ZIMMERMANN 230.2373.20 (230237320) Brake Disc

ZIMMERMANN part 230.2373.20 (230237320) Brake Disc

ZIMMERMANN 230.2373.20 (230237320) Brake Disc

by ZIMMERMANN

Manufacturer Part Number: 230.2373.20 (230237320)

Сharacteristics:
  • Brake Disc Type: Internally Vented
  • Surface: Coated
  • Outer diameter [mm]: 280
  • Thickness [mm]: 28
  • Minimum thickness [mm]: 25,9
  • Height [mm]: 71,5
  • Hole Arrangement / Number: 7/5
  • Weight [kg]: 7,7
  • Bolt Hole Circle Ø 1 [mm]: 118
  • Hub Bore Ø [mm]: 73

Product Details

BrandZIMMERMANN
ZIMMERMANN article (MPN)230.2373.20 (230237320)
Vehicle subsystemBrake System

Original (OEM) part numbers

Suitable for CITROEN / PEUGEOT, FIAT / LANCIA / ALFA vehicles

OE manufacturerOEM reference numbers
CITROEN / PEUGEOT1607872180, 4249K2, 4249.28, 4249.29, 4249.98
FIAT / LANCIA / ALFA51705749, 51740246, 51742246, 51848620, 51848621

Aftermarket cross reference / interchange guide

The aftermarket competitive interchanges for ZIMMERMANN 230.2373.20 (230237320) Brake Disc offered by ABE, A.B.S., ACDelco, ALANKO, AP, ATE, BENDIX, BORG & BECK, BOSCH, BRECO, BREMBO, CAR, CIFAM, COMLINE, DELPHI, DENCKERMANN, E.T.F., FERODO, FIRST LINE, FREMAX, fri.tech., FTE, GIRLING, GRAF, HANS PRIES, HELLA, HELLA PAGID, ICER, JURID, KAGER, KAMOKA, KAWE, KRAFT, LPR, MAGNETI MARELLI, MALÒ, METELLI, METZGER, MEYLE, MINTEX, NK, OPEN PARTS, OPTIMAL, PAGID, PEX, PILENGA, QUINTON HAZELL, R BRAKE, REMSA, ROADHOUSE, ROULUNDS BRAKING, SASIC, sbs, SIMER, TEMPLIN, TEXTAR, TRISCAN, TRUSTING, TRW, VAICO, VALEO, VEMA, VILLAR, WAGNER LOCKHEED, WOKING, ZIMMERMANN manufacturers

ManufacturerReference numbers
ABEC3C032ABE
A.B.S.17740OE, 17740
ACDelcoAC3189D
ALANKO305071
AP25227, 25080
ATE24.0128-0213.1, 428213
BENDIX562468B
BORG & BECKBBD4608
BOSCH0986479313
BRECOBS8667, BS8837
BREMBO09.A235.10, 09.A235.20
CAR142.1409
CIFAM800884C, 800-884
COMLINEADC1571V
DELPHIBG4059
DENCKERMANNB130292
E.T.F.19-7412
FERODODDF1566, DDF1800-1
FIRST LINEFBD1680
FREMAXBD-5622
fri.tech.DF1224
FTEBS7169
GIRLING6047715
GRAFDF29884
HANS PRIES722458
HELLA8DD355113-691
HELLA PAGID8DD355113-691
ICER78BD5622-2
JURID562468J
KAGER37-1200
KAMOKA103139
KAWE6120310
KRAFT6045909
LPRP1009V
MAGNETI MARELLI360407100100, 360704006600
MALÒ1110126
METELLI23-0884, 230884C
METZGER25080, 61015.10, 6110354
MEYLE2155210029
MINTEXMDC2685, MDC1849
NK311958, 201942, 201958
OPEN PARTSBDA2438.20
OPTIMALBS-8382
PAGID55750, 54572
PEX14.0856
PILENGAV021
QUINTON HAZELLBDC5661, HP58923
R BRAKE78RBD25622
REMSA6884.10
ROADHOUSE6884.10
ROULUNDS BRAKINGWD01463
SASIC6100017
sbs1815311958, 1815201942, 1815201958
SIMERD2278
TEMPLIN03.110.2600.080
TEXTAR92275003, 92157203, 92157200
TRISCAN8120101005, 8120101005C
TRUSTINGDF1224
TRWDF4771S
VAICOV24-80008
VALEO197248
VEMA98622
VILLAR628.2079
WAGNER LOCKHEEDWGR1800-1
WOKINGD6884.10
ZIMMERMANN230.2373.50, 230.2373.52, 230.2373.00

