ZIMMERMANN 400.3605.20 (400360520) Brake Disc

ZIMMERMANN part 400.3605.20 (400360520) Brake Disc

ZIMMERMANN 400.3605.20 (400360520) Brake Disc

by ZIMMERMANN

Manufacturer Part Number: 400.3605.20 (400360520)

Сharacteristics:
  • Brake Disc Type: Internally Vented
  • Surface: Coated
  • Machining: High-carbon
  • Outer diameter [mm]: 285
  • Thickness [mm]: 22
  • Minimum thickness [mm]: 19
  • Height [mm]: 93
  • Hole Arrangement / Number: 6/6
  • Weight [kg]: 7,3
  • Bolt Hole Circle Ø 1 [mm]: 145
  • Hub Bore Ø [mm]: 120

Product Details

BrandZIMMERMANN
ZIMMERMANN article (MPN)400.3605.20 (400360520)
Vehicle subsystemBrake System

Original (OEM) part numbers

Suitable for MERCEDES-BENZ, VAG vehicles

OE manufacturerOEM reference numbers
MERCEDES-BENZ9044230212, 9044230312, 9044230512
VAG2D0615601B

Aftermarket cross reference / interchange guide

The aftermarket competitive interchanges for ZIMMERMANN 400.3605.20 (400360520) Brake Disc offered by ABE, A.B.S., ACDelco, AP, ATE, AUTOMEGA, BARUM, BENDIX, BERAL, BOSCH, Brake ENGINEERING, BRECO, BREMBO, BSG, CAR, CASALS, CIFAM, DELPHI, E.T.F., FARCOM, FEBI BILSTEIN, FENOX, FERODO, FIRST LINE, FOMAR, FREMAX, fri.tech., FTE, GIRLING, GRAF, G.U.D, HANS PRIES, HELLA, HELLA PAGID, HP, JP GROUP, JURID, KAGER, KAWE, KRAFT, LEMFÖRDER, LPR, MAGNETI MARELLI, MAPCO, METELLI, METZGER, MEYLE, MINTEX, OPEN PARTS, OPTIMAL, PAGID, PETERS ENNEPETAL, PEX, PILENGA, PROFIT, QUINTON HAZELL, REMSA, ROADHOUSE, ROTINGER, ROULUNDS BRAKING, sbs, SWAG, TEMPLIN, TEXTAR, TRISCAN, TRUCKTEC AUTOMOTIVE, TRUSTING, TRW, VAICO, VILLAR, WOKING, ZIMMERMANN manufacturers

ManufacturerReference numbers
ABEC4M015ABE
A.B.S.16950
ACDelcoAC2541D
AP44062
ATE24.0122-0196.1
AUTOMEGA3061506012D0B
BARUMBAR22196
BENDIX567810B, 562475B
BERALBCR191A
BOSCH0986479B38, 0986478555
Brake ENGINEERINGDI955854S
BRECOBS8601
BREMBO09.8475.10
BSGBSG60-210-009
CARHPD473, 142.473
CASALS55202
CIFAM800-645
DELPHIBG3399
E.T.F.19-P6123
FARCOM230911
FEBI BILSTEIN10639
FENOXTB219147
FERODOFCR191A
FIRST LINEFBD1248
FOMARFO2541
FREMAXBD-0185
fri.tech.DF132
FTEBS4543
GIRLING6040895
GRAFDF29645
G.U.DGDB122196
HANS PRIES110439
HELLA8DD355105811, 8DD355105801
HELLA PAGID8DD355105801, 8DD355105811
HPHP57843
JP GROUP1163204709
JURID567810J
KAGER370189
KAWE662310
KRAFT6051430
LEMFÖRDER2722801
LPRV2444V
MAGNETI MARELLI360406033200
MAPCO25805
METELLI23-0645
METZGER44062
MEYLE0155232036, 0155232036PD
MINTEXMDC1079
OPEN PARTSBDA1786.20, BDR1786.20
OPTIMALBS-6580
PAGID52169, 52169PRO
PETERS ENNEPETAL01666700A
PEX14.0340
PILENGAV292
PROFIT50100191
QUINTON HAZELLBDC4543, HP57843
REMSA6623.10
ROADHOUSE6623.10
ROTINGERRT2716T5, RT2716
ROULUNDS BRAKINGD2541
sbs1815203344
SWAG99910639
TEMPLIN0311082580, 04.01.42.400509, 0311082585
TEXTAR92089803, 92089800, 92089805
TRISCAN812023144
TRUCKTEC AUTOMOTIVE02.35.056
TRUSTINGDF132
TRWDF4089S
VAICOV30-80046
VILLAR628.1782
WOKINGD6623.10
ZIMMERMANN400.3605.20, 400.3605.52, 400.3605.50

