TRW DF4053S Brake Disc

TRW part DF4053S Brake Disc

TRW DF4053S Brake Disc

by TRW

Manufacturer Part Number: DF4053S

Сharacteristics:
  • Brake Disc Type: Vented
  • Diameter [mm]: 305
  • Brake Disc Thickness [mm]: 28
  • Minimum thickness [mm]: 25
  • Centering Diameter [mm]: 68
  • Height [mm]: 50,3
  • Number of Holes: 5
  • Thread Size: 16,5
  • Bolt Hole Circle Ø [mm]: 108
  • Colour: Black
  • Surface: Painted

Product Details

BrandTRW
TRW article (MPN)DF4053S
Vehicle subsystemBrake System

Original (OEM) part numbers

Suitable for VOLVO vehicles

OE manufacturerOEM reference numbers
VOLVO2724045, 274170, 2741702, 274559, 31262707, 31262716, 272404, 31400740

Aftermarket cross reference / interchange guide

The aftermarket competitive interchanges for TRW DF4053S Brake Disc offered by A.B.S., AP, APEC braking, ATE, BARUM, BENDIX, BORG & BECK, BOSCH, Brake ENGINEERING, BRECO, BREMBO, BREMSI, CAR, CIFAM, DELPHI, DENCKERMANN, Dr!ve+, E.T.F., EUROBRAKE, FARCOM, FEBI BILSTEIN, FERODO, FIRST LINE, FOMAR, fri.tech., FTE, GIRLING, G.U.D, HELLA, HELLA PAGID, HP, ICER, JP GROUP, JURATEK, JURID, KAGER, KAMOKA, KAWE, KEY PARTS, LPR, MAGNETI MARELLI, MAPCO, METELLI, METZGER, MEYLE, MGA, MINTEX, NATIONAL, NECTO, NIBK, NK, OPEN PARTS, OPTIMAL, PAGID, PATRON, PEX, PILENGA, PROTECHNIC, QUINTON HAZELL, R BRAKE, REMSA, ROADHOUSE, ROTINGER, ROULUNDS RUBBER, RUVILLE, sbs, STARLINE, STELLOX, SWAG, TEXTAR, TRISCAN, TRUSTING, VAICO, VALEO, VEMA, VILLAR, WOKING, ZIMMERMANN manufacturers

ManufacturerReference numbers
A.B.S.17012
APX24845, 24845V, 24845, 24845X
APEC brakingDSK974
ATE24112801231, 24012801231, 24032801231
BARUMBAR28123
BENDIX562173B, 562173BC
BORG & BECKBBD5899S
BOSCH0986AB6595, 0986478494
Brake ENGINEERINGDI955887
BRECOBV8469, BS8469
BREMBO09913075, 09776410, 09.9130.10, 09913011, 0991301X
BREMSIDBB078V
CARHPD649, 142649
CIFAM800561C
DELPHIBG9514, BG3418, BG9514C
DENCKERMANNB130135
Dr!ve+DP1010110787
E.T.F.194045
EUROBRAKE5815204842
FARCOM231196
FEBI BILSTEIN18050
FERODODRF1078, DDF1078, DDF1078C1, DDF1079, DDF10781
FIRST LINEFBD1154, FBD1245
FOMARFO1423
fri.tech.BD0554
FTEBS4728B, BS4728
GIRLING6040535
G.U.DGDB128123
HELLA8DD355107072, 8DD355107071, 8DD355107061
HELLA PAGID8DD355107071, 8DD355107072, 8DD355107061
HP57904
ICER78BD40452
JP GROUP4963101009
JURATEKVOL126
JURID562173JC, 562173J
KAGER370545, 371412
KAMOKA1032156
KAWE659110
KEY PARTSKBD5899S
LPRV1483V
MAGNETI MARELLI431602042710, 360406051800, 353616029240
MAPCO15966
METELLI230561C, 230561
METZGER6110222, 24845V
MEYLE5155210001/PD, 5145210001
MGAD1376
MINTEXMDC1433
NATIONALNBD1072
NECTOWN1090
NIBKRN1113
NK344842, 204842, 314842
OPEN PARTSBDR184620
OPTIMALBS-5910, BS5910C
PAGID50283, 50283PRO
PATRONPBD4053
PEX140669
PILENGAV263
PROTECHNICPRD2423
QUINTON HAZELLBDC4728, BSF4728, 57904
R BRAKE78RBD24045
REMSA659110
ROADHOUSE659110
ROTINGERRT2799, RT2799T5
ROULUNDS RUBBERD1423
RUVILLEBFR410210
sbs1815204842, 1815314842
STARLINEPB2799C
STELLOX60204842VSX
SWAG55918050
TEXTAR92100600, 92100605, 92100603
TRISCAN812027130C, 812027130
TRUSTINGDF554
VAICOV9580005
VALEO297741, 186741
VEMA98606
VILLAR6281764
WOKINGD659110
ZIMMERMANN610370250, 610370252, 610370200, 610370270, 610370220

