ZIMMERMANN 470241300 Brake Disc

ZIMMERMANN part 470241300 Brake Disc

ZIMMERMANN 470241300 Brake Disc

by ZIMMERMANN

Manufacturer Part Number: 470241300

Сharacteristics:
  • Brake Disc Type: Externally Vented
  • Machining: High-carbon
  • Outer diameter [mm]: 280
  • Thickness [mm]: 24
  • Minimum thickness [mm]: 21,8
  • Height [mm]: 47
  • Hole Arrangement / Number: 7/5
  • Weight [kg]: 7,14
  • Bolt Hole Circle Ø 1 [mm]: 108
  • Hub Bore Ø [mm]: 61

Product Details

BrandZIMMERMANN
ZIMMERMANN article (MPN)470241300
Vehicle subsystemBrake System

Original (OEM) part numbers

Suitable for RENAULT vehicles

OE manufacturerOEM reference numbers
RENAULT7701206613, 8200007121

Aftermarket cross reference / interchange guide

The aftermarket competitive interchanges for ZIMMERMANN 470241300 Brake Disc offered by ABE, A.B.S., ACDelco, AP, ATE, BENDIX, BORG & BECK, BOSCH, Brake ENGINEERING, BRECO, BREMBO, BREMSI, BSF, CAR, CIFAM, DELPHI, DENCKERMANN, E.T.F., FARCOM, FEBI BILSTEIN, FENOX, FERODO, FIRST LINE, FOMAR, FREMAX, fri.tech., FTE, GALFER, GIRLING, GRAF, HELLA, HELLA PAGID, ICER, JURID, KAGER, KAWE, KRAFT, LPR, MAGNETI MARELLI, MAPCO, METELLI, METZGER, MEYLE, MINTEX, NECTO, NK, OPEN PARTS, OPTIMAL, PAGID, PATRON, PEX, PILENGA, PROTECHNIC, QH International, QUINTON HAZELL, RAMEDER, REMSA, ROADHOUSE, ROTINGER, ROULUNDS BRAKING, SASIC, sbs, SWAG, TEMPLIN, TEXTAR, TRISCAN, TRUSTING, TRW, VAICO, VALEO, VILLAR, WOKING, ZIMMERMANN manufacturers

ManufacturerReference numbers
ABEC3R027ABE
A.B.S.17153, 17153S
ACDelcoAC2606D
AP24826, 24826V
ATE24.0124-0169.1
BENDIX562182B, 562182BC
BORG & BECKBBD4270
BOSCH0986479743
Brake ENGINEERINGDI956209
BRECOBV8451, BS8451
BREMBO09.8936.10, DP68027, 09893611
BREMSIDBB182V
BSF11432V
CAR142.365, HPD365
CIFAM800-676, 800676C
DELPHIBG3733
DENCKERMANNB130378
E.T.F.19-2234
FARCOM231225
FEBI BILSTEIN23332
FENOXTB219191
FERODODDF11821, DDF1182
FIRST LINEFBD1268
FOMARFO2606
FREMAXBD-2234
fri.tech.BD0814, DF814
FTEBS5431
GALFERB1G22401691
GIRLING6041791
GRAFDF29676
HELLA8DD355109281, 8DD355109271
HELLA PAGID8DD355109271, 8DD355109281
ICER78BD2234
JURID562182J, 562182JC
KAGER37-1203
KAWE669710
KRAFT6045450
LPRR1001V
MAGNETI MARELLI351404620500, 360406008600
MAPCO15133
METELLI230676C, 23-0676
METZGER24826, 6110600
MEYLE16155210014, 16-155210015
MINTEXMDC1533
NECTOWN1209
NK203930, 313930
OPEN PARTSBDR1958.20, BDRS1958.25
OPTIMALBS-7954
PAGID54189
PATRONPBD4179
PEX14.0838N, 14.0838
PILENGAV134
PROTECHNICPRD2629
QH InternationalHP58018
QUINTON HAZELLBDC5431, HP58018
RAMEDERT0620195
REMSA6697.10
ROADHOUSE6697.10
ROTINGERRT20056T5, RT20056
ROULUNDS BRAKINGD2606
SASIC4004298J
sbs1815313930, 1815203930
SWAG60923332
TEMPLIN0311025340, 0311025345, 01.25.42.121191
TEXTAR92118903, 92118900, 89014000
TRISCAN812025138
TRUSTINGDF814
TRWDF4179
VAICOV46-80011
VALEO186715
VILLAR628.1153
WOKINGD6697.10
ZIMMERMANN470.2413.52, 470.2413.20

Vehicle fitment / ZIMMERMANN 470241300 Brake Disc compatibility

This product fits the following models: RENAULT LAGUNA II, etc. See all vehicles this product (ZIMMERMANN 470241300) fits below to verify fitment for your vehicle.
MakeModelVariantPeriodEngineDriveBody Style
RENAULTLAGUNA II
BG0/1
KG0/1
1.6 16V
1.6 FlexFuel
1.8 16V
1.9 dCi
1.9 dCI
2.0 16V
2.0 16V IDE
2.0 16V Turbo

