ZIMMERMANN 610.1197.20 (610119720) Brake Disc

ZIMMERMANN part 610.1197.20 (610119720) Brake Disc

ZIMMERMANN 610.1197.20 (610119720) Brake Disc

by ZIMMERMANN

Manufacturer Part Number: 610.1197.20 (610119720)

Сharacteristics:
  • Brake Disc Type: Solid
  • Surface: Coated
  • Outer diameter [mm]: 295
  • Thickness [mm]: 10
  • Minimum thickness [mm]: 8,4
  • Height [mm]: 72,5
  • Hole Arrangement / Number: 7/5
  • Weight [kg]: 5
  • Bolt Hole Circle Ø 1 [mm]: 108
  • Hub Bore Ø [mm]: 68

Product Details

BrandZIMMERMANN
ZIMMERMANN article (MPN)610.1197.20 (610119720)
Vehicle subsystemBrake System

Original (OEM) part numbers

Suitable for VOLVO vehicles

OE manufacturerOEM reference numbers
VOLVO271794, 271794.0, 31262099

Aftermarket cross reference / interchange guide

The aftermarket competitive interchanges for ZIMMERMANN 610.1197.20 (610119720) Brake Disc offered by ABE, A.B.S., ACDelco, AP, ATE, BENDIX, BORG & BECK, BOSCH, Brake ENGINEERING, BRECO, BREMBO, CAR, CIFAM, DELPHI, E.T.F., FARCOM, FEBI BILSTEIN, FERODO, FIRST LINE, FOMAR, FREMAX, fri.tech., FTE, GIRLING, GRAF, HELLA, HELLA PAGID, HP, JURATEK, JURID, KAGER, KAWE, KRAFT, KWP, LEMFÖRDER, LPR, LUCAS ELECTRICAL, MAGNETI MARELLI, MAPCO, METELLI, METZGER, MEYLE, MINTEX, NK, OPEN PARTS, OPTIMAL, PAGID, PATRON, PEX, PILENGA, QUINTON HAZELL, RAMEDER, REMSA, ROADHOUSE, ROTINGER, ROULUNDS BRAKING, sbs, SWAG, TEMPLIN, TEXTAR, TRISCAN, TRUSTING, TRW, VALEO, VEMA, WOKING, ZIMMERMANN manufacturers

ManufacturerReference numbers
ABEC4V003ABE
A.B.S.16237
ACDelcoAC2306D
AP14454E, 14454V, X14454
ATE24111002141, 24.0110-0214.1
BENDIX561867, 561867BC, 561867B
BORG & BECKBBD5062
BOSCH0986479892, 0986478628
Brake ENGINEERINGDI955515
BRECOBS7481, BV7481
BREMBO08.5569.20, 08.5569.21, 08.5569.76, 08.5569.24
CAR142.668, 142.688, HPD668
CIFAM800-376C, 800-376
DELPHIBG2842
E.T.F.19-7940
FARCOM230860
FEBI BILSTEIN11455
FERODODDF552
FIRST LINEFBD802
FOMARFO2306
FREMAXBD-7940
fri.tech.DF061
FTEBS3913B, BS3913
GIRLING6026604
GRAFDF29376, DF29376C
HELLA8DD355103702, 8DD355103701, 8DD355103691
HELLA PAGID8DD355103701, 8DD355103691, 8DD355103702
HP57563, HP57563
JURATEKVOL116
JURID561867J, 561867
KAGER37-0456
KAWE37882, 641100
KRAFT6056325
KWP129376
LEMFÖRDER19090
LPRV1293PR, V1293P
LUCAS ELECTRICALDF2660
MAGNETI MARELLI360406051500, 353616025550
MAPCO15965
METELLI23-0376, 23-0376C
METZGER14454E, 14454V
MEYLE5155235014, 5155235014/PD
MINTEXMDC920
NK204833
OPEN PARTSBDA1616.10, BDR1616.10
OPTIMALBS4110C, BS-4110
PAGID54009, 54009PRO
PATRONPBD2660
PEX14.0665
PILENGA5264
QUINTON HAZELLBDC3913, HP57563, 81YD
RAMEDERT0620493
REMSA6411.00
ROADHOUSE6411.00
ROTINGERRT1068, RT1068T5
ROULUNDS BRAKINGD2306
sbs1815204833
SWAG55911455
TEMPLIN0311029630, 0311029635, 01.07.42.107629
TEXTAR92066803, 92066800, 92066805, 982000668, 98200066801
TRISCAN812027120C, 812027120
TRUSTINGDF061, DF601
TRWDF2660
VALEO186528
VEMA98600
WOKINGD6411.00
ZIMMERMANN610.1197.50, 610.1197.00, 610.1197.52

