TRW DF4109 Brake Disc

TRW part DF4109 Brake Disc

TRW DF4109 Brake Disc

by TRW

Manufacturer Part Number: DF4109

Сharacteristics:
  • Surface: Painted
  • Brake Disc Type: Vented
  • Diameter [mm]: 280
  • Brake Disc Thickness [mm]: 24
  • Minimum thickness [mm]: 21,8
  • Centering Diameter [mm]: 61
  • Height [mm]: 44
  • Number of Holes: 5
  • Thread Size: 13,5
  • Bolt Hole Circle Ø [mm]: 108
  • Machining: High-carbon
  • Supplementary Article/Info 2: with screws
  • Colour: Black

Product Details

BrandTRW
TRW article (MPN)DF4109
Vehicle subsystemBrake System

Original (OEM) part numbers

Suitable for RENAULT vehicles

OE manufacturerOEM reference numbers
RENAULT7700802231, 7700830283, 7701204305, 7701205231, 7701205843, 7701206198, 7703004176, 7703004128

Aftermarket cross reference / interchange guide

The aftermarket competitive interchanges for TRW DF4109 Brake Disc offered by A.B.S., ACDelco, ALANKO, AP, APEC braking, ATE, BARUM, BENDIX, BORG & BECK, BOSCH, Brake ENGINEERING, BRECO, BREMBO, BREMSI, CAR, CIFAM, DELPHI, DENCKERMANN, DJ AUTO, Dr!ve+, E.T.F., EUROBRAKE, FARCOM, FEBI BILSTEIN, FENOX, FERODO, FIRST LINE, FOMAR, fri.tech., FTE, GALFER, GIRLING, G.U.D, HELLA, HELLA PAGID, HP, ICER, JP GROUP, JURID, KAGER, KAWE, KRAFT, LEMFÖRDER, LPR, MAGNETI MARELLI, MAPCO, METELLI, METZGER, MEYLE, MGA, MINTEX, MOTAQUIP, NATIONAL, NECTO, NK, OPEN PARTS, OPTIMAL, PAGID, PEX, PILENGA, PROTECHNIC, QUINTON HAZELL, R BRAKE, REMSA, ROADHOUSE, ROTINGER, ROULUNDS RUBBER, SASIC, sbs, STARLINE, STELLOX, SWAG, TEMPLIN, TEXTAR, TRISCAN, TRUSTING, VAICO, VALEO, VEMA, VILLAR, WAGNER LOCKHEED, WOKING, ZIMMERMANN manufacturers

ManufacturerReference numbers
A.B.S.16219
ACDelcoAC2513D, AC2168D
ALANKO304220
AP22025E, X22025
APEC brakingDSK834
ATE24032401261, 24032401711, 24012401261, 24012401711
BARUMBAR24171
BENDIX561593BC, 562104BC, 562104B, 561593B
BORG & BECKBBD5020
BOSCH0986478734, 0986BB4080, 0986478797
Brake ENGINEERINGDI955321
BRECOBS8392
BREMBO09738610, 09.8137.14, 09738630, 09813775, 09568610
BREMSIDBB123V
CARHPD561, HPD544, 142561, 142544
CIFAM800533
DELPHIBS4406, BG2697
DENCKERMANNB130082
DJ AUTOBD1793
Dr!ve+DP1010110736
E.T.F.194305
EUROBRAKE5815203913
FARCOM230924
FEBI BILSTEIN12097
FENOXTB217748, TB217744
FERODODDF11231, DRF3695, DRF369S, DDF369, DDF1123, DRF1123, DDF1101
FIRST LINEFBD1240, FBD540
FOMARFO2168
fri.tech.BD0507
FTEBS4406B, BS4406
GALFERB1G22401711
GIRLING6041091
G.U.DGDB124171
HELLA8DD355108621, 8DD355108631
HELLA PAGID8DD355108621, 8DD355108631
HP57969, 57453
ICER78BD61982
JP GROUP4363102009
JURID561593J, 561593JC, 562104JC, 562104J
KAGER370216
KAWE630110
KRAFT6045112
LEMFÖRDER1816301
LPRR1571V, R1311V
MAGNETI MARELLI353614030206, 431602040790, 431602041760, 360406044000
MAPCO15118, 15118/2
METELLI230533, 230540
METZGER6110386, 22025E
MEYLE16-155210016
MGAD1372
MINTEXMDC778
MOTAQUIPLVBD722
NATIONALNBD491
NECTOWN1107
NK203913, 89011663, 313913
OPEN PARTSBDR181620, BDR187920, BDA187920
OPTIMALBS3010
PAGID54138, 50288, 54138PRO
PEX140498
PILENGAV744
PROTECHNICPRD2607, PRD2137
QUINTON HAZELLBDC4406, 820805, BDC4339, 57453, 57969, BSF4339, BSF4406
R BRAKE78RBD26198
REMSA662210, 630110, 820805
ROADHOUSE630110, 820805
ROTINGERRT2930, RT2930T5
ROULUNDS RUBBERD2168, D2513
SASIC4004282J
sbs1815313913, 1815203913
STARLINEPB2540C
STELLOX60203913VSX
SWAG60912097
TEMPLIN0311025230, 0311025235
TEXTAR98200102101, 89010600, 98200065201, 92113800, 92113803
TRISCAN812025110, 812025127
TRUSTINGDF507
VAICOV4680007
VALEO186600
VEMA98067
VILLAR6280558
WAGNER LOCKHEEDWGR11231
WOKINGP630110, D630110
ZIMMERMANN47024110, 470241120, 47241150, 470241100, 470241150

