AP24368
APEC brakingDSK618
ASHIKA6009900, 6009909
ATE24012201561
BENDIX561643BC, 561643B
BLUE PRINTADZ94302, AD794302
BORG & BECKBBD4932
BOSCH0986479R42, 986478596, F026A00782, 0986AB9872, 0986AB9770, 0986478596, 0986AB6128
Brake ENGINEERINGDI951152
BRECOBS8056
BREMBO09557710
BREMSIDBA385V
BSF11129V
CAR142517, HPD517
CIFAM800351
DELPHI464601V, BG524, 24368, 98200075801, 3798, 618810, 52418, J3309009, BG2524, 5172
DJ AUTOBD1242
E.T.F.192376
FARCOM230739
FEBI BILSTEIN10750
FERODODDF3851, DDF385
FIRST LINEFBD408
FOMARFO2457
fri.tech.BD0421
FTEBS3828
GIRLING6030491
HELLA8DD355104-711
HELLA PAGID8DD355104711
HERTH+BUSS JAKOPARTSJ3309009
HP53707
ICER78BD23762
JAPANPARTSDI909, DI900
JAPKO60900, 60909
JURID561643JC, 561643J
KAGER370597
KAVO PARTSBR3701C, BR3701
KAWE618810
KLAXCAR FRANCE25031Z
LEMFÖRDER1611002
LPRO1251V
MAGNETI MARELLI600000089520, 360406014900, 353610406240
MAPCO15842
MDRMFD2900, MFD2909
METELLI230351
MEYLE42-155210000/PD
MGAD1151
MINTEXMDC738
MOTAQUIPLVBD458Z
NATIONALNBD209
NECTOWN703
NIBKRN1326
NIPPARTSJ3309009
NK319929, 209929
OPEN PARTSBDA106720
OPTIMALBS-1880
PAGID52418
PEX140073
PILENGAV370
PROTECHNICPRD2214
QUINTON HAZELLBDC3828, 53707, BSF3828
R BRAKE78RBD22376
REMSA618810
ROADHOUSE618810
ROTINGERRT2323T5, RT2323
ROULUNDS RUBBERD2457
sbs1815209929, 1815319929
SWAG40910750
TEMPLIN0311017470
TEXTAR92075800, 98200075801
TRISCAN812010130
TRUSTINGDF421
VAICOV4080035
VALEO186488
VEMA98312
VILLAR6281042
WOKINGD618810, P618810
ZIMMERMANN430147250, 430147200

Vehicle fitment / TRW DF3049 Brake Disc compatibility

This product fits the following models: HOLDEN JACKAROO, HOLDEN RODEO, ISUZU BIGHORN, ISUZU CAMPO, ISUZU D-MAX, ISUZU ELF, ISUZU FASTER, ISUZU GEMINI, ISUZU I-MARK, ISUZU INVADER, ISUZU KB, ISUZU RODEO, ISUZU SPACECAB, ISUZU TF, ISUZU TFRTFS, ISUZU TROOPER, OPEL CAMPO, OPEL FRONTERA A, VAUXHALL BRAVA, VAUXHALL FRONTERAI, etc. See all vehicles this product (TRW DF3049) fits below to verify fitment for your vehicle.
MakeModelVariantPeriodEngineDriveBody Style
HOLDENJACKAROO
UBS
2.6 4x4
2.8 TD 4x4
UBS17
UBS55
1987/10 - 1991/094JB1-T 101 hp 74 kW 2.8 L Diesel
4ZE1 116 hp 85 kW 2.6 L Petrol
AWD / 4WD
Full-size SUV / Compact SUV / Mid-size SUV / Compact SUV / Crossover SUV
HOLDENRODEO
TF
2.2 i
2.3 i
2.5 D
2.5 D 4x4
2.6 i
2.6 i 4x4
2.8 TD
2.8 TD 4x4
3.0 TD
3.0 TD 4x4
TFR16
TFR17
TFR30
TFR30
TFR25
TFR54
TFR55
TFR77
TFS17
TFS54
TFS55
TFS77
1988/02 - 2003/084JA1 78 hp 57 kW 2.5 L Diesel
4JB1-T 101 hp 74 kW 2.8 L Diesel
4JH1-TC 131 hp 96 kW 3 L Diesel
4ZD1 94 hp 69 kW 2.3 L Petrol
4ZE1 120 hp 88 kW 2.6 L Petrol
C22NE 118 hp 87 kW 2.2 L Petrol
AWD / 4WD
Rear wheel
Pickup truck / Pickup
With flatbed/undercarriage
ISUZUBIGHORN
UBS
2.2 D 4x4
2.3
2.6 4x4
2.6 CLS Plane 4x4
2.6 i
2.8 TD

