ZIMMERMANN 150.1284.20 (150128420) Brake Disc
ZIMMERMANN 150.1284.20 (150128420) Brake Disc
by ZIMMERMANNManufacturer Part Number: 150.1284.20 (150128420)
- Brake Disc Type: Internally Vented
- Machining: High-carbon
- Surface: Coated
- Outer diameter [mm]: 296
- Thickness [mm]: 22
- Minimum thickness [mm]: 20,4
- Height [mm]: 76
- Hole Arrangement / Number: 6/5
- Weight [kg]: 7,38
- Bolt Hole Circle Ø 1 [mm]: 120
- Hub Bore Ø [mm]: 79
Product Details
| Brand | ZIMMERMANN |
| ZIMMERMANN article (MPN) | 150.1284.20 (150128420) |
| Vehicle subsystem | Brake System |
Original (OEM) part numbers
Suitable for BMW vehicles
| OE manufacturer | OEM reference numbers |
|---|---|
| BMW | 34111163013, 34111163081, 34116767061, 34111164839 |
Aftermarket cross reference / interchange guide
The aftermarket competitive interchanges for ZIMMERMANN 150.1284.20 (150128420) Brake Disc offered by ABE, A.B.S., ACDelco, AP, ATE, BARUM, BENDIX, BORG & BECK, BOSCH, Brake ENGINEERING, BRECO, BREMBO, CAR, CIFAM, DELPHI, DENCKERMANN, Dr!ve+, E.T.F., FARCOM, FEBI BILSTEIN, FENOX, FERODO, FIRST LINE, FOMAR, FREMAX, fri.tech., FTE, GALFER, GIRLING, GRAF, G.U.D, HANS PRIES, HELLA, HELLA PAGID, HERZOG GERMANY, HP, JURATEK, JURID, KAGER, KAWE, KRAFT, KWP, LEMFÖRDER, LPR, MAGNETI MARELLI, MAPCO, MAXGEAR, METELLI, METZGER, MEYLE, MINTEX, NK, OPEN PARTS, OPTIMAL, PAGID, PATRON, PEX, PILENGA, QUINTON HAZELL, RAMEDER, REMSA, ROADHOUSE, ROTINGER, ROULUNDS BRAKING, SASIC, sbs, SWAG, TEMPLIN, TEXTAR, TRISCAN, TRUCKTEC AUTOMOTIVE, TRUSTING, TRW, VAICO, VALEO, WOKING, ZIMMERMANN manufacturers
| Manufacturer | Reference numbers |
|---|---|
| ABE | C3B012ABE |
| A.B.S. | 16332, 16332S |
| ACDelco | AC2406D |
| AP | 24637V, 24637E, X24637 |
| ATE | 24.0322-0159.1, 24.0122-0159.1 |
| BARUM | BAR22159 |
| BENDIX | 562035B, 562035, 562035BC |
| BORG & BECK | BBD4067 |
| BOSCH | 0986478848, 0986479R72 |
| Brake ENGINEERING | DI955610 |
| BRECO | BV8256, BS8256 |
| BREMBO | 09.6924.10, 09.6924.75, 09.6924.14, 09.6924.11 |
| CAR | HPD101, 142.101 |
| CIFAM | 800-396C, 800-396 |
| DELPHI | BG3043 |
| DENCKERMANN | B130255 |
| Dr!ve+ | DP1010110711 |
| E.T.F. | 19-4839 |
| FARCOM | 231172 |
| FEBI BILSTEIN | 10753 |
| FENOX | TB217124 |
| FERODO | DDF834 |
| FIRST LINE | FBD1003 |
| FOMAR | FO2406 |
| FREMAX | BD-4839, BD-4839-50 |
| fri.tech. | DF475, BD0475 |
| FTE | BS4623HB, BS4623, BS4623B |
| GALFER | B1G22201591 |
| GIRLING | 6027691 |
| GRAF | DF29396C, DF29396 |
| G.U.D | GDB122159 |
| HANS PRIES | 500570 |