BG00
BG0K
BG0P
BG0W
BG04
BG0B
BG0C
BG0V
BG05
BG06
BG0J
BG0M
BG08
BG0G
BG0A
BG0L
BG0B
BG0C
BG0J
BG0M
BG0V
BG0B
BG0M
BG0E
BG0N
BG0R
BG0S
BG0Z
BG1L
BG1M
BG1A
BG1V
BG1A
BG1W
BG1G
BG1H
KG00
KG0K
KG0W
KG05
KG0A
KG0L
KG0B
KG0M
KG0E
KG0E
KG0R
KG0G
KG0J
KG0N
KG0S
KG0Z
KG1L
KG1M
KG12
KG1A
KG1W
KG1V
2001/03 - F4P770 116 hp 85 kW 1.8 L Petrol
F4P771 116 hp 85 kW 1.8 L Petrol
F4P773 116 hp 85 kW 1.8 L Petrol
F4P774 116 hp 85 kW 1.8 L Petrol
F4P775 116 hp 85 kW 1.8 L Petrol
F4P770 116 hp 85 kW 1.8 L Petrol
F4P771 116 hp 85 kW 1.8 L Petrol
F4P774 116 hp 85 kW 1.8 L Petrol
F4P775 116 hp 85 kW 1.8 L Petrol
F4P770 117 hp 86 kW 1.8 L Petrol
F4P770 121 hp 89 kW 1.8 L Petrol
F4P774 121 hp 89 kW 1.8 L Petrol
F4P770 117 hp 86 kW 1.8 L Petrol
F4P774 117 hp 86 kW 1.8 L Petrol
F4P770 120 hp 88 kW 1.8 L Petrol
F4P773 120 hp 88 kW 1.8 L Petrol
F4P770 121 hp 89 kW 1.8 L Petrol
F4P772 121 hp 89 kW 1.8 L Petrol
F4R712 135 hp 99 kW 2 L Petrol
F4R713 135 hp 99 kW 2 L Petrol
F4R714 135 hp 99 kW 2 L Petrol
F4R715 135 hp 99 kW 2 L Petrol
F4R714 133 hp 98 kW 2 L Petrol
F4R715 133 hp 98 kW 2 L Petrol
F4R784 170 hp 125 kW 2 L Petrol
F4R786 170 hp 125 kW 2 L Petrol
F4R787 170 hp 125 kW 2 L Petrol
F4R886 204 hp 150 kW 2 L Petrol
F4R887 204 hp 150 kW 2 L Petrol
F4R714 133 hp 98 kW 2 L Petrol
F4R784 170 hp 125 kW 2 L Petrol
F4R786 170 hp 125 kW 2 L Petrol
F4R787 170 hp 125 kW 2 L Petrol
F4R886 204 hp 150 kW 2 L Petrol
F4R887 204 hp 150 kW 2 L Petrol
F4R764 163 hp 120 kW 2 L Petrol
F4R765 163 hp 120 kW 2 L Petrol
F4R786 163 hp 120 kW 2 L Petrol
F4R787 163 hp 120 kW 2 L Petrol
F5R700 140 hp 103 kW 2 L Petrol
F5R701 140 hp 103 kW 2 L Petrol
F9Q650 120 hp 88 kW 1.9 L Diesel
F9Q670 120 hp 88 kW 1.9 L Diesel
F9Q674 120 hp 88 kW 1.9 L Diesel
F9Q750 120 hp 88 kW 1.9 L Diesel
F9Q664 90 hp 66 kW 1.9 L Diesel
F9Q718 107 hp 79 kW 1.9 L Diesel
F9Q750 125 hp 92 kW 1.9 L Diesel
F9Q754 107 hp 79 kW 1.9 L Diesel
F9Q664 92 hp 68 kW 1.9 L Diesel
F9Q670 120 hp 88 kW 1.9 L Diesel
F9Q674 120 hp 88 kW 1.9 L Diesel
F9Q750 120 hp 88 kW 1.9 L Diesel
F9Q674 110 hp 81 kW 1.9 L Diesel
F9Q758 110 hp 81 kW 1.9 L Diesel
F9Q718 107 hp 79 kW 1.9 L Diesel
F9Q750 116 hp 85 kW 1.9 L Diesel
F9Q750 125 hp 92 kW 1.9 L Diesel
F9Q754 107 hp 79 kW 1.9 L Diesel
F9Q752 100 hp 74 kW 1.9 L Diesel
F9Q752 105 hp 77 kW 1.9 L Diesel
F9Q754 100 hp 74 kW 1.9 L Diesel
F9Q758 116 hp 85 kW 1.9 L Diesel
F9Q759 116 hp 85 kW 1.9 L Diesel
F9Q758 130 hp 96 kW 1.9 L Diesel
F9Q759 130 hp 96 kW 1.9 L Diesel
K4M710 107 hp 79 kW 1.6 L Petrol
K4M714 107 hp 79 kW 1.6 L Petrol
K4M716 112 hp 82 kW 1.6 L Petrol
K4M718 103 hp 76 kW 1.6 L Petrol
Front wheel
Estate / Turnier / Vario / Wagon
Hatchback / Sportback / Sport hatch