Vehicle fitment / TRW DF4109 Brake Disc compatibility

This product fits the following models: RENAULT ESPACE III, RENAULT ESPACEIII, RENAULT LAGUNA I, RENAULT LAGUNA I NEVADA, RENAULT SAFRANE  , RENAULT SAFRANE I, RENAULT SAFRANE II, RENAULT SAFRANEII, RENAULT SCÉNIC I, etc. See all vehicles this product (TRW DF4109) fits below to verify fitment for your vehicle.
MakeModelVariantPeriodEngineDriveBody Style
RENAULTESPACE III
JE0
1.9 dTi
2.0
2.0 16V
2.2 12V TD
2.2 D
3.0

JE0A
JE0D
JE0E
JE0H
JE0P
JE0M
JE0N
JE0L
JE02
1996/11 - 2002/10F3R728 114 hp 84 kW 2 L Petrol
F3R729 114 hp 84 kW 2 L Petrol
F3R742 114 hp 84 kW 2 L Petrol
F3R768 114 hp 84 kW 2 L Petrol
F3R769 114 hp 84 kW 2 L Petrol
F4R700 139 hp 102 kW 2 L Petrol
F4R701 139 hp 102 kW 2 L Petrol
F4R700 140 hp 103 kW 2 L Petrol
F4R701 140 hp 103 kW 2 L Petrol
F9Q722 98 hp 72 kW 1.9 L Diesel
G8T714 113 hp 83 kW 2.2 L Diesel
G8T716 113 hp 83 kW 2.2 L Diesel
G8T760 113 hp 83 kW 2.2 L Diesel
G8T716 114 hp 84 kW 2.2 L Diesel
Z7X775 167 hp 123 kW 3 L Petrol
Front wheel
MPV / Van / Minivan
RENAULTESPACEIII
JE0
1.9 dTi
2.0
2.0 16V
2.2 12V TD
2.2 D
3.0

JE0A
JE0D
JE0E
JE0H
JE0P
JE0M
JE0N
JE0L
JE02
1996/11 - 2002/10F3R728 114 hp 84 kW 2 L Petrol
F3R729 114 hp 84 kW 2 L Petrol
F3R742 114 hp 84 kW 2 L Petrol
F3R768 114 hp 84 kW 2 L Petrol
F3R769 114 hp 84 kW 2 L Petrol
F4R700 139 hp 102 kW 2 L Petrol
F4R701 139 hp 102 kW 2 L Petrol
F4R700 140 hp 103 kW 2 L Petrol
F4R701 140 hp 103 kW 2 L Petrol
F9Q722 98 hp 72 kW 1.9 L Diesel
G8T714 113 hp 83 kW 2.2 L Diesel
G8T716 113 hp 83 kW 2.2 L Diesel
G8T760 113 hp 83 kW 2.2 L Diesel
G8T716 114 hp 84 kW 2.2 L Diesel
Z7X775 167 hp 123 kW 3 L Petrol
Front wheel
MPV / Van / Minivan
RENAULTLAGUNA I
B56
556
K56
1.6 16V
1.8 16V
2.0
2.0 16V
2.2 dT
2.9 24V
3.0
3.0 24V