Vehicle fitment / ZIMMERMANN 230.2373.20 (230237320) Brake Disc compatibility

This product fits the following models: CITROËN JUMPER, CITROËN RELAY, FIAT DUCATO, PEUGEOT BOXER, PEUGEOT MANAGER, etc. See all vehicles this product (ZIMMERMANN 230.2373.20 (230237320)) fits below to verify fitment for your vehicle.
MakeModelVariantPeriodEngineDriveBody Style
CITROËNJUMPER
2.2 HDi 100
2.2 HDi 110
2.2 HDi 120
2.2 HDi 130
2.2 HDi 150
3.0 HDi 145
3.0 HDi 155
3.0 HDi 160
3.0 HDi 180
2006/04 - 4HG(P22DTE) 110 hp 81 kW 2.2 L Diesel
4HH(P22DTE) 130 hp 96 kW 2.2 L Diesel
4HJ(P22DTE) 150 hp 110 kW 2.2 L Diesel
4HU(P22DTE) 120 hp 88 kW 2.2 L Diesel
4HV(P22DTE) 101 hp 74 kW 2.2 L Diesel
F1CE0481D(F30DT) 156 hp 115 kW 3 L Diesel
F1CE0481D(F30DT) 157 hp 115 kW 3 L Diesel
F1CE0481D(F30DT) 157 hp 116 kW 3 L Diesel
F1CE0481D(F30DT) 177 hp 130 kW 3 L Diesel
F1CE3481N 146 hp 107 kW 3 L Diesel
Front wheel
LCV / Van / Cargo
Passenger Van / Wagon / Minibus
With flatbed/undercarriage
CITROËNRELAY
2.2 HDi 100
2.2 HDi 110
2.2 HDi 120
2.2 HDi 130
2.2 HDi 150
3.0 HDi 145
3.0 HDi 155
3.0 HDi 160
3.0 HDi 180
2006/04 - 4HG(P22DTE) 110 hp 81 kW 2.2 L Diesel
4HH(P22DTE) 130 hp 96 kW 2.2 L Diesel
4HJ(P22DTE) 150 hp 110 kW 2.2 L Diesel
4HU(P22DTE) 120 hp 88 kW 2.2 L Diesel
4HV(P22DTE) 101 hp 74 kW 2.2 L Diesel
F1CE0481D(F30DT) 156 hp 115 kW 3 L Diesel
F1CE0481D(F30DT) 157 hp 115 kW 3 L Diesel
F1CE0481D(F30DT) 157 hp 116 kW 3 L Diesel
F1CE0481D(F30DT) 177 hp 130 kW 3 L Diesel
F1CE3481N 146 hp 107 kW 3 L Diesel
Front wheel
LCV / Van / Cargo
Passenger Van / Wagon / Minibus
With flatbed/undercarriage
FIATDUCATO
250
290
100 Multijet 2
2 D
110 Multijet 2
3 D
115 Multijet 2
0 D
120 Multijet 2
3 D
120 Multijet 2
3 D 4x4
130 Multijet 2
3 D
140 Natural Power
150 Multijet 2
3 D
150 Multijet 3
0 D
160 Multijet 3
0 D
180 Multijet 3
0 D
2006/07 - 250A1.000 116 hp 85 kW 2 L Diesel
250A2.000 116 hp 85 kW 2 L Diesel
4HV 100 hp 74 kW 2.2 L Diesel
F1AE0481D 120 hp 88 kW 2.3 L Diesel