| HELLA | 8DD355104581, 8DD355122112, 8DD355104591 |
| HELLA PAGID | 8DD355104591, 8DD355122112, 8DD355104581 |
| HERZOG GERMANY | 201315 |
| HP | 57715, HP57715 |
| JURATEK | BMW104 |
| JURID | 562035JC, 562035J |
| KAGER | 37-0265, 371341 |
| KAWE | BDRS1669.25, 38047, 651410 |
| KRAFT | 6042630 |
| KWP | 129396C, 129396 |
| LEMFÖRDER | 1957202, 19572 |
| LPR | B2441VR, B2441V |
| MAGNETI MARELLI | 353610636240, 360406016300 |
| MAPCO | 15767 |
| MAXGEAR | 190692MAX, 190692 |
| METELLI | 23-0396C, 23-0396 |
| METZGER | 6514.10, X24637, 24637V |
| MEYLE | 3155213019, 3155213019/PD |
| MINTEX | MDK0204, MDC989 |
| NK | 341536, 201536, 301536 |
| OPEN PARTS | BDR1669.20, BDRS1669.25 |
| OPTIMAL | BS5140C, BS-5140 |
| PAGID | 50439PRO, 50439 |
| PATRON | PBD2769 |
| PEX | 14.0108N, 14.0108 |
| PILENGA | V124 |
| QUINTON HAZELL | BDC4623, HP57715 |
| RAMEDER | T0620624, T0600173, T0620874 |
| REMSA | 6514.10 |
| ROADHOUSE | 6514.10 |
| ROTINGER | RT2496, RT2496T5 |
| ROULUNDS BRAKING | D2406 |
| SASIC | 9004497J |
| sbs | 1815201536, 1815301536, 1815341536 |
| SWAG | 20910753 |
| TEMPLIN | 01.02.34.101211, 0311011955, 0311011950 |
| TEXTAR | 92075005, 89003500, 92075000, 98200075001, 92075003 |
| TRISCAN | 812011133 |
| TRUCKTEC AUTOMOTIVE | 08.34.021 |
| TRUSTING | DF475 |
| TRW | DF7318, DF2769 |
| VAICO | V20-80025 |
| VALEO | 186697 |
| WOKING | D6514.10 |
| ZIMMERMANN | 150.1284.50, 150.1284.70, 150.1284.52, 150.1284.00, 150.1284.75 |
Vehicle fitment / ZIMMERMANN 150.1284.20 (150128420) Brake Disc compatibility
This product fits the following models: BMW 5, etc. See all vehicles this product (ZIMMERMANN 150.1284.20 (150128420)) fits below to verify fitment for your vehicle.| Make | Model | Variant | Period | Engine | Drive | Body Style |
|---|---|---|---|---|---|---|
| BMW | 5 E39 | 520 d 520 i 523 i 525 d 525 i 525 td 525 tds 528 i 530 d 535 i | 1995/11 - 2004/05 | M47D20(204D1) 136 hp 100 kW 2 L Diesel M51D25(256T1) 116 hp 85 kW 2.5 L Diesel M51D25(256T1) 143 hp 105 kW 2.5 L Diesel M52B20(206S3) 136 hp 100 kW 2 L Petrol M52B20(206S3) 150 hp 110 kW 2 L Petrol M54B22(226S1) 170 hp 125 kW 2.2 L Petrol M52B25(256S3) 170 hp 125 kW 2.5 L Petrol M52B28(286S1) 193 hp 142 kW 2.8 L Petrol M52B28(286S2) 193 hp 142 kW 2.8 L Petrol M54B25(256S5) 192 hp 141 kW 2.5 L Petrol M57D25(256D1) 163 hp 120 kW 2.5 L Diesel M57D30(306D1) 184 hp 135 kW 3 L Diesel M62B35(358S1) 235 hp 173 kW 3.5 L Petrol M62B35(358S2) 235 hp 173 kW 3.5 L Petrol | Rear wheel | Estate / Turnier / Vario / Wagon Sedan / Saloon |