UBS16
UBS17
UBS55
1984/05 - 1991/124JB1T 101 hp 74 kW 2.8 L Diesel
4JB1T 97 hp 71 kW 2.8 L Diesel
4JB1-TC 106 hp 78 kW 2.8 L Diesel
4ZD1 90 hp 66 kW 2.3 L Petrol
4ZE1 116 hp 85 kW 2.6 L Petrol
4ZE1 90 hp 66 kW 2.6 L Petrol
C223 53 hp 39 kW 2.2 L Diesel
AWD / 4WD
Full-size SUV / Compact SUV / Mid-size SUV / Compact SUV / Crossover SUV
SUV hardtop / SUV softtop / SUV Sport / SUV cabrio
ISUZUCAMPO
KB
2.2
2.2 D
2.2 D 4WD
2.5 D
2.5 D 4WD
KBD27
KBD42
KBD47
KBD47
TFS
1983/01 - 1990/124JA1 75 hp 55 kW 2.5 L Diesel
4ZD1 90 hp 66 kW 2.2 L Petrol
C223 53 hp 39 kW 2.2 L Diesel
AWD / 4WD
Rear wheel
Pickup truck / Pickup
ISUZUD-MAX
8DH
2.5 D
2.5 D 4x4
2002/05 - 4JA1-TC 101 hp 74 kW 2.5 L Diesel
AWD / 4WD
Rear wheel
Pickup truck / Pickup
ISUZUELF
NHR5
NKR7
NKS7
NHR6
2.5 TD
2.7 TD
2.8 D
2.8 TD
3.1 TD
1985/10 - 2003/094JB1 57 hp 42 kW 2.8 L Diesel
4JB1T 78 hp 57 kW 2.8 L Diesel
4JG2 98 hp 72 kW 3.1 L Diesel
TD25II 83 hp 61 kW 2.5 L Diesel
TD27 86 hp 63 kW 2.7 L Diesel
Rear wheel
Rear wheel
AWD / 4WD
LCV / Van / Cargo
With flatbed/undercarriage
ISUZUFASTER
KB
2.2
2.2 D
2.2 D 4WD
2.5 D
2.5 D 4WD
KBD27
KBD42
KBD47
KBD47
TFS
1983/01 - 1990/124JA1 75 hp 55 kW 2.5 L Diesel
4ZD1 90 hp 66 kW 2.2 L Petrol
C223 53 hp 39 kW 2.2 L Diesel
AWD / 4WD
Rear wheel
Pickup truck / Pickup
ISUZUGEMINI

JT
1.5
1.5 D
1.5 i
1.5 TD
1.6
1.6 GTI 16V
1.6 i
1980/09 - 1993/124EC1 50 hp 37 kW 1.5 L Diesel
4EC1T 67 hp 49 kW 1.5 L Diesel
4XC1 99 hp 73 kW 1.5 L Petrol
4XC1UKat. 71 hp 52 kW 1.5 L Petrol
4XC1UKat. 71 hp 52 kW 1.5 L Petrol
4XC1UT 120 hp 88 kW 1.5 L Petrol
4XE1 114 hp 84 kW 1.6 L Petrol
4XE1-WU 132 hp 97 kW 1.6 L Petrol
Front wheel
Hatchback / Sportback / Sport hatch
Sedan / Saloon
ISUZUI-MARK
1.5 D
1980/09 - 1984/094EC1 50 hp 37 kW 1.5 L Diesel
Front wheel
Sedan / Saloon
ISUZUINVADER
TF
2.5 TD
2.8 D
1988/09 - 1999/084JA1T 117 hp 86 kW 2.5 L Diesel
4JB1 101 hp 74 kW 2.8 L Diesel
AWD / 4WD
Rear wheel
AWD / 4WD
Pickup truck / Pickup
ISUZUKB

TF
2.3
2.3 4WD
2.4 DiTD
2.5 TD
2.5 TDi
2.8 D
2.8 TD
2.8 TD 4WD
3.0 DiTD
3.1 TD
3.1 TD 4WD
3.5 4WD
1988/04 - 2003/09120 hp 88 kW 2.4 L Diesel
4JA1T 117 hp 86 kW 2.5 L Diesel
4JA1T 90 hp 66 kW 2.5 L Diesel
4JB1 101 hp 74 kW 2.8 L Diesel
4JB1-TC 106 hp 78 kW 2.8 L Diesel
4JG2 98 hp 72 kW 3.1 L Diesel
4JH1-TC 131 hp 96 kW 3 L Diesel
4ZD1 87 hp 64 kW 2.3 L Petrol
4ZD1 90 hp 66 kW 2.3 L Petrol
6VE1 230 hp 169 kW 3.5 L Petrol
AWD / 4WD
AWD / 4WD
Rear wheel
Rear wheel
Pickup truck / Pickup
ISUZURODEO

