TRW DF4116 Brake Disc

TRW part DF4116 Brake Disc

TRW DF4116 Brake Disc

by TRW

Manufacturer Part Number: DF4116

Сharacteristics:
  • Brake Disc Type: Vented
  • Diameter [mm]: 285
  • Brake Disc Thickness [mm]: 28
  • Minimum thickness [mm]: 26
  • Centering Diameter [mm]: 84
  • Height [mm]: 45,5
  • Number of Holes: 6
  • Thread Size: M10 x 1.25
  • Bolt Hole Circle Ø [mm]: 127
  • Colour: Black
  • Surface: Painted

Product Details

BrandTRW
TRW article (MPN)DF4116
Vehicle subsystemBrake System

Original (OEM) part numbers

Suitable for BRILLIANCE, TOYOTA vehicles

OE manufacturerOEM reference numbers
BRILLIANCE3016054
TOYOTA4351226140, 4351226160

Aftermarket cross reference / interchange guide

The aftermarket competitive interchanges for TRW DF4116 Brake Disc offered by A.B.S., ACDelco, ALANKO, AP, APEC braking, ASHUKI, ATE, BLUE PRINT, BORG & BECK, BOSCH, Brake ENGINEERING, BRECO, BREMBO, BREMSI, CAR, CIFAM, DELPHI, DENCKERMANN, DJ AUTO, E.T.F., FEBI BILSTEIN, FERODO, FIRST LINE, fri.tech., FTE, GIRLING, HELLA, HELLA PAGID, HERTH+BUSS JAKOPARTS, HP, JURATEK, KAGER, KAMOKA, KAVO PARTS, KAWE, LPR, MAGNETI MARELLI, METELLI, MEYLE, MINTEX, MOTAQUIP, NATIONAL, NIBK, NIPPARTS, NK, OPTIMAL, PAGID, PEX, PILENGA, PROTECHNIC, QUINTON HAZELL, REMSA, ROADHOUSE, ROULUNDS RUBBER, sbs, STARLINE, SWAG, TEMPLIN, TEXTAR, TRISCAN, TRUSTING, VILLAR, WAGNER LOCKHEED, WOKING manufacturers

ManufacturerReference numbers
A.B.S.16615
ACDelcoAC2506D
ALANKO303750
AP25039
APEC brakingDSK2049
ASHUKIT60277, 09901212
ATE24012801891
BLUE PRINTADT343101
BORG & BECKBBD4176
BOSCH0986478693, 0986AB9667, F026A01303
Brake ENGINEERINGDI955766
BRECOBS8636
BREMBO09.A203.10
BREMSIDBA991V
CAR142682, HPD682
CIFAM8001058C
DELPHI204567, BG3193, 140602, 333356V, 812013157
DENCKERMANNB130612
DJ AUTOBD1852
E.T.F.193314
FEBI BILSTEIN29981
FERODODDF9911, DDF991
FIRST LINEFBD1151
fri.tech.BD0718
FTEBS7686, BS7686B
GIRLING6041161
HELLA8DD355118001, 8DD355108-531
HELLA PAGID8DD355118001, 8DD355108531
HERTH+BUSS JAKOPARTSJ3302104
HP57745
JURATEKTOY102
KAGER370674
KAMOKA1031982
KAVO PARTSBR9462, BR9390C, BR9390
KAWE663410
LPRT2876V
MAGNETI MARELLI360406070200, 600000087210
METELLI231058C
MEYLE30155210086
MINTEXMDC1785, MDC2347
MOTAQUIPLVBD1072Z
NATIONALNBD849
NIBKRN1266
NIPPARTSJ3302104
NK314567, 204567
OPTIMALBS-7990
PAGID55381, 54130
PEX140602
PILENGAV656
PROTECHNICPRD2539
QUINTON HAZELLBDC4945, 57745, BSF4945, 663410
REMSA663410
ROADHOUSE663410
ROULUNDS RUBBERD2506
sbs1815204567, 1815314567
STARLINEPB20220C
SWAG81929981
TEMPLIN0311027920
TEXTAR92238100, 92113000
TRISCAN812013157
TRUSTINGDF718
VILLAR6282112
WAGNER LOCKHEEDWGR09911
WOKINGP663410, D663410