Vehicle fitment / ZIMMERMANN 610.1197.20 (610119720) Brake Disc compatibility

This product fits the following models: VOLVO 850, VOLVO C70 I, VOLVO S70, VOLVO V70  , VOLVO V70 I, etc. See all vehicles this product (ZIMMERMANN 610.1197.20 (610119720)) fits below to verify fitment for your vehicle.
MakeModelVariantPeriodEngineDriveBody Style
VOLVO850
LS
LW
2.0
2.0 Turbo
2.3
2.3 T5
2.3 T5 R
2.3 T5-R
2.3 Turbo R
2.4 GLE
2.5
2.5 AWD
2.5 TDI
1991/06 - 1997/10B5202S 126 hp 93 kW 2 L Petrol
B5204F 143 hp 105 kW 2 L Petrol
B5204FT 210 hp 155 kW 2 L Petrol
B5204T 210 hp 155 kW 2 L Petrol
B5204T2 179 hp 132 kW 2 L Petrol
B5204FT 210 hp 155 kW 2 L Petrol
B5204T 210 hp 155 kW 2 L Petrol
B5204T2 180 hp 132 kW 2 L Petrol
B5234FS 144 hp 106 kW 2.3 L Petrol
B5234FT 226 hp 166 kW 2.3 L Petrol
B5234T2 239 hp 176 kW 2.3 L Petrol
B5234T4 250 hp 184 kW 2.3 L Petrol
B5234T5 241 hp 177 kW 2.3 L Petrol
B5252 140 hp 103 kW 2.5 L Petrol
B5252FS 144 hp 106 kW 2.5 L Petrol
B5254S 170 hp 125 kW 2.5 L Petrol
B5254T 193 hp 142 kW 2.4 L Petrol
B5254T 193 hp 142 kW 2.5 L Petrol
D5252T 140 hp 103 kW 2.5 L Diesel
AWD / 4WD
Front wheel
Estate / Turnier / Vario / Wagon
Sedan / Saloon
VOLVOC70 I
2.0
2.0 T
2.3 T-5
2.3 T5
2.4 T
2.5
2.5 T
1997/03 - 2005/10B5204T2 180 hp 132 kW 2 L Petrol
B5204T3 226 hp 166 kW 2 L Petrol
B5204T4 163 hp 120 kW 2 L Petrol
B5234T3 239 hp 176 kW 2.3 L Petrol
B5234T9 245 hp 180 kW 2.3 L Petrol
B5234T3 240 hp 176 kW 2.3 L Petrol
B5244S 170 hp 125 kW 2.5 L Petrol
B5254S 165 hp 121 kW 2.5 L Petrol
B5254S 170 hp 125 kW 2.5 L Petrol
B5244T 193 hp 142 kW 2.5 L Petrol
B5254T 193 hp 142 kW 2.5 L Petrol
B5244T7 200 hp 147 kW 2.4 L Petrol
B5254S 170 hp 125 kW 2.5 L Petrol
Front wheel
Convertible / cabrio
Coupe / Sports car / Grand tourer / Speedster / Roadster
VOLVOS70
LS
2.0
2.0 Turbo
2.3 T-5
2.3 Turbo
2.4
2.4 Turbo
2.5
2.5 Bifuel
2.5 TDI
1997/01 - 2000/11B5202FS 126 hp 93 kW 2 L Petrol
B5202S 126 hp 93 kW 2 L Petrol
B5204F 143 hp 105 kW 2 L Petrol
B5204T2 180 hp 132 kW 2 L Petrol
B5204T 210 hp 155 kW 2 L Petrol
B5204T3 226 hp 166 kW 2 L Petrol
B5234FT+ 250 hp 184 kW 2.3 L Petrol
B5234T3 239 hp 176 kW 2.3 L Petrol
B5244S 170 hp 125 kW 2.4 L Petrol
B5244S2 140 hp 103 kW 2.4 L Petrol
B5244SG 140 hp 103 kW 2.4 L Petrol
B5254S 170 hp 125 kW 2.4 L Petrol
B5244T 193 hp 142 kW 2.4 L Petrol
B5254T 193 hp 142 kW 2.4 L Petrol
B5252FS 144 hp 106 kW 2.5 L Petrol
B5254S 165 hp 121 kW 2.5 L Petrol