Vehicle fitment / TRW DF4053S Brake Disc compatibility

This product fits the following models: VOLVO S60 I, VOLVO S80 I, VOLVO V70  , VOLVO V70 I, VOLVO V70 II, VOLVO V70II, VOLVO V70 XC, VOLVO XC70 CROSS COUNTRY, etc. See all vehicles this product (TRW DF4053S) fits below to verify fitment for your vehicle.
MakeModelVariantPeriodEngineDriveBody Style
VOLVOS60 I
2.0 T
2.3 T5
2.4
2.4 Bifuel
2.4 D
2.4 D5
2.4 T
2.4 T5
2.4 T AWD
2.5 T
2.5 T AWD
T5

CNG
LPG
2000/07 - 2010/04B5204T5 180 hp 132 kW 2 L Petrol
B5234T3 250 hp 184 kW 2.3 L Petrol
B5234T7 265 hp 195 kW 2.3 L Petrol
B5244S 170 hp 125 kW 2.4 L Petrol
B5244S2 140 hp 103 kW 2.4 L Petrol
B5244T4 180 hp 132 kW 2.4 L Petrol
B5244SG 140 hp 103 kW 2.4 L Petrol
B5244SG2 140 hp 103 kW 2.4 L Petrol
B5244T3 200 hp 147 kW 2.4 L Petrol
B5244T5 260 hp 191 kW 2.4 L Petrol
B5254T2 210 hp 154 kW 2.5 L Petrol
D5244T 163 hp 120 kW 2.4 L Diesel
D5244T4 185 hp 136 kW 2.4 L Diesel
D5244T2 130 hp 96 kW 2.4 L Diesel
D5244T5 163 hp 120 kW 2.4 L Diesel
D5244T6 122 hp 90 kW 2.4 L Diesel
D5244T7 126 hp 93 kW 2.4 L Diesel
AWD / 4WD
Front wheel
Sedan / Saloon
VOLVOS80 I
TS
XY
2.0
2.0 T
2.4
2.4 Bifuel
2.4 D
2.4 D5
2.4 LTP
2.4 T
2.4 T5 AWD
2.5 T
2.5 T AWD
2.5 TDI
2.8 T6
2.9
3.0
3.0 T6

CNG
LPG
1998/05 - 2006/07B5204T3 226 hp 166 kW 2 L Petrol
B5204T5 180 hp 132 kW 2 L Petrol
B5204T4 163 hp 120 kW 2 L Petrol
B5244S 170 hp 125 kW 2.4 L Petrol
B5244S2 140 hp 103 kW 2.4 L Petrol
B5244SG 140 hp 103 kW 2.4 L Petrol
B5244SG2 140 hp 103 kW 2.4 L Petrol
B5244T3 200 hp 147 kW 2.4 L Petrol
B5244T4 179 hp 132 kW 2.4 L Petrol
B5254T2 210 hp 154 kW 2.5 L Petrol
B6284T 272 hp 200 kW 2.8 L Petrol
B6294S 200 hp 147 kW 2.9 L Petrol
B6304S3 204 hp 150 kW 2.9 L Petrol
B6294S2 196 hp 144 kW 3 L Petrol
B6294T 272 hp 200 kW 3 L Petrol
D5244T 163 hp 120 kW 2.4 L Diesel
D5244T2 131 hp 96 kW 2.4 L Diesel
D5252T 140 hp 103 kW 2.5 L Diesel
AWD / 4WD
Front wheel
Sedan / Saloon
VOLVOV70
LV
2.0
2.3 Turbo
2.4
2.5 AWD
2.5 TDI
2.5 Turbo AWD
1997/01 - 2000/05B5202S 126 hp 93 kW 2 L Petrol
B5204T2 180 hp 132 kW 2 L Petrol
B5234FT+ 250 hp 184 kW 2.3 L Petrol
B5244S2 140 hp 103 kW 2.4 L Petrol
B5244SG2 140 hp 103 kW 2.4 L Petrol
B5244T 193 hp 142 kW 2.5 L Petrol
B5254T 193 hp 142 kW 2.5 L Petrol
B5244T2 265 hp 195 kW 2.5 L Petrol
D5252T 140 hp 103 kW 2.5 L Diesel
AWD / 4WD
Front wheel
Estate / Turnier / Vario / Wagon
VOLVOV70 I
LV
2.0
2.3 Turbo
2.4
2.5 AWD
2.5 TDI
2.5 Turbo AWD
1997/01 - 2000/05B5202S 126 hp 93 kW 2 L Petrol
B5204T2 180 hp 132 kW 2 L Petrol
B5234FT+ 250 hp 184 kW 2.3 L Petrol
B5244S2 140 hp 103 kW 2.4 L Petrol
B5244SG2 140 hp 103 kW 2.4 L Petrol
B5244T 193 hp 142 kW 2.5 L Petrol
B5254T 193 hp 142 kW 2.5 L Petrol
B5244T2 265 hp 195 kW 2.5 L Petrol
D5252T 140 hp 103 kW 2.5 L Diesel
AWD / 4WD
Front wheel
Estate / Turnier / Vario / Wagon
VOLVOV70 II
SW
2.0 T
2.3 T5
2.4
2.4 Bifuel
2.4 D
2.4 D5
2.4 D5 AWD
2.4 T
2.4 T5
2.4 T AWD
2.5 T
2.5 T AWD
2.5 TDI