Vehicle fitment / TRW DF4116 Brake Disc compatibility

This product fits the following models: JINBEI (BRILLIANCE) GRANSE, JINBEI (BRILLIANCE) GRANSE III, TOYOTA HIACE, TOYOTA HIACE COMMUTER V, TOYOTA HIACE III, TOYOTA HIACE IV, TOYOTA HIACE SBV IV, TOYOTA HIACE V, TOYOTA QUANTUM III, TOYOTA QUANTUM V, etc. See all vehicles this product (TRW DF4116) fits below to verify fitment for your vehicle.
MakeModelVariantPeriodEngineDriveBody Style
JINBEI (BRILLIANCE)GRANSE
2.0
2.4
2004/02 - 4G20D4L 125 hp 92 kW 2 L Petrol
4RB2 139 hp 102 kW 2.4 L Petrol
Rear wheel
MPV / Van / Minivan
JINBEI (BRILLIANCE)GRANSE III
2.4
2009/05 - 4RB2 139 hp 102 kW 2.4 L Petrol
Rear wheel
MPV / Van / Minivan
TOYOTAHIACE
2.2 D
1979/01 - 1985/07L 67 hp 49 kW 2.2 L Diesel
Rear wheel
Pickup truck / Pickup
TOYOTAHIACE COMMUTER V
TRH2
KDH2
2.5 D-4D
2.7 VVTi
2005/01 - 2KD-FTV 102 hp 75 kW 2.5 L Diesel
2TR-FE 151 hp 111 kW 2.7 L Petrol
Rear wheel
Passenger Van / Wagon / Minibus
TOYOTAHIACE III
LH1
RZH1
2.4
3.4
3.4 4WD
1995/08 - 2004/082RZ-E 116 hp 85 kW 2.4 L Petrol
5VZ-FE 178 hp 131 kW 3.4 L Petrol
AWD / 4WD
Rear wheel
Passenger Van / Wagon / Minibus
TOYOTAHIACE IV
LH1
LXH1
RZH1
LH1
2.4
2.4 D
2.4 i
2.4 SBV
2.4 TD
2.5 D-4D
2.5 D-4D 4WD
2.7
2.7 4WD

LXH12
LXH22
RCH12
RCH22
RCH13
RCH23
RCH19
RCH29
RZH10
1995/08 - 2KD-FTV 102 hp 75 kW 2.5 L Diesel
2KD-FTV 117 hp 86 kW 2.5 L Diesel
2KD-FTV 88 hp 65 kW 2.5 L Diesel
2KD-FTV 95 hp 70 kW 2.5 L Diesel
2KD-FTV 117 hp 86 kW 2.5 L Diesel
2L 79 hp 58 kW 2.4 L Diesel
2L-T 90 hp 66 kW 2.4 L Diesel
2RZ-E 115 hp 85 kW 2.4 L Petrol
2RZ-E 116 hp 85 kW 2.4 L Petrol
2RZ-E 120 hp 88 kW 2.4 L Petrol
3RZ-FE 143 hp 105 kW 2.7 L Petrol
3RZ-FE 144 hp 106 kW 2.7 L Petrol
AWD / 4WD
Rear wheel
LCV / Van / Cargo
Passenger Van / Wagon / Minibus
TOYOTAHIACE SBV IV
LXH1
RZH1
LH1
2.4
2.4 D
2.4 i
2.4 SBV
2.4 TD
2.5 D-4D
2.7
2.7 4WD

LXH12
LXH22
RCH12
RCH22
RCH13
RCH23
RCH19
RCH29
RZH10
1995/08 - 2KD-FTV 102 hp 75 kW 2.5 L Diesel
2KD-FTV 117 hp 86 kW 2.5 L Diesel
2KD-FTV 88 hp 65 kW 2.5 L Diesel
2KD-FTV 95 hp 70 kW 2.5 L Diesel
2L 79 hp 58 kW 2.4 L Diesel
2L-T 90 hp 66 kW 2.4 L Diesel
2RZ-E 116 hp 85 kW 2.4 L Petrol
2RZ-E 120 hp 88 kW 2.4 L Petrol
3RZ-FE 143 hp 105 kW 2.7 L Petrol
3RZ-FE 144 hp 106 kW 2.7 L Petrol
AWD / 4WD
Rear wheel
LCV / Van / Cargo
TOYOTAHIACE V
TRH2
KDH2
2.5 D-4D
2006/09 - 2KD-FTV 102 hp 75 kW 2.5 L Diesel
2KD-FTV 117 hp 86 kW 2.5 L Diesel
2KD-FTV 95 hp 70 kW 2.5 L Diesel
Rear wheel
LCV / Van / Cargo
TOYOTAQUANTUM III
LH1
RZH1
2.4
3.4
3.4 4WD
1995/08 - 2004/082RZ-E 116 hp 85 kW 2.4 L Petrol
5VZ-FE 178 hp 131 kW 3.4 L Petrol
AWD / 4WD
Rear wheel
Passenger Van / Wagon / Minibus
TOYOTAQUANTUM V
TRH2
KDH2
2.5 D-4D
2.7 VVTi
2005/01 - 2KD-FTV 102 hp 75 kW 2.5 L Diesel
2KD-FTV 102 hp 75 kW 2.5 L Diesel
2KD-FTV 117 hp 86 kW 2.5 L Diesel
2KD-FTV 95 hp 70 kW 2.5 L Diesel
2TR-FE 151 hp 111 kW 2.7 L Petrol
Rear wheel
LCV / Van / Cargo
Passenger Van / Wagon / Minibus