B563
B564
B569
B56D/M
B56E/R
B565
B56V
K568
K569
K56D/M
K56R
K565
K56V
1993/11 - 2001/03F3R611 109 hp 80 kW 2 L Petrol
N7Q700 140 hp 103 kW 2 L Petrol
N7Q704 140 hp 103 kW 2 L Petrol
F4P760 120 hp 88 kW 1.8 L Petrol
F4P770 120 hp 88 kW 1.8 L Petrol
G8T760 113 hp 83 kW 2.2 L Diesel
K4M720 107 hp 79 kW 1.6 L Petrol
K4M724 107 hp 79 kW 1.6 L Petrol
L7X700 190 hp 140 kW 3 L Petrol
L7X701 190 hp 140 kW 3 L Petrol
N7Q700 139 hp 102 kW 2 L Petrol
N7Q704 139 hp 102 kW 2 L Petrol
Z7X760 167 hp 123 kW 3 L Petrol
Z7X765 167 hp 123 kW 3 L Petrol
Z7X765 167 hp 123 kW 3 L Petrol
Front wheel
Estate / Turnier / Vario / Wagon
Hatchback / Sportback / Sport hatch
RENAULTLAGUNA I NEVADA
K56
1.6 16V
2.0 16V
2.2 dT
3.0
3.0 24V
K568
K569
K56D/M
K56R
K565
K56V
1995/09 - 2001/03G8T760 113 hp 83 kW 2.2 L Diesel
K4M720 107 hp 79 kW 1.6 L Petrol
K4M724 107 hp 79 kW 1.6 L Petrol
L7X700 190 hp 140 kW 3 L Petrol
L7X701 190 hp 140 kW 3 L Petrol
N7Q700 139 hp 102 kW 2 L Petrol
N7Q704 139 hp 102 kW 2 L Petrol
Z7X765 167 hp 123 kW 3 L Petrol
Front wheel
Estate / Turnier / Vario / Wagon
RENAULTSAFRANE
B54
3.0
3.0 Biturbo 4x4
3.0 V6
3.0 V6 4x4

B545
B54B
B544
1992/12 - 1996/10Z7X721 167 hp 123 kW 3 L Petrol
Z7X722 167 hp 123 kW 3 L Petrol
Z7X723 167 hp 123 kW 3 L Petrol
Z7X721 167 hp 123 kW 3 L Petrol
Z7X722 167 hp 123 kW 3 L Petrol
Z7X723 167 hp 123 kW 3 L Petrol
Z7X753 167 hp 123 kW 3 L Petrol
Z7X721 170 hp 125 kW 3 L Petrol
Z7X723 170 hp 125 kW 3 L Petrol
Z7X726 262 hp 193 kW 3 L Petrol
AWD / 4WD
Front wheel
Hatchback / Sportback / Sport hatch
RENAULTSAFRANE I
B54
3.0
3.0 Biturbo 4x4
3.0 V6
3.0 V6 4x4

B545
B54B
B544
1992/12 - 1996/10Z7X721 167 hp 123 kW 3 L Petrol
Z7X722 167 hp 123 kW 3 L Petrol
Z7X723 167 hp 123 kW 3 L Petrol
Z7X721 167 hp 123 kW 3 L Petrol
Z7X722 167 hp 123 kW 3 L Petrol
Z7X723 167 hp 123 kW 3 L Petrol
Z7X753 167 hp 123 kW 3 L Petrol
Z7X721 170 hp 125 kW 3 L Petrol
Z7X723 170 hp 125 kW 3 L Petrol
Z7X726 262 hp 193 kW 3 L Petrol
AWD / 4WD
Front wheel
Hatchback / Sportback / Sport hatch
RENAULTSAFRANE II
B54
2.0 16V
2.2 dT
2.5 20V
2.9 24V
3.0 V6
B54F
B54G
B54L
B54M
B54N
1996/07 - 2000/12G8T740 113 hp 83 kW 2.2 L Diesel
L7X713 190 hp 140 kW 2.9 L Petrol
N7Q710 136 hp 100 kW 2 L Petrol
N7Q711 136 hp 100 kW 2 L Petrol
N7U700 165 hp 121 kW 2.5 L Petrol
N7U701 165 hp 121 kW 2.5 L Petrol
Z7X755 167 hp 123 kW 3 L Petrol
Front wheel
Hatchback / Sportback / Sport hatch
RENAULTSAFRANEII
B54
2.0 16V
2.2 dT
2.5 20V
2.9 24V
3.0 V6
B54F
B54G
B54L
B54M
B54N
1996/07 - 2000/12G8T740 113 hp 83 kW 2.2 L Diesel
L7X713 190 hp 140 kW 2.9 L Petrol
N7Q710 136 hp 100 kW 2 L Petrol
N7Q711 136 hp 100 kW 2 L Petrol
N7U700 165 hp 121 kW 2.5 L Petrol
N7U701 165 hp 121 kW 2.5 L Petrol
Z7X755 167 hp 123 kW 3 L Petrol
Front wheel
Hatchback / Sportback / Sport hatch
RENAULTSCÉNIC I
JA0/1
1.9 dCi RX4
2.0 16V RX4
2000/06 - 2003/08F4R744 139 hp 102 kW 2 L Petrol
F4R746 139 hp 102 kW 2 L Petrol
F9Q740 102 hp 75 kW 1.9 L Diesel
AWD / 4WD
MPV / Van / Minivan
