TRW DF4796 Brake Disc

TRW part DF4796 Brake Disc

TRW DF4796 Brake Disc

by TRW

Manufacturer Part Number: DF4796

Сharacteristics:
  • Colour: Black
  • Minimum thickness [mm]: 20
  • Brake Disc Type: Vented
  • Brake Disc Thickness [mm]: 22
  • Thread Size: 14,5
  • Diameter [mm]: 257
  • Number of Holes: 6
  • Centering Diameter [mm]: 60
  • Height [mm]: 40,5
  • Bolt Hole Circle Ø [mm]: 100
  • Surface: Painted

Product Details

BrandTRW
TRW article (MPN)DF4796
Vehicle subsystemBrake System

Original (OEM) part numbers

Suitable for FIAT / LANCIA / ALFA, OPEL, VAUXHALL vehicles

OE manufacturerOEM reference numbers
FIAT / LANCIA / ALFA51830236, 0000055700918, 51806099, 55700398, 55700920, 55700921, 55700918, 51806103
OPEL0569024, 569065, 569024
VAUXHALL93188917, 93197241

Aftermarket cross reference / interchange guide

The aftermarket competitive interchanges for TRW DF4796 Brake Disc offered by A.B.S., AP, APEC braking, ATE, BENDIX, BLUE PRINT, BORG & BECK, BOSCH, Brake ENGINEERING, BRECK, BRECO, BREMBO, BSF, CAR, CIFAM, DELPHI, DENCKERMANN, DJ AUTO, Dr!ve+, E.T.F., EUROBRAKE, FARCOM, FEBI BILSTEIN, FENOX, FERODO, FIRST LINE, FOMAR, fri.tech., FTE, GALFER, GIRLING, G.U.D, HELLA, HELLA PAGID, HP, ICER, JP GROUP, JURATEK, JURID, KAGER, KAMOKA, KAWE, KEY PARTS, KORTEX, LEMFÖRDER, LPR, MAGNETI MARELLI, MALÒ, MAPCO, MENSAN, METELLI, METZGER, MEYLE, MGA, MILES, MINTEX, MOTAQUIP, NECTO, NIBK, NK, OPEN PARTS, OPTIMAL, PAGID, PATRON, PEX, PILENGA, PROFIT, PROTECHNIC, QUINTON HAZELL, R BRAKE, REMSA, ROADHOUSE, ROTINGER, sbs, STARLINE, STELLOX, SWAG, TEMPLIN, TEXTAR, TRISCAN, TRUSTING, VAICO, VALEO, VEMA, VILLAR, WOKING, ZIMMERMANN manufacturers