F1AE0481D 120 hp 88 kW 2.3 L Diesel
FPT 120 hp 88 kW 2.3 L Diesel
F1AE0481N 131 hp 96 kW 2.3 L Diesel
F1AE0481T 126 hp 93 kW 2.3 L Diesel
F1AE3481D 131 hp 96 kW 2.3 L Diesel
F1AGL411D 131 hp 96 kW 2.3 L Diesel
F1AE3481D 131 hp 96 kW 2.3 L Diesel
F1AGL411D 131 hp 96 kW 2.3 L Diesel
F1AE3481E 148 hp 109 kW 2.3 L Diesel
F1AE3481G 113 hp 83 kW 2.3 L Diesel
F1CE0441A 136 hp 100 kW 3 L Petrol
F1CE0441A 136 hp 100 kW 3 L Petrol
F1CFA401A 136 hp 100 kW 3 L Petrol
F1CE0481D 156 hp 115 kW 3 L Diesel
F1CE0481D 158 hp 116 kW 3 L Diesel
F1CE3481M 158 hp 116 kW 3 L Diesel
F1CE0481D 158 hp 116 kW 3 L Diesel
F1CE3481M 156 hp 115 kW 3 L Diesel
F1CE3481E 177 hp 130 kW 3 L Diesel
F1CE3481N 146 hp 107 kW 3 L Diesel
AWD / 4WD
Front wheel
LCV / Van / Cargo
Passenger Van / Wagon / Minibus
With flatbed/undercarriage
PEUGEOTBOXER
2.2 HDi 100
2.2 HDi 110
2.2 HDi 120
2.2 HDi 130
2.2 HDi 150
3.0 HDi
3.0 HDi 145
3.0 HDi 160
3.0 HDi 175
2006/04 - 120 hp 88 kW 2.2 L Diesel
146 hp 107 kW 3 L Diesel
4HG(P22DTE) 110 hp 81 kW 2.2 L Diesel
4HH(P22DTE) 131 hp 96 kW 2.2 L Diesel
4HJ(P22DTE) 150 hp 110 kW 2.2 L Diesel
4HU(P22DTE) 120 hp 88 kW 2.2 L Diesel
4HV(P22DTE) 101 hp 74 kW 2.2 L Diesel
F1CE0481D(F30DT) 156 hp 115 kW 3 L Diesel
F1CE0481D(F30DT) 156 hp 116 kW 3 L Diesel
F1CE0481D(F30DT) 177 hp 130 kW 3 L Diesel
Front wheel
LCV / Van / Cargo
Passenger Van / Wagon / Minibus
With flatbed/undercarriage
PEUGEOTMANAGER
2.2 HDi 100
2.2 HDi 110
2.2 HDi 120
2.2 HDi 130
2.2 HDi 150
3.0 HDi
3.0 HDi 145
3.0 HDi 160
3.0 HDi 175
2006/04 - 120 hp 88 kW 2.2 L Diesel
146 hp 107 kW 3 L Diesel
4HG(P22DTE) 110 hp 81 kW 2.2 L Diesel
4HH(P22DTE) 131 hp 96 kW 2.2 L Diesel
4HJ(P22DTE) 150 hp 110 kW 2.2 L Diesel
4HU(P22DTE) 120 hp 88 kW 2.2 L Diesel
4HV(P22DTE) 101 hp 74 kW 2.2 L Diesel
F1CE0481D(F30DT) 156 hp 115 kW 3 L Diesel
F1CE0481D(F30DT) 156 hp 116 kW 3 L Diesel
F1CE0481D(F30DT) 177 hp 130 kW 3 L Diesel
Front wheel
LCV / Van / Cargo
Passenger Van / Wagon / Minibus
With flatbed/undercarriage