D5252T 140 hp 103 kW 2.5 L Diesel
GB5252S 144 hp 106 kW 2.5 L Petrol
Front wheel
Sedan / Saloon
VOLVOV70
LV
2.0
2.0 Turbo
2.0 Turbo AWD
2.3 AWD
2.3 T-5
2.3 T-5 AWD
2.3 T AWD
2.3 Turbo
2.4
2.4 Bifuel
2.4 Turbo
2.5
2.5 AWD
2.5 Bifuel
2.5 TDI
2.5 Turbo AWD
1997/01 - 2000/05B5202S 126 hp 93 kW 2 L Petrol
B5204F 143 hp 105 kW 2 L Petrol
B5204T2 180 hp 132 kW 2 L Petrol
B5204T4 163 hp 120 kW 2 L Petrol
B5204T 211 hp 155 kW 2 L Petrol
B5204T3 226 hp 166 kW 2 L Petrol
B5204T3 226 hp 166 kW 2 L Petrol
B5234FT+ 250 hp 184 kW 2.3 L Petrol
B5234FT+ 250 hp 184 kW 2.3 L Petrol
B5234T4 250 hp 184 kW 2.3 L Petrol
B5234T3 239 hp 176 kW 2.3 L Petrol
B5234T7 265 hp 195 kW 2.3 L Petrol
B5234T8 265 hp 195 kW 2.3 L Petrol
B5244S 170 hp 125 kW 2.4 L Petrol
B5244S2 140 hp 103 kW 2.4 L Petrol
B5244SG2 140 hp 103 kW 2.4 L Petrol
B5254S 170 hp 125 kW 2.4 L Petrol
B5244SG 140 hp 103 kW 2.4 L Petrol
B5244T 193 hp 142 kW 2.4 L Petrol
B5254T 193 hp 142 kW 2.4 L Petrol
B5244T 193 hp 142 kW 2.5 L Petrol
B5254T 193 hp 142 kW 2.5 L Petrol
B5244T2 265 hp 195 kW 2.5 L Petrol
B5252FS 144 hp 106 kW 2.5 L Petrol
B5254S 165 hp 121 kW 2.5 L Petrol
D5252T 140 hp 103 kW 2.5 L Diesel
GB5252S 144 hp 106 kW 2.5 L Petrol
AWD / 4WD
Front wheel
Estate / Turnier / Vario / Wagon
VOLVOV70 I
LV
2.0
2.0 Turbo
2.0 Turbo AWD
2.3 AWD
2.3 T-5
2.3 T-5 AWD
2.3 T AWD
2.3 Turbo
2.4
2.4 Bifuel
2.4 Turbo
2.5
2.5 AWD
2.5 Bifuel
2.5 TDI
2.5 Turbo AWD
1997/01 - 2000/05B5202S 126 hp 93 kW 2 L Petrol
B5204F 143 hp 105 kW 2 L Petrol
B5204T2 180 hp 132 kW 2 L Petrol
B5204T4 163 hp 120 kW 2 L Petrol
B5204T 211 hp 155 kW 2 L Petrol
B5204T3 226 hp 166 kW 2 L Petrol
B5204T3 226 hp 166 kW 2 L Petrol
B5234FT+ 250 hp 184 kW 2.3 L Petrol
B5234FT+ 250 hp 184 kW 2.3 L Petrol
B5234T4 250 hp 184 kW 2.3 L Petrol
B5234T3 239 hp 176 kW 2.3 L Petrol
B5234T7 265 hp 195 kW 2.3 L Petrol
B5234T8 265 hp 195 kW 2.3 L Petrol
B5244S 170 hp 125 kW 2.4 L Petrol
B5244S2 140 hp 103 kW 2.4 L Petrol
B5244SG2 140 hp 103 kW 2.4 L Petrol
B5254S 170 hp 125 kW 2.4 L Petrol
B5244SG 140 hp 103 kW 2.4 L Petrol
B5244T 193 hp 142 kW 2.4 L Petrol
B5254T 193 hp 142 kW 2.4 L Petrol
B5244T 193 hp 142 kW 2.5 L Petrol
B5254T 193 hp 142 kW 2.5 L Petrol
B5244T2 265 hp 195 kW 2.5 L Petrol
B5252FS 144 hp 106 kW 2.5 L Petrol
B5254S 165 hp 121 kW 2.5 L Petrol
D5252T 140 hp 103 kW 2.5 L Diesel
GB5252S 144 hp 106 kW 2.5 L Petrol
AWD / 4WD
Front wheel
Estate / Turnier / Vario / Wagon