ManufacturerReference numbers
A.B.S.17710
AP24584X, 24980E
APEC brakingDSK2509
ATE24.0112-0184.1, 24032202311, 24012202311
BENDIX562304BC, 562304B
BLUE PRINTADZ94332
BORG & BECKBBD4553, BBD4715
BOSCH0986479B89, 0986479223, 0986479C11, 0986479963, 0986479402
Brake ENGINEERINGDI956403
BRECKBR330VA100
BRECOBS8599
BREMBO09584334, 0958433X, 08508621, 08.5086.24
BSF11506V
CAR1421180, HPD1180, 1421412, HPD1412
CIFAM800835
DELPHIBG4004, BG4004C
DENCKERMANNB130512, B130333
DJ AUTOBD1295
Dr!ve+DP1010110484
E.T.F.190125
EUROBRAKE5815202348
FARCOM231304
FEBI BILSTEIN28177
FENOXTB217761
FERODODDF1784C, DDF1304C, DDF1304, DDF1784C1, DDF1304C1, DDF17841, DDF13041, DDF1784
FIRST LINEFBD1615
FOMARFO2685
fri.tech.BD1278
FTEBS7135B, BS7133
GALFERB1G22202311
GIRLING6047961
G.U.DGDB122231
HELLA8DD355114351, 8DD355112581, 8DD355112571
HELLA PAGID8DD355112571, 8DD355112581
HP58360
ICER78BD09202
JP GROUP1263103609, 1263103600
JURATEKFIA111
JURID562304JC, 562304J
KAGER371351, 371077
KAMOKA1032608
KAWE698110
KEY PARTSKBD4553
KORTEXKD0173
LEMFÖRDER3087001
LPRO1017V
MAGNETI MARELLI353611540240, 360406024300
MALÒ1110059, 1110110
MAPCO25711
MENSAN380213
METELLI230835, 230858
METZGER6110075, 24980E
MEYLE6155216044, 6155216044PD, 6155210003
MGAD1591
MILESK000077
MINTEXMDK0225, MDC1735
MOTAQUIPLVBD1252Z
NECTOWN1326
NIBKRN1592
NK202348, 312348
OPEN PARTSBDR225820, BDA225820
OPTIMALBS7664C, BS-7664
PAGID54646PRO, 54457PRO, 54457
PATRONPBD4796
PEX140902
PILENGAV046
PROFIT50101304
PROTECHNICPRD2534, PRD2686
QUINTON HAZELLBDC5720, 58360, BDC5743, BSF5744, BDC5498, BSF5720, BSF5498, BDC5744, BSF5743
R BRAKE78RBD20920
REMSA698110
ROADHOUSE698110
ROTINGERRT20425, RT20425T5
sbs1815202348, 1815312348
STARLINEPB20425C
STELLOX60209957SX
SWAG70928177
TEMPLIN0311015735, 0311015730
TEXTAR92164603, 92145703, 92145700
TRISCAN812024151C, 812010195, 812010195C, 812024151
TRUSTINGDF1081, DF1278
VAICOV4080015
VALEO297044, 197028, 197044
VEMA98609, 98919
VILLAR6281575
WOKINGD698110
ZIMMERMANN230236920, 230236952, 430.2609.20, 230236900