Vehicle fitment / ZIMMERMANN 400.3605.20 (400360520) Brake Disc compatibility

This product fits the following models: MERCEDES-BENZ , MERCEDES-BENZ SPRINTER 4-T, VW LT 28-46 II, VW LTII, etc. See all vehicles this product (ZIMMERMANN 400.3605.20 (400360520)) fits below to verify fitment for your vehicle.
MakeModelVariantPeriodEngineDriveBody Style
MERCEDES-BENZ
512 D
667.321
667.322
667.323
667.351
667.352
667.353
1996/09 - OM602.984 122 hp 90 kW 2.9 L Diesel
Rear wheel
LCV / Van / Cargo / Small truck
With flatbed/undercarriage
MERCEDES-BENZSPRINTER 4-T
904
408 CDI
408 D
410 D
410 D 4x4
411 CDI
411 CDI 4x4
412 D
412 D 4x4
413 CDI
413 CDI 4x4
414
414 4x4
416 CDI
416 CDI 4x4
1996/02 - 2006/05M111.979 143 hp 105 kW 2.3 L Petrol
OM601.943 79 hp 58 kW 2.3 L Diesel
OM602.980 102 hp 75 kW 2.9 L Diesel
OM602.980 115 hp 85 kW 2.9 L Diesel
OM602.980 122 hp 90 kW 2.9 L Diesel
OM611.981 109 hp 80 kW 2.1 L Diesel
OM611.981 129 hp 95 kW 2.1 L Diesel
OM611.987 82 hp 60 kW 2.1 L Diesel
OM612.981 156 hp 115 kW 2.7 L Diesel
AWD / 4WD
Rear wheel
LCV / Van / Cargo
Passenger Van / Wagon / Minibus
With flatbed/undercarriage
VWLT 28-46 II
2DA
2DD
2DH
2DC
2DF
2
2.3
2.5 SDI
2.5 TDI
2.8 TDI
1996/05 - 2006/07AGK 125 hp 92 kW 2.8 L Diesel
ATA 130 hp 96 kW 2.8 L Diesel
AUH 158 hp 116 kW 2.8 L Diesel
BCQ 158 hp 116 kW 2.8 L Diesel
AGL 143 hp 105 kW 2.3 L Petrol
AGX 75 hp 55 kW 2.5 L Diesel
AHD 102 hp 75 kW 2.5 L Diesel
ANJ 109 hp 80 kW 2.5 L Diesel
APA 90 hp 66 kW 2.5 L Diesel
AVR 109 hp 80 kW 2.5 L Diesel
BBE 83 hp 61 kW 2.5 L Diesel
BBF 95 hp 70 kW 2.5 L Diesel
Rear wheel
LCV / Van / Cargo
With flatbed/undercarriage
VWLTII
2DA
2DD
2DH
2DC
2DF
2DG

2.3
2.5 SDI
2.5 TDI
2.8 TDI
1996/05 - 2006/07AGK 125 hp 92 kW 2.8 L Diesel
ATA 130 hp 96 kW 2.8 L Diesel
AUH 158 hp 116 kW 2.8 L Diesel
BCQ 158 hp 116 kW 2.8 L Diesel
AGL 143 hp 105 kW 2.3 L Petrol
AGX 75 hp 55 kW 2.5 L Diesel
AHD 102 hp 75 kW 2.5 L Diesel
ANJ 109 hp 80 kW 2.5 L Diesel
APA 90 hp 66 kW 2.5 L Diesel
AVR 109 hp 80 kW 2.5 L Diesel
BBE 83 hp 61 kW 2.5 L Diesel
BBF 95 hp 70 kW 2.5 L Diesel
Rear wheel
LCV / Van / Cargo
With flatbed/undercarriage
