Aftermarket EAA EAA-111174 Starter
Offers from our partners
As an Amazon Associate I earn from qualifying purchases. Product prices and availability are accurate as of the date/time indicated and are subject to change. Any price and availability information displayed on at the time of purchase will apply to the purchase of this product. CERTAIN CONTENT THAT APPEARS ON THIS SITE COMES FROM . THIS CONTENT IS PROVIDED ‘AS IS’ AND IS SUBJECT TO CHANGE OR REMOVAL AT ANY TIME.
Product Details for EAA-111174 by EAA
Aftermarket EAA Starter with part number EAA-111174 in the Electrics category. Designed for DAF, Fiat, Iveco vehicles. Find the best offer for EAA EAA-111174 from our trusted suppliers.
For detailed technical data, visit Product specifications.
EAA EAA-111174 is also known by the following OEM part numbers: 1516716R, 4169095, 2995120, 4682999, 4692477, etc.
See original manufacturer codes in OEM part numbers.
This product fits the following models: FIAT Series 100, FIAT Series 110, FIAT Series 300, FIAT Series 50, FIAT Series 55, FIAT Series 75, FIAT Series 80, FIAT Series 90, IVECO ZETA, etc.
Fitment data is a guide, not a guarantee. Compare with the part you’re replacing, or ask your mechanic, before ordering.
Will it fit your vehicle? Check all compatible models in Vehicle compatibility.
Aftermarket EAA EAA-111174 Starter is also cross-referenced with the following part numbers: AINDE CGB-50398, BOSCH 0001360015, CASCO CST10733AS, CEVAM 8664, DELCO REMY DRS1310, etc.
Find equivalent parts from other brands in Cross reference.
Product Specifications & Characteristics
These are the detailed technical specifications, characteristics and key features of EAA EAA-111174, including material, dimensions, and design details.
|
Characteristic
Technical parameter
|
Value
Specification
|
|---|---|
| Voltage [V] | 24 |
| Number of Teeth | 9 |
| Rated Power [kW] | 4 |
| Quality | NUEVO |
| Length [mm] | 341 |
| Bore Ø [mm] | 12,5 |
| Position/Degree | links |
| Clamp | 30 |
| Clamp | 50 |
| Rotation Direction | Clockwise rotation |
| Flange Ø [mm] | 110 |
| Bore Ø 2 [mm] | 12,5 |
| Bore Ø 3 [mm] | 12,5 |
| Starter Type | Self-supporting |
| Number of mounting bores | 3 |
| Connecting Angle [Degree] | 60 |
| Pinion Rest Position [mm] | 27 |
| Jaw opening angle measurement [Degree] | 30 |
| Fastening hole angle measurement [Degree] | 60 |
Original (OE/OEM) part numbers
These are the original OE/OEM numbers equivalent to EAA EAA-111174.
|
Manufacturer
Vehicle brand
|
OEM Part Numbers
Original equipment manufacturer codes
|
|---|---|
| DAF | 1516716R |
| FIAT | 4169095, 4682999, 4692477, 4709418, 4755108, 77040560, 77040561, 77414430, 77414431, 77444430 |
| IVECO | 2995120, 611466605 |
Cross References & Interchange Guide
Here you can find parts from other brands equivalent to EAA EAA-111174, offering the same fit and function as the original component. Aftermarket interchanges for EAA EAA-111174 are offered by Ainde, Bosch, Casco, Cevam, Delco Remy.
|
Producer
Aftermarket brand
|
Cross Numbers
Compatible part numbers
|
|---|---|
| AINDE | CGB-50398 |
| BOSCH | 0001360015, 0001360043, 0001368019, 0986011310, 0986011321 |
| CASCO | CST10733AS, CST30601GS |
| CEVAM | 8664 |
| DELCO REMY | DRS1310 |
| HELLA | CS232 |
| LUCAS ELECTRICAL | LRS00837 |
Vehicle Fitment for EAA EAA-111174
This section lists all vehicle models compatible with EAA EAA-111174, helping you verify if the part fits your specific make and model. Suitable for FIAT Series 100, FIAT Series 110, FIAT Series 300, FIAT Series 50, FIAT Series 55, FIAT Series 75, FIAT Series 80, FIAT Series 90, IVECO ZETA and other models listed below.
Heavy & Commercial & Industrial Vehicles:
100E, 100NC
4x2
Platform/Chassis: 10.0t
110NC
4x2
Dump Truck: 11.0t, Platform/Chassis: 11.0t
314/3
4x2
Bus: 9.0t
50N, 50NC
4x2
Platform/Chassis: 4.9t
55N
4x2
Platform/Chassis: 5.6t
75P
4x4
Platform/Chassis: 7.0t, Platform/Chassis: 7.5t, Platform/Chassis: 7.9t
80N, 80NC
4x2
Platform/Chassis: 7.5t, Platform/Chassis: 8.3t
90N, 90NC, 90P
4x2, 4x4
Platform/Chassis: 8.8t, Platform/Chassis: 9.0t, Platform/Chassis: 9.2t, Platform/Chassis: 9.6t, Platform/Chassis: 9.8t
109-14, 109-14 H, 79-13, 79-14, 79-14 H, 79-14 V, 95-14, 95-14 H
4x2
Dump Truck: 7.5t, Dump Truck: 8.1t, Dump Truck: 9.4t, Dump Truck: 10.9t, Estate Van: 7.5t, Estate Van: 8.1t, Platform/Chassis: 7.5t, Platform/Chassis: 8.1t, Platform/Chassis: 9.4t, Platform/Chassis: 10.9t
Alternative parts
Alternative part numbers are provided for reference only. Verify fitment against the manufacturer catalog before ordering.