Vehicle fitment / TRW DF4796 Brake Disc compatibility

This product fits the following models: FIAT GRANDE PUNTO, FIAT PUNTO, FIAT PUNTO EVO, OPEL ADAM, OPEL CORSA D, OPEL CORSA E, VAUXHALL ADAM, VAUXHALL CORSAIII, VAUXHALL CORSAIV, etc. See all vehicles this product (TRW DF4796) fits below to verify fitment for your vehicle.
MakeModelVariantPeriodEngineDriveBody Style
FIATGRANDE PUNTO
199
1.2
1.2 LPG
1.3 D Multijet
1.4
1.4 16V
1.4 LPG
1.4 Natural Power
2005/10 - 169A4.000 69 hp 51 kW 1.2 L Petrol
199A4.000 65 hp 48 kW 1.2 L Petrol
199A2.000 75 hp 55 kW 1.3 L Diesel
199A4.000 69 hp 51 kW 1.2 L Petrol
199A6.000 95 hp 70 kW 1.4 L Petrol
199A7.000 75 hp 55 kW 1.4 L Petrol
350A1.000 77 hp 57 kW 1.4 L Petrol
350A1.000 78 hp 57 kW 1.4 L Petrol
Front wheel
Hatchback / Sportback / Sport hatch
FIATPUNTO
199
0.9
0.9 Bifuel
0.9 Twinair Turbo
1.2
1.2 LPG
1.3 D Multijet
1.4
1.4 16V
1.4 Bifuel
1.4 LPG
1.4 Multi Air
1.4 Natural Power
2005/10 - 169A4.000 69 hp 51 kW 1.2 L Petrol
199A4.000 65 hp 48 kW 1.2 L Petrol
199B9.000 67 hp 49 kW 1.2 L Petrol
199A2.000 75 hp 55 kW 1.3 L Diesel
199A9.000 75 hp 55 kW 1.3 L Diesel
199A2.000 75 hp 55 kW 1.3 L Diesel
199A9.000 75 hp 55 kW 1.3 L Diesel
199B4.000 84 hp 62 kW 1.3 L Diesel
199A4.000 69 hp 51 kW 1.2 L Petrol
199A6.000 95 hp 70 kW 1.4 L Petrol
199A7.000 75 hp 55 kW 1.4 L Petrol
350A1.000 77 hp 57 kW 1.4 L Petrol
350A1.000 78 hp 57 kW 1.4 L Petrol
199B6.000 101 hp 74 kW 0.9 L Petrol
199B6.000 105 hp 77 kW 0.9 L Petrol
312A2.000 86 hp 63 kW 0.9 L Petrol
350A1.000 78 hp 57 kW 1.4 L Petrol
955A6.000 105 hp 77 kW 1.4 L Petrol
Front wheel
Hatchback / Sportback / Sport hatch
LCV / Van / Cargo
FIATPUNTO EVO
199
1.2
1.3 D Multijet
1.4
1.4 16V
1.4 LPG
1.4 Natural Power
2008/07 - 2012/02169A4.000 69 hp 51 kW 1.2 L Petrol
199A4.000 65 hp 48 kW 1.2 L Petrol
199A2.000 75 hp 55 kW 1.3 L Diesel
199A9.000 75 hp 55 kW 1.3 L Diesel
199B2.000 69 hp 51 kW 1.3 L Diesel
199A7.000 75 hp 55 kW 1.4 L Petrol
350A1.000 77 hp 57 kW 1.4 L Petrol
350A1.000 78 hp 57 kW 1.4 L Petrol
955A6.000 105 hp 77 kW 1.4 L Petrol
Front wheel
Hatchback / Sportback / Sport hatch
OPELADAM
1.0
1.2
1.4
1.4 LPG
1.4 S
2012/10 - A12XEL 69 hp 51 kW 1.2 L Petrol
B12XEL 69 hp 51 kW 1.2 L Petrol
A14XEL 87 hp 64 kW 1.4 L Petrol
A14XER 101 hp 74 kW 1.4 L Petrol
B14XEL 87 hp 64 kW 1.4 L Petrol
B14XER 101 hp 74 kW 1.4 L Petrol
A14XEL 87 hp 64 kW 1.4 L Petrol
B14XEL 87 hp 64 kW 1.4 L Petrol
B10XFL 90 hp 66 kW 1 L Petrol
B10XFT 115 hp 85 kW 1 L Petrol
B14NEH 150 hp 110 kW 1.4 L Petrol
Front wheel
Hatchback / Sportback / Sport hatch
OPELCORSA D
1.0
1.2
1.2 LPG
1.3 CDTI
1.4
1.4 LPG
2006/07 - A10XEP 60 hp 44 kW 1 L Petrol
A10XEP 65 hp 48 kW 1 L Petrol
A10XEP 65 hp 48 kW 1 L Petrol
Z10XEP 60 hp 44 kW 1 L Petrol
A12XEL 69 hp 51 kW 1.2 L Petrol
A12XER 86 hp 63 kW 1.2 L Petrol
Z12XEP 80 hp 59 kW 1.2 L Petrol
A12XER 83 hp 61 kW 1.2 L Petrol