8DH
2.3 4WD
2.5 D
2.5 D 4x4
1988/04 - 4JA1-TC 101 hp 74 kW 2.5 L Diesel
4ZD1 90 hp 66 kW 2.3 L Petrol
AWD / 4WD
Rear wheel
Pickup truck / Pickup
ISUZUSPACECAB
2.3
2.8 TD
2000/05 - 2003/094JB1T 106 hp 78 kW 2.8 L Diesel
4ZD1 87 hp 64 kW 2.3 L Petrol
Rear wheel
Pickup truck / Pickup
ISUZUTF
2.3
2.8 TD
2000/05 - 2003/094JB1T 106 hp 78 kW 2.8 L Diesel
4ZD1 87 hp 64 kW 2.3 L Petrol
Rear wheel
Pickup truck / Pickup
ISUZUTFRTFS
TF
2.5 TD
2.8 D
1988/09 - 1999/084JA1T 117 hp 86 kW 2.5 L Diesel
4JB1 101 hp 74 kW 2.8 L Diesel
AWD / 4WD
Rear wheel
AWD / 4WD
Pickup truck / Pickup
ISUZUTROOPER
UBS
2.2 D 4x4
2.3
2.6 4x4
2.6 CLS Plane 4x4
2.6 i
2.8 TD

UBS16
UBS17
UBS55
1984/05 - 1991/124JB1T 101 hp 74 kW 2.8 L Diesel
4JB1T 97 hp 71 kW 2.8 L Diesel
4JB1-TC 106 hp 78 kW 2.8 L Diesel
4ZD1 90 hp 66 kW 2.3 L Petrol
4ZE1 116 hp 85 kW 2.6 L Petrol
4ZE1 90 hp 66 kW 2.6 L Petrol
C223 53 hp 39 kW 2.2 L Diesel
AWD / 4WD
Full-size SUV / Compact SUV / Mid-size SUV / Compact SUV / Crossover SUV
SUV hardtop / SUV softtop / SUV Sport / SUV cabrio
OPELCAMPO
TF
2.2 D
2.2 D 4x4
2.3
2.3 4x4
2.5 D
2.5 D 4x4
2.5 DTI
2.5 DTI 4x4
2.5 TD
2.5 TD 4x4
3.1 TD
3.1 TD 4x4

TFR16
TFR52
TFR54
TFR69
TFS16
TFS52
TFS54
TFS69
1987/08 - 23P 98 hp 72 kW 2.3 L Petrol
4ZD1 94 hp 69 kW 2.3 L Petrol
4ZD1 98 hp 72 kW 2.3 L Petrol
4FD1 61 hp 45 kW 2.2 L Diesel
4JA1 101 hp 74 kW 2.5 L Diesel
4JA1 76 hp 56 kW 2.5 L Diesel
4JA1T 76 hp 56 kW 2.5 L Diesel
4JG2T 109 hp 80 kW 3.1 L Diesel
4ZD1 94 hp 69 kW 2.3 L Petrol
4ZD1 98 hp 72 kW 2.3 L Petrol
C223 53 hp 39 kW 2.2 L Diesel
C223 61 hp 45 kW 2.2 L Diesel
AWD / 4WD
Rear wheel
Pickup truck / Pickup
OPELFRONTERA A
5MWL4
5SUD2
2.0 i
2.3 TD
2.4 i
52SUD2
55SUD2
53MWL4
5JMWL4
1992/03 - 1998/1023DTR 100 hp 74 kW 2.3 L Diesel
C20NE 115 hp 85 kW 2 L Petrol
X20SE 115 hp 85 kW 2 L Petrol
C24NE 125 hp 92 kW 2.4 L Petrol
AWD / 4WD
Full-size SUV / Compact SUV / Mid-size SUV / Compact SUV / Crossover SUV
SUV hardtop / SUV softtop / SUV Sport / SUV cabrio
VAUXHALLBRAVA
2.2 D
2.2 D 4x4
2.3
2.3 4x4
2.5 D
2.5 D 4x4
2.5 DTI
2.5 DTI 4x4
2.5 TD
2.5 TD 4x4
3.1 D

TFR16
TFR52
TFR54
TFS16
TFS52
TFS54
1988/12 - 2002/1223P 98 hp 72 kW 2.3 L Petrol
4ZD1 94 hp 69 kW 2.3 L Petrol
4FD1 61 hp 45 kW 2.2 L Diesel
4JA1 101 hp 74 kW 2.5 L Diesel
4JA1 76 hp 56 kW 2.5 L Diesel
4JA1T 76 hp 56 kW 2.5 L Diesel
4JG2T 108 hp 80 kW 3.1 L Diesel
C223 53 hp 39 kW 2.2 L Diesel
AWD / 4WD
Rear wheel
Pickup truck / Pickup
VAUXHALLFRONTERAI
A
A Sport
2.0 i
2.3 TD
2.4 i
1991/09 - 1998/1023DTR 100 hp 74 kW 2.3 L Diesel
C20NE 115 hp 85 kW 2 L Petrol
X20SE 115 hp 85 kW 2 L Petrol
C24NE 125 hp 92 kW 2.4 L Petrol
AWD / 4WD
Full-size SUV / Compact SUV / Mid-size SUV / Compact SUV / Crossover SUV
SUV hardtop / SUV softtop / SUV Sport / SUV cabrio