CNG
LPG
2000/03 - 2007/08B5204T5 180 hp 132 kW 2 L Petrol
B5234T3 250 hp 184 kW 2.3 L Petrol
B5244S 170 hp 125 kW 2.4 L Petrol
B5244S2 140 hp 103 kW 2.4 L Petrol
B5244SG 140 hp 103 kW 2.4 L Petrol
B5244SG2 140 hp 103 kW 2.4 L Petrol
B5244T3 200 hp 147 kW 2.4 L Petrol
B5244T5 260 hp 191 kW 2.4 L Petrol
B5254T2 209 hp 154 kW 2.5 L Petrol
D5244T 163 hp 120 kW 2.4 L Diesel
D5244T2 163 hp 120 kW 2.4 L Diesel
D5244T4 185 hp 136 kW 2.4 L Diesel
D5244T5 163 hp 120 kW 2.4 L Diesel
D5244T 163 hp 120 kW 2.4 L Diesel
D5244T4 185 hp 136 kW 2.4 L Diesel
D5244T5 163 hp 120 kW 2.4 L Diesel
D5244T2 131 hp 96 kW 2.4 L Diesel
D5244T7 126 hp 93 kW 2.4 L Diesel
D5252T 140 hp 103 kW 2.5 L Diesel
AWD / 4WD
Front wheel
Estate / Turnier / Vario / Wagon
VOLVOV70II
SW
2.0 T
2.3 T5
2.4
2.4 Bifuel
2.4 D
2.4 D5
2.4 D5 AWD
2.4 T
2.4 T5
2.4 T AWD
2.5 T
2.5 T AWD
2.5 TDI

CNG
LPG
2000/03 - 2007/08B5204T5 180 hp 132 kW 2 L Petrol
B5234T3 250 hp 184 kW 2.3 L Petrol
B5244S 170 hp 125 kW 2.4 L Petrol
B5244S2 140 hp 103 kW 2.4 L Petrol
B5244SG 140 hp 103 kW 2.4 L Petrol
B5244SG2 140 hp 103 kW 2.4 L Petrol
B5244T3 200 hp 147 kW 2.4 L Petrol
B5244T5 260 hp 191 kW 2.4 L Petrol
B5254T2 209 hp 154 kW 2.5 L Petrol
D5244T 163 hp 120 kW 2.4 L Diesel
D5244T2 163 hp 120 kW 2.4 L Diesel
D5244T4 185 hp 136 kW 2.4 L Diesel
D5244T5 163 hp 120 kW 2.4 L Diesel
D5244T 163 hp 120 kW 2.4 L Diesel
D5244T4 185 hp 136 kW 2.4 L Diesel
D5244T5 163 hp 120 kW 2.4 L Diesel
D5244T2 131 hp 96 kW 2.4 L Diesel
D5244T7 126 hp 93 kW 2.4 L Diesel
D5252T 140 hp 103 kW 2.5 L Diesel
AWD / 4WD
Front wheel
Estate / Turnier / Vario / Wagon
VOLVOV70 XC
2.4 D5 AWD
2.4 D5 XC AWD
2.4 T XC AWD
2.5 T XC AWD
2000/03 - 2007/08B5244T3 200 hp 147 kW 2.4 L Petrol
B5254T2 209 hp 154 kW 2.5 L Petrol
D5244T 163 hp 120 kW 2.4 L Diesel
D5244T4 185 hp 136 kW 2.4 L Diesel
AWD / 4WD
Estate / Turnier / Vario / Wagon
VOLVOXC70 CROSS COUNTRY
2.4 D5 AWD
2.4 D5 XC AWD
2.4 T XC AWD
2.5 T XC AWD
2000/03 - 2007/08B5244T3 200 hp 147 kW 2.4 L Petrol
B5254T2 209 hp 154 kW 2.5 L Petrol
D5244T 163 hp 120 kW 2.4 L Diesel
D5244T4 185 hp 136 kW 2.4 L Diesel
AWD / 4WD
Estate / Turnier / Vario / Wagon