A12XER 86 hp 63 kW 1.2 L Petrol
Z12XEP 75 hp 55 kW 1.2 L Petrol
Z12XEP 80 hp 59 kW 1.2 L Petrol
A13DTC 75 hp 55 kW 1.3 L Diesel
A13DTE 95 hp 70 kW 1.3 L Diesel
A13DTR 95 hp 70 kW 1.3 L Diesel
Z13DTE 95 hp 70 kW 1.3 L Diesel
Z13DTH 90 hp 66 kW 1.3 L Diesel
Z13DTJ 75 hp 55 kW 1.3 L Diesel
A13DTC 75 hp 55 kW 1.3 L Diesel
A13DTE 95 hp 70 kW 1.3 L Diesel
A13DTR 95 hp 70 kW 1.3 L Diesel
Z13DTE 95 hp 70 kW 1.3 L Diesel
Z13DTJ 75 hp 55 kW 1.3 L Diesel
A14XEL 87 hp 64 kW 1.4 L Petrol
A14XER 100 hp 74 kW 1.4 L Petrol
Z14XEP 90 hp 66 kW 1.4 L Petrol
A14XEL 87 hp 64 kW 1.4 L Petrol
Z14XEP 90 hp 66 kW 1.4 L Petrol
Front wheel
Hatchback / Sportback / Sport hatch
LCV / Van / Cargo
OPELCORSA E
1.0
1.2
1.3 CDTI
1.4
1.4 LPG
1.4 Turbo
2014/09 - B10XFL 90 hp 66 kW 1 L Petrol
B10XFT 115 hp 85 kW 1 L Petrol
B12XEL 69 hp 51 kW 1.2 L Petrol
B13DTC 75 hp 55 kW 1.3 L Diesel
B13DTE 95 hp 70 kW 1.3 L Diesel
B13DTR 95 hp 70 kW 1.3 L Diesel
B14NEH 150 hp 110 kW 1.4 L Petrol
B14NEJ 101 hp 74 kW 1.4 L Petrol
B14XEJ 75 hp 55 kW 1.4 L Petrol
B14XEL 90 hp 66 kW 1.4 L Petrol
B14XEL 90 hp 66 kW 1.4 L Petrol
Front wheel
Hatchback / Sportback / Sport hatch
LCV / Van / Cargo
VAUXHALLADAM
1.0
1.2
1.4
1.4 S
2012/10 - A12XEL 69 hp 51 kW 1.2 L Petrol
B12XEL 69 hp 51 kW 1.2 L Petrol
A14XEL 87 hp 64 kW 1.4 L Petrol
A14XER 101 hp 74 kW 1.4 L Petrol
B10XFT 116 hp 85 kW 1 L Petrol
B14NEH 150 hp 110 kW 1.4 L Petrol
Front wheel
Hatchback / Sportback / Sport hatch
VAUXHALLCORSAIII
D
D L8
1.0
1.0 i 12V
1.2
1.2 i 16V
1.2 LPG
1.3 CDTI
1.4
1.4 LPG
2006/07 - A10XEP 60 hp 44 kW 1 L Petrol
Z10XEP 60 hp 44 kW 1 L Petrol
A10XEP 65 hp 48 kW 1 L Petrol
A12XEL 69 hp 51 kW 1.2 L Petrol
Z12XEP 80 hp 59 kW 1.2 L Petrol
A12XER 86 hp 63 kW 1.2 L Petrol
A12XER 86 hp 63 kW 1.2 L Petrol
Z12XEP 80 hp 59 kW 1.2 L Petrol
A13DTC 75 hp 55 kW 1.3 L Diesel
A13DTE 95 hp 70 kW 1.3 L Diesel
A13DTR 95 hp 70 kW 1.3 L Diesel
B13DTR 95 hp 70 kW 1.3 L Diesel
Z13DTE 95 hp 70 kW 1.3 L Diesel
Z13DTJ 75 hp 55 kW 1.3 L Diesel
A13DTC 75 hp 55 kW 1.3 L Diesel
A13DTE 95 hp 70 kW 1.3 L Diesel
A13DTR 95 hp 70 kW 1.3 L Diesel
Z13DTE 95 hp 70 kW 1.3 L Diesel
Z13DTH 90 hp 66 kW 1.3 L Diesel
Z13DTJ 75 hp 55 kW 1.3 L Diesel
A14XEL 87 hp 64 kW 1.4 L Petrol
A14XER 101 hp 74 kW 1.4 L Petrol
Z14XEP 90 hp 66 kW 1.4 L Petrol
A14XEL 87 hp 64 kW 1.4 L Petrol
Z14XEP 90 hp 66 kW 1.4 L Petrol
Front wheel
Hatchback / Sportback / Sport hatch
LCV / Van / Cargo
VAUXHALLCORSAIV
E
1.0
1.2
1.3 CDTi
1.4
2014/08 - B10XFL 116 hp 85 kW 1 L Petrol
B10XFL 90 hp 66 kW 1 L Petrol
B12XEL 69 hp 51 kW 1.2 L Petrol
B13DTC 75 hp 55 kW 1.3 L Diesel
B13DTE 95 hp 70 kW 1.3 L Diesel
B13DTC 75 hp 55 kW 1.3 L Diesel
B13DTE 95 hp 70 kW 1.3 L Diesel
B13DTR 95 hp 70 kW 1.3 L Diesel
B14NEH 150 hp 110 kW 1.4 L Petrol
B14NEL 101 hp 74 kW 1.4 L Petrol
B14XEL 90 hp 66 kW 1.4 L Petrol
Front wheel
Hatchback / Sportback / Sport hatch
LCV / Van / Cargo
